ECU FUNCTIONS AND CONTROLS IN THE SWS
SMART WIRING SYSTEM (SWS)54B-18
WINDSHIELD WIPER LINKED WITH WASHER FUNCTION (INITIAL CONDITION: WITH
THE WINDSHIELD WIPER LINKED WITH WASHER FUNCTION)
AC309988AC
t
t
T T
ON
OFF
ON
OFF
ON
OFF ON
OFF
Windshield wiper
auto stop signal Windshield washer relay Windshield washer switch
Windshield wiper relay
Wiper switch in
off positionWiper switch in intermittent
operation position
t: 0.2 or 0.3 second
T: Intermittent wiper intermittent time
Wiper
switchOFF positionIntermittent operation positionLow-speed or
high-speed
operation
position
Washer
switch ON
time (t)0.3
second or
less0.3 to 0.5
second0.5
second or
more0.2
seconds
or less0.2 to 0.4
second0.4 to 0.6
second0.6
second or
more−
T0 second2 seconds3 seconds0 second1 second2 seconds3 seconds3 seconds
When th e windshie l d washer switch in the column
switch is turned
ON with the ignition switch in th e
ACC or ON positio
n, the ET ACS-ECU turn s ON the
windsh
i eld washe r rela y .
When the windshie l d washer switch is kept ON for
0.3 secon
d s, th e windshie l d wip e r drive signa l (the
wiper drive sign
al ou tput time varie s de pending on
the condit
i ons. For d e t a ils, refer t o the t ables) is
turned ON, and
the win d shield wiper is ope rated a t
high
spee d. Three seconds af ter turn ing OFF th e
windshie
l d wa sh er switch, th e win d sh ield wip e r tu rns
OFF
.
Even when the win d shield wa sher switch is turne d
ON while the windsh
i eld wiper is o perating in termit
-
tently, the intermittent action is ke pt af ter th e linked
operation is finished.
If the igniti on switch is se t to the ACC position while
t
h e wind shie ld wa sher swit ch i s be ing tu rn ed ON, t he
windshield washe
r rela y becomes ON, but th e wind
-
shield wipe r doe s not st art the lin ked operation.
When th
e windshie l d washer switch is t u rned OFF
and the
n ON a gain , the win d shield wiper make s the
linked o
peration.
NOTE: .
•Using a cust omisation fun c tion, the driver ca n
en
ab le or dis abl e th e wi nd shi e ld wi per lin ked wit h
washer functio
n . For more information about the
customisatio
n featu r e, refer to
P.54B-25.
•When the windsh i eld wiper linked with washe r
fun
c tio n is disabled by the customisa t ion feature ,
the
windshield wiper does not op erate in synch r o
-
nization with the win d shield wa sher . However ,
the
windshield wash er ca n be activated. It is use
-
ful to melt do wn the ices of th e frozen wind shield.

ECU FUNCTIONS AND CONTROLS IN THE SWS
SMART WIRING SYSTEM (SWS)54B-20
REAR WIPER LINKED WITH WASHER FUNCTION (THE INITIAL CONDITION: WITH
FUNCTION)
AC207003AB
t
tt
ON
OFF
ON
OFF
ON
OFF T1T1 T1T2
T3
T4 T4 t : 0.3 second
T1 : 3 seconds
T2 : 7.4 seconds
T3 : 8 seconds
T4 : 0.6 second Rear wiper switch
in off position
Rear wiper switch in on position
Rear washer switch
Rear washer relay
Rear wiper relay
•Whe
n the re ar wash er swit ch on the column
switch is tu
rned ON with th e ign i tio n switch ACC
or ON, ET
ACS-ECU t u rns ON the rear wash er
relay
. When the re ar washe r switch signa l from
th
e co lu m n swi t c h re ma in s ON f o r 0. 3 se co nd s or
more, ET
ACS-ECU turns ON the r ear wiper relay
to o
perate the rea r wiper continuously . Wh en the
rear
wa sher switch is turned OFF , the
ET
ACS-ECU turns OFF the rea r wiper relay 3
se
cond s later . Th en the rear wip e r sto p s at th e
aut
o sto p positio n.•Even turning ON the rea r wa sher switch during
rear
wiper op eratio n ca uses the r ear wipe r relay
to switch the o
peration to continuou s ope ration ,
and
then t he rear wiper resumes intermittent
ope
ration at interva l s of eig h t se cond s, 7. 4 sec
-
onds af ter t he co mpletion of the con t inuo us op er-
ation.
