2006 NISSAN MURANO air condition

TIRE AND LOADING INFORMATION
LABELThe cold tire pressure is shown on the Tire and
Loading Information label affixed to the driver’s
door center pillar.
AIR CONDITIONER SPECIFICATION
LABELThe air conditioner specification label is affixed
inside of the hood as shown.
STI0373
STI0339
9-12
Technical and consumer information


05.8.26/Z50-D/V5.0


WARNING

Properly secure all cargo with
ropes or straps to help prevent
it from sliding or shifting. Do
not place cargo higher than the
seatbacks. In a sudden stop or
collision, unsecured cargo
could cause personal injury.

Do not load your vehicle any
heavier than the GVWR or the
maximum front and rear
GAWRs. If you do, parts of your
vehicle can break, tire damage
could occur, or it can change
the way your vehicle handles.
This could result in loss of con-
trol and cause personal injury.

Overloading not only can
shorten the life of your vehicle
and the tire, but can also cause
unsafe vehicle handling and
longer braking distances. Thismay cause a premature tire fail-
ure which could result in a seri-
ous accident and personal in-
jury. Failures caused by
overloading are not covered by
the vehicle’s warranty.
PAYLOAD WEIGHT CAPACITYThe payload weight capacity is the maxi-
mum total weight of passengers, optional
equipment (air conditioning, trailer hitch,
etc.) and cargo that your vehicle is de-
signed to carry.
Before driving a loaded vehicle, confirm
that you do not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR) for your
vehicle. See “Vehicle loading informa-
tion” earlier in this section for details.
Also check tires for proper inflation pres-
sures. See the tire and loading informa-
tion label affixed to the driver’s door
center pillar.
Payload Weight Capacity Unit: lb(kg)
VQ35DE
2WD AWD
US1,050
(475)1,055
(480)
Canada1,070
(485)1,070
(485)MEASUREMENT OF WEIGHTSSecure loose items to prevent weight
shifts that could affect the balance of
your vehicle. When the vehicle is loaded,
drive to a scale and weigh the front and
the rear wheels separately to determine
axle loads. Individual axle loads should
not exceed either of the gross axle weight
ratings (GAWR). The total of the axle
loads should not exceed the gross ve-
hicle weight rating (GVWR). These rat-
ings are given on the vehicle certification
label. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.Technical and consumer information
9-17


05.8.26/Z50-D/V5.0


the proper equipment and to have it
installed.
Trailer lights should comply with federal and/or
local regulations. For assistance in hooking up
trailer lights, contact a NISSAN dealer or repu-
table trailer dealer.Trailer brakesIf your trailer is equipped with a braking system,
make sure it conforms to federal and/or local
regulations and that it is properly installed.
WARNING
Never connect a trailer brake system
directly to the vehicle brake system.Pre-towing tips
Be certain your vehicle maintains a level
position when a loaded and/or unloaded
trailer is hitched. Do not drive the vehicle if it
has an abnormal nose-up or nose-down con-
dition; check for improper tongue load, over-
load, worn suspension or other possible
causes of either condition.
Always secure items in the trailer to prevent
load shifts while driving.

Load the trailer so approximately 60% of the
trailer load is in the front half and 40% is in
the back half.

Check your hitch, trailer tire pressure, vehicle
tire pressure, trailer light operation, and trailer
wheel lug nuts every time you attach a trailer
to the vehicle.

Be certain your rear view mirrors conform to
all federal, state or local regulations. If not,
install any mirrors required for towing before
driving the vehicle.
Trailer towing tipsIn order to gain skill and an understanding of the
vehicle’s behavior, you should practice turning,
stopping and backing up in an area which is free
from traffic. Steering stability, and braking per-
formance will be somewhat different than under
normal driving conditions.

Always secure items in the trailer to prevent
load shift while driving.

Avoid abrupt starts, acceleration or stops.

Avoid sharp turns or lane changes.

Always drive your vehicle at a moderate
speed. Some states or provinces have spe-cific speed limits for vehicles that are towing
trailers. Obey the local speed limits.

When backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small corrections and back
up slowly. If possible, have someone guide
you when you are backing up.

Always block the wheels on both vehicle and
trailer when parking. Parking on a slope is not
recommended; however, if you must do so,
first block the wheels and apply the parking
brake, and then move the selector lever into
the P (Park) position. If you move the selector
lever to the P (Park) position before blocking
the wheels and applying the parking brake,
transmission damage could occur.

When going down a hill, shift into a lower
gear and use the engine braking effect.
When going up a long grade, downshift the
transmission to a lower gear and reduce
speed to reduce chances of engine overload-
ing and/or overheating.

