4ExteriorAnti-corrosion treatment ___ 280
Body __________________ 279
Service program _________ 288
Sunroof ________________ 138
Touching up paintwork ____ 279
Washing _______________ 277
Waxing and polishing _____ 279Brake lights _____________ 240
Changing bulbs __________ 232
Light switches ___________ 102
Taillights _______________ 240Towing _________________ 205
Towing hook eyes ________ 205
Towing a trailer __________ 198Folding down the rear seat _ 146
Lighting ________________ 240
Load-through hatch _______ 148
Spare wheel ____________ 150
Tools __________________ 150
Trunk __________________ 146
Maximum loads _______________ 294
Mounting holes for roof carriers ___ 202
Roof load ____________________ 202
Hood _______________________ 214
Washing the engine bay_________ 277
Central locking __________ 50
Child safety locks ________ 54
Lock buttons ____________ 50
Trunk lock ______________ 53Changing bulbs _________ 232
Dipswitch ______________ 102
Direction indicators_______ 104
Front lights _____________ 234
Headlight levelling (xenon) _ 102
Headlight switches _______ 102
Headlight washers _______ 231Economical motoring _____ 193
Fuel filler door __________ 167
Fuel gauge _____________ 91
Fuel grade _____________ 299
Refueling ______________ 167
Braking _____________________ 180
Changing wheels ______________ 273
Spare wheel _________________ 270
Tire pressure ________________ 306
Tires _______________________ 256
Wheels _____________________ 304
Winter driving ________________ 195
93U S M 06.book Page 4 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

8
Coolant:Never open when engine hot!
Radiator fan:Radiator fan may start at any
time.
Battery: No sparks, flames or smoking
 Shield eyes, explosive gases can cause blindness or injury
 Sulphuric acid can cause blindness or severe burns
 Flush eyes immediately with water. Get medical help fast
 Do not tip battery. Do not open battery
 NO SPARKS, FLAMES OR SMOKING
 SHIELD EYES
 KEEP OUT OF REACH FROM CHILDREN
ACID
 SEE OWNER’S MANUAL
 EXPLOSIVE GASWarning labelsA/C system:Refrigerant at high pressure.
Do not loosen or remove the A/C system fittings before discharging the A/C
system. Improper service methods may cause personal injury.
System to be
serviced by qualified personnel only. For instructions consult dealer man-
ual.
The A/C system complies with SAE J639.
Charge: 680 g R134a.
Compressor oil: 150 cc PAG oil SP-10 alt.
Saab oil 4759106
DANGER/POISON
700 CCA (SAE)
LEVEL INDICATOR
INDICATEUR DE NIVEAU
DARK / NOIR No sparks, flames or smoking.  Flush eyes immediatly with water
 Do not tip battery. Do not open battery
KEEP OUT OF REACH FROM CHILDREN.
000 12102-EP
 Shield eyes, explosive gases can cause
blindness or injury.Get medical help fast.
 Sulfuric acid can cause blindness or severeMAINTENANCE-FREE BATTERY-P/N 53 52 000 12V/700A/125min(SAE) 12V/700A/70Ah (EN)
Saab Automobile AB 53 53 057 Manufactured by Tudor Spain (Exide Technologies) 12102-EPburns.
OK
CLEAR
CLAIRLOW
BAS
DANGER/POISON
700 CCA (SAE)
 Éviter les étincelles et les flammes. Ne pas fumer.  Rincer immédiatement les yeux avec de
 Ne pas pencher ni ouvrir la batterie.
GARDER HORS DE LA PORTÉE DES
ENFANTS
000 12103-EP
 Protéger les yeux car les gaz explosife peuvent
causer la cécité ou des blessures.l'oau Consulter un médecin rapidement.
 L'acide sulfurique peut causer la cécité ou desBATTERIE SANS ENTRETIEN-P/N 53 52 000 12V/700A/125min(SAE) 12V/700A/70Ah (EN)
Saab Automobile AB 53 53 085 Fabriquée par Tudor Espagne (Exide Technologies) 12103-EPbrûlures graves.
CANADA
NETTOYER LE BOUCHON
DE REMPLISSAGE
AVANT DE L’ENLEVER.
UTILISER SEULEMENT
DU LIQUIDE DOT 4 PROV-
ENANT D’UN CONTE-
NANT SCELLÉ.
93U S M 06.book Page 8 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

