2006 MERCEDES-BENZ G500 Owner's Manual

128 Controls in detail
Control system
Standard display menu
Press buttonk orj to select
the functions in the standard display
menu.
The following functions are available:
Display digital speedometer
Press buttonj twice.
The current vehicle speed is shown in
the multifunction display.
AUDIO menu
The functions in the
AUDIO menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO OFF is shown in the
display.
The following functions are available:
i
The headings used in the menus table
are designed to facilitate navigation
within the system and are not neces-
sarily identical to those shown in the
control system displays.
The first function displayed in each
menu will automatically show you
which part of the system you are in.
FunctionPage
Call up coolant temperature
display120
Call up digital speedometer128
Call up maintenance service
indicator281
Check engine oil level244
FunctionPage
Select radio station129
Select satellite radio station*
(USA only)129
Operate CD player130

129 Controls in detail
Control system
Select radio station
Turn on COMAND and select radio. Re-
fer to separate COMAND operating in-
structions.
Press buttonè orÿ repeatedly
until you see the currently tuned sta-
tion in the display.
1Station
2Waveband setting
3Setting for station selection using
memory
Press buttonk orj repeatedly
until the desired station is found.
The type of search depends on the set-
ting for the station tuning:

The next stored station is selected
(SP)

Station searchSelect satellite radio station*
(USA only)
The satellite radio is treated as a radio ap-
plication.
Select satellite radio with the corre-
sponding key on the COMAND control
panel (SAT).
Press buttonèorÿ repeatedly
until you see the currently tuned sta-
tion in the multifunction display.
1Channel name or number
2SAT mode and preset number
3Setting for station selection using
memory
Press buttonjork repeatedly
until the desired channel is found.
i
You can only store new stations by us-
ing the corresponding feature on the
radio. Refer to separate operating in-
structions.
You can also operate the radio in the
usual manner.

130 Controls in detail
Control system
Operate the CD player
Turn on COMAND and select CD. Refer
to separate COMAND operating in-
structions.
Press buttonè orÿ repeatedly
until the settings for the CD currently
being played are shown in the display.
1Current track
2Current CD (for CD changer)
Press buttonk orj repeatedly
until the desired track is selected.
NAVI menu
The
NAVI menu contains the functions
needed to operate your navigation system.
Press buttonè orÿ repeatedly
until you see the message
NAVI in the
display.

If the navigation system is off, the mes-
sage
NAVI OFF is shown in the display.

If the navigation system is on, the mes-
sage
NAVI READY is shown in the dis-
play.
Please refer to the COMAND manual for in-
structions on how to activate the route
guidance system*.
i
Additional optional satellite radio
equipment and a subscription to satel-
lite radio service provider are required
for satellite radio operation. Contact an
authorized Mercedes-Benz Light Truck
Center for details and availability for
your vehicle.
For more information, refer to separate
COMAND operating instructions.
i
Satellite radio service may be unavail-
able or interrupted from time to time
for a variety of reasons, such as envi-
ronmental or topographic conditions
and other things beyond the service
provider’s or our control. Service might
also not be available in certain places
(e.g. in tunnels, parking garages, or
within or next to buildings) or near
other technologies.
i
To select a CD from the magazine,
press a number on the COMAND sys-
tem key pad located in the center dash-
board.

131 Controls in detail
Control system
Vehicle status message memory menu
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.Press buttonè orÿ repeatedly
until the vehicle status message mem-
ory appears in the multifunction dis-
play.
No vehicle status messages
If no conditions are recorded in memory,
the message in the multifunction display
is:
NO MALFUNCTION
Vehicle status messages have been
recorded
If conditions have occurred causing status
messages to be recorded, the number of
messages appears in the multifunction dis-
play:
1Number of messages
Press buttonk orj.
The stored messages will now be dis-
played in order. See the “Practical
hints” section for malfunction and
warning messages (
page 298).
Should the vehicle’s system record any
conditions while driving, the number of
messages will reappear in the multifunc-
tion display when the SmartKey in the
starter switch is turned to position0 or re-
moved from the starter switch.
Warning!G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Light Truck Center to address the malfunc-
tion and warning messages (
page 298).
i
The vehicle status message memory
will be cleared when you switch on igni-
tion (
page 35). You will then only see
high-priority messages in the multi-
function display (
page 298).

132 Controls in detail
Control system
Settings menu
In the
SETTINGS... menu there are two
functions:

The function TO RESET: R BUTTON FOR
3SEC.
, with which you can reset all the
settings to those set at the factory.

A collection of submenus with which
you can make individual settings for
your vehicle.
Press buttonè orÿ repeatedly
until the
SETTINGS... menu is seen in
the display.Resetting all settings
You can reset all the functions of all sub-
menus to the factory settings.
Press the reset button in the instru-
ment cluster (
page 120) for approxi-
mately three seconds.
In the display you will see the request
to press the reset button again to con-
firm.
Press the reset button again.
The functions of all the submenus will
reset to factory settings.
i
The settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time. Approximately five seconds after
pressing the reset button for the sec-
ond time, the
SETTINGS... menu reap-
pears in the display.
For safety reasons, the following func-
tions are not reset while driving:

the LIGHT CIRCUIT HEADLIGHT MODE
function in the
LIGHTING submenu

the SETTINGS KEY- DEPENDENT func-
tion in the
CONVENIENCE submenu

133 Controls in detail
Control system
Submenus in the Settings menu
Press buttonj.
In the display you see the collection of
the submenus.
Press buttonç.
The selection marker moves to the next
submenu.The submenus are arranged by hierarchy.
Scroll down with theç button, scroll up
with theæ button.
With the selection marker on the desired
submenu, use the jbutton to access
the individual functions within that sub-
menu. Once within the submenu, you can
use the jbutton to move to the next
function or the kbutton to move to the
previous function within that submenu.
The settings themselves are made with
buttonæ orç.Resetting the functions of a submenu
For each submenu you can reset all the
functions to the factory settings.
Move to a function in the submenu.
Press the reset button in the instru-
ment cluster (
page 120) for approxi-
mately three seconds.
In the display you will see the request
to press the reset button again to con-
firm.
Press the reset button again.
All functions of the submenu will reset
to factory settings


134 Controls in detail
Control system
i
The settings you have changed will not
be reset unless you confirm the action
by pressing the reset button a second
time. Approximately five seconds after
pressing the reset button for the sec-
ond time, the
SETTINGS... menu reap-
pears in the display.


135 Controls in detail
Control system
The table below shows what settings can
be changed within the various menus.
Detailed instructions on making individual
settings can be found on the following
pages.
INSTRUMENT CLUSTERLIGHTINGVEHICLECONVENIENCE
(page 136)(page 138)(page 142)(page 143)
Select time display modeSet daytime running lamp mode
(USA only)Set station selection mode
(radio)Activate easy-entry/exit feature
Select temperature display
modeSet locator lightingSet automatic lockingSet key-dependency
Select speedometer display
modeSet night security illuminationSet parking position for exterior
rear view mirror
Select languageSet interior lighting delayed
shut-off
Select display (speed display or
outside temperature)