If the engine coolant rises to an extremely
high temperature when the air conditioning
system is on, turn off the air conditioner.
Coolant heat can be additionally vented by
opening the windows, switching the fan con-
trol to high and setting the temperature con-
9-22
Technical and consumer information


05.8.26/Z50-D/V5.0


WARNING
A vehicle equipped with AWD (All-
Wheel Drive) should never be tested
using a two wheel dynamometer, similar
to the dynamometers used by some
states for emissions testing, or similar
equipment. Make sure you inform the
test facility personnel that your vehicle
is an AWD equipped vehicle before it is
placed on a dynamometer. Failure to do
so may result in transmission damage
or unexpected vehicle movement which
could result in serious vehicle damage
or personal injury.
Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired orthe battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, check the vehicle’s inspection/
maintenance test readiness condition. Turn the
ignition switch ON without starting the engine. If
the Malfunction Indicator Lamp (MIL) comes on
steady for 20 seconds and then blinks for 10
seconds, the I/M test condition is “not ready”. If
the MIL does not blink after 20 seconds, the I/M
test condition is “ready”. If the MIL indicates the
vehicle is in a “not ready” condition, drive the
vehicle through the following pattern to set the
vehicle to the ready condition. If you cannot or
do not want to perform the driving pattern, a
NISSAN dealer can conduct it for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedalcompletely and keep it released for at least
10 seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 9
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 10 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the transmission se-
lector lever in the “P” or “N” position.
9. Turn the engine off.
10. Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.
READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)9-26
Technical and consumer information


05.8.26/Z50-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-31
Adjusting pedal position .......................................... 3-29
Aiming control, Headlights...................................... 2-25
Air bag system, Front passenger air bag
and status light .......................................................... 1-47
Air bag warning labels ............................................. 1-53
Air bag warning light .................................... 1-54, 2-13
Air cleaner housing filter.......................................... 8-17
Air conditioner
Air conditioner operation .................................. 4-23
Air conditioner service ........................... 4-23, 4-26
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant
and lubricant recommendations ............ 4-26, 9-6
Heater and air conditioner (automatic) ......... 4-23
In-cabin microfilter .............................................. 4-26
Alcohol, drugs and driving......................................... 5-6
All-wheel drive (AWD) ............................................. 5-24
All-wheel drive (AWD) LOCK indicator light ..... 2-14
All-wheel drive (AWD) warning light ...................... 2-9
All-wheel drive (AWD), AWD lock switch
operations.................................................................... 5-25
Anchor point locations
Top tether strap .................................................. 1-30
Antenna ........................................................................ 4-44
Anti-lock Brake System (ABS) .............................. 5-31
Anti-lock Brake System (ABS) waring light ....... 2-10Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Armrest ........................................................................... 1-9
Audible reminders ..................................................... 2-16
Audio operation precautions .................................. 4-28
Audio system .............................................................. 4-27
Autolight system ........................................................ 2-23
Automatic
Anti-glare inside mirror ...................................... 3-31
Automatic sunroof .............................................. 2-38
Drive positioner ................................................... 3-33
Seat positioner .................................................... 3-33
Avoiding collision and rollover .................................. 5-5
B
Back door (See lift gate)......................................... 3-24
Battery .......................................................................... 8-14
Battery saver system ......................................... 2-25
Battery replacement
Intelligent Key system .......................................... 3-8
Remote keyless entry system............................. 3-8
Before starting the engine ...................................... 5-12
Belts (See drive belts) ............................................. 8-16
Booster seats ............................................................. 1-34
Brake
Anti-lock brake system (ABS) ......................... 5-31
Brake booster ...................................................... 8-21Brake fluid............................................................. 8-13
Brake pedal check ............................................. 8-20
Brake system ....................................................... 5-30
Parking brake check .......................................... 8-20
Parking brake operation .................................... 5-21
Warning light ....................................................... 2-10
Break-in schedule ..................................................... 5-23
Brightness control, Instrument panel ................... 2-26
Bulbcheck/instrument panel .................................... 2-9
Bulbreplacement ...................................................... 8-27
C
Cabin air filter ............................................................. 4-26
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-44
Cargo (See vehicle loading information)............. 2-35
Cargo net .................................................................... 2-35
Cassette player (See audio system) .................... 4-40
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-42
Ceiling light ................................................................. 2-40
Cellular phone holder ............................................... 2-31
Charge warning light ................................................ 2-11
Child restraints ........................................................... 1-21
Booster seats ...................................................... 1-34
Installation on rear seat outboard or center
positions ................................................................ 1-23
LATCH system .................................................... 1-28


