2007 Acura RL check engine

To check if they are set, turn the
ignition switch to the ON (II)
position, without starting the engine.
The malfunction indicator lamp will
come on for 20 seconds. If it then
goes off, the readiness codes are set.
If it blinks five times, the readiness
codes are not set. If possible, do not
take your vehicle for a state
emissions test until the readiness
codes are set. Refer to
for more
info rmation (see page ).
Your
vehicle has certain ‘‘readiness
codes’’ that are part of the on-board
diagnostics for the emissions
systems. In some states, part of the
emissions testing is to make sure
these codes are set. If they are not
set, the test cannot be completed.
If
this indicator comes on
while driving, or if you see
a ‘‘CHECK EMISSION
SYSTEM’’ message on the multi-
info rmation display, it means one of
the engine’s emissions control
systems may have a problem. Even
though you may feel no difference in
your vehicle’s performance, it can
reduce your fuel economy and cause
increased emissions. Continued
operation may cause serious damage.If
the indicator comes on repeatedly,
even though it may go off as you
continue driving, have the vehicle
checked by your dealer as soon as
possible.
If you have recently refueled your
vehicle, the indicator coming on
could be due to a loose or missing
fuel fill cap. You will also see a
‘‘TIGHTEN FUEL CAP’’ message on
the multi-information display.
Tighten the cap until it clicks at least
once (see page ). Tightening the
cap will not turn the indicator of f
immediately; it can take several days
of normal driving. If the battery in your vehicle has
been disconnected or gone dead,
these codes are erased. It can take
several days of driving under various
conditions to set the codes again.
328 471State
Emissions T esting
Readiness Code
Malf unction Indicator L amp
444
If you keep driving with the
malf unction indicator lamp on, you can
damage your vehicle’s emissions
controls and engine. Those repairs may
not be covered by your vehicle’s
warranties.
——
y

y
(yy

The primary under-hood fuse box is
in the engine compartm ent on the
driver’s side. To open it, push the
tabs as shown. The
secondary under-hood fuse box
is on the battery. To open it, push
thetabsasshown.
To check the fuse box, remove the
battery cover f irst (see page ). 424
Fuses
448
PRIMARY UNDER-HOOD FUSE BOX SECONDARY UNDER-HOOD FUSE BOX
TAB TAB
——
y

y
(yy

µµ
µ
(


%
)
$
%

.
"

#
) This manual covers maintenance and recommended
procedures f or repair to engine and chassis components.
It is written f or the journeyman mechanic, but is simple
enough f or most mechanically-inclined owners to under-
stand.
This manual complements the service manual by
providing in-depth troubleshooting inf ormation f or each
electrical circuit in your vehicle.
This manual describes the procedures involved in the
replacement of damaged body parts.
Authorized Manuals
Service Manual:
Electrical T roubleshooting Manual:
Body Repair Manual:
478
NOTE: Dealers and Companies please provide dealer or company name,
and also the name of the person to whose attention the shipment should
be sent. For purchases outside U.S.A. please write to the address shown
below for a quotation.
P.O. BOX 07280·DETROIT, MICHIGAN 48207·1-800-782-4356
Customer Name Attention
Apartment Number
State & Zip Code
City
Daytime Telephone Number
Check or money order enclosed payable to Helm Inc U.S. funds only.
Do not send cash
Master
Card VISA
Check here if your billing address is different
from the shipping address shown above.
Account Number Expiration: Mo. Yr.
CUSTOMER SIGNATURE DATE
Street Address No P.O. Box Number
()
These Publications cannot be returned for credit without receiving advance authorization within 14
days of delivery. On returns, a restocking fee may be applied against the original order.
——
y

