ContentsSafety and Security........................... 59
Occupant safety................................... 60
Air bags .......................................... 61
Seat belts ....................................... 67
Preventive occupant safety
(PRE-SAFE
®)................................... 70
Children in the vehicle .................... 71
Override switch for rear
passenger compartment ................ 77
Panic alarm .......................................... 78
Activating ....................................... 78
Deactivating ................................... 78
Driving safety systems ......................... 79
ABS ................................................ 79
BAS ................................................ 80
ESP
®.............................................. 81
Four wheel electronic traction
system (4MATIC) with the ESP
®..... 84
Anti-theft systems................................ 85
Immobilizer..................................... 85
Anti-theft alarm system .................. 86
Tow-away alarm ............................. 88
Controls in detail............................... 91
Locking and unlocking ......................... 92
SmartKey ....................................... 92
SmartKey with KEYLESS-GO* ........ 96
Opening the doors
from the inside ............................. 102
Opening the trunk ........................ 103
Closing the trunk.......................... 105
Trunk lid emergency release ........ 111
Power closing assist for doors
and trunk lid ................................. 112
Automatic central locking ............ 112
Locking and unlocking
from the inside ............................. 113
Seats ................................................. 114
Easy-entry/exit feature ................ 114
Removing and installing front
seat head restraints ..................... 116
Rear seats .................................... 117
Rear seat head restraints ............. 120
Lumbar support............................ 122
Multicontour backrest* ................ 122
Drive-dynamic seat* .................... 124
Seat heating* ............................... 125
Seat ventilation* .......................... 127Memory function ............................... 128
Storing positions into memory ..... 129
Recalling positions from memory . 129
Storing exterior rear view
mirror parking position ................ 130
Lighting ............................................. 131
Exterior lamp switch .................... 131
Combination switch ..................... 135
Hazard warning flasher ................ 136
Interior lighting ............................ 137
Courtesy lighting .......................... 139
Door entry lamps ......................... 139
Trunk lighting ............................... 139
Instrument cluster ............................. 140
Instrument cluster illumination .... 140
Coolant temperature gauge ......... 141
Trip odometer .............................. 141
Tachometer .................................. 142
Outside temperature indicator ..... 142
Clock............................................ 142
Control system .................................. 143
Multifunction display.................... 143
Multifunction steering wheel........ 144
Menus .......................................... 146
Standard display menu ................ 148
AUDIO menu ................................ 148

ContentsLoading .............................................. 239
Roof rack* .................................... 239
Loading instructions ..................... 240
Cargo tie-down hooks .................. 240
Useful features .................................. 241
Vanity mirrors............................... 241
Storage compartments................. 242
Cup holders .................................. 248
Ashtrays ....................................... 249
Cigarette lighters.......................... 250
Heated steering wheel*
(except S 55 AMG and
S 65 AMG) .................................... 252
Telephone*................................... 253
Tele Aid ........................................ 254
Garage door opener ..................... 263
Infrared reflecting windshield ....... 269
Operation......................................... 271
The first 1000 miles (1500 km) ......... 272
Driving instructions............................ 273
Drive sensibly – save fuel ............. 273
Drinking and driving ..................... 273
Pedals .......................................... 273
Power assistance ......................... 273
Brakes .......................................... 274
Driving off .................................... 276
Parking ......................................... 276
Tires ............................................. 277
Hydroplaning ................................ 277
Tire traction.................................. 278
Tire speed rating .......................... 278
Winter driving instructions ........... 279
Standing water ............................. 280
Passenger compartment .............. 281
Driving abroad.............................. 281
Control and operation of
radio transmitters ........................ 281
Catalytic converter ....................... 282
Emission control .......................... 282
Coolant temperature .................... 283At the gas station .............................. 284
Refueling ...................................... 284
Check regularly and before
a long trip..................................... 285
Engine compartment ......................... 287
Hood ............................................ 287
Engine oil ..................................... 288
Transmission fluid level ................ 293
Active Body Control* (ABC*)
fluid level ..................................... 293
Coolant level ................................ 294
Battery ......................................... 295
Windshield washer system and
headlamp cleaning system*......... 296
Tires and wheels................................ 297
Important guidelines .................... 297
Tire care and maintenance........... 298
Direction of rotation..................... 300
Loading the vehicle ...................... 300
Recommended tire
inflation pressure ......................... 306
Checking tire inflation pressure ... 308
Tire labeling ................................. 313
Load identification ....................... 317