NOTE: Using a cust omisation fun c tio n , a d r ive r can
enable or disab l e th e rear wip e r linked with washer
funct
i
on. F o r mo re inf o rmation ab out th e customisa
-
tion feature, refer to P.54B-25.
ELECTRIC RETRACT ABLE RE MOTE CONTROLLED MIRROR
ELECTRIC RETRACTABLE REMOTE CONTROLLED MIRROR TIMER FUNCTION
AC309810
Ignition switch (ACC)
AC
t: 0.1 second
T1: 30 seconds
T2: 16 seconds
ON
OFF
T2
T2
T2
T2
T2 T2
t
tt
T1
T1
OFFON
OFF
ON
OFF ON
Door mirror unfold relay
Door mirror fold relay Remote controlled mirror switch
(folding/unfolding switch)
When th
e unfo l din g /folding switch on t he fold switch
remote
controlled mir r or switch is turn ed ON with the
ignition
switch at th e ACC o r ON po sition, th e door
mirro
r unfold relay or fold r e lay is turned on for 16
seconds
t o unfold or fold the d oor mirrors. Even af ter
the ig
nition switch is tu rned OFF , the do or mirrors
can o
perate for 30 seconds.If the un fold ing/f o lding switch o n the remote con t rol-
led mirror switch is turne d ON while on e of th e door
mirro
r unfold relay or door mirror fo ld relay is in op er
-
ation, the o t her relay fo r the o pposite motio n is
turned
ON af ter 0.1 second.

ECU FUNCTIONS AND CONTROLS IN THE SWS
SMART WIRING SYSTEM (SWS)54B-21
NOTE: Whether the door mirrors are at the unfolding
or folding position is determined according to the
memory of the door mirror fold relay operated previ
-
ously. For this reason, if the door mirrors are manu-
ally retracted, they may not move when the
unfolding/folding switch on the fold switch remote
controlled mirror switch is pressed next time.
AUTOMATIC UNFOLDING FUNCTION1.
AC207002AB
ON
OFF ON
OFF ON
OFF ON
OFF
T
T
Ignition switch 30 km/h
0 km/h
Unfolding Folding
Vehicle speed
Remote controlled mirror switch
(folding/unfolding switch)
Door mirror position Door mirror unfold relay
Door mirror fold relay
T : 16 seconds
Ve hicle speed-d epend ent au tomat i c u n fold ing func-
tion
When th e ve hicle speed re ache s 30 km/h, with the
ig nition switch ON and the mirrors retracted,
ET ACS-ECU turns on the retraction mirror relay
(unf olding) for 16 se cond s to return th e door mir
-
rors. However, the door mirrors do not return to
the
i r normal p o sitions auto m atically if the ignition
switch is tu
rned fro m OFF to ON, and then th e
unf
olding/folding switch on the remote contro lled
mirror switch
is operate d .
NOTE: Whe t her the door mirrors are at th e unfo l din g
or fold
ing p o sition is d e termined accordin g to th e
memory o f the re traction mirror re lay operat ed previ
-
ously. For th is re ason , if t he mirrors are manually
retract
ed, the y may n o t mo ve when the u n fold
-
ing/folding switch is pre s sed next time.
FLASHER TIMER FUNCTION
TURN-SIGNAL LAMP (I NITIAL SETTING:
TURN SIGNAL LAMP CAN BE OPERA
T ED
W
H EN THE IGNITION SW ITCH IS IN THE
ON POSITION)
AC101508
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
Ignition
switch (IG)
Turn-signal lamp
switch RH
Turn-signal lamp
switch LH
Turn-signal lamp
output RH
Turn-signal lamp
output LH
AC
When th
e turn-sign a l lamp switch is ON (LH o r RH)
with the
ignition switch is ON, t he turn -sig nal lamp
output
(flash signal) is turned ON.
