STARTING AND DRIVING
444
Pre collision sensor
The millimeter wave radar sensor detects vehicles or
objects near or on the road your vehicle is traveling and
determines the possibility of a collision based on the
object position, vehicle speeds and the course you are
traveling.
The pre− collision sensor will operate when the vehicle speed
is about 5 km/h (3 mph) or over.
G31019
1 Millimeter wave grille cover
2Millimeter wave radar sensor
The millimeter wave radar sensor is installed in the front grille
of the hood.
The millimeter wave radar sensor cannot detect plastic objects
such as pylons, and may not detect people, animals, bicycles,
motor cycles, trees, snowbanks, etc. as objects with which
your vehicle may collide.
CAUTION
To ensure that pre collision system will function
properly while driving, observe the following. Failure to
follow these instructions could reduce the
effectiveness of the pre collision system in case of
vehicle accident:
Always keep the millimeter wave radar sensor and
grille cover clean. When cleaning, use a soft cloth
and be careful not to damage the sensor and grille
cover.
Avoid strong impacts around the millimeter wave
radar sensor. An incorrect millimeter wave radar
sensor alignment will result in system malfunction.
A special device is required to adjust the millimeter
wave radar sensor alignment. Be sure to have the
sensor adjusted by your Lexus dealer.
Do not disassemble the millimeter wave radar
sensor.
Do not affix a sticker (including a transparent sticker)
or attach an accessory around the millimeter radar
sensor or the grille cover.
Do not modify or paint the grille cover. When
replacing the grille cover, be sure to use a genuine
grille cover.
Page 466 of 622
STARTING AND DRIVING
445
Pre collision seat belts (Front seat belts only)
When the pre collision sensor detects an object or
vehicle with which your vehicle might collide and
determines that a collision may be unavoidable, the seat
belts are quickly drawn back by the retractors to enhance
the effects of the seat belt pretensioners. The
pre collision seat belts also work as well when hard
braking.
The pre −collision seat belts will operate in the following
conditions:
When the approaching speed in regard to the object or the
vehicle exceeds about 30 km/h (18 mph).
When the front seat occupants wear the seat belts.
In the following conditions, the seat belts are quickly drawn
back by the retractors regardless of the possibility of the
collision:
When the vehicle speed is about 14 km/h (9 mph) or over.
When the vehicle is spinning or cannot take a turn properly.
Pre collision brake assist system
When the pre collision sensor detects an object or
vehicle with which your vehicle might collide, and
determines that a collision may be unavoidable,
depressing the brake pedal provides more powerful
braking according to the amount of pedal depression.
The pre −collision brake assist system will operate in the
following conditions:
When the vehicle speed is about 30 km/h (18 mph) or over.
When the brake pedal is depressed.
When the approaching speed in regard to the object or the
vehicle exceeds about 30 km/h (18 mph).
If the brake pedal is kept depressed before the sensor’s
determination of unavoidable collision, the pre −collision brake
assist system will operate soon after the sensor’s
determination.
Page 467 of 622
STARTING AND DRIVING
446
Adaptive variable suspension control (GS430
only)
When the pre collision sensor detects an object or
vehicle with which your vehicle may collide, and
determines that a collision may be unavoidable, the
adaptive variable suspension adjusts the damping effect
on the shock absorbers and regulates the vehicle not to
pitch forward so much.
The adaptive variable suspension will operate in the following
conditions:
When the vehicle speed is about 5 km/h (3 mph) or over.
When the approaching speed in regard to the object or the
vehicle exceeds about 30 km/h (18 mph).
Pre collision system failure warning
G31079
Pre collision system warning light
The light warns that there is a problem somewhere in the
pre collision system.
The light comes on when the engine switch is selected in
“IG−ON” mode. If the system works properly, the light goes off
after a few seconds.
If the light does not come on when the engine switch is selected
in “IG−ON” mode, have your vehicle checked by your Lexus
dealer.
If the system has a problem, the pre− collision system warning
light comes on or blinks. At this time, the master warning light
comes on, a warning tone sounds, and either of the following
messages appears on the multi−information display.
PCS DISABLED NOW
CHECK PCS
Page 468 of 622
STARTING AND DRIVING
447
G13030
The pre collision system warning light blinks, and the
above message appears in the following conditions:
The millimeter wave radar sensor or the grille cover is
dirty.
Clean the grille or sensor with a soft cloth to remove the dirt.
The pre collision seat belts are activated repeatedly for
a short time.
The system turns of f temporarily for overheating protection.
The above conditions do not indicate a malfunction. If the
problem is removed, the warning lights and message go out
and the system returns to normal.
G13031
If the pre−collision system warning light remains on, and the above message appears, the pre −collision system may not
operate. Contact your Lexus dealer as soon as possible to
service the vehicle.
Precaution for pre collision system
It should be noted that the pre −collision sensor may detect the
following as the objects with which your vehicle might collide,
and the pre −collision system may operate, even though there
is no possibility of collision.
When traveling through a curve, there is an object on the
edge of the road.
When traveling through a curve, another vehicle is passing
from the opposite direction.
When traveling across a narrow iron bridge.
When there is a metallic object on the road.
When there is a steel plate on the road at a construction site.
When there is a bump on the road.
When waiting to turn to the left in an intersection, and
another vehicle is passing from the opposite direction.