39 Safety
The passenger sensing system is designed
to enable (may inflate) the right front
passenger’s frontal airbag anytime the
system senses that a person of adult size is
sitting properly in the right front passenger’s
seat. When the passenger sensing system
has allowed the airbag to be enabled, the on
indicator will light and stay lit to remind you
that the airbag is active.
For some children who have outgrown child
restraints and for very small adults, the pas-
senger sensing system may or may not turn
off the right front passenger’s frontal airbag,
depending upon the person’s seating pos-
ture and body build. Everyone in your vehi-
cle who has outgrown child restraints
should wear a safety belt properly —
whether or not there is an airbag for that per-
son.If a person of adult-size is sitting in the right
front passenger’s seat, but the off indicator
is lit, it could be because that person is not
sitting properly in the seat. If this happens,
turn the vehicle off and ask the person to
place the seatback in the fully upright posi-
tion, then sit upright in the seat, centered on
the seat cushion, with the person’s legs
comfortably extended. Restart the vehicle
and have the person remain in this position
for about two minutes. This will allow the
system to detect that person and then
enable the passenger’s airbag.Aftermarket equipment, such as seat
covers, can affect how well the passenger
sensing system operates. You may want to
consider not using seat covers or other
aftermarket equipment if your vehicle has
the passenger sensing system. See Adding
Equipment to Your Airbag-Equipped Vehi-
cle for more information about modifications
that can affect how the system operates.
WARNING
If the airbag readiness light in the instru-
ment panel cluster ever comes on and
stays on, it means that something may be
wrong with the airbag system. If this ever
happens, havethe vehicle serviced
promptly, because an adult-size person
sitting in the right front passenger’s seat
may not have the protection of the frontal
airbag. See Airbag warning lamp on
page 43 for more on this, including impor-
tant safety information.
WARNING
Stowing of articles under the passenger’s
seat or between the passenger’s seat
cushion and seatback may interfere with
the proper operation of the passenger
sensing system.
93U S M 06.book Page 39 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

85 Instruments and controls
This light will come on if the engine oil pres-
sure is too low. If the warning light flashes or
comes on while you are driving, stop imme-
diately in a safe place, switch off the engine
and check the oil level (see page 219).
The following message is shown on the
Saab Information Display (SID):This light indicates a malfunction in the fuel
or ignition system. The car may still be
driven with care but the performance of the
engine will be somewhat diminished (see
page 164).
The following message is shown on the
Saab Information Display (SID):
Warning, oil pressure
(engine oil)
NOTICE
Never drive the car when the oil pressure
warning lamp is on. Low oil pressure can
cause serious engine damage.
Oil pressure low.
Make a safe stop.
Turn off engine.
Engine malfunction
(CHECK ENGINE)
WARNING
An illuminated “Engine malfunction
(CHECK ENGINE)” indicator light indi-
cates an engine-related problem. While
your car may be able to be driven with the
“Engine malfunction (CHECK ENGINE)”
indicator light illuminated (limp-home
mode), you are advised to have your car
serviced at an authorized Saab dealer as
soon as possible.
Continued driving without this problem
being corrected might cause serious
further damage to your car and create
unsafe driving conditions. The operator
should be prepared to take action if such
unsafe conditions arise (e.g. brake
smoothly, engage neutral, stop in a suita-
ble place, switch off the engine, etc.)
Engine malfunction.
Contact Saab dealer.
NOTICEThe car should be checked immediately
at a Saab dealer to prevent more serious
faults from arising.
93U S M 06.book Page 85 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

