2006 Nissan Towing Guide 24

















Passenger Vehicles – The towing capacity for Altima, Maxima, Sentra, and 350Z (Coupe
only) is 1,000 lbs.; the maximum trailer tongue load is 100 lbs.
NOTE – For passenger vehicles, the trailer tongue load must be subtracted from the
GVWR as shown on the F.M.V.S.S. certification label located in the driver’s-side door area.

Other Recommendations and Information – Towing performance and speed are affected
by vehicle payload, tow weight, road grades, and weather conditions, including high
temperatures. See your owner’s manual for details.
2006 XTERRA TOWING DATA
Engine Type 4.0L V6
Transmission A/T
Model(s) 4x2 & 4x4
Maximum Trailer Weight1 (lbs.) 5,000
Maximum Trailer Tongue Load (lbs.) 500
Gross Combined Weight Rating (lbs.) 9,658
1 Maximum Trailer Weight values are calculated assuming a base vehicle with driver and any options
required to achieve the rating. Additional passengers, cargo and/or optional equipment will add
weight to the vehicle and reduce your vehicle’s maximum towing capacity and trailer tongue load.
2 The Maximum Trailer Weight when using the Genuine Nissan step bumper in this application as a ball
mount is 5,000 lbs.; the Maximum Trailer Tongue Load is 500 lbs.
3 The Maximum Trailer Weight when using the Genuine Nissan step bumper in this application as a ball
mount is 3,500 lbs.; the Maximum Trailer Tongue Load is 350 lbs.
4 The vehicle optional tow package does not include a trailer hitch ball mount. Two ball mount options
are available through your Nissan dealer:
Š Class III hitch ball mount for trailers with a Maximum Trailer Weight of 5,000 lbs. or less.
NOTE – A hitch ball is not included with the Class III ball mount. This ball mount can be
used with any hitch ball with a shank diameter of 1” or larger.
Š Class IV Weight-Distributing hitch ball mount is STRONGLY RECOMMENDED when towing
trailers with a Maximum Trailer Weight greater than 5,000 lbs., and can also be used with
trailers under 5,000 lbs. Maximum Trailer Weight.

NOTE – The Class IV ball mount includes a 2 5/16” hitch ball rated for 10,000 lbs. Smaller
hitch ball sizes may be used by following the instructions included in the ball mount kit.
NOTES:
Š Most states require a separate braking system on trailers with a loaded weight above a specific
amount. Check local ordinances.
Š M/T – Manual Transmission, A/T – Automatic Transmission

2006 Nissan Towing Guide 25 TOWING EQUIPMENT CLASSES

Class I
Trailer hitch
equipment* can be
used to tow trailers
with a maximum
weight of 2,000 lbs.
Class II
Trailer hitch
equipment* can be
used to tow trailers
with a maximum
weight of 3,500 lbs.
Class III
Trailer hitch
equipment* can be
used to tow trailers
with a maximum
weight of 5,000 lbs.
Class IV
Trailer hitch
equipment* can be
used to tow trailers
with a maximum
weight of 10,000 lbs.

Bumper
Towing
Receiver
Hitch
Bumper
Towing
Receiver
Hitch
Bumper
Towing
Receiver
Hitch
Bumper
Towing
Receiver
Hitch
Armada X
Frontier X X
Murano X
Pathfinder X
Quest X
Titan X X
Xterra X
Passenger
Vehicles X

NOTES:
Š Towing capability of the vehicle may be less than the maximum towing rating of the
equipment. See TOWING CAPACITIES earlier in this section, or refer to your owner’s
manual for detailed information regarding the towing capacity of your specific vehicle.
Š A weight-distributing hitch should be used to tow trailers that weigh over 5,000 lbs.
Š You can tow a trailer with a lower rating than the hitch. For example, a Class IV hitch can
tow a Class II trailer.

