2006 PONTIAC SOLSTICE engine

Vehicle Damage Warnings
Also, in this manual you will nd these notices:
Notice:These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by your vehicle’s warranty, and it could be costly. But
the notice will tell what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors or in
different words.
There are also warning labels on the vehicle. They use
the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use symbols
instead of text. Symbols are shown along with the text
describing the operation or information relating to a
specic component, control, message, gage, or indicator.
If you need help guring out a specic name of a
component, gage, or indicator, reference the following
topics:
Seats and Restraint Systems in Section 1
Features and Controls in Section 2
Instrument Panel Overview in Section 3
Climate Controls in Section 3
Warning Lights, Gages, and Indicators in Section 3
Audio System(s) in Section 3
Engine Compartment Overview in Section 5
iv

Keys...............................................................2-2
Remote Keyless Entry System.........................2-3
Remote Keyless Entry System Operation...........2-4
Doors and Locks.............................................2-7
Manual Door Locks.........................................2-7
Power Door Locks..........................................2-7
Delayed Locking.............................................2-8
Automatic Door Lock.......................................2-8
Automatic Door Unlock....................................2-9
Trunk............................................................2-9
Windows........................................................2-11
Manual Windows..........................................2-12
Power Windows............................................2-12
Sun Visors...................................................2-12
Theft-Deterrent Systems..................................2-13
Content Theft-Deterrent.................................2-13
PASS-Key
®III+............................................2-14
PASS-Key®III+ Operation..............................2-15
Starting and Operating Your Vehicle................2-16
New Vehicle Break-In....................................2-16
Ignition Positions..........................................2-17
Retained Accessory Power (RAP)...................2-19
Starting the Engine.......................................2-19Automatic Transmission Operation...................2-20
Manual Transmission Operation......................2-23
Parking Brake..............................................2-24
Shifting Into Park (P)
(Automatic Transmission)............................2-25
Shifting Out of Park (P)
(Automatic Transmission)............................2-26
Parking Your Vehicle
(Manual Transmission)................................2-27
Parking Over Things That Burn.......................2-27
Engine Exhaust............................................2-28
Running the Engine While Parked...................2-28
Mirrors...........................................................2-29
Manual Rearview Mirror.................................2-29
Manual Rearview Mirror with OnStar
®................2-29
Outside Manual Mirror...................................2-30
Outside Power Mirrors...................................2-30
OnStar
®System.............................................2-30
Storage Areas................................................2-33
Glove Box...................................................2-33
Cupholder(s)................................................2-33
Center Console Storage Area.........................2-33
Convertible Top..............................................2-33
Section 2 Features and Controls
2-1

Automatic Door Unlock
If your vehicle has power door locks, the doors with
automatically unlock when the shift lever is moved into
PARK (P) for vehicles with an automatic transmission.
For vehicles with a manual transmission, the doors
will automatically unlock when the key is removed from
the ignition. The automatic unlock feature cannot be
disabled unless your vehicle has a Driver Information
Center (DIC) and an automatic transmission.
If your vehicle has a Driver Information Center (DIC),
it can be programmed to automatically unlock the doors
several ways for vehicles with an automatic transmission.
SeeDIC Vehicle Personalization on page 3-40for more
information.
Trunk
To release the trunk lid from the outside, use the
remote keyless entry (RKE) transmitter, if equipped.
If your vehicle does not have an RKE transmitter,
see “Remote Trunk Release” following.
{CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You cannot see or smell
CO. It can cause unconsciousness and even
death. If you must drive with the trunk lid open
or if electrical wiring or other cable connections
must pass through the seal between the body
and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select the
control setting that will force outside air
into your vehicle. See Climate Control
System.
If you have air outlets on or under the
instrument panel, open them all the way.
SeeEngine Exhaust on page 2-28.
2-9

This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
PASS-Key
®III+ uses a radio frequency transponder in
the key that matches a decoder in your vehicle.
PASS-Key®III+ Operation
Your vehicle is equipped with PASS-Key®III+
(Personalized Automotive Security System)
theft-deterrent system. PASS-Key
®III+ is a passive
theft-deterrent system. This means you do not have to do
anything special to arm or disarm the system. It works
when you insert or remove the key from the ignition.
When the PASS-Key
®III+ system senses that someone
is using the wrong key, it prevents the vehicle from
starting. Anyone using a trial-and-error method to start
the vehicle will be discouraged because of the high
number of electrical key codes.When trying to start the vehicle if the engine does not
start and the security light on the instrument panel cluster
comes on, the key may have a damaged transponder.
Turn the ignition off and try again.
If the engine still does not start, and the key appears to be
not damaged, try another ignition key. At this time, you
may also want to check the fuse, seeFuses and Circuit
Breakers on page 5-78. If the engine still does not start
with the other key, your vehicle needs service. If your
vehicle does start, the rst key may be faulty. See your
dealer who can service the PASS-Key
®III+ to have a
new key made. In an emergency, contact Roadside
Assistance. SeeRoadside Assistance Program on
page 7-6.
It is possible for the PASS-Key
®III+ decoder to “learn”
the transponder value of a new or replacement key.
Up to 10 keys may be programmed for the vehicle. The
following procedure is for programming additional keys
only. If all the currently programmed keys are lost or do
not operate, you must see your dealer or a locksmith who
can service PASS-Key
®III+ to have keys made and
programmed to the system.
See your dealer or a locksmith who can service
PASS-Key
®III+ to get a new key blank that is cut
exactly as the ignition key that operates the system.
2-15