If the lamp bulb of the front o r rear turn -sig nal lamp
has burned out, the flashing speed beco
m es faster to
alert t
he driver th at the lamp bulb has burne d out.
NOTE: Using a cust omisation fun c tio n , this fu nction
beco
m
es ava ilab l e even whe n the ignit i on switch is
in the
ACC po sit i on. F o r mo re info rmation ab out th e
customisation fe ature, re fer to
P.54B-25.

ECU FUNCTIONS AND CONTROLS IN THE SWS
SMART WIRING SYSTEM (SWS)54B-22
HAZARD LAMP
AC101509
ON
OFF
ON
OFF
ON
OFF
Hazard lamp
switch
Turn signal
lamp output
RH
Turn signal
lamp output
LH
AC
When th
e hazard lamp switch inp u t signal turning
from OFF
to ON is dete c te d, the fla s h i ng st a t es tu rns
over b
y the signal (When th e hazard lamp is n o t
blin
kin g , it b lin ks. If it is b linking , it tu rns o f f).
NOTE: .
1.The push -return switch is adop ted for t he hazard
la mp switch .
2. Even if th e lamp bulb has burn ed o u t, the fla s hing
sp eed o f the ha zard lamp is not chang ed.
TURN-SIGNAL LAMP INDICAT O R
The ETACS-ECU sen d s th e turn sign al lamp indica-
tor ON sig nal to the combin ation mete r throu gh CAN
communicat
i on in synchronization with the turn sig
-
nal lamp operat ion. T he co mbination me ter receives
the tran
smitted sig nal a nd turns ON o r OFF the
turn-signal lamp indicator
.
HEADLAMP
HIGH-BEAM INDICA T O R
The ETACS-ECU sends th e high be am in dica tor ON
sig
nal to the comb ination meter th rough CAN co m
-
munication in synchr onizatio n with t he high bea m
headlamp
operation. T he co mbinatio n me ter
receives the
transmit t ed signa l and turns ON o r OF F
the high be
am indicator .
FOG LAMP
FOG LAMP CONTROL
AC401793AB
OFFON
(Extinguished) OFF (Illuminated) ON
(Extinguished) OFF (Illuminated) ON Tail lamp
Headlamp
OFF
Fog lamp switch Lighting switch
Headlamp
Tail lamp
(Extinguished) OFF(Illuminated) ON
Fog lamp output
When th e fog lamp switch is turn ed to ON with th e
t
a il lamp o r the h eadla m p lit (th e t a il lamp switch or
the hea
dlamp switch is ON), the fog lamp relay turns
ON, and
the fo g lamp s turn on.
If the ta il la mp or the he adlamp is turn ed of f with th e
ligh
t ing switch OF F while the fo g lamp s lit, the fog
lamp
s turn o f f the same time to prevent una ttende d
operation.
FOG LAMP INDICAT O R
The ETACS-ECU sen d s th e fog lamp indicat o r ON
sig
nal to the comb ination meter th rough CAN co m
-
munication in synchr onizatio n with t he fog lamp
operation.
The comb ination meter receives the trans
-
mitted signal and t u rns ON or OFF the fog lamp indi-
cator.