TOW VEHICLE WIRING HARNESSES

*Includes matched receiver, ball mount, and hitch ball.
Harness Type Trailer Lighting Electric Trailer Brakes
Armada 7-pin connector wiring
harness Pre-wired
Receiver hitch: 7-pin
connector wiring harness
Pre-wired with 7-pin harness. Requires an
electric trailer brake controller (supplied by
customer), and an electric trailer brake
controller wiring harness (included with
vehicle or available from Nissan dealer). Frontier 4-pin connector wiring
harness
Murano 4-pin connector wiring
harness
Tow harness kit
available
Quest 4-pin connector wiring
harness
Available in factory
tow package
Standard equipment:
4-pin connector wiring
harness
N/A
Pathfinder
7-pin connector wiring
harness
Tow harness kit
available
Titan 7-pin connector wiring
harness Pre-wired

Xterra
Receiver hitch: 7-pin
connector wiring harness
Tow harness kit
available
Pre-wired with 7-pin harness. Requires an
electric trailer brake controller (supplied by
customer), and an electric trailer brake
controller wiring harness (included with
vehicle or available from Nissan dealer).

2006 Nissan Towing Guide 26
PROTECTION

At Nissan, we back everything we build. So we’re proud that every Nissan is protected by
some of the best New Vehicle Limited Warranties, including 36-month/36,000-mile basic
coverage. All 2006 models also feature 60-month/60,000-mile powertrain coverage.* And,
Nissan warranties are completely transferable if you should sell your Nissan.
If you want additional peace of mind, we proudly offer the Nissan Security+Plus
®
Vehicle Protection Plan. This plan offers quality mechanical protection long after your New
Vehicle Limited Warranty expires.
The Security+Plus
® Vehicle Protection Plan is backed by Nissan and designed
exclusively for Nissan owners. From a variety of plans available, you can choose the one
that best fits your driving needs (up to 84 months/100,000 miles!). For the maximum
coverage, you’ll want to opt for Security+Plus Gold Preferred.
Whichever plan you choose, coverage is available throughout the United States. Repair
work will be done at authorized Nissan dealers by Nissan-trained technicians utilizing
Genuine Nissan Parts.
For more information about Security+Plus
® Vehicle Protection Plans, contact your
participating Nissan dealer.
The quality of Genuine Nissan Parts and Accessories is backed by the integrity of a
Genuine Nissan Replacement Parts and Accessories Limited Warranty. If purchased within
the basic coverage period of 36 months/36,000 miles, Genuine Nissan Parts and
Accessories are covered by the remaining period of the warranty. If the remaining period is
less than 12 months/12,000 miles (or if the vehicle warranty has expired), then Genuine
Nissan Accessories are covered by their own 12-month/12,000-mile Limited Warranty.
See your Warranty Information Booklet or ask your Nissan dealer for specific details.

CONCERN FOR YOUR SAFETY
Nissan urges you to always use your seat belt whenever you drive. And please make sure
all passengers are buckled up. Keep in mind that air bags are a supplemental restraint
system and must always be used in conjunction with a seat belt.
Also, with a front passenger air bag, a rear-facing child restraint must never be placed
in the front passenger's seat. Children 12 and under should ride in the rear seat properly
secured in child restraints, booster seats, or seat belts, according to their size. Please see
your owner's manual for more details.


*For complete warranty details, read the Warranty Information Booklet or see your nearest Nissan
dealer.

2006 Nissan Towing Guide 27
COMMITMENT

At Nissan, our commitment to your satisfaction extends well beyond building a full line of
quality products. It begins with people dedicated to designing vehicles to satisfy your
needs. Then building them to standards that are beyond your expectations. Our nationwide
network of nearly 1,100 dealers will help you select the Nissan that’s right for you. For
further assistance, search our Web site at www.NissanUSA.com. For Nissan dealer
locations or for more information on this and other Nissan products, call 1-800-239-8810.
Or call 1-800-NISSAN-1 for answers to product-related issues and solutions to your
transportation needs.



All illustrations, photographs, and specifications in this publication are based on the latest
product information available at the time of printing. Some vehicle parts cannot be shown
in certain photographs. Some vehicles are shown with optional equipment. See the actual
vehicle for complete accuracy. Availability and delivery time for particular models and
equipment combinations may vary. Nissan North America, Inc. reserves the right to make
changes at any time, without prior notice, in prices, colors, materials, equipment,
specifications, and models, and to discontinue models or equipment. All specifications,
options, and accessories shown in this publication apply to the 49 continental states.
Specifications, options, and accessories may differ in Hawaii, U.S. territories, and other
countries. For information on availability, additional options, or accessories, see your
Nissan dealer.

Nissan, the Nissan Brand Symbol, “SHIFT_” tagline, and Nissan Model names are Nissan
trademarks.










©2005 Nissan North America, Inc.
