2006 NISSAN MURANO sunroof

1. Hood (Page 3-24)
2. Windshield wiper and washer switch
(P.2-20)/Wiper replacement (P.8-18)
3. Headlight and turn signal switch (P.2-22)/
Bulbreplacement (P.8-28)
4. Interior light (P.2-40)
5. Sunroof* (P.2-38)
6. Power windows (P.2-36)
7. Recovery hook (P.6-14)
8. Fog light switch* (P.2-27)/
Daytime running light (for Canada) (P.2-25)
9. Tires
— Wheel and tires (P.8-30, P.9-9)
— Flat tire (P.6-2)
10. Mirrors (P.3-30)
11. Doors
— Keys (P.3-2)
— Door locks (P.3-3)
— Remote keyless entry system (P.3-5)
(P.3-20)
— Intelligent Key* (P.3-9)
*: if so equipped
SSI0008
EXTERIOR FRONT0-2
Illustrated table of contents


05.8.26/Z50-D/V5.0


1. Seat belts (P.1-10)
2. Head restraints (P.1-8)
3. Supplemental curtain side-impact air bags
(P.1-39)
4. Power windows (P.2-36)
5. Interior lights (P.2-40)
6. Sunroof* (P.2-38)
7. Front passenger air bag status light (P.1-47)
8. Inside mirror (P.3-30)
— Automatic anti-glare inside mirror*
(P.3-31)
— HomeLink
Universal Transceiver*
(P.2-43)
9. Seats (P.1-2)
10. Supplemental side-impact air bags
(P.1-39)
11. Console box (P.2-34)
12. Continuously Variable Transmission (CVT)
selector lever (P.5-13)
*: if so equipped
SSI0168
PASSENGER COMPARTMENT0-4
Illustrated table of contents


05.8.26/Z50-D/V5.0


2 Instruments and controlsInstrument panel ..................................................................... 2-2
Meters and gauges ............................................................... 2-3
Speedometer and odometer ......................................... 2-4
Tachometer ........................................................................ 2-4
Engine coolant temperature gauge ............................. 2-5
Fuel gauge ......................................................................... 2-5
Compass display (if so equipped) .................................... 2-6
Warning/indicator lights and audible reminders ............ 2-9
Checking bulbs................................................................. 2-9
Warning lights ................................................................... 2-9
Indicator lights ................................................................ 2-14
Audible reminders.......................................................... 2-16
Security systems.................................................................. 2-17
Vehicle security system (if so equipped) ................ 2-17
NISSAN Vehicle Immobilizer System ....................... 2-18
Windshield wiper and washer switch ........................... 2-20
Rear window wiper and washer switch ....................... 2-21
Rear window and outside mirror defroster switch...... 2-22
Headlight and turn signal switch ................................... 2-22
Xenon headlights (if so equipped) .......................... 2-22
Headlight switch ........................................................... 2-23
Daytime running light system (Canada only) ........ 2-25
Instrument brightness control ..................................... 2-26
Turn signal switch ........................................................ 2-27Fog light switch (if so equipped) .............................. 2-27
Hazard warning flasher switch ......................................... 2-27
Horn ........................................................................................ 2-28
Heated seats (if so equipped) ......................................... 2-28
Vehicle dynamic control (VDC) off switch (if so
equipped) .............................................................................. 2-29
Power outlet.......................................................................... 2-30
Storage .................................................................................. 2-31
Coin box........................................................................... 2-31
Cellular phone holder ................................................... 2-31
Cup holders .................................................................... 2-32
Glove box ........................................................................ 2-33
Console box .................................................................... 2-34
Cargo net (if so equipped) ......................................... 2-35
Tonneau cover (if so equipped)................................. 2-36
Windows................................................................................ 2-36
Power windows.............................................................. 2-36
Sunroof (if so equipped) ................................................... 2-38
Automatic sunroof ......................................................... 2-38
Interior lights ......................................................................... 2-40
Ceiling light ..................................................................... 2-40
Map light .......................................................................... 2-41
Rear personal light ........................................................ 2-41
Luggage light .................................................................. 2-42


05.8.26/Z50-D/V5.0


Automatic operationTo fully open or close the driver’s or front
passenger’s side window, completely push
down
Aor pull up
Bthe switch and release it;
it need not be held. The window will automati-
cally open or close all the way. To stop the
window, just push or lift the switch on the
opposite side.
Auto reverse function (if so equipped)If the control unit detects something caught in a
front window as it moves up, the window will be
immediately lowered.
The auto reverse function can be activated whena front window is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the ACC, OFF or LOCK position. The
doors remain closed.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the window
occurs.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-
side the vehicle before closing the win-
dow.
AUTOMATIC SUNROOFThe sunroof will only operate when the ignition
switch is in the ON position.
The automatic sunroof is operational for about
45 seconds, even if the ignition switch is turned
to the ACC, OFF or LOCK position. If the
driver’s door or the front passenger’s door is
opened during this period of about 45 seconds,
power to the sunroof is canceled.Sliding the sunroofTo open the roof, slide the switch to the
side
1. When the roof is tilted up, it will
automatically tilt down and then open.
SIC1893E
SIC2062
SUNROOF (if so equipped)
2-38
Instruments and controls


