2006 MERCEDES-BENZ S600 language

143 Controls in detail
Control system
Control system
The control system is activated as soon as
the SmartKey in the starter switch is
turned to position1 or as soon as the
KEYLESS-GO* start/stop button
(page 35) is in position1. The control
system enables you to:


call up information about your vehicle


change vehicle settings
For example, you can use the control sys-
tem to find out when your vehicle is next
due for service, to set the language for
messages in the instrument cluster dis-
play, and much more.
The control system relays information to
the multifunction display.
Multifunction display
1Trip odometer
2Main odometer
iThe displays for the audio systems (ra-
dio, CD player etc.) will appear in En-
glish, regardless of the language
selected.
Warning!
G
A driver’s attention to the road and traffic
conditions must always be his/her primary
focus when driving.
For your safety and the safety of others, se-
lecting features through the multifunction
steering wheel should only be done by the
driver when traffic and road conditions per-
mit it to be done safely.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.

162 Controls in detailControl systemThe table below shows what settings can
be changed within the various menus. De-
tailed instructions on making individual
settings can be found on the following pag-
es.INSTRUMENT CLUSTER
LIGHTING
VEHICLE
CONVENIENCE
Select temperature display
mode
Set daytime running lamp mode
(USA only)
Set automatic locking
Set key-dependency
Select multifunction display
mode
Set locator lighting
Limiting opening height of trunk
lid*
Activate easy-entry/exit feature
Select language
Exterior lamps delayed shut-off
Set parking position for exterior
rear view mirror
Select tire inflation pressure
unit
Interior lighting delayed shut-off
Set fold-in function for exterior
rear view mirrorsAdjusting the drive-dynamic
seat

163 Controls in detail
Control system
Instrument cluster submenu
Access the
INST. CLUS.
submenu via the
SETTINGS
menu. Use the
INST. CLUS.
submenu to change the instrument cluster
display settings. The following functions
are available:Selecting temperature display mode

Move the selection marker with
theæ orç button to the
INST.
CLUS.
submenu.

Press buttonj ork repeatedly
until you see this message in the multi-
function display:
TEMP. INDICATOR
.
The selection marker is on the current
setting.

Pressæ orç to set the temper-
ature unit to degrees Celsius (
°C) or de-
grees Fahrenheit (
°F).Selecting multifunction display mode

Move the selection marker with
theæ orç button to the
INST.
CLUS.
submenu.

Press buttonj ork repeatedly
until you see this message in the multi-
function display:
DISPLAY VALUES IN
.
The selection marker is on the current
setting.

Press æ or ç to set speedome-
ter unit to
MILES
or KM
.
Function
Page
Select temperature display
mode
163
Select multifunction display
mode
163
Select language
164
Select tire inflation pressure unit
164

164 Controls in detailControl systemSelecting language
Move the selection marker with
theæ orç button to the
INST.
CLUS.
submenu.

Press buttonj ork repeatedly
until you see this message in the multi-
function display:
LANGUAGE
.
The selection marker is on the current
setting.

Pressæ orç to select the lan-
guage to be used for the multifunction
display messages.Available languages:


German


English


French


Italian


Spanish
Selecting tire inflation pressure unit
Use this function to set the unit for the tire
inflation pressure display.

Move the selection marker with
theæ orç button to the
INST.
CLUS.
submenu.

Press buttonj ork repeatedly
until you see this message in the multi-
function display:
DISPLAY UNIT TIRE
PRESSURE
.
The selection marker is on the current
setting.

Press æ or ç to select the de-
sired tire inflation pressure unit.
Lighting submenu
Access the
LIGHTING
submenu via the
SET-
TINGS
menu. Use the
LIGHTING
submenu
to change the lamp and lighting settings on
your vehicle. The following functions are
available:
Function
Page
Set daytime running lamp mode
(USA only)
165
Set locator lighting
166
Exterior lamps delayed shut-off
166
Interior lighting delayed shut-off
167

461 Index
Height adjustments
Vehicle level 230, 233
High beam 50
Replacing bulbs 395
High beam flasher 135
High beam headlamps
Messages in display 370
Switching on 135
High mounted brake lamp 395
High-performance brake system
(S 65 AMG only) 275
Hood 287
Closing 288
Message in display 368
Opening 287
Hydroplaning 277
I
Identification labels 422
Emission control information
label 422
Vacuum line routing diagram
label 422
Ignition 34, 36
Switching on 34, 46, 47Immobilizer 85
Activating 85
Deactivating 85
Indicator lamps see Lamps, indicator and
warning
Individual seats* 117
Head restraint height 118
Infant and child restraint systems 71
Installing 74
LATCH child seat anchors 75
Information
About service and warranty 10
Button for Tele Aid 259
Infrared reflecting windshield 269
Inside rear view mirror
Auto-dimming 186
Installing
Infant and child restraint systems 74
Towing eye bolt 415
Wiper blades 402
Instrument cluster 24, 140, 446
Cleaning 337
Coolant temperature gauge 141
Illumination 140Multifunction display 143
Outside temperature indicator 142
Selecting language 164
Integrated remote control
Canadian programming 267
Erasing memory 268
Hand-held transmitter 265
Operating 268
Rolling code programming 266
Interior illumination
Delayed switch-off 167
Interior lighting 137
Activating automatic control 137
Deactivating automatic control 137
Manual operation 137
Reading lamps in the front 138
Reading lamps in the rear 138
Interior rear view mirror
Adjusting 41
J
Jump starting 411