05.8.26/Z50-D/V5.0


Precautions on child restraints........................ 1-21
Top tether strap .................................................. 1-29
Top tether strap anchor point locations ....... 1-30
Child safety ................................................................. 1-12
Child safety rear door lock ........................................ 3-5
Chimes
Audible reminders............................................... 2-16
Seat belt warning light and chime ................. 2-13
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ......................................................... 4-4, 4-9, 4-18
Coin box ...................................................................... 2-31
Cold weather driving ................................................ 5-34
Compact Disc (CD) changer (See audio
system) ......................................................................... 4-41
Compact Disc (CD) player (See audio
system) ......................................................................... 4-35
Compass display ......................................................... 2-6
Console box................................................................ 2-34
Continuously Variable Transmission (CVT)
indicator light .............................................................. 2-14
Control panel buttons (models with navigation
system) ......................................................................... 4-11
Control panel buttons (models without
navigation system) ....................................................... 4-2
Controls
Control panel buttons (display with
navigation system) .............................................. 4-11
Control panel buttons (display without
navigation system) ................................................ 4-2
Heater and air conditioner controls
(automatic)............................................................ 4-23
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cover, Tonneau cover .............................................. 2-36
Cruise control............................................................. 5-21
Cruise main switch indicator light......................... 2-14
Cruise set indicator light ......................................... 2-14
Cup holders ................................................................ 2-32
CVT fluid...................................................................... 8-12
CVT, Driving with CVT (Continuously Variable
Transmission) ............................................................. 5-13
D
Daytime running light system ................................. 2-25
Defroster switch, Rear window and outside
mirror defroster switch ............................................. 2-22
Dimensions and weights ............................................ 9-9
Display controls (See control panel buttons),
With navigation system............................................ 4-11
Display controls (See control panel buttons),
Without navigation system ........................................ 4-2
Door open warning light .......................................... 2-11
Drive belts ................................................................... 8-16
Drive positioner .......................................................... 3-33
Driving
All-wheel drive (AWD) ...................................... 5-24
Cold weather driving ......................................... 5-34
Driving with CVT (Continuously Variable
Transmission) ....................................................... 5-13
On-pavement and offroad driving ..................... 5-6
Precautions when starting and driving ............ 5-2
Safety precautions ................................................ 5-6E
Economy, Fuel............................................................ 5-24
Emergency unlock lever........................................... 3-25
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-25
Engine
Before starting the engine................................ 5-12
Break-in schedule............................................... 5-23
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil ........................................... 8-10
Changing engine oil filter ................................. 8-11
Checking engine coolant level........................... 8-8
Checking engine oil level .................................... 8-9
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-36
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil................................................................. 8-9
Engine oil and oil filter recommendation......... 9-5
Engine oil pressure warning light ................... 2-11
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ................................... 6-11
Starting the engine............................................. 5-12
Entry/exit function, Automatic drive
positioner ..................................................................... 3-33
Event data recorders ................................................ 9-27
Exhaust gas (Carbon monoxide).............................. 5-2


05.8.26/Z50-D/V5.0

10-2

F
F.M.V.S.S. certification label................................... 9-11
Filter
Air cleaner housing filter ................................... 8-17
Changing engine oil filter ................................. 8-11
Flashers (See hazard warning flasher switch) ... 2-27
Flat tire............................................................................ 6-2
Flat towing .................................................................. 9-23
Floor mat cleaning ....................................................... 7-4
Fluid
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
CVT fluid ............................................................... 8-12
Engine coolant ....................................................... 8-8
Engine oil................................................................. 8-9
Power steering fluid ........................................... 8-12
Window washer fluid ......................................... 8-14
FM-AM-SAT radio with cassette player and
CD player .................................................................... 4-37
FM-AM-SAT radio with CD player ....................... 4-33
Fog light switch ......................................................... 2-27
Front manual seat adjustment .................................. 1-3
Front passenger air bag and status light ............ 1-47
Front power seat adjustment .................................... 1-4
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Fuel economy ...................................................... 5-24
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Fuel-filler cap ....................................................... 3-26
Fuel-filler door...................................................... 3-26Gauge ...................................................................... 2-5
Fuses ............................................................................ 8-21
Fusible links ................................................................ 8-23
G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-43
Gas cap ....................................................................... 3-26
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Fuel gauge .............................................................. 2-5
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-4
General maintenance .................................................. 8-2
Glove box .................................................................... 2-33
H
Hazard indicator light ............................................... 2-16
Hazard warning flasher switch............................... 2-27
Head restraints ............................................................. 1-8
Headlights
Aiming control ..................................................... 2-25
Bulbreplacement ............................................... 8-28
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-28
Heater
Engine block heater ........................................... 5-36
Heater and air conditioner (automatic) ......... 4-23
High beam indicator light ........................................ 2-14HomeLink
Universal Transceiver ......................... 2-43
Hood release .............................................................. 3-24
Horn .............................................................................. 2-28
I
Ignition knob(Intelligent Key system) .................. 3-13
Ignition switch
Except for Intelligent Key equipped
model ...................................................................... 5-9
Intelligent Key System equipped model ...... 5-10
Ignition switch key positions ..................................... 5-9
Immobilizer system .................................................... 2-18
In-cabin microfilter .................................................... 4-26
Indicator light ................................................................ 2-9
All-wheel drive (AWD) LOCK indicator
light......................................................................... 2-14
Continuously Variable Transmission (CVT)
indicator light ....................................................... 2-14
Cruise main switch indicator light .................. 2-14
Cruise set indicator light .................................. 2-14
Front passenger air bag status indicator
light......................................................................... 2-14
High beam indicator light ................................. 2-14
Malfunction indicator light ................................ 2-14
Security indicator light....................................... 2-15
Slip indicator light............................................... 2-15
Turn signal/hazard indicator light ................... 2-16
Vehicle dynamic control (VDC) off indicator
light......................................................................... 2-16
Inside
Automatic anti-glare mirror............................... 3-31
Mirror...................................................................... 3-30
Inspection/maintenance (I/M) test ........................ 9-26