ContentsTechnical data.................................. 419
Parts service ...................................... 420
Warranty coverage ............................. 421
Loss of Service and Warranty
Information Booklet...................... 421
Identification labels............................ 422
Layout of poly-V-belt drive ................. 423
S 350/S 430/S 430 4MATIC/
S 500/ S 500 4MATIC ................. 423
S 55 AMG ..................................... 423
S 600 and S 65 AMG.................... 423
Engine ................................................ 424
Rims and tires .................................... 426
Same size tires ............................. 428
Mixed size tires ............................ 430
Spare wheel ................................. 431
Electrical system................................ 432Main dimensions and weights............ 433
Main dimensions .......................... 433
Weights ........................................ 433
Fuels, coolants, lubricants, etc. ......... 434
Capacities .................................... 434
Engine oils.................................... 437
Engine oil additives ...................... 437
Air conditioning refrigerant .......... 437
Brake fluid .................................... 437
Premium unleaded gasoline ......... 438
Fuel requirements ........................ 438
Gasoline additives ........................ 439
Coolants....................................... 439
Windshield and headlamp
washer system ............................. 442
Technical terms............................... 443Index................................................. 451

25 At a glance
Instrument cluster
Item
Page
1
Coolant temperature gauge
141
2
Fuel gauge with fuel tank
reserve warning lamp
343
3
LLeft turn signal
indicator lamp
51
KRight turn signal
indicator lamp
51
4
Speedometer with:vElectronic Stability
Program (ESP
®)
warning lamp
345
lDistance warning
lamp
Vehicles without Distronic*:
Distance warning lamp with-
out function. It illuminates
when the ignition is on. It
should go out when the en-
gine is running.
344
5
Tachometer
142
Item
Page
6
Right display with: 345
AHigh beam headlamp
indicator lamp
50
-Antilock Brake
System (ABS)
indicator lamp
340
7
JReset button
140
8
Display with:

Gear selector lever
position
174


Program mode
174


Digital clock
(see COMAND operating
instructions)
9
Multifunction display with:

Trip odometer
141


Main odometer
141
Item
Page
a
Outside temperature
indicator
142
b
Left display with:1Supplemental
Restraint System
(SRS) indicator lamp
347
;Brake warning lamp,
USA only
341
3Brake warning lamp,
Canada only
341
?Engine malfunction in-
dicator lamp,
USA only
342
±Engine malfunction in-
dicator lamp, Canada
only
342
HTire inflation pressure
warning lamp
346
c
Knob for instrument cluster il-
lumination
140

54 Getting startedDrivingProblems while driving
The engine runs erratically and misfires

An ignition cable may be damaged.


The engine electronics may not be op-
erating properly.


Unburned gasoline may have entered
the catalytic converter and damaged it.

Give very little gas.

Have the problem repaired by an au-
thorized Mercedes-Benz Center as
soon as possible.The coolant temperature is above
248°F (120°C)
The coolant is too hot and is no longer
cooling the engine.

Stop the vehicle as soon as possible
and turn off the engine. Allow engine
and coolant to cool.

Check the coolant level and add cool-
ant if necessary (
page 294).In case of accident
If the vehicle is leaking gasoline:

Do not start the engine under any cir-
cumstances.

Notify local fire and/or police authori-
ties.
If the extent of the damage cannot be de-
termined:

Notify an authorized Mercedes-Benz
Center.
If no damage can be determined on the


major assemblies


fuel system


engine mount:

Start the engine in the usual manner.
iExcessive coolant temperatures trigger
a warning message in the multifunction
display (
page 363).

