The HomeLink
Universal Transceiver provides a
convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.
HomeLink
Universal Transceiver:

Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.

Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink
will retain all program-
ming.
Once the HomeLinkUniversal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink
Universal Transceiver buttons
should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink
” later in this sec-
tion.
WARNING

Do not use the HomeLink
Universal
Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-
dards became effective for opener
models manufactured after April 1,
1982). A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.

During programming procedure, your
garage door or security gate may
open or close. Make sure that people
and objects are clear of the garage
door, gate, etc. that you are program-
ming.

Your vehicle’s engine should be
turned off while programming theHomeLink
Universal Transceiver.
HomeLink
UNIVERSAL
TRANSCEIVER (if so equipped)
Instruments and controls
2-43


05.8.26/Z50-D/V5.0


3 Pre-driving checks and adjustmentsKeys ........................................................................................... 3-2
NISSAN Vehicle Immobilizer System (NVIS)
keys ...................................................................................... 3-2
Doors......................................................................................... 3-3
Locking with key ............................................................... 3-3
Locking with inside lock knob...................................... 3-4
Locking with power door lock switch ......................... 3-4
Child safety rear door lock ............................................ 3-5
Remote keyless entry system (models without
Intelligent Key system) .......................................................... 3-5
How to use remote keyless entry system.................. 3-6
Intelligent Key system (if so equipped) ............................ 3-9
Door locks/unlocks precaution ................................. 3-11
Intelligent Key operation .............................................. 3-12
Operating the engine.................................................... 3-13
Intelligent Key operating range ................................. 3-15
Warning signals ............................................................. 3-17
Trouble-shooting guide ................................................ 3-19
Operation with intelligent remote keyless entry
system .............................................................................. 3-20Operation with the mechanical key and valet
key ..................................................................................... 3-23
Hood ....................................................................................... 3-24
Lift gate .................................................................................. 3-24
Fuel-filler door ...................................................................... 3-26
Open the fuel-filler door .............................................. 3-26
Fuel-filler cap .................................................................. 3-27
Steering wheel ..................................................................... 3-28
Tilt operation ................................................................... 3-28
Pedal position adjustment (if so equipped).................. 3-29
Sun visors.............................................................................. 3-30
Mirrors .................................................................................... 3-30
Inside mirror .................................................................... 3-30
Automatic anti-glare inside mirror (if so
equipped)......................................................................... 3-31
Outside mirrors .............................................................. 3-32
Automatic drive positioner (if so equipped) ................. 3-33
Entry/exit function .......................................................... 3-33
Memory storage ............................................................. 3-33
System operation ........................................................... 3-34


05.8.26/Z50-D/V5.0


The Intelligent Key uses coded radio signals to
communicate with the vehicle. When the Intelli-
gent Key is near the vehicle, such as when
standing near the vehicle with the Intelligent Key
in your pocket or purse, it allows the vehicle to
be locked or unlocked. And, when you are inside
the vehicle while carrying the Intelligent Key with
you, it allows the engine to be started without
inserting the key to the ignition switch. It is also
possible to use the remote keyless entry func-
tion.
CAUTION

Be sure to carry the Intelligent Key
with you.

Do not leave the vehicle with the
Intelligent Key inside.

The Intelligent Key may not function
correctly depending on the environment
or operating conditions. It could also
malfunction if you do not use it cor-
rectly.

The Intelligent Key transmits faint radio
waves.
In the following situations, the Intelli-
gent Key and remote keyless entry func-tions may not operate correctly, and you
may have to use the metal key (me-
chanical key or valet key):
•when there are strong signals com-
ing from a television tower, power
station or broadcasting station.
•when you have wireless equipment
or a cellular phone with you.
•when the Intelligent Key is in contact
with or covered by a metallic mate-
rial.
•when radio wave-type remote control
entry is used nearby.
•when the Intelligent Key is placed
near an electric appliance such as a
personal computer.