05.8.26/Z50-D/V5.0


To close the roof, slide the switch to the
side
2.
Sliding position of lid can be chosen according
to sliding amount of switch.
To fully open or close the roof, completely move
the switch to the
1
or
2
side.
Tilting the sunroofTo tilt up, push the
side
3
of the tilt
switch. When the roof is open, it will automati-
cally close and then tilt up. To tilt down the
sunroof, push the
side
4. When the roof
is open, it will automatically close.
Restarting the sunroof sliding switchThe sliding switch will become inoperable after
the battery terminal is disconnected, the electri-
cal supply interrupted and/or some abnormality
detected. Use the following re-set procedure to
return sunroof operation to normal.
1. Keep pushing the tilting switch toward tilt UP.
2. After the lid has tilted up gradually, it will
automatically close all the way, then return to
normal operation.Auto reverse function (When closing
the sunroof)If the control unit detects something caught inthe sunroof as it moves to the front or tilts down,
the sunroof will immediately open backward or
tilt up.
The auto reverse function can be activated when
the sunroof is closed by automatic operation
when the ignition switch is in the ON position or
for about 45 seconds after the ignition switch is
turned to the ACC, OFF or LOCK position.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the sunroof
occurs.
If the auto reverse function malfunctions and
repeats opening or tilting up the sunroof, keep
pushing toward the close position or keep push-
ing the tilt down switch within 5 seconds after it
happens, then the sunroof will fully close gradu-
ally. In this case, make sure nothing is caught in
the sunroof.
WARNING
There are some small distances imme-
diately before the closed position which
cannot be detected. Make sure that all
passengers have their hands, etc., in-side the vehicle before closing the
sunroof.
Sun shadeOpen or close the sun shade by sliding it
backward or forward.
The shade will open automatically when the
sunroof is opened. However, it must be closed
manually.Comfortable position (
A)
Depending on the driving speed and air recircu-
lating conditions, wind noise may occur when
the sunroof is fully opened. Closing the sunroof
one step toward the front position
A
from full
open will decrease the wind noise.
WARNING

In an accident you could be thrown
from the vehicle through an open
sunroof. Always use seat belts and
child restraints.

Do not allow anyone to stand up or
extend any portion of their body out
Instruments and controls
2-39


05.8.26/Z50-D/V5.0


of the sunroof opening while the ve-
hicle is in motion or while the sun-
roof is closing.
CAUTION

Remove water drops, snow, ice or
sand from the sunroof before open-
ing.

Do not place any heavy object on the
sunroof or surrounding area.If the sunroof does not closeHave a NISSAN dealer check and repair the
sunroof.
CEILING LIGHTThe ceiling light has a three-position switch.
When the switch is in the ON position
1, the
light will illuminate.
When the switch is in the OFF position
2, the
light will turn off.
When the switch is in the DOOR position3,
the light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:

The doors are unlocked by the remote key-
less entry system, a key, power door lock
switch or using the Intelligent Key systemwhile all doors are closed.

The driver’s door is opened and then closed
while the key is removed from the ignition
switch or the ignition switch is turned to the
LOCK position (Intelligent Key system).

The key is removed from the ignition switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system) while all
doors are closed.
The ceiling light will turn off while the 30 second
timer is activated, when:

The driver’s door is locked by the remote
keyless entry system, a key or the power door
lock switch.

The ignition switch is turned ON.
When the ceiling light switch or map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear and
vanity mirror lights will automatically turn
off 30 minutes after the ignition switch has
been turned to the ACC or OFF position. To
turn on the light again, turn the ignition
switch to the ONposition.
After the above procedure, the ceiling, map, rear
personal and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operation
SIC2063
INTERIOR LIGHTS
2-40
Instruments and controls