87 Instruments and controls
This light reminds the driver to buckle up.
This light comes on when the parking brake
is applied (see page 187).
The parking brake is mechanical and oper-
ates on the rear wheels.This light comes on if a potentially serious
fault has occurred in the airbag system.
The following message is shown on the
Saab Information Display (SID):This light will come on for about four sec-
onds when the ignition switch is turned to
the Start or Drive position.
This light comes on when there is less than
about 2.5 gallons (10 litre) of fuel left in the
tank.
Safetybelt reminder
Parking brake warning
light
WARNING
Always apply the parking brake when
parking, see page 187.
Always apply the parking brake
before removing the remote control.
Do not apply the parking brake while
the car is moving.
Airbag warning lightAirbag malfunction.
Contact Saab dealer.
WARNING
 If the airbag readiness light stays on
after you start your vehicle, it means
the airbag system may not be working
properly. One or more of the following
conditions may occur:
- Non-deployment of the airbags in the
event of a crash.
- Deployment of the airbags without a
crash.
- Deployment of the airbags in crashes
less severe than intended.
 To help avoid injury to yourself or
others, have your vehicle serviced
right away if the airbag readiness light
stays on after you start your vehicle.
Indicator, fuel
NOTICE
If the car runs out of fuel, air can be drawn
in with the fuel, which, in turn, can cause
the catalytic converter to be damaged by
overheating.
93U S M 06.book Page 87 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

171 Starting and driving
whether the fuel contains MMT. Saab does
not recommend the use of such gasolines.
Fuels containing MMT can reduce the life of
spark plugs and the performance of the
emission control system may be affected.
The malfunction indicator lamp may turn on.
If this occurs, return to your authorized Saab
dealer for service.
Fuels in Foreign Countries
If you plan on driving in another country out-
side the United States or Canada, the
proper fuel may be hard to find. Never use
leaded gasoline or any other fuel not recom-
mended in the previous text on fuel. Costly
repairs caused by use of improper fuel
would not be covered by your warranty.
To check the fuel availability, ask an auto
club, or contact a major oil company that
does business in the country where you will
be driving.
Engine Break-in PeriodPistons, cylinder bores and bearings need
time to obtain uniform, wear-resistant
surfaces.
If a new engine is driven too hard, this grad-
ual process of bedding-in will not be possi-
ble and the life of the engine will be short-
ened.
During the first 1,200 miles (2,000 km),
do not exceed 5,000 rpm.
In addition, refrain from driving the car at full
throttle, other than for brief instances,
during the first 1,800 miles (3,000 km).
Wearing in new brake padsNew brake pads take time to bed in, about
90 miles (150 km) if the car is driven largely
under stop-and-go conditions or about
300 miles (500 km) of highway driving.
To extend the useful life of the pads, avoid
hard braking as much as possible.
93U S M 06.book Page 171 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

299 Technical data
Fuel
When to change engine oil.
Your vehicle has a display (SID) where time for service will be
shown. Based not only on mileage but also on driving condi-
tions the mileage at which a service will be indicated can vary
considerably.
Under normal circumstances the service indication will come on
at or around 15 000 miles or 2 years.
For this service system to work it is of outmost importance that
the right engine oil is used.
When the message for service is displayed you need to have
the required service done as soon as possible.
After the service your service personnel will reset the service in-
dicator. It is important to reset the service indicator in order to
optimize the time to the next service.
Oil capacity, including filter (oil change)
Petrol engine, 4-cyl. ________________ 6.3 qts. (6.0 l)
Petrol engine, V6 __________________ 6.0 qts. (5.7 l)Fuel tank capacity ________________ 16.05 U.S. gal. (61 l)
For optimum performance Saab recom-
mends: _______________________ 2.0t 175 hp – AON 90.
2.0T 210 hp – AON 90.
2.8 V6 230 hp and
250 hp — AON 90.
Gasoline with a lower octane rating can be used, although not
lower than AON 87. However, engine performance will fall slightly
and heavy loading and laboring should be avoided. For optimum
performance, use the recommended grade of fuel.
For further information on fuel, see page 169.93U S M 06.book Page 299 Friday, February 18, 2005 1:15 PM
ProCarManuals.com