The Intelligent Key continually con-
sumes battery power as the key receives
a signal to communicate with the ve-
hicle. Battery life of the Intelligent Key is
about 2 years, although it varies de-
pending on the operating conditions.
When the battery of the Intelligent Key
is low, the green blinking key warning
light goes out about 30 seconds after
the ignition switch is turned to ON. If the
battery runs down, replace it with a new
one.
If the Intelligent Key receives strong
signal over an extended period of time,
the battery of the Intelligent Key could
quickly run down. Do not place the In-
telligent Key near an electric appliance
such as a television set or personal
computer.

Because the ignition switch is electroni-
cally controlled, if the vehicle battery is
completely discharged when the igni-
tion switch is in the LOCK position, the
steering lock cannot be released or the
ignition switch cannot be turned (not by
the mechanical key either).

In case the vehicle battery is completely
discharged, make sure to recharge the
vehicle battery immediately.INTELLIGENT KEY SYSTEM (if so
equipped)
Pre-driving checks and adjustments
3-9


05.8.26/Z50-D/V5.0


the vehicle, doors can be locked with an-
other Intelligent Key.
Unlocking doors and fuel-filler door1. Push the door handle request switch or lift
gate request switch once.
Driver’s side:

The driver door and fuel-filler door unlock.
Front passenger side or lift gate:

Only corresponding door unlocks.
2. The hazard indicator flashes once and out-
side buzzer sounds once if all doors are
completely closed with the ignition key in any
position except the ON position.
3. Push the door handle request switch or lift
gate request switch again within 5 seconds.

All doors and the fuel-filler door unlock.

The hazard indicator flashes once and out-
side buzzer sounds once if all doors are
completely closed.
All doors will be locked automatically after push-
ing the door handle request switch or lift gate
request switch unless one of the following op-
erations is performed within 1 minute.

any door is opened
the ignition switch is pushed

the mechanical key or the valet key is inserted
into the ignition switch
Re-lock time can be adjusted or cancelled with
the vehicle electronic systems on the monitor
(see “4. Display screen, heater, air conditioner
and audio systems”).
The room light will come on for 30 seconds
when the door is unlocked using the request
switch.
The room light can be turned off without waiting
for 30 seconds by turning the ignition switch to
the ON position or by locking the doors.
OPERATING THE ENGINE
Ignition switch positionsPush in the ignition switch in the range (
A
to
B) when you turn it.
LOCK (Normal parking position)
A:
The ignition switch can only be locked in the
A
position.
The ignition switch will be unlocked when it is
pushed in, and turned to the ACC position
C
while carrying the Intelligent Key.
SSD0417
Pre-driving checks and adjustments
3-13


05.8.26/Z50-D/V5.0


ACC (Accessories)
C:
This position activates electrical accessories
such as the radio, when the engine is not
running.
ON(Normal operating position)
D:
This position turns on the ignition system and
electrical accessories.
START
E:
This position starts the engine. As soon as the
engine has started, release the switch immedi-
ately. It will automatically return to the ON posi-
tion.
For important safety information, see “Ignition
switch” in the “5. Starting and driving” section.
The ignition switch cannot be turned back to the
LOCK position unless the selector lever is in P
position. (It can be turned to only
B.) If the
ignition switch cannot be turned back to the
LOCK position after shifting the selector lever to
the P position, turn the ignition switch to the
ACC position once and turn back to the LOCK
position.
CAUTION
Do not leave the vehicle with the igni-
tion switch in ACC or ONpositions when
the engine is not running for an ex-
tended period. This can discharge the
battery.
Starting the engineWhen driving the vehicle, be sure to carry the
Intelligent Key with you.
1. Securely depress the brake pedal.
2. Slowly push the ignition switch in.
When the Intelligent Key warning light
A
in
the instrument panel comes on in green, the
ignition switch can be turned.
3. Turn the ignition switch to the START posi-
tion and the engine will be started.
4. When the engine starts, release the ignition
switch.
SPA2174
3-14
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


WARNING
Do not start the engine from outside the
vehicle through the window. Doing so
could lead to an accident and injury. Be
sure to sit in the driver’s seat to use the
key.
For important safety information, see “Starting
the engine” in the “5. Starting and driving”
section.