05.8.26/Z50-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-31
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag
and status light .......................................................... 1-47
Air bag warning labels ............................................. 1-53
Air bag warning light .................................... 1-54, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-24
All-wheel drive (AWD) LOCK indicator light ..... 2-14
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Anchor point locations
Top tether strap .................................................. 1-30
Antenna ........................................................................ 4-44
Anti-lock Brake System (ABS) .............................. 5-31
Anti-lock Brake System (ABS) waring light ....... 2-10Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-38
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-34
Brake
Anti-lock brake system (ABS) ......................... 5-31
Brake booster ...................................................... 8-21Brake fluid............................................................. 8-13
Brake pedal check ............................................. 8-20
Brake system ....................................................... 5-30
Parking brake check .......................................... 8-20
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-23
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-27
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-44
Cargo (See vehicle loading information)............. 2-35
Cargo net .................................................................... 2-35
Cassette player (See audio system) .................... 4-40
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-42
Ceiling light ................................................................. 2-40
Cellular phone holder ............................................... 2-31
Charge warning light ................................................ 2-11
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-34
Installation on rear seat outboard or center
positions ................................................................ 1-23
LATCH system .................................................... 1-28


05.8.26/Z50-D/V5.0


Three-point type with retractor ....................... 1-14
Seat(s)
Driver-side memory ............................................ 3-33
Heated seats........................................................ 2-28
Seats ........................................................................ 1-2
Security indicator light ............................................. 2-15
Security system (NISSAN Vehicle Immobilizer
System), Engine start ............................................... 2-18
Security system, Vehicle security system ........... 2-17
Selector lever, Shift lock release ............... 5-15, 5-19
Servicing air conditioner .............................. 4-23, 4-26
Shift lock release, Transmission ................ 5-15, 5-19
Shifting, CVT (Continuously Variable
Transmission) ............................................................. 5-13
Shoulder belt height adjustment ........................... 1-16
Slip indicator light ..................................................... 2-15
Spark plugs................................................................. 8-16
Speedometer ................................................................ 2-4
Starting
Before starting the engine................................ 5-12
Jump starting .......................................................... 6-8
Precautions when starting and driving ............ 5-2
Push starting ........................................................ 6-10
Starting the engine............................................. 5-12
Status light, Front passenger air bag .................. 1-47
Steering
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Tilting steering wheel......................................... 3-28
Steering switch for audio control.......................... 4-43
Storage ........................................................................ 2-31
Sun shade ................................................................... 2-39
Sun visors ................................................................... 3-30
Sunroof ........................................................................ 2-38Automatic sunroof .............................................. 2-38
Supplemental air bag warning labels................... 1-53
Supplemental air bag warning light .......... 1-54, 2-13
Supplemental restraint system............................... 1-39
Precautions on supplemental restraint
system.................................................................... 1-39
Switch
Autolight switch .................................................. 2-23
AWD lock switch operations........................... 5-25
Fog light switch................................................... 2-27
Hazard warning flasher switch ........................ 2-27
Headlight aiming control ................................... 2-25
Headlight switch ................................................. 2-23
Power door lock switch....................................... 3-4
Rear window and outside mirror defroster
switch..................................................................... 2-22
Turn signal switch .............................................. 2-27
Vehicle dynamic control (VDC) off switch ... 2-29
T
Tachometer.................................................................... 2-4
Temperature gauge, Engine coolant
temperature gauge ...................................................... 2-5
Theft (NISSAN Vehicle Immobilizer System),
Engine start................................................................. 2-18
Three-way catalyst....................................................... 5-3
Tilting steering wheel ............................................... 3-28
Tire pressure, Low tire pressure warning light .. 2-12
Tires
Flat tire ..................................................................... 6-2
Low tire pressure warning system .................... 5-3
Spare tire (temporary use only (T-type)
spare tire) ............................................................. 8-41Tire and Loading information label ................. 8-32
Tire and Loading Information label................. 9-12
Tire chains ............................................................ 8-38
Tire dressing ........................................................... 7-3
Tire pressure ........................................................ 8-30
Tire pressure information (display)........ 4-6, 4-14
Tire pressure monitoring system
(TPMS)............................................................ 5-3, 6-2
Tire rotation .......................................................... 8-39
Types of tires ....................................................... 8-37
Uniform tire quality grading .............................. 9-24
Wheel/tire size ....................................................... 9-9
Wheels and tires ................................................ 8-30
Tonneau cover ........................................................... 2-36
Top tether strap child restraints ............................ 1-29
Towing
Flat towing ............................................................ 9-23
Tow truck towing ................................................ 6-12
Towing a trailer.................................................... 9-18
Towing load/specification chart ...................... 9-18
Towing safety....................................................... 9-20
Towing load/specification chart............................. 9-20
TPMS, Tire pressure monitoring system................ 5-3
TPMS, Tire pressure warning system..................... 6-2
Trailer towing .............................................................. 9-18
Transceiver, HomeLink
Universal
Transceiver .................................................................. 2-43
Transmission
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
Transmission selector lever lock
release ....................................................... 5-15, 5-19
Transmitter, With Intelligent Key system
(See Intelligent Key system) ................................... 3-20


05.8.26/Z50-D/V5.0

10-6