To program the new key do the following:
1. Verify that the new key has a “+” with a circle
around it stamped on it.
2. Insert the already programmed key in the ignition
and start the engine. If the engine will not start,
see your dealer for service.
3. After the engine has started, turn the key to LOCK,
and remove the key.
4. Insert the key to be programmed and turn it to the
RUN position within ve seconds of the original key
being turned to the LOCK position.
5. The security light will turn off once the key has
been programmed.
6. Repeat Steps 1 through 5 if additional keys are to
be programmed.
If you are ever driving and the security light comes on
and stays on, you may be able to restart your engine if
you turn it off. Your PASS-Key
®III+ system, however,
is not working properly and must be serviced by
your dealer. Your vehicle is not protected by the
PASS-Key
®III+ system at this time.
If you lose or damage your PASS-Key
®III+ key,
see your dealer or a locksmith who can service
PASS-Key
®III+ to have a new key made.
Starting and Operating Your
Vehicle
New Vehicle Break-In
Notice:Your vehicle does not need an elaborate
break-in. But it will perform better in the long run if
you follow these guidelines for the rst 500 miles
(805 km):
Do not drive at any one constant speed, fast
or slow.
Do not exceed 70 mph (113 km/h).
Do not make full-throttle starts; also refrain from
using the full throttle while driving. Avoid
downshifting to brake, or slow, the vehicle.
If these break-in procedures are not followed,
the vehicle’s engine, axle, or other parts could
be damaged.
Avoid making hard stops for the rst 200 miles
(322 km) or so. During this time your new brake
linings are not yet broken in. Hard stops with new
linings can mean premature wear and earlier
replacement. Follow this breaking-in guideline
every time you get new brake linings.
Following break-in, engine speed and load can be
gradually increased.
2-16

Ignition Positions
With the key in the ignition switch, you can turn it to
four different positions.
Notice:Using a tool to force the key from the
ignition switch could cause damage or break the key.
Use the correct key and turn the key only with your
hand. Make sure the key is all the way in. If it is, turn
the steering wheel left and right while you turn the
key hard. If none of this works, then your vehicle
needs service.
9(LOCK):This position locks your steering column.
It is a theft-deterrent feature. You will only be able
to remove your key when the ignition is turned to LOCK.If you have an automatic transmission, the ignition switch
cannot be turned to LOCK unless the shift lever is in
PARK (P).
If you have a manual transmission, the ignition switch can
be turned to LOCK in any shift lever position.
{CAUTION:
If you have a manual transmission removing the
key from the ignition switch will lock the
steering column and result in a loss of ability to
steer the vehicle. This could cause a collision. If
you need to turn the engine off while the vehicle
is moving, turn the key to ACC.
ACC (ACCESSORY):This position operates some of
your electrical accessories. It unlocks the steering wheel
and ignition.
R(RUN):This is the position the switch returns to after
you start your engine and release the switch. The switch
stays in the RUN position when the engine is running. But
even when the ignition is not running, you can use RUN
to operate your electrical accessories and to display
some warning and indicator lights.
2-17

/(START):This position starts the engine. When the
engine starts, release the key. The ignition switch will
return to RUN for normal driving.
A warning tone will sound if you open the driver’s door
while in LOCK or ACC, when the key has not been
removed from the ignition.
Shift Lock Release
The following procedure allows the ignition to be turned
to LOCK and for ignition key removal in case of a dead
battery or low voltage battery.
1. Make sure the shift lever is in PARK (P).2. Using a tool, pry off the cover from the bottom of
the steering column.
3. Place your nger into the access hole and locate
the plunger.
4. Press and hold the plunger toward the driver’s door
while turning the ignition key to LOCK. Remove
the key.
Have your vehicle serviced at your GM dealer as soon
as possible.
2-18

Retained Accessory Power (RAP)
Your vehicle is equipped with a Retained Accessory
Power (RAP) feature which will allow the radio and
power windows to continue to work up to 10 minutes
after the ignition is turned off.
Your vehicle’s radio will work when the ignition key is in
RUN or ACC. Once the key is turned off, the radio, power
windows will continue to work for up to 10 minutes or until
any door is opened.
Starting the Engine
Automatic Transmission
Move your shift lever to PARK (P) or NEUTRAL (N). Your
engine will not start in any other position — that is a
safety feature. To restart when you are already moving,
use NEUTRAL (N) only.
Notice:Do not try to shift to PARK (P) if your
vehicle is moving. If you do, you could damage the
transmission. Shift to PARK (P) only when your
vehicle is stopped.
Manual Transmission
The shift lever should be in NEUTRAL and the parking
brake engaged. Hold the clutch pedal to the oor and
start the engine. Your vehicle will not start if the clutch
pedal is not all the way down — that is a safety feature.
Starting Procedure
1. With your foot off the accelerator pedal, turn your
ignition to START. When the engine starts, let go
of the key. The idle speed will go down as your
engine gets warm.
Notice:Holding your key in START for longer than
15 seconds at a time will cause your battery to be
drained much sooner. And the excessive heat can
damage your starter motor. Wait about 15 seconds
between each try to help avoid draining your battery
or damaging your starter.
2. If it does not start, wait about 15 seconds and try
again to start the engine by turning the ignition to
START. Wait about 15 seconds between each try.
When your engine has run about 10 seconds to
warm up, your vehicle is ready to be driven. Do not
run your engine at high speed when it is cold.
If the weather is below freezing (32°F or 0°C),
let the engine run for a few minutes to warm up.
2-19
