2006 SAAB 9-2X CD player

5
Audio
Antenna system .................................................. 5-2
Printed antenna ....................................................... 5-2
FM reception ........................................................... 5-2
Installation of accessories ................................ 5-2
Audio Systems ................................................... 5-3
AM/FM/Single-CD Audio System ........................... 5-3
Premium AM/FM/6
-CD Audio System ................... 5-3
AM/FM/Single-CD Audio System
3 ................... 5-4
Radio operation ...................................................... 5-4
Compact disc player operation ............................. 5-8
CD changer control (if optional in-dash CD
changer is connected) ......................................... 5-10
Premium AM/FM/6-CD Audio System
3 ........... 5-12
Radio operation ...................................................... 5-12
Built in CD changer operation ............................... 5-16
Precautions to observe when handling a
compact disc ................................................... 5-193 Asterisk means: equipment not fitted in all cars (can depend
on model variant, engine variant, market specification, options
or accessories)
.
A1910BE-A-GSAAB.book Page 1 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

Audio
5-3
5
Audio SystemsYour Saab may be equipped with one of
the following audio sets. See the pages in-
dicated in this section for operating de-
tails.
AM/FM/Single-CD Audio Sys-
tem
Radio operation: refer to page 5-4

Compact disc player operation: refer to
page 5-8

CD changer control: refer to page 5-9

Premium AM/FM/6-CD Audio
System
Radio operation: refer to page 5-12

Built-in CD changer operation: refer to
page 5-16
500014
500246
A1910BE-A-GSAAB.book Page 3 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

5-8
Audio

Compact disc player operation
500024
(7) (8)
(11) (10)(9)
(7) Eject button
(8) Disc slot
(9) DISC button
(10) Repeat/Random button
(11) Track selection buttons

To play back a compact disc
When CD is not in the player
Hold a disc with a finger in the center hole
while gripping the edge of the disc, then
insert it in to the slot (with the label side
up) and the player will automatically pull
the disc into position.
A single CD (8 cm/3 inch CD) may also be
used without any adapter.NOTE
Make sure to always insert a disc
with the label side up. If a disc is insert-
ed with the label side down, it might be
ejected or the player might shut off.

After the last song finishes, the play-
er will automatically return to track 1
(the first song on the disc).

CD-RWs cannot be used. Also, some
CD-Rs cannot be played.
When CD is in the player
Press the “DISC” button (9). The display
will show “CD” and the player will start
playback.
A1910BE-A-GSAAB.book Page 8 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

Audio
5-9
5
– CONTINUED –
NOTEAfter the last song finishes, playback
will automatically return to track 1 (the
first song on the disc).

To select a song from its beginning
Forward direction
Briefly press the “ ” side of the track se-
lection button (11) to skip to the beginning
of the next track. Each time this side of the
button is pressed, the indicated track
number will increase.
Backward direction
Briefly press the “ ” side of the button
(11) to skip to the beginning of the current
track. Each time this side of the button is
pressed, the indicated track number will
decrease.

Fast-forwarding and fast-reversing
Fast-forwarding
Press the “ ” side of the button (11)
continuously to fast-forward the disc.
Release the button to stop fast-forward-
ing.
Fast-reversing
Press the “
” side of the button (11)
continuously to fast-reverse the disc.
Release the button to stop fast-reversing.
Repeat playback
Press the “RPT/RDM” button (10) and re-
lease it in less than 2 seconds while a
song is playing to play the song repeated-
ly. The “RPT” indicator will come on and
the song will be played continuously. To
cancel the repeat mode, press the button
again. Then the “RPT” indicator goes out,
and normal playback mode is restored.

Random playback
Press the “RPT/RDM” button (10) and
hold it in for more than 2 seconds while a
disc is being played back to play all songs
on the disc in a random order. The “RDM”
indicator will come on and all songs on the
disc will be played in a random order.
To cancel the random mode, press the
button again. Then the “RDM” indicator
goes out, and normal playback mode is
restored.