If your vehicle approaches another vehicle ahead very
quickly.
Page 469 of 622
STARTING AND DRIVING
448
CAUTION
Do not rely solely on the pre collision system to
avoid accidents. Your safe and attentive driving
practices are still the best way to avoid accidents and
you are always responsible for the operation of the
vehicle and the safety of your passengers. When
driving, always pay attention to the surrounding
conditions and the course you are driving.
The pre collision sensor’s collision detection
performance is limited. The sensor is able to detect
a forward object within 10 degrees on either left or
right side. If it is out of the range, or if there is no or
weak millimeter wave reflection, the sensor could not
detect the object and the system does not work
properly.
Even if the pre collision system is operative in an
unavoidable collision, unless the seat belts are worn
and the brake pedal is depressed, the pre collision
seat belts and pre collision brake assist system will
not work.
NOTICE
Even if there is no object with which your vehicle may
collide, the pre collision system may be activated as
follows:
The pre collision seat belts work to quickly draw
back the front seat belts by the retractors
(pre collision seat belts).
The pre collision brake assist system works to apply
more powerful braking than normal braking.
Page 490 of 622
IN CASE OF AN EMERGENCY
469
NOTICE
Do not use liquid sealants for a flat tire as tire
pressure sensors will be damaged.
Take due care not to go over a curb stone and
be careful of the holes in the road because
deflated tire pressure affects tire cushion
performance. The wheels, tires, body,
suspension and other components could be
damaged.
Your ground clearance is reduced if the run flat
tire goes flat so avoid driving over obstacles
and drive slowly on rough, unpaved roads and
speed bumps. Also, do not attempt to go
through an automatic car wash as the vehicle
may get caught, resulting in damage.
When the tires must be replaced, have them
replaced by the nearest Lexus dealer or
authorized tire dealer. The tire pressure
sensors will be affected by the installation or
removal of tires.
When the tires must be replaced, replace the
grommets for tire pressure sensors as well.
IF YOU HAVE A FLAT TIRE
(Vehicles with standard tires)
CAUTION
If the low tire pressure warning light comes on,
observe the following instructions:
Decelerate as soon as possible to the most
appropriate speed that conditions permit.
Avoid abrupt steering wheel maneuvering and
braking. If the vehicle tires deteriorate, you
could lose control of the steering wheel or the
brakes, causing death or serious injury.
The warning system may not activate
immediately if bursts or sudden air leakage
should occur.
1. Reduce your speed gradually, keeping a straight line.
Move cautiously off the road to a safe place − well away
from the traffic. Avoid stopping on the center divider of
a highway. Park on a level spot with firm ground.
2. Stop the engine and turn on your emergency flashers.
3. Firmly set the parking brake and put the transmission
in ”P”.
4. Have everyone get out of the vehicle on the side away
from traffic.
Page 491 of 622
IN CASE OF AN EMERGENCY
470
5. Read the following instructions thoroughly.
CAUTION
When jacking, be sure to observe the following to
reduce the possibility of personal injury:
Follow jacking instructions.
Do not put any part of your body under a vehicle
supported by a jack. Otherwise, personal injury
may occur.
Do not start or run the engine while your vehicle
is supported by the jack.
Stop the vehicle on a level firm ground, firmly
set the parking brake and put the transmission
in ”P”. Block the wheel diagonally opposite to
the one being changed if necessary.
Make sure to set the jack properly in the jack
point. Raising the vehicle with jack improperly
positioned will damage the vehicle or may allow
the vehicle to fall off the jack and cause
personal injury.
Never get under the vehicle when the vehicle is
supported by the jack alone.
Use the jack only for lifting your vehicle during
wheel changing.
Do not raise the vehicle with someone in the
vehicle.
When raising the vehicle, do not put an object
on or under the jack.
Raise the vehicle only high enough to remove
and change the tire.
NOTICE
Do not use liquid sealants for a flat tire as tire
pressure sensors will be damaged.
Do not continue driving with a deflated tire.
Driving even a short distance can damage a tire
beyond repair.
When the tires must be repaired or replaced,
have them repaired or replaced by the nearest
Lexus dealer or authorized tire dealer. The tire
pressure sensors will be affected by the
installation or removal of tires.
When the tires must be replaced, replace the
grommets for tire pressure sensors as well.
Page 492 of 622
IN CASE OF AN EMERGENCY
471
Compact spare tire
G40025
The compact spare tire is designed for temporary
emergency use only.
The compact spare tire is identified by the distinctive
wording “TEMPORARY USE ONLY” molded into the
side wall of the tire.
To keep the compact spare tire noticeable, do not hide
the wheel by a wheel cover or such.
The compact spare tire saves space in your luggage
compartment, and its lighter weight helps to improve fuel
economy and permits easier installation in case of a flat
tire. The compact spare tire is not equipped with the tire
pressure sensor
. If tire inflation pressure becomes low,
the tire pressure warning system will not be activated.
Also, if you replace the compact spare tire after the low
tire pressure warning light comes on, the light remains
on.
The compact spare tire can be used many times, if
necessary. It has tread life of up to 4800 km (3000 miles)
depending on road conditions and your driving habits.
When tread wear indicators appear on the tire, replace
the tire. (See “Checking and replacing tires” on page
554.)