CONSTRUCTION DIAGRAM
ACTIVE STABILITY CONTROL SYSTEM (ASC)35C-10
C1226Control solenoid valve
(FR) pressure holding
systemProhibitedProhibitedProhibitedProhibitedProhibitedProhibited
C1231Control solenoid valve
(FR) decompressing
system
C1236Control solenoid valve
(FL) pressure holding
system
C1241Control solenoid valve
(FL) pressure reducing
system
C1246Control solenoid valve
(RR) pressure holding
system
C1251Control solenoid valve
(RR) pressure reducing
system
C1256Control solenoid valve
(RL) pressure holding
system
C1261Control solenoid valve
(RL) decompressing
system
C1266Motor system (seizure)ProhibitedBack-up
controlProhibitedProhibitedProhibitedProhibited
C1273Motor relay stuck OFF
C1274Motor relay stuck ON
C1276Valve relay systemEnabledEnabledEnabledEnabledProhibitedProhibited
C1278Valve relay system stuck
offEnabledEnabledEnabledEnabledProhibitedProhibited
C1279Valve relay system stuck
onProhibitedEnabledProhibitedProhibitedProhibitedProhibited
C1300Cut valve (FR/RL)
systemProhibitedProhibitedProhibitedProhibitedProhibitedProhibited
C1305Suction valve (FR/RL)
system
C1310Cut valve (FL/RR)
system
C1315Suction valve (FL/RR)
system
C1340Stop lamp switch signal
errorEnabledEnabledProhibitedProhibitedProhibitedProhibited
C1345Low brake fluid levelEnabledEnabledEnabledEnabledEnabledEnabled
C1364Internal malfunction of
pressure sensorProhibitedEnabledProhibitedProhibitedProhibitedProhibited
C1366Lateral G-sensor signal
errorEnabledEnabledProhibitedProhibitedProhibitedProhibited
Diagnosis
code No.Item ABS EBD TCL ASC
Engine
controlBrake
controlEngine
controlBrake
control

CONSTRUCTION DIAGRAM
ACTIVE STABILITY CONTROL SYSTEM (ASC)35C-13
C1226Control solenoid valve
(FR) pressure holding
systemIlluminatesIlluminatesIlluminatesIlluminates
C1231Control solenoid valve
(FR) decompressing
system
C1236Control solenoid valve
(FL) pressure holding
system
C1241Control solenoid valve
(FL) pressure reducing
system
C1246Control solenoid valve
(RR) pressure holding
system
C1251Control solenoid valve
(RR) pressure
reducing system
C1256Control solenoid valve
(RL) pressure holding
system
C1261Control solenoid valve
(RL) decompressing
system
C1266Pump motor rotation
malfunction OffIlluminatesIlluminatesIlluminates
C1273Pump motor drive
circuit malfunction
C1274Pump motor drive
circuit stuck on
C1276Valve relay systemIlluminatesIlluminatesIlluminatesIlluminates
C1278Valve relay stuck off
C1279Valve relay stuck on IlluminatesIlluminatesIlluminatesIlluminates
C1300Front-right cut valve
(Primary)IlluminatesIlluminatesIlluminatesIlluminates
C1305Front-right suction
valve (Primary)
C1310Front-left cut valve
(secondly)
C1315Front-left suction valve
(secondly)
C1340Abnormal stop lamp
switch signalOffIlluminatesIlluminatesIlluminates
C1345Low brake fluid levelIlluminatesOffOffOff
Diagnosis
code No.Item Brake warning
lampABS warning lamp Active stability
control system
(ASC) indicator
lamp ASC OFF indicator
lamp

CVT
CONTINUOUSLY VARIABLE TRANSMISSION (CVT)23-4
DIAGNOSIS CLASSIFICATION TABLE
M2231015000056
ItemDiagnosisData listActuator
test
Code No.Trouble symptomsItem No.Display
Crank angle sensor−−01r/min−
CVT fluid temperature sensor15Open circuit08°C−
16Short circuit
Line pressure sensor18Open circuit09MPa−
19Short circuit
Turbine speed sensor22Open circuit02r/min−
Primary speed sensor23Open circuit03r/min−
26System failure
Secondary speed sensor24Open circuit04r/min−
25System failure
Accelerator pedal position sensor (APS)−−06mV−
Primary pressure sensor27Open circuit11MPa−
28Short circuit
Gear ratio−−12Displays the
gear ratio.−
Line pressure control solenoid valve31Open circuit/short
circuit 16%01
Shift control solenoid valve32Open circuit15%02
36Short circuit
Damper clutch control solenoid valve33Open circuit14%03
37Short circuit
Clutch pressure control solenoid valve34Open circuit17%04
38Short circuit
Shift system42System failure−−−
Damper clutch system44System failure10r/min−
45
Clutch system46System failure−−−
48
Inhibitor switch51Open circuit26P/R/N/D/Ds/L−
52Short circuit
Stop lamp switch53Open circuit33ON/OFF−
54Short circuit
Battery voltage−−24V−
CVT control relay56Open circuit25V11
Steel belt system59System failure−−−
Line pressure system57System failure−−−
71
72
