2006 TOYOTA HIGHLANDER HYBRID fuses

’06 HIGHLANDER HB_U (L/O 0503)
379
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Spare fuses
If you perform maintenance by yourself,
be sure to follow the correct procedure
given in this Section.
You should be aware that improper or in-
complete servicing may result in operating
problems.
Performing do−it−yourself maintenance
during the warranty period may affect your
warranty coverage. Read the separate
Toyota Warranty statement for details and
suggestions.
This Section gives instructions only for
those items that are relatively easy for an
owner to perform. As explained in Section
6, there are still a number of items that
must be done by a qualified technician
with special tools.
For information on tools and parts for do −
it −yourself maintenance, see “Parts and
tools” on page 382 in this Section.
Utmost care should be taken when work-
ing on your vehicle to prevent accidental
injury. Here are a few precautions that
you should be especially careful to ob-
serve:
Doityourself service
precautions

’06 HIGHLANDER HB_U (L/O 0503)
383
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Tools:
Funnel (only for adding coolant)
CHECKING BRAKE FLUID
Parts (if level is low):
SAE J1703 or FMVSS No.116 DOT 3
brake fluid
Tools:
Rag or paper towel
Funnel (only for adding fluid)
CHECKING AUXILIARY BATTERY
CONDITION
Tools:
Warm water
Baking soda
Grease
Conventional wrench
(for terminal clamp bolts)
CHECKING AND REPLACING FUSES
Parts (if replacement is necessary):
Fuse with same amperage rating as
original ADDING WASHER FLUID
Parts:
Water
Washer fluid containing antifreeze
(for winter use)
Tools:
Funnel
REPLACING LIGHT BULBS
Parts:
Bulb with same number and wattage
rating as original (See charts in
“Replacing light bulbs” on page 404 in
Section 7 −3.)
Tools:
Screwdriver

’06 HIGHLANDER HB_U (L/O 0503)
399
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
DOITYOURSELF MAINTENANCE
Electrical components
Checking auxiliary battery condition 400
. . . . . . . . . . . . . . . . . . . . . . . . . .
Auxiliary battery recharging precautions 401
. . . . . . . . . . . . . . . . . . . . . .
Checking and replacing fuses 402
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding washer fluid 403
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . .
Replacing light bulbs 404
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . .
SECTION 7 3

’06 HIGHLANDER HB_U (L/O 0503)
402
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
GoodBlown
Ty p e A
Good Blown
Ty p e B
Good Blown
Ty p e C
If the headlights or other electrical
components do not work, check the
fuses. If any of the fuses are blown,
they must be replaced.
See “Fuse locations” on page 378 in Sec-
tion 7 −1 for locations of the fuses.
Turn the ignition switch and inoperative
component off. Pull the suspected fuse
straight out and check it.
Determine which fuse may be causing the
problem. The lid of the fuse box shows
the name of the circuit for each fuse. See
page 415 in Section 8 for the functions
controlled by each circuit.
Checking and replacing fuses

’06 HIGHLANDER HB_U (L/O 0503)
403
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Type A fuses can be pulled out by using
the pull−out tool. The location of the pull −
out tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the “CRT” or
“CIG” fuse, which may be dispensable for
normal driving, and use it if its amperage
rating is the same.
If you cannot use one of the same amper-
age, use one that is lower, but as close
to the rating as possible. If the amperage
is lower than that specified, the fuse
might blow out again but this does not
indicate anything wrong. Be sure to get
the correct fuse as soon as possible and
return the substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies. If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.
You should normalize the moon roof if it
does not operate automatically or the jam
protection function does not operate cor-
rectly after replacing blown fuses. To
normalize the moon roof, see “Electric
moon roof” on page 45 in Section 1
−2.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
If the washer does not work or the
“LOW WASHER FLUID” warning mes-
sage appears on the multiinformation
display, the washer tank may be empty.
Add washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below the freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer ’s directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-
age your vehicle’s paint.
Adding washer fluid

’06 HIGHLANDER HB_U (L/O 0503)
409
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
SPECIFICATIONS
Specifications
Dimensions and weights 410
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Engine 410
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . .
Fuel 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
Traction motor 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Traction battery 411
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . .
Service specifications 412
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Tires 415
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . .
Fuses 415
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . .
SECTION 8

’06 HIGHLANDER HB_U (L/O 0503)
415
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Engine compartment
Tires
Ti r e siz eTi r e inf lat ion pr es s ur e
Front Rear
225/65R17 101S 220 (2.2, 32) 220 (2.2, 32) Wheel size
17 6 1/ 2 J
When driving under the above load condition at sustained high speeds above
160 km/h (100 mph), in countries where such speeds are permitted by −low,
inflate the front and rear tires to the following tire inflation pressure provided
that it does not exceed the maximum cold tire inflation pressure molded
on the tire sidewall.
240 kPa (2.4 kgf/cm
2 or bar, 35 psi)
Wheel nut torque, N
·m (kgf·m, ft·lbf):
103 (10.5, 76)
NOTE: For a complete information on tires (e.g. replacing tires or replacing wheels), see “Checking tire inflation pressure” through “Aluminum
wheel precautions”, pages 391 through 398, in Section 7 −2.
Tire size and cold tire inflation pressure:
kPa (kgf/cm
2 or bar, psi)
Fuses

’06 HIGHLANDER HB_U (L/O 0503)
416
2006 HIGHLANDER (Hybrid) from Mar. ’05 Prod. (OM48530U)
Engine compartment
Fuses (type A)
1. ETCS 10 A: Hybrid system
2. DC/DCS 10 A: Hybrid system
3. ABS NO.2 10 A: Electronically con-
trolled brake system
4. ABS NO.1 10 A: Electronically con-
trolled brake system
5. BATT FAN 15 A: Hybrid system
6. ABS NO.3 15 A: Electronically con-
trolled brake system
7. OIL PUMP 10 A: Transmission fluid
cooling system
8. ST 7.5 A: Hybrid system
Engine compartment
9. RR HTR 15 A: Rear heater system
10. DRL 7.5 A: Daytime running light sys-
tem
11. HLP L LWR 15 A: Left−hand head-
light (low beam)
12. HLP L UPR 15 A: Left−hand headlight
(high beam)
13. HLP R UPR 15 A: Right−hand head-
light (high beam)
14. PWR OUTLET NO.2 20 A: Power out-
let (115 VAC)
15. TOWING 20 A: Trailer lights
Instrument panel
16. HAZ 15 A: Turn signal lights, emergen-
cy flashers
17. SECURITY 15 A: Theft deterrent sys-
tem
18. AM2 NO.1 30 A: “IGN”, “IG2” and “ST”
fuses
19. MPXB1 7.5 A: Electric power steering
system
20. HORN 10 A: Horns
21. RADIO NO.1 25 A: Audio system