y
(yy

CONT INUED
BatteryCharging System ...........................
Indicator . 62, 443
............................
Jump Starting .437
..............................
Maintenance .423
..........................................
Cover .424
............................
Specif ications .461
..............................
Bef ore Driving .325..................................
Belts, Seat . 10, 21
.........................
Beverage Holders .190
..................................
Booster Seats .53
Brakes Anti-lock Brake System .....................................
(ABS) .353
.............
Break-in, New Linings . 326
...........................................
Fluid .402
.......................................
Parking .187
.................
System Indicator . 63, 445
........................
Wear Indicators .352
.............................
Braking System .352
.................
Break-in, New Vehicle . 326
Brightness Control, ...............................
Instruments .145
......................
Brights, Headlights .140
Bulb Replacement ..........................
Back-up Lights .410
.................................
Fog Lights .408
...............
Front Position Lights . 407
........
Front Side Marker Lights . 407
.................................
Headlights .404
............................
Specif ications .461
....................
Turn Signal Lights . 406
....................................
Accessories .333
ACCESSORY (Ignition Switch .....................................
Position) .151
............
Accessory Power Sockets . 192
......................................
AcuraLink .297
Adaptive Cruise Control (ACC) .....................................
Indicator .278
...................................
Operation .280
Adaptive Front Lighting System ..........................................
(AFS) .143
....................
Additives, Engine Oil . 395
.............................
Airbag (SRS) . 11, 27
............................
Air Conditioning .198
.......................
Air Pressure, Tires .417
.......................
Alcohol in Gasoline .326
......................................
Antif reeze .398
Anti-lock Brakes (ABS) ...............................
Indicator . 64, 353
...................................
Operation .353
..............
Anti-thef t, Audio System . 239
Anti-thef t Steering Column ............................................
Lock .151
.........................................
Ashtrays .193
................................
Audio System .207 Auto Control Mode, Starting
........................................
Engine .341
..........
Automatic Climate Control . 205
.......................
Automatic Lighting .141
...
Automatic Seat Belt Tensioners . 23
.............
Automatic Speed Control . 275
..............
Automatic Transmission . 343
..........................
Capacity,Fluid .460
...............
Checking Fluid Level . 400
.......................................
Shif ting .343
Shif t Lever Position ...............................
Indicators .343
................
Shif t Lever Positions . 343
....................
Shif t Lock Release . 348
......................
Auxiliary Input Jack .236
Index
A
B
INDEX
I
——
y

y
(yy

Î
CONT INUED
..............
Daytime Running Lights .142
.......................................
Indicator .66
.................................
Dead Battery .437
............
Def ects, Reporting Saf ety . 476
..............
Def ogger, Rear Window . 146
..............
Def rosting the Windows . 204
..........................
Dif f erential Fluid .460
....................................
Dimensions .460
.............
Dimming the Headlights . 140
Dipstick ..........
Automatic Transmission . 400
..................................
Engine Oil .331
........................
Directional Signals .140
........
Disc Brake Wear Indicators . 352
.....................
Disposal of Used Oil .397
Doors ............
Locking and Unlocking . 152
..................
Lockout Prevention . 152
.................
Monitor Indicator . 13,79
....................
Power Door Locks . 152
........
DOT Tire Quality Grading . 462
...........
Driver and Passenger Safety . 7
.......................................
Driver’s ID .81
...........................................
Driving .339
....................................
Economy .332 Driving Position Memory
........................................
System .160
..................
Dust and Pollen Filter . 411
..............................
Economy, Fuel .332
..................................
Emergencies .427
.............
Battery, Jump Starting . 437
...........
Brake System Indicator . 445
................
Changing a Flat Tire . 432
.....
Charging System Indicator . 443
..................
Checking the Fuses . 449
.......
Hazard Warning Flashers . 145
............................
Jump Starting .437
.....
Low Oil Pressure Indicator . 443
...
Malf unction Indicator Lamp . 444
Opening the Fuel Fill Door ................................
Manually .446
..................
Overheated Engine . 440
.......................................
Towing .455
.........................
Emergency Brake .187
....................
Emergency Flashers .145
......................
Emergency Towing .455
..........
Emergency Trunk Opener . 154
.......................
Emissions Controls .468 .............
Emissions Testing, State . 471
Engine ............
Check Starting System . 342
...............
Compartment Covers . 394
....
Coolant Temperature Gauge . 70
.........................
If It Won’t Start .436
Malf unction Indicator ................................
Lamp . 62, 444
.........................................
Oil lif e .381
........
Oil Pressure Indicator . 62, 443
..............
Oil, What Kind to Use . 395
...............................
Overheating .440
............................
Specif ications .461
............................
Speed Limiter .348
.......................................
Starting .341
...................
Engine Speed Limiter . 348
......................
Ethanol in Gasoline .326
.
Evaporative Emissions Controls . 468
...............................
Exhaust Fumes . 56
Exhaust Gas Recirculation ........................................
System .469
Expectant Mothers, Use of Seat ........................................
Belts by .19
Index
E
INDEX
III
——
y
y
(yy