When the ignition switch is pushed under the
following conditions, the key warning light in
the instrument panel comes on in red. It is not
possible to turn the ignition switch when:
•you do not have the Intelligent Key with
you
•the Intelligent Key battery has run down
•you have a Intelligent Key for another
vehicle with you

Slowly turn the ignition switch after the key
warning light comes on in green. If it is turned
quickly, it may stick and be difficult to turn.

The engine may not start if the Intelligent Key
is placed:•inside the glove box or the door pocket
•on the instrument panel
•in the corner of interior compartment.

If it is difficult to turn the ignition switch,
perform the following:
•Push the ignition switch again and slowly
turn it left and to the right.
•Turn the ignition switch while gently turn-
ing the steering wheel to the left or right.
Stopping the engine1. Shift the selector lever to the P position.
2. Turn the ignition switch to the ACC position.
WARNING
When you leave the vehicle, be sure to
observe the following:

Shift the selector lever to P. (In other
positions, the ignition switch will not
return to LOCK.)

Securely return the ignition switch to
LOCK.

Set the parking brake. Failure to do
so could result in unexpected vehicle
movement and could lead to severe
injury.INTELLIGENT KEY OPERATING
RANGEThe Intelligent Key functions can be used only
when you carry the key with you and operate as
specified in the operating range inside or outside
the vehicle.
When the Intelligent Key battery runs down or
where there are strong radio waves or noise, the
operating range may be narrower or the key may
be inoperative.Pre-driving checks and adjustments
3-15


05.8.26/Z50-D/V5.0


Operating range of the door lock/
unlock functionThe operating range of the door lock/unlock
function by pushing the door handle requestswitch or the lift gate request switch is shown in
the illustration.
131.5 in (0.8 m) from the door handle request
switch
231.5 in (0.8 m) from the lift gate request
switch

If you are too close to the door or door glass,
the Intelligent Key may not operate.

If the Intelligent Key is in the operating range,
it is possible for anyone who does not carry
the Intelligent Key to lock/unlock the doors by
pushing the door handle request switch or
the lift gate request switch.
Operating range for engine start
functionThe operating range for starting the engine is
inside the vehicle.

If the Intelligent Key is on the instrument
panel, inside the glove box or door pocket, or
the corner of interior compartment, it may not
be possible to start the engine.

If the Intelligent Key is near the door or door
glass outside the vehicle, it may be possible
to start the engine.
SPA1948
SPA1949
3-16
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


WARNING SIGNALSTo help prevent the vehicle from moving unex-
pectedly by erroneous operation of the Intelli-
gent Key or to help prevent the vehicle from
being stolen, a chime or buzzer sounds from
inside and outside the vehicle and a warning
light comes on in the instrument panel.
When a chime or beep sounds or the warning
light comes on, be sure to check the vehicle and
Intelligent Key.Audible reminder and warning when
locking the doorsWhen the chime or buzzer sounds from inside
and outside the vehicle, check for the following:

The ignition switch is turned to the LOCK
position.

The Intelligent Key is not left inside the
vehicle.

Doors are closed securely.

The selector lever is in the P position.
Audible reminder and warning when
the engine stopsWhen the P position selecting warning light
B
in the instrument panel blinks in red:

Make sure the selector lever is in the P
position.
When the chime sounds intermittently:

Make sure the selector lever is in the P
position and the ignition switch is turned to
the LOCK position.
If the chime sounds continuously when the
driver’s door is opened, check the following:
The selector lever is in the P position and the
ignition switch is turned to the LOCK posi-
tion.

The mechanical key or the valet key is not
inserted into the ignition switch.

The warning chime may stop when one of the
following is performed.
•Returning the ignition switch to the LOCK
position.
•Removing the mechanical key or the valet
key.
•Closing the doors.
Alarm and warning when the engine
startsWhen the key warning light
A
is blinking in red
and the outside buzzer sounds, make sure the
Intelligent Key is inside the vehicle.
Warning for low battery power
This warning is to let you know that the
battery of the Intelligent Key will run down
soon. Replace it with a new one. Refer to the
“8. Maintenance and do-it-yourself” section
for battery replacement.
•The green blinking key warning light
A
goes out about 30 seconds after the
SPA2175
Pre-driving checks and adjustments
3-17


05.8.26/Z50-D/V5.0