05.8.26/Z50-D/V5.0

10-3

Instrument brightness control ................................ 2-26
Instrument panel........................................................... 2-2
Intelligent Key system
Engine starting .................................................... 3-13
Key operating range........................................... 3-15
Key operation....................................................... 3-12
Mechanical key and valet key .......................... 3-23
Operating the engine......................................... 3-13
Remote keyless operation ................................ 3-20
Trouble-shooting guide ..................................... 3-19
Warning light ....................................................... 2-11
Warning signals .................................................. 3-17
Intelligent key warning light .................................... 2-11
Interior light replacement......................................... 8-29
Interior lights ............................................................... 2-40
ISOFIX child restraint ............................................... 1-28
J
Jump starting................................................................. 6-8
K
Keyless entry
With Intelligent Key system (See Intelligent
Key system) .......................................................... 3-20
Without Intelligent Key system (See remote
keyless entry system) ........................................... 3-5
Keys................................................................................. 3-2
Keys, For Intelligent Key system .............................. 3-9L
Labels
Air bag warning labels ...................................... 1-53
Air conditioner specification label .................. 9-12
Emission control information label ................. 9-11
Engine serial number ......................................... 9-11
F.M.V.S.S. certification label ............................ 9-11
Tire and Loading Information label ..... 8-32, 9-12
Vehicle identification number (VIN)................ 9-10
LATCH system ........................................................... 1-28
License plate, Installing front license plate......... 9-13
Lift gate ........................................................................ 3-24
Light
Bulbreplacement ............................................... 8-27
Ceiling light .......................................................... 2-40
Fog light switch................................................... 2-27
Headlight switch ................................................. 2-23
Headlights bulb replacement........................... 8-28
Indicator lights ..................................................... 2-14
Interior lights ........................................................ 2-40
Luggage light ....................................................... 2-42
Map light ............................................................... 2-41
Rear personal light ............................................. 2-41
Replacement ........................................................ 8-27
Vanity mirror light ................................................ 2-42
Warning/indicator lights and audible
reminders................................................................. 2-9
Xenon headlights ................................................ 2-22
Lights, Exterior and interior light replacement ... 8-29
Loading information (See vehicle loading
information) ................................................................. 9-14
Lock
Door locks ............................................................... 3-3Glove box lock..................................................... 2-33
Lift gate lock ........................................................ 3-24
Power door lock .................................................... 3-3
Low fuel warning light .............................................. 2-12
Low tire pressure warning light ............................. 2-12
Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) ..................... 5-3
Low washer fluid warning light .............................. 2-13
Luggage light ............................................................. 2-42
M
Maintenance
Battery ................................................................... 8-14
General maintenance ........................................... 8-2
Inside the vehicle................................................... 8-3
Maintenance precautions .................................... 8-5
Maintenance requirements.................................. 8-2
Outside the vehicle............................................... 8-2
Seat belt maintenance ...................................... 1-20
Under the hood and vehicle ............................... 8-4
Malfunction indicator lamp (MIL) ........................... 2-14
Manual front seat adjustment ................................... 1-3
Map light...................................................................... 2-41
Meters and gauges ..................................................... 2-3
Mirror
Automatic anti-glare inside mirror .................. 3-31
Inside mirror ......................................................... 3-30
Outside mirrors ................................................... 3-32
N
Net, Cargo net ........................................................... 2-35


05.8.26/Z50-D/V5.0

10-4
