Contents
Automatic transmission ..................... 155
Gear selector lever position ......... 157
Driving tips ................................... 158
Gear ranges ................................. 160
Automatic shift program .............. 161
Gear selector lever one-touch
gearshifting .................................. 162
Steering wheel gearshift control
one-touch gearshifting ................. 163
Manual shift program ................... 165
Emergency operation
(Limp-Home Mode) ...................... 168
Good visibility .................................... 169
Headlamp cleaning system* ........ 169
Rear view mirrors ......................... 169
Sun visors .................................... 171
Rear window sunshade* .............. 172
Rear window defroster ................. 173
Climate control .................................. 174
Deactivating the climate control
system ......................................... 177
Operating the climate control
system in automatic mode ........... 177
Setting the temperature ............... 178
Adjusting air distribution and
volume ......................................... 178Adjusting air volume ..................... 179
Front defroster.............................. 179
Air recirculation mode .................. 180
Air conditioning............................. 182
Rear passenger compartment
adjustable air vents....................... 183
Automatic climate control*
(Canada only) ..................................... 184
Deactivating the automatic
climate control system ................. 187
Operating the automatic climate
control system in automatic mode 187
Setting the temperature................ 188
Adjusting air distribution............... 189
Adjusting air volume ..................... 190
Front defroster.............................. 190
Maximum cooling MAXCOOL ........ 191
Air recirculation mode .................. 191
Charcoal filter ............................... 193
Air conditioning............................. 194
Residual heat and ventilation ........ 195
Rear passenger compartment
adjustable air vents....................... 196Audio system...................................... 197
Audio and telephone, operation .... 197
Operating safety ........................... 197
Operating and display elements ... 198
Button and soft key operation ...... 200
Operation...................................... 200
Radio operation ............................ 205
Introduction to satellite radio*
(USA only) ..................................... 209
CD mode....................................... 214
GSM network phones ................... 223
TDMA or CDMA network phones .. 229
Emergency calls “911” ................. 235
Power windows .................................. 238
Opening and closing the windows 238
Synchronizing power windows ...... 240
Summer opening feature .............. 241
Convenience closing feature......... 241
Power tilt/sliding sunroof .................. 242
Opening and closing the power
tilt/sliding sunroof........................ 242
Synchronizing the power
tilt/sliding sunroof........................ 244
Driving systems .................................. 245
Cruise control ............................... 245

Contents
Technical data.................................. 423
Parts service ...................................... 424
Warranty coverage ............................. 425
Loss of Service and Warranty
Information Booklet...................... 425
Identification labels............................ 426
Layout of poly-V-belt drive ................. 427
Engine ................................................ 428
Rims and Tires ................................... 429
Same size tires ............................. 431
Mixed size tires ............................ 432
Spare wheel (collapsible tire) ....... 433
Electrical system................................ 434
Main dimensions and weights ............ 435
Main dimensions .......................... 435
Weights ........................................ 435Fuels, coolants, lubricants, etc. ......... 436
Capacities .................................... 436
Engine oils.................................... 437
Engine oil additives ...................... 437
Air conditioning refrigerant .......... 437
Brake fluid .................................... 437
Premium unleaded gasoline ......... 438
Gasoline additives ........................ 438
Fuel requirements ........................ 439
Coolants....................................... 439
Windshield washer and headlamp
cleaning system* ......................... 442Technical terms............................... 443
Index................................................. 449