To eject a disc from the player
When a disc is being played back or when
a disc is in the player, press the “Eject”
button “
” (7). The disc will be ejected.
The disc may be removed even when the
ignition switch is in the “LOCK” position.
NOTEAvoid driving the vehicle with a CD
sticking out, because vibration might
make it fall out.
A1910BE-A-GSAAB.book Page 9 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

5-10
Audio

CD changer control (if optional in-dash CD changer is connect-
ed)An optional CD changer can be connected to this audio unit. Consult the instructions that
accompany the CD changer for operating the CD changer itself (e.g., how to load or un-
load CDs). See your Saab dealer for more information.
500025
(14) (15)(13) (12)
(12) Track selection buttons
(13) DISC button
(14) Repeat/Random button
(15) Disc select button

To start playback
When the “CD” button (13) is pressed, the
CD changer will start playback. The dis-
play shows the current disc number, track
number and the elapsed time during play-
back.NOTE
If a disc is in the player, the “DISC”
button is used to change from CD play-
er operation to DISC changer opera-
tion. Each time the “DISC” button is
pressed, the operating mode will
change alternately.

At the end of the disc, the player au-
tomatically continues with the next
disc.

After playback on the last disc finish-
es, playback will automatically return
to the first disc.

If you have loaded fewer than 6
discs, any missing disc is automatical-
ly skipped.

Selection of a desired disc
You can select a desired disc from among
the discs contained in the CD changer
A1910BE-A-GSAAB.book Page 10 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

5-16
Audio

Built in CD changer operation
(9)
(17) (16)(12) (11) (10) (13) (14) (15)
500249
(9) LOAD button
(10) Disc slot
(11) Repeat button
(12) Random button
(13) SCAN button
(14) CD button
(15) Eject button
(16) Fast-forwarding/Fast-reversing and
track UP/DOWN knob
(17) Disc select buttonNOTE
Make sure to always insert a disc
with the label side up. If a disc is insert-
ed with the label side down, it might be
ejected or the player might shut off.

Certain CD-Rs and CD-RWs cannot
be played.

How to insert a CD(s)
Inserting a CD
1. Press “LOAD” button (9). If the maga-
zine in the player has an open position
where you can insert a disc, the “DISC” in-
dicator associated with the open position
will blink. The capacity is 6 discs.
If no indicator blinks, it means that there is
no open position in the magazine.
2. As soon as the “DISC” indicator begins
to blink, the “LOAD” will appear on display
for a period of 15 seconds. Insert a disc
A1910BE-A-GSAAB.book Page 16 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

Audio
5-17
5
– CONTINUED –
during the period. The disc will be then au-
tomatically drawn in, and the player will
begin to play back the first track of the
disc.

To insert more discs in succession, re-
peat Steps 1 and 2. The magazine will be
loaded with discs in the ascending order
of position number.
If you do not insert any disc in 15 seconds
after you have pressed the “LOAD” but-
ton, the player will begin to play back the
first track of the last disc you have insert-
ed.

The disc indicator steadily lights up if a
disc is already inserted in the correspond-
ing position of the magazine.

While the player is in the loading mode,
if you press any of the other mode buttons
“FM” (1), “AM” (2), the player will enter the
standby mode. Press the “CD” button (14)
to start playback.
Inserting a disc in a desired position
1. Press the “LOAD” button (9). If the
magazine in the player has an open posi-
tion where you can insert a disc, the
“DISC” indicator associated with the open
position will blink.
The positions in the magazine the indica-
tor of which steadily lights up are already
loaded with discs.
2. Press the “Disc select” button (17) atthe position where you want to insert a
disc. The associated “DISC” indicator will
blink, and the “LOAD” will be displayed.
3. If you insert a disc during the 15-sec-
ond period while the “LOAD” is on display,
the disc will be automatically drawn in,
and the player will start playback of the
disc, beginning with the first track.

