20
„
Combination meter
T Non-turbo models
12 3 4
5
6
7
8
9
UBF063BB
1) Fuel gauge (page 3-8)
2) Speedometer (page 3-6)
3) Tachometer (page 3-8)
4) Temperature gauge (page 3-9)
5) Clock setting knob (page 3-19)
6) Clock and outside temperature
indicator (page 3-19, 3-8)
7) Selector lever po sition indicator
(page 3-17)
8) Trip meter A/B selection and trip
meter reset knob (page 3-6)
9) Trip meter and odometer (page
3-6)

21
–
CONTINUED –
TTurbo models
12 4 35
6
7
8
9
10
UBF064BB
1) Fuel gauge (page 3-8)
2) Speedometer (page 3-6)
3) Gear position indicator (page 3-
17)
4) Tachometer (page 3-8)
5) Temperature gauge (page 3-9)
6) Clock setting knob (page 3-19)
7) Clock and outside temperature indicator (page 3-19, 3-8)
8) Selector lever position indicator
(page 3-17)
9) Trip meter A/B selection and trip
meter reset knob (page 3-6)
10) Trip meter and odometer (page 3-6)

3-1
3
Instruments and controls
Ignition switch .............................................. 3-2 LOCK .................................................................. 3-3
ACC .................................................................... 3-4
ON ....................................................................... 3-4
START ................................................................ 3-4
Key reminder chime .......................................... 3-4
Ignition switch light (if equipped) .................... 3-4
Key interlock release (AT vehicles) ................. 3-5
Hazard warning flasher ................................ 3-6
Meters and gauges ....................................... 3-6 Speedometer ..................................................... 3-6
Odometer/Trip meter ........................................ 3-6
Tachometer ........................................................ 3-8
Outside temperature indicator (if equipped) .. 3-8
Fuel gauge ......................................................... 3-8
Temperature gauge ........................................... 3-9
Warning and indicator lights ....................... 3-11 Seatbelt warning light and chime .................... 3-11
SRS airbag system warning light .................... 3-11
CHECK ENGINE warning light/Malfunction indicator lamp ................................................. 3-12
Charge warning light ........................................ 3-13
Oil pressure warning light ................................ 3-13
AT OIL TEMPerature warning light (AT vehicles) ................................................... 3-13
ABS warning light ............................................. 3-14
Brake system warning light ............................. 3-15
Door ajar warning lights ................................... 3-15
Switchback door indicator light ...................... 3-15
Low fuel warning light ...................................... 3-16
All-Wheel Drive warning light (AT vehicles) ... 3-16 Security system status indicator light
(if equipped) .................................................... 3-17
Selector lever position indicator (AT vehicles) ................................................... 3-17
Gear position indicator (Turbo-AT vehicles) .. 3-17
Turn signal indicator lights .............................. 3-17
High beam indicator light ................................. 3-18
Cargo lamp indicator light ............................... 3-18
Cruise control set indicator light .................... 3-18
Clock .............................................................. 3-19
Light control switch ...................................... 3-19 Headlights ......................................................... 3-20
High/low beam change (dimmer) .................... 3-20
Headlight flasher ............................................... 3-21
Daytime running light system ......................... 3-21
Turn signal lever ........................................... 3-22
Illumination brightness control ................... 3-23
Parking light switch ...................................... 3-23
Front fog light button ................................... 3-24
Wiper and washer ......................................... 3-25 Windshield wiper and washer switches ......... 3-26
Rear window defogger button ..................... 3-28
Windshield wiper deicer (if equipped) ........ 3-29
Mirrors ............................................................ 3-30 Inside mirror ...................................................... 3-30
Outside mirrors ................................................. 3-32
Tilt steering wheel ......................................... 3-34
Horn ................................................................ 3-35

3-6
Instruments and controls
Hazard warning flasherHazard warning flasher
The hazard warning flasher is used to warn other driv-
ers when you have to park your vehicle under emer-
gency conditions. The hazard warning flasher works
with the ignition switch in any position.
To turn on the hazard warning flasher, push the haz-
ard warning button on the instrument panel. To turn off
the flasher, push the button again.
NOTE
When the hazard warning flasher is on, the turn
signals do not work.
Meters and gaugesMeters and gauges
NOTE
Liquid-crystal displays are used in some of the
meters and gauges in the combination meter. You
will find their indications hard to see if you wear
polarized glasses. „
Speedometer
„SpeedometerThe speedometer shows the vehicle speed. „Odometer/Trip meter
„Odometer/Trip meter
To ensure safety, do no t attempt to change the
function of the indicator during driving, as an
accident could result.
UB8002BA

3-7
Instruments and controls
– CONTINUED –
1) Trip meter
2) Odometer
T Odometer
The odometer shows the total distance that the vehicle
has been driven. T
Double trip meter
1) A trip meter
2) B trip meter
The trip meter shows the distance that the vehicle has
been driven since you last set it to zero.
To change the mode indication, briefly push the knob.
Each press of the knob changes the function alter-
nately.
To set the trip meter to zero , select either the A trip or
B trip meter and push the knob and keep it pushed for
1
2
UB3026BB
1 2
UB3027BB
A trip meter B trip meter

