HOW TO USE THIS MANUAL
viii
HOW TO USE THIS MANUAL
The contents of this manual are explained briefly on this
page to help you make the best use of the manual. Please
read this page and the rest of the Owner’s Manual
carefully to make sure you fully understand the operation
of your vehicle.
This will help you enjoy safe and comfortable driving.
TABLE OF CONTENTS
The table of contents and the pictorial index provide easy
reference to the appropriate pages.
BASIC OPERATION QUICK REFERENCE
Operation of basic equipment is briefly explained in an easily
understandable way for quick reference.
SECTION 1 INSTRUMENTS AND CONTROLS
The vehicle’s equipment is divided into the 7 groups listed
below. Use of the equipment is explained, including any points
you should pay particular attention to.
1. Keys and doors
2. Switches
3. Gauges, meters and service reminder indicators
4. Interior equipment
5. Exterior equipment
6. Occupant restraint systems
7. Steering wheel and mirrors
SECTION 2 AIR CONDITIONING AND AUDIO
The features of the vehicle’s air conditioning and audio are
explained in detail. Be sure to read this section so that you can
make full use of them.
SECTION 3 STARTING AND DRIVING
Starting the engine, driving, stopping, operation of features
affecting vehicle handling, hints on vehicle safety and safe
driving techniques are all explained. Please read everything
in this section, and remember − drive safely!
SECTION 4 IN CASE OF AN EMERGENCY
This section explains what to do in the event of an urgent
situation such as the engine not starting or getting a flat tire,
etc. If such a problem occu rs, check the contents of this
Owner’s Manual and follow the instructions given.
SECTION 5 MAINTENANCE
This section explains the importance of regular maintenance.
Regular and periodic inspection and maintenance of your
Lexus will help to keep your vehicle in its best condition.
SECTION 6 SERVICE PROCEDURES AND
SPECIFICATIONS
Simple maintenance procedure and service data are provided
here for your reference should you wish to perform inspection
and maintenance yourself.
INDEX
The page number is listed for each item in the Owner ’s Manual
so that you can rapidly find the item and page you are
searching for.

SECTION 1 – 3
47
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder
indicators
Fuel gauge48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Engine coolant temperature gauge 48
. . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil pressure gauge 49
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
Tachometer 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Odometer and trip meter 51
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 52
. . . . . . . . . . . . . .
Trip information display 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
FUEL GAUGE
13X500
Low fuel level warning light
The gauge indicates the approximate quantity of fuel
remaining in the tank when the ignition switch is on.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches “E” or the low fuel level warning light\
comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible. See the inner back cover for fuel capacity and recommended
fuel selection.
ENGINE COOLANT
TEMPERATURE GAUGE
13X501
 Normal range
The gauge indicates the engine coolant temperature when
the ignition switch is on. The engine operating
temperature will vary with changes in weather and engine
load.
If the needle points to the red zone or higher, stop your vehicle
and allow the engine to cool.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
Your vehicle may overheat during severe operating conditions,
such as:

Driving up a long hill on a hot day.
 Reducing speed or stopping after high speed driving.
 Idling for a long period with the air conditioning on in
stop−and−go traffic.
 Towing a trailer.
NOTICE
Do not remove the thermostat in the engine cooling
system as this may cause the engine to overheat. The
thermostat is designed to control the flow of coolant
to keep the temperature of the engine within the
specified operating range.
 Do not continue driving with an overheated engine.
See “If your vehicle overheats” on page 338.
ENGINE OIL PRESSURE GAUGE
13X623
 1
Normal driving 2Idling
The engine oil pressure gauge indicates engine oil
pressure when the ignition is on. Check it while driving to
make sure the needle is in the proper range.
If the engine oil pressure should stay below the normal range,
pull off the road to a safe place and stop the engine
immediately. Call a Lexus dealer or qualified repair shop for
assistance.
Engine oil pressure may not build up when the engine oil level
is too low. The engine oil pressure gauge is not designed to
indicate engine oil level, and the engine oil level must be
checked using the level dipstick.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
NOTICE
Do not drive the vehicle with the engine oil pressure
below the normal range until the cause is fixed it may
ruin the engine.
VOLTMETER
13X503a
 1 Normal range 2Charging system warning light
The voltmeter tells whether the battery is charged or
discharged. Check it while the engine is running the
needle should always indicate as shown above.
If the needle reads below or above the normal range while the
engine is running, it indicates the charging system needs
immediate repair.
However, it is normal for the needle to drop below the normal
range during engine starting.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
TACHOMETER
13X504c
The tachometer indicates engine speed in thousands of
rpm (revolutions per minute). Use it while driving to
prevent engine overrevving.
Driving with the engine running too fast causes excessive
engine wear and poor fuel economy. Remember, in most
cases the slower the engine speed, the greater the fuel
economy.
NOTICE
Do not let the indicator needle get into the red zone. This
may cause severe engine damage.
ODOMETER AND TRIP METER
13X505
“ODO/TRIP” knob
This meter displays the odometer and two trip meters. To
change the mode indication, push the “ODO/TRIP” knob
briefly. Each time you push the knob, the mode changes
in order from the odometer to trip meter A to trip meter B,
then back to the odometer, etc.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To set the A trip meter to zero, display the A meter reading,
push the knob and hold it. The same applies for the B trip
meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
SERVICE REMINDER INDICATORSAND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...DO THIS.
(a)
or
(Indicator and buzzer)If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver’s seat
belt.
(c)Fasten front
passenger’s seat belt.
(d)Take vehicle to Lexus
dealer immediately.
(e)214Replace engine oil.
IF THIS INDICATOR OR BUZZER COMES ON ...DO THIS.
(f)orTake vehicle to Lexus
dealer.
(g)or
Take vehicle to Lexus
dealer.
If the brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
(h)Close all doors.
(i)WG6
Adjust tire inflation
pressure.
If light remains on,
contact Lexus dealer.
(j)Shift four− wheel drive
control out of “N”.
(k)Stop and check.

GAUGES, METERS AND SERVICE REMINDER INDICATORS
53
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(l)andw73zTake vehicle to Lexus
dealer.
(m)218Take vehicle to Lexus
dealer.
(n)213Replace bulb.
(o)Stop immediately and
contact Lexus dealer.
(p)Fill up tank.
IF THIS INDICATOR ORBUZZER COMES ON ...DO THIS.
(q)Add washer fluid.
(r)Key reminder
buzzerRemove key.