141 Controls in detail
Instrument cluster
Coolant temperature gauge
During severe operating conditions,
e.g. stop-and-go traffic, the coolant tem-
perature may rise close to 248°F (120°C),
i.e. close to the red zone of the tempera-
ture gauge.
The engine should not be operated with
the coolant temperature above 248°F
(120°C), i.e. in the red zone of the coolant
temperature gauge. Doing so may cause
serious engine damage which is not cov-
ered by the Mercedes-Benz Limited War-
ranty.
Trip odometer
Make sure you are viewing the trip
odometer display.

If it is not displayed, press the è or
ÿ button on the multifunction
steering wheel repeatedly until the trip
odometer appears (
page 143).

Press and hold reset buttonJ
(page 140) until the trip odometer is
reset.
Warning!
G


Driving when your engine is badly over-
heated can cause some fluids which
may have leaked into the engine com-
partment to catch fire. You could be se-
riously burned.


Steam from an overheated engine can
cause serious burns and can occur just
by opening the hood. Stay away from
the engine if you see or hear steam com-
ing from it.
Turn off the engine, get out of the vehicle
and do not stand near the vehicle until the
engine has cooled down.
iExcessive coolant temperature triggers
a warning in the multifunction display
(page 363).

203 Controls in detail
Automatic climate control
Deactivating
Press buttonT (
page 193).
The indicator lamp on buttonT
goes out.
The residual heat is automatically turned
off:


when the ignition is switched on


after approximately 30 minutes
(15 minutes when residual heat and
ventilation in the rear* are also
switched on)


if the battery voltage drops
Ventilated storage compartment
Depending on vehicle model and configu-
ration, your vehicle is equipped with a stor-
age compartment under the front armrest
(page 244) which can be ventilated
when the automatic air conditioning is
switched on. If so equipped, the switch is
located inside the storage compartment in
the front. The air temperature is about the
same as that of the center air vents.
The air volume is dependent on the setting
of:


air distribution control


air volume control


air vents in the dashboard
The air temperature is about the same as
that of the dashboard air vents. It cannot
be regulated separately.Switching ventilation on

Open the storage compartment in front
of the armrest, see “Storage compart-
ment in front of armrest” (
page 244).

Push upper portion of switch.
Switching ventilation off

Open the storage compartment in front
of the armrest, see “Storage compart-
ment in front of armrest” (
page 244).

Push lower portion of switch.
iHow long the system will provide heat-
ing depends on the coolant tempera-
ture and the temperature set by the
operator. The blower will run at speed
setting 1 regardless of the air distribu-
tion control setting.
!Do not obstruct the air vent in the stor-
age compartment.iThe compartment can get very warm
due to its confined space. When storing
heat sensitive objects in the compart-
ment, close the air vent while heating
the passenger compartment.

207 Controls in detail
Automatic climate control
Adjusting air volume
Adjusting automatically
PressA on air volume switch6
(page 205).
The display shows
AUTO
The air volume
is adjusted automatically.
Reducing air volume

Press switch6 down until the desired
air volume is reached.
The display shows the current level.
Increasing air volume

Press switch6 up until the desired air
volume is reached.
The display shows the current level.Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior.
This feature makes use of the residual heat
produced by the engine.
Activating

Turn the SmartKey in the starter switch
to position1 or0, or remove it from
the starter switch.

Press buttonT (
page 205).Deactivating

Press buttonT (
page 205).
The residual heat is automatically turned
off:


when the ignition is switched on


after approximately 30 minutes
(15 minutes when residual heat and
ventilation in the front are also
switched on)


if the battery voltage dropsiHow long the system will provide heat-
ing depends on the coolant tempera-
ture and the temperature set by the
operator. The blower will run at speed
setting 1 regardless of the air distribu-
tion control setting.