To insert more discs in succession, re-
peat Steps 1 and 2.

While the player is in the loading mode,
if you press any of the other mode buttons
“FM” (1), “AM” (2), the player will enter
standby mode. Press the “CD” button (14)
to start playback.
Loading the magazine (Full disc
loading mode)
1. If you continue to press the “LOAD”
button (9) for more than 1.5 seconds, the
player will produce a beeping sound and
will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the
“ALL LOAD” will be on display for a period
of 15 seconds. If a disc is successfully
loaded during this period, the “DISC” indi-
cator will stop blinking and will steadily
light.
3. When the loading of a disc is complete,
the next “DISC” indicator will blink. Then
repeat Step 2.
4. When the magazine is filled with discsby repeating Steps 2 and 3, the player will
start playback of the discs, beginning with
the one inserted first.
If you fail to insert any disc during each 15
seconds interval, the full disc loading
mode will be canceled, and the player will
start playback of the disc inserted first.

How to play back a CD or make a
pause
When there is no CD inserted:
Insert a CD by referring to “How to Insert
a CD(s)”.
When a CD is loaded, the player will start
playback of the CD, beginning with the
first track.
When there are CDs loaded:
Press a desired one of the “Disc select”
buttons (17) the “DISC” indicator of which
steadily lights up. The player will then start
playback of the selected CD, beginning
with the first track.
A1910BE-A-GSAAB.book Page 17 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com

5-18
Audio

Selecting a desired track (TRACK)
: Skipping forward: Skipping backward: Fast-forwarding: Fast-reversing
Skipping forward
Turn the “TRACK” knob (16) clockwise
and release it immediately to skip to the
beginning of the next track. Each time the
knob is turned and released, the indicated
track number will increase.
Skipping backward
Turn the “TRACK” knob (16) counter-
clockwise and release it immediately to
skip to the beginning of the current track.
If you continue to turn and release the
knob, the indicated track number will de-
crease.Fast-forwarding
Turn the “TRACK” knob (16) clockwise
and hold it continuously to fast-forward the
disc.
Release the knob to stop fast-forwarding.
Fast-reversing
Turn the “TRACK” knob (16) counter-
clockwise and hold it continuously to fast-
reverse the disc.
Release the knob to stop fast-reversing.

Repeat playback
Press the “RPT” button (11) while a song
is playing to play the song repeatedly. The
“RPT” indicator will come on and the song
will be played continuously. To cancel the
repeat mode, press the button again.
Then the “RPT” indicator goes out, and
normal playback mode is restored.

Random playback
Press the “RDM” button (12) while a disc
is being played back to play all songs on
the disc in a random order. The “RDM” in-
dicator will come on and all songs on the
disc will be played in a random order.
To cancel the random mode, press the
button again. Then the “RDM” indicator
goes out, and normal playback mode is
restored.
Scan
When the “SCAN” button (13) is pressed
while the disc is being played back, you
can hear the first 10 seconds of each track
to search for the desired program. To con-
tinue listening to the program, press the
“SCAN” button again. After all tracks on
the disc have been scanned, normal play-
back mode is restored.

How to unload CDs from the player
Ejecting a CD from the player
Of the discs loaded, you can select and re-
move only one disc.
1. Press the “Disc select” button (17) of
the disc whose “DISC” indicator is ON.
2. Press the “Eject” button (15). Then the
“DISC” indicator associated with the disc
you have selected will blink, and the disc
will be ejected.
To remove more discs in succession, re-
peat Steps 1 and 2.
Ejecting all discs from the player
(All disc ejection mode)
1. If you continue to press the “Eject” but-
ton (15), the player will produce a beeping
sound and will enter the all disc ejection
mode.
2. Remove the disc that has been eject-
ed. The other discs loaded will then be
ejected one after another. If you do not re-
500248
A1910BE-A-GSAAB.book Page 18 Tuesday, September 6, 2005 8:37 AM
ProCarManuals.com