462 IndexK
Key see SmartKey 57, 58
Key, mechanical 388
Key, SmartKey
Checking the batteries 95
Locking 58
Key-dependency memory
Settings 169
KEYLESS-GO* 446
Activating ignition with 36
Locking 58
Locking the vehicle 101
Loss of SmartKey with
KEYLESS-GO 102
Messages in display 368
Starting the engine 47
Turning off engine 57
Kickdown 177, 446
Kilometers/miles in speedometer 163
Kilopascal 324
Km/h or mph in speedometer 163L
Lamp bulbs, exterior 394
Lamps, exterior
Front 395
Light sensor 370
Messages in display 371
Rear 395
Lamps, indicator and warning
ABS 340
Air bag off 65
Battery (SmartKey with
KEYLESS-GO*) 100
Battery (SmartKey) 94
Brakes 341
Coolant 362
Distronic* 220
Engine diagnostics 342, 343
Engine malfunction indicator
lamp 342, 343
ESP
®
344, 345
Front passenger front air bag off 348Fuel reserve 343
Instrument cluster 340–347
Seat belts telltale 345
Service indicator 329
SRS 61
Language
Multifunction display 164
Setting 164
LATCH child seat anchors 75
Layout of poly-V-belt drive 423
Leather upholstery
Cleaning 338
Lever
For cruise control 222
License plate lamps
Replacing bulbs 395, 400
Light alloy wheels
Cleaning 337
Light sensor 370
Lighter
Center console 250

465 Index
Mph or km/h in speedometer 163
Multicontour backrest* 122
Multifunction display 143, 447
Selecting language 164
Standard display 147
Multifunction display messages
ABC 351
ABS 353
Airmatic 358
Brake fluid 361
Brake pads 361
Check engine 342, 343
Coolant 363
Coolant level 362
Distronic* 354
Doors 365
Engine 342, 343
Engine oil level 366
Entry position 368
Hood 368Lamps 371
Parking brake 360
Selector lever 357
SmartKey 368
SmartKey with KEYLESS-GO* 368
TeleAid 374
Telephone* 374
Tires 376–383
Trunk 375
Washer fluid 375
Multifunction steering wheel 26, 144,
447
Buttons 144
N
Navigation system
Operating 155
See separate COMAND* operating in-
structions
Night security illumination 133
Normal occupant weight 324O
Occupant distribution 324
Occupant safety 60
Air bags 61
Children and air bags 62
Children in the vehicle 71
Fastening the seat belt 43
Infant and child restraint systems 71
LATCH child seat anchors 75
Seat belts 43, 64
Oil
Adding 292
Consumption 288
Dipstick 288
Filler neck 291, 292, 293
Viscosity 445
Oil level
Checking 286
Oil level via control system
Checking 289

470 IndexSeat ventilation*
Switching off 127
Switching on 127
Seating capacity 302
Seats 114
Adjusting 37
Adjusting lumbar support 123
Adjusting shoulder support 123
Easy entry/exit feature 114
Heater 125
Massage function 123
Multicontour backrest* 122
Rear power seat bench* 117
Rear seats 117
Securing cargo
Cargo tie-down hooks 240
Selector lever
Lock 46, 173
Message in display 357
Position 173
Self-test
BabySmart
TM air bag deactivation
system 73
Tele Aid 255Service
Major service (Service B) 329
Minor service (Service A) 329
When due 329
Service (maintenance) 329
Service and warranty information 10
Service indicator 329
Service life (tires) 298
Service System see FSS 329
Setting
Convenience functions 169
Cruise control 216
Daytime running lamp mode 165
Digital clock 25
Distronic* time interval 225
Following distance in Distronic* 225
Higher speed in cruise control 217
Higher speed in Distronic* 224
Individual vehicle settings 160
Interior illumination delayed
switch-off 167
Lamps and lighting (control
system) 164
Language, multifunction display 164
Locator lighting 166
Lower speed in cruise control 217Lower speed in Distronic* 224
Miles/kilometers in
speedometer 163
Parking position for exterior rear view
mirrors 170, 172
Slower speed in cruise control 217
Slower speed in Distronic* 224
SmartKey dependent memory 169
Speed in Distronic* 223
Speedometer display mode 163
Suspension tuning 232
Temperature (interior) 195
Temperature (rear passenger
compartment) 206
Temperature indicator 163
Tire inflation pressure units 164
To last stored speed (“Resume” func-
tion) in cruise control 217
To last stored speed in Distronic* (“Re-
sume” function) 224
Units
Speedometer 163
Temperature 163
Tire inflation pressure 164
Vehicle level control 230, 233
Setting current speed 216