8-15
Driving tips
– CONTINUED –
give superior wiping performance in snowy conditions.
Be sure to use blades that are suitable for your vehi-cle.
During high-speed driving, non-freezing type
wiper blades may not perform as well as stan-
dard wiper blades. If this happens, reduce the
vehicle speed.
NOTE
When the season requiring non-freezing type wip-
er blades is over, replace them with standard wip-
er blades. „Corrosion protection
Refer to the “Corrosion protection” section (chapter
10). „ Snow tires
yWhen replacing original tires with winter
(snow) tires, make sure you use only the same size and construction as recommended. Using
other sizes and construction may affect speed-
ometer/odometer calibration and clearance be-
tween the body and tires. It also may be danger-
ous and lead to loss of vehicle control.y
You must install four winter tires that are of
the same size, circumferences, construction,
brand, and load range. Mixing other sizes, cir-
cumferences or constructions may result in se-
vere mechanical damage to the drive train of
your vehicle and may affect ride, handling,
braking and speedometer/odometer calibra-
tion. It also may be dangerous and lead to loss
of vehicle control.y Do not use a combination of radial, belted
bias or bias tires since it may cause dangerous
handling characteristi cs and lead to an acci-
dent.
Your vehicle is equipped with “all season tires” which
are designed to provide an adequate measure of trac-tion, handling and braking performance in year-round
driving. In winter, it may be possible to enhance per-
formance through use of tires designed specifically for
winter driving conditions.
If you choose to install winte r tires on your vehicle, be
sure to use the correct tire size and type. You must in-

11 - 5 2
Maintenance and service
shown on the tire placard.
Using tires of a non-specified size detracts from con-
trollability, ride comfort, braking performance, speed-
ometer accuracy and odometer accuracy. It also cre-
ates incorrect body-to-tire
clearances and inappropri-
ately changes the vehicle’s ground clearance.
All four tires must be the same in terms of manufactur-
er, brand (tread pattern), construction, and size. You
are advised to replace the ti res with new ones that are
identical to those fitted as standard equipment.
For safe vehicle operation, SUBARU recommends re-
placing all four tires at the same time.
y All four tires must be the same in terms of
manufacturer, brand (trea d pattern), construc-
tion, degree of wear, speed symbol, load index
and size. Mixing tires of different types, sizes or
degrees of wear can result in damage to the ve-
hicle’s power train. Use of different types or siz-
es of tires can also dangerously reduce control-
lability and braking performance and can lead
to an accident. y Use only radial tires. Do not use radial tires
together with belted bias tires and/or bias-ply tires. Doing so can dangerously reduce control-
lability, resulting in an accident.
„ Wheel replacement
„Wheel
„ ReplacementWhen replacing wheels due, for example, to damage,
make sure the replacement wheels match the specifi-
cations of the wheels that are fitted as standard equip-
ment. Replacement wheels are available from
SUBARU dealers.
Use only those wheels that are specified for
your vehicle. Wheels not meeting specifica-
tions could interfere with brake caliper opera-
tion and may cause the tires to rub against the
wheel well housing during turns. The resulting
loss of vehicle control could lead to an acci-
dent.

14-6
Index
LSD (Limited slip differential) ............................ 7-30 M
Main fuse ......................................................... 11-61
Maintenance
Precautions .................................................. 11-3
Schedule .............. ........................................ 11-3
Seatbelt ........................................................ 1-21
Malfunction indicator lamp (Check Engine
light) ............................................................... 3-12
Manual transmission ......................................... 7-12
Manual transmission oil ................................... 11-27
Map light .............................................................. 6-3
Maximum load limits .......................................... 8-25
Meters and gauges ............................................. 3-6
Mirrors ............................................................... 3-30
Moonroof ........................................................... 2-36 N
New vehicle break-in driving – the first 1,000
miles (1,600 km) .............................................. 8-2
O
Odometer/Trip meter ........................................... 3-6
Off road driving .................................................... 8-9 Oil level
Engine ........................................................ 11-10
Front differential (AT vehi cles) ................... 11-32
Manual transmission .................................. 11-27
Rear differential .............. ............................ 11-33
Oil pressure warning light .................................. 3-13
Outside mirrors .................... .............................. 3-32
Overheating engine ........................................... 9-21 P
Parking Brake ............................................................ 7-35
Brake stroke ............................................... 11-46
Light switch ................................................... 3-23
Periodic inspections ............................................ 8-6Power
Door locking switches ..................................... 2-5
Steering ........................................................ 7-31
Steering fluid .............................................. 11-36
Windows ....................................................... 2-25
R
Rear Center console ............................................... 6-6
Combination lights ...................................... 11-72
Differential gear oil ..................................... 11-33
Seats .............................................................. 1-9