ÎÎ
...................................
Fan, Interior .200
.........................................
Features .197
....................
Filling the Fuel Tank .327
Filters
.........................
Dust and Pollen .411
...............................................
Oil .396
...........
Flashers, Hazard Warning .145
...................
Flat Tire, Changing a .432
.....................................
Floor Mats .412
Fluids ..........
Automatic Transmission .400
..........................................
Brake .402
..........................
Power Steering .402
..................
Windshield Washer .400
.....................................
Fog Lights .142
........................
Four-way Flashers .145
............................
Front Airbags . 11, 29
......................................
Front Seat .155
....................................
Adjusting .155
.......................................
Heaters .178
...................................
Airbags . 11, 29
...........................
Air Ventilation .179
.................................................
Fuel .326
......................
Fill Door and Cap .327 ...........................................
Gauge .70
.....................
Low Fuel Indicator .66
................
Octane Requirement . 326
Opening the Fuel Fill Door ................................
Manually .446
...............................
Oxygenated .326
........................
Tank, Ref ueling .327
......................
Tighten Fuel Cap .328
.....................
Fuses, Checking the .449
................
Gas Mileage Improving . 332
.........................................
Gasoline .326
...........................................
Gauge .70
.....................
Low Fuel Indicator .66
................
Octane Requirement . 326
........................
Tank, Ref ueling .327
................
Gas Station Procedures . 327
.............................................
Gauges .70
...
Engine Coolant Temperature . 70
...............................................
Fuel .70
GAWR (Gross Axle Weight .......................................
Rating) .374
............
Gearshif t Lever Positions . 343
......................................
Glove Box .189 ...........................
GPS initialization .257
GVWR (Gross Vehicle Weight .......................................
Rating) .374
.............
Halogen Headlight Bulbs . 404
..........................
HandsFreeLink .306
............
Hazard Warning Flashers . 145
Headlights Adaptive Front Lighting System
......................................
(AFS) .143
........................................
Aiming .404
..................
Automatic Lighting . 141
.........
Daytime Running Lights . 142
..................
High Beam Indicator . 66
....................
Lights On Indicator . 64
..........
Low Beams, Turning on . 140
.......................
Reminder Chime .140
........
Replacing Halogen Bulbs . 404
..........
High beams, Turning on . 140
...................................
Washer .138
............................
Head Restraints .156
...............................
Heated Mirror .159
...................................
Heater, Seat .178
.............
High Altitude, Starting at . 341
Index
G H
F
IV
TM
——
y

y
(yy

.......................
Label, Certif ication .458
...............
Lane Change, Signaling .140
........................
Lap/Shoulder Belts .22
........................
Lights On Indicator .64
Lights ....................
Bulb Replacement .404
.......................................
Indicator .61
......................................
Position .140
................................
Turn Signal .140
.....................................
Load Limit .373
....
LOCK (Ignition Key Position) .151
Locks
.....
Anti-thef t Steering Column .151
........................
Childproof Door .154
............................
Fuel Fill Door .327
..................................
Glove Box .189
...............................
Power Door .152
.........................................
Trunk .153
......
Trunk Pass-through Cover . 157
........................
Low Coolant Level .331
.........................
Low Fuel Indicator .66
...
Low Oil Pressure Indicator . 62, 443
...
Lubricant Specif ications Chart . 460
..........................
Luggage, Storing .335 ...................
Neutral Gear Position . 344..................
New Vehicle Break-in . 326
...................
NOTICE, Explanation of . i
...............
Numbers, Identif ication . 458
..................................
Maintenance .379
................................
Main Items .389
........................................
Minder .381
Owner’s Maintenance ...................................
Checks .388
.................................
Record . 391-392
..........................................
Saf ety .380
...................................
Sub Items .390
.
Malfunction Indicator Lamp . 62, 444
...........
Memory, Driving Position . 160
.............................
Message Display .78
..........................
Message Indicator .68
...............................
Meters, Gauges .70
...................
Methanol in Gasoline . 326
........................
Mirrors, Adjusting .158
.................................
Modif ications .333
...............
Modif ying Your Vehicle . 334
................................
Moonroof . 183-186
................................................
MP3 .230
.............
Multi-Inf ormation Display . 71 ...
Octane Requirement, Gasoline . 326
.........................................
Odometer .72
...............................
Odometer, Trip .72
Oil ........................
Change, How to .396
......................
Change, When to .381
......................
Checking Engine .331
...............................
Lif e, Engine .381
..............
Pressure Indicator . 62, 443
Selecting Proper Viscosity ......................................
Chart .395
.....
ON (Ignition Switch Position) . 151
Onboard Ref ueling Vapor ....................................
Recovery .468
............................
Outside Mirrors .158
....
Outside Temperature Indicator . 73
....................
Overheating, Engine .440
....
Owner’s Maintenance Checks . 388
.........................
Oxygenated Fuels .326
Index
O
M
N
L
VI
——
y
y
(yy
