Page 199 of 303
197
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
B Bayonet type bulbs:press the
bulb, turn counter-clockwise to re-
move this type of bulb from its
holder.
C Tubular bulbs:release them
from their contacts to remove.D-E Halogen bulbs: to remove the
bulb, release the clip holding the
bulb in place.
F Gas-discharge bulbs
(Bixenon).TYPES OF BULBS fig. 24
Various types of bulbs are fitted to your
car:
A Glass bulbs: clipped into posi-
tion. Pull to remove.
A0E0117mfig. 24
Page 200 of 303
198
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
BULBS FIGURE 24 TYPE POWER
Main beam headlights D H7 55W
Dipped beam headlights D H7 55W
Main beams/Dipped beams
(versions with Bixenon headlights) (where provided) F D1S 55W
Additional main beams (where provided) D H1 55W
Front sidelights (1 per headlight) A W5WB 5W
Taillights
(1 on fixed light unit - 1 on mobile light unit) B P21/5W 5W
Front fog lights E H7 55W
Front direction indicator B PY21W 21W
Side direction indicator A W5W 5W
Rear direction indicator B P21W 21W
Brake lights B P21/5W 21W
Third brake light A W2,3W 2,3W
Reversing light B P21W 21W
Rear fog lights B P21W 21W
Number plate lights A W5W 5W
Front ceiling light 2xA+1C 2xW5+10W 5+5+10W
Boot light C 10W 10W
Rear ceiling light A 2xW5W 5+5W
Courtesy mirror lights A 1,5W 1.5W
Glovebox light A W5W 5W
Puddle/door lights A W5W 5W
Page 201 of 303

199
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCYMain beam headlights
(halogen bulbs)
To change the bulb, proceed as follows:
❒remove cover A-fig. 25by turning
it counter-clockwise;
❒disconnect the electric connectorA-
fig. 25;
❒release the bulb holder catch B;
IF AN EXTERIOR
LIGHT BURNS OUT
For the type of bulb and power rating,
see “When needing to change a bulb”.
FRONT LIGHT UNITS
The front light units contain main beam,
sidelights, direction indicator and dipped
beam bulbs.
To change the bulbs, turn cap counter-
clockwise and then remove it.
The bulbs are arranged inside the light
unitfig. 25as follows:
AMain beam headlights
BSidelights/direction indicators
CDipped beam headlights
A0E0191mfig. 25
After replacement, re-
fit the covers correctly
checking that they are proper-
ly secured.
WARNING
A0E0223mfig. 26
❒remove the bulb and replace it;
❒fit the new bulb and refit bulb hold-
er catch B-fig. 26;
❒reconnect the electrical connector A;
❒refit the protective cover properly.
Page 202 of 303

200
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
Sidelights
To change the bulb, proceed as follows:
❒turn cover B-fig. 25counter-clock-
wise;
❒press tab A-fig. 27, remove the
bulb and replace it;
❒refit the bulb holder, it shall click in-
to place; look at the light from the
outside to check for proper bulb po-
sitioning;
❒refit the protective cover properly.
A0E0193mfig. 27A0E0194mfig. 28A0E0192mfig. 29
Front direction indicators
To change the bulb, proceed as follows:
❒turn cover B-fig. 25counter-clock-
wise;
❒turn the bulb holder A-fig. 28coun-
terclockwise, remove the bulb and re-
place it;
❒refit the bulb holder, it shall click into
place; look at the light from the out-
side to check for proper bulb position-
ing;
❒refit the protective cover properly.Dipped beam headlights
(halogen bulbs)
To change the bulb, proceed as follows:
❒turn cover C-fig. 25counter-clock-
wise;
❒disconnect the electric connector A-
fig. 29;
❒release the bulb holder catch B;
❒remove the bulb and replace it;
❒fit the new bulb and refit bulb holder
catchB-fig. 29;
Page 203 of 303

201
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
Side direction indicators
To change the bulb, proceed as follows:
❒push the lens by hand in opposite run-
ning direction in order to press the
catchA-fig. 30. Release the front
part and remove the unit;
❒turn the bulb holder B-fig. 31coun-
terclockwise and remove it from lens
C.
❒remove bulb Dand replace it;
❒fit the bulb holder Binto the lens C
then position the unit, the catch shall
click into place A-fig. 30.Front fog lights fig. 32
(where provided)
IMPORTANTContact Alfa Romeo Au-
thorized Services to have front fog lights
replaced and adjusted.
A0E0163mfig. 30A0E0164mfig. 31
Be careful not to dam-
age the car body or the
lens.
A0E0196mfig. 32
Due to high voltage,
the bulb of (Bixenon)
gas-discharge headlights must
only be replaced by experts:
danger of death! Contact Alfa
Romeo Authorized Services.
WARNING
Gas-discharge dipped
beam/main beam headlights
(Bixenon) (where provided)
Page 204 of 303
202
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
Reversing light/rear fog
lights
To replace the bulbs proceed as follows:
❒open the tailgate;
❒turn deviceA-fig. 33 to open lid
B;
❒lower the lid and remove the bulb
holder unit by pressing the retaining tabs
C-fig. 34;
❒remove and replace the burnt-out
bulb by pressing it slightly and turn-
ing it counterclockwise fig. 35:
D:reversing light bulb on passenger
side (or right side);
D:reversing light bulb on driver side (or
left side)
❒refit the bulb holder unit securing it
properly using the retaining tabs C-
fig. 34;
❒close lidB-fig. 33.
REAR LIGHT UNITS
Rear light units contain: reversing light,
rear fog light, direction indicators, tail-
lights, number plate lights, brake light
and third brake light bulbs.
A0E0165mfig. 33A0E0166mfig. 34A0E0167mfig. 35
Page 205 of 303
203
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
Direction indicators/
Taillights/Brake lights
To replace the bulbs proceed as follows:
❒open the tailgate;
❒loosen screw A-fig. 37and remove
the protection cover B;
❒remove the bulb holder unit C-
fig. 38by pressing the retaining
tabsD.
A0E0170mfig. 37
Taillight bulb on tailgate
To replace the bulbs proceed as follows:
❒open the tailgate;
❒turn deviceA-fig. 33 to open lid
B;
❒lower the lid and remove the bulb
holder unit by pressing the retaining
tabsC-fig. 34;
A0E0229mfig. 36
❒remove and replace the burnt-out
bulb by pressing it slightly and turn-
ing it counterclockwisefig. 36:
D: taillight bulb on right/left headlight
❒refit the bulb holder unit securing it
properly using the retaining tabs C-
fig. 34;
❒close lidB-fig. 33.
A0E0040mfig. 38
Page 206 of 303
204
SAFETY
DEVICES
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
CORRECT USE
OF THE CAR
DASHBOARD
AND
CONTROLS
IN AN
EMERGENCY
Additional brake light
(third stop)
Contact Alfa Romeo Authorized Services
to have the third brake light replaced. ❒remove and replace the burnt-out
bulb by pressing it slightly and turn-
ing it counter-clockwisefig. 39:
Etaillight/brake light bulb;
Fdirection indicator bulb.
❒refit the bulb holder unit securing it
properly using the retaining tabs D-
fig. 38;
❒refit the protection cover B-fig. 37
and tighten screw A.Number plate light
To replace the bulbs proceed as follows:
❒operate with a flat blade screwdriver pro-
tected by a soft cloth on device A-fig.
40to remove the light unit B;
❒remove the bulb holderC-fig. 41by
turning it slightly and replace the snap-
fitted bulb D.
A0E0041mfig. 39A0E0168mfig. 40A0E0169mfig. 41