11 Introduction
Operator’s Manual
Important notice for California retail
buyers and lessees of Mercedes-Benz
automobiles
Under California law you may be entitled to
a replacement of your vehicle or a refund
of the purchase price or lease price, if
Mercedes-Benz USA, LLC and/or its au-
thorized repair or service facilities fail to fix
one or more substantial defects or mal-
functions in the vehicle that are covered by
its express warranty after a reasonable
number of repair attempts. During the pe-
riod of 18 months from original delivery of
the vehicle or the accumulation of
18 000 miles (approximately 29 000 km)
on the odometer of the vehicle, whichever
occurs first, a reasonable number of repair
attempts is presumed for a retail buyer or
lessee if one or more of the following
occurs: (1) the same substantial defect or mal-
function results in a condition that is
likely to cause death or serious bodily
injury if the vehicle is driven, that de-
fect or malfunction has been subject to
repair two or more times, and you have
directly notified Mercedes-Benz USA,
LLC in writing of the need for its repair,
(2) the same substantial defect or mal-
function of a less serious nature than
category (1) has been subject to repair
four or more times and you have direct-
ly notified us in writing of the need for
its repair, or(3) the vehicle is out of service by reason
of repair of the same or different sub-
stantial defects or malfunctions for a
cumulative total of more than
30 calendar days.
Written notification should be sent to us,
not a dealer, at Mercedes-Benz USA, LLC,
Customer Assistance Center,
One Mercedes Drive, Montvale,
NJ 07645-0350.

122 Controls in detail
Instrument cluster
For a full view illustration of the instrument
cluster, see “At a glance” (
page 24).
1Reset button
The instrument cluster is activated when
you

open a door

switch on the ignition (page 33)

press reset button1

switch on the exterior lighting
You can change the instrument cluster
settings in the Instrument cluster submenu
of the control system (
page 138).
Instrument cluster illumination
Use reset button1 to adjust the
illumination brightness for the instrument
cluster.
To brighten illumination
Turn reset button1 clockwise.
The instrument cluster illumination will
brighten.
To dim illumination
Turn reset button1 counterclock-
wise.
The instrument cluster illumination will
dim.
Warning!G
No messages will be displayed if either the
instrument cluster or the multifunction dis-
play is inoperative.
As a result, you will not be able to see infor-
mation about your driving conditions, such
as speed or outside temperature, warning/
indicator lamps, malfunction/warning mes-
sages or the failure of any systems. Driving
characteristics may be impaired.
If you must continue to drive, please do so
with added caution. Visit an authorized
Mercedes-Benz Center as soon as possible.
i
The instrument cluster illumination is
dimmed or brightened automatically to
suit ambient light conditions.
The instrument cluster illumination will
also be adjusted automatically when
you switch on the vehicle’s exterior
lamps.

176 Controls in detail
Climate control
The climate control is operational when-
ever the engine is running. You can oper-
ate the climate control system in either the
automatic or manual mode. The system
cools or heats the interior depending on
the selected interior temperature and the
current outside temperature.Nearly all dust particles, pollutants and
odors are filtered out before outside air en-
ters the passenger compartment through
the air distribution system.
The air conditioning will not engage (no
cooling) if the mode A/C is deactivated
(
page 182).
Warning!G
When operating the climate control, the air
that enters the passenger compartment
through the air vents can be very hot or very
cold (depending on the set temperature).
This may cause burns or frostbite on unpro-
tected skin in the immediate area of the air
vents. Always keep sufficient distance be-
tween unprotected parts of the body and the
air vents. If necessary, use the air distribu-
tion control (
page 178) to direct the air to
air vents in the vehicle interior that are not
in the immediate area of unprotected skin.
Warning!G
Follow the recommended settings for heat-
ing and cooling given on the following pag-
es. Otherwise the windows could fog up,
impairing visibility and endangering you and
others.
i
Severe conditions (e.g. strong air
pollution) may require replacement of
the filter before its scheduled interval.
A clogged filter will reduce the air
volume to the interior.
If the vehicle interior is hot, ventilate
the interior before driving off, see
“Summer opening feature”
(
page 241). The climate control will
then adjust the interior temperature to
the set value much faster.
Keep the air intake grille in front of the
windshield free of snow and debris.
Do not obstruct air flow by placing
objects on the air flow-through exhaust
slots below the rear window.

179 Controls in detail
Climate control
Turn air distribution control 4
(
page 175) to the desired symbol.
Opening center and side air vents
Turn thumbwheels 3, 4, 7 and 8
(
page 175) upward.
The center air vents 5 and 6 and side
air vents 2 and 9 are open.
Closing center and side air vents
Turn thumbwheels 3, 4, 7 and 8
(
page 175) downward.
The center air vents 5 and 6 and side
air vents 2 and 9 are closed.
Adjusting air volume
Six blower speeds are available.
Press buttonU (page 175).
The indicator lamp in the button goes
out. The automatic air volume control
is switched off. The air volume is
adjusted according to the currently
selected setting.
Use the air volume control4
(
page 175) to adjust the air volume.
Front defroster
You can use this setting to defrost the
windshield, for example if it is iced up.
You can also defog the windshield and the
side windows.Activating
Press buttonP or0
(
page 175).
The indicator lamp on the button
comes on.
The air conditioning switches
automatically to the following functions:

maximum blowing and heating
power

air flows onto the windshield and
the front side windows

the air recirculation mode is
switched off
Deactivating
Press buttonP or0
(
page 175) again.
The indicator lamp on the button goes
out. Defrosting is turned off.
i
Keep this setting selected only until the
windshield or the side windows are
clear again.
i
The cooling remains switched on.

180 Controls in detail
Climate control
Windshield fogged on the outside
Switch the windshield wipers on
(
page 50).
Press buttonU (page 175).
The indicator lamp on the button
comes on. Air distribution and air vol-
ume are adjusted automatically.
If the automatic mode of the climate con-
trol is switched off:
Turn air distribution control4
toaorY (
page 175).
Air recirculation mode
Switch to air recirculation mode to prevent
unpleasant odors from entering the vehicle
from the outside (e.g. before driving
through a tunnel). This setting cuts off the
intake of outside air and recirculates the
air in the passenger compartment.Activating
Press button, (page 175).
The indicator lamp on the button
comes on.i
Keep this setting selected only until the
windshield is clear again.
Warning!G
Fogged windows impair visibility, endanger-
ing you and others. If the windows begin to
fog on the inside, switching off the air
recirculation mode immediately should clear
interior window fogging. If interior window
fogging persists, make sure the air
conditioning (
page 182) is activated, or
press buttonP or 0.
i
The air recirculation mode is activated
automatically at high outside tempera-
tures.
The indicator lamp on button, is
not lit when the air recirculation mode
is automatically switched on.
A quantity of outside air is added after
approximately 30 minutes.
Warning!G
Never operate the side windows and the
tilt/sliding sunroof if there is the possibility
of anyone being harmed by the closing pro-
cedure.

181 Controls in detail
Climate control
Deactivating
Press button, (page 175).
The indicator lamp on the button goes
out.
In the event that the closing procedure
causes potential danger, the closing of the
side windows can be immediately halted by
pressing or pulling the respective window
switch. The closing of the tilt/sliding
sunroof can be immediately halted by
moving the tilt/sliding sunroof switch in the
overhead control panel in any direction.
The closing of the side windows and
tilt/sliding sunroof can be reversed by again
pressing and holding the, button.
i
Press and hold button, for approx.
2 seconds. The side windows and
tilt/sliding sunroof will close. You can
release button, once the closing
procedure has begun. The windows
and tilt/sliding sunroof continue clos-
ing until they are fully closed.
i
The air recirculation mode is deactivat-
ed automatically:

after 5 minutes if the outside
temperature is below
approximately 41°F (5°C)

after 5 minutes if the air condition-
ing is turned off

after 30 minutes if the outside
temperature is above
approximately 41°F (5°C)
i
Press and hold button, for approx.
2 seconds. The side windows and or
tilt/sliding sunroof will return to their
previous position. You can release
button, once the opening proce-
dure has begun. The windows and
tilt/sliding sunroof continue opening
until they have reached their previous
position.
A window or tilt/sliding sunroof will
only return to its previous position if it
has not been moved to another posi-
tion using the respective window
switch or tilt/sliding sunroof switch af-
ter it was closed with button,. A
window or tilt/sliding sunroof that was
moved will remain in its current posi-
tion if button, is used to re-open
the remaining windows or tilt/sliding
sunroof.
