2006 Lexus GS430 stop start

AUDIO
307
DVD player operation (For a Mark Levinson
brand audio system)
The DVD player can play audio CDs, DVD video discs and
video CDs.
For appropriate discs for this paper, see “Audio system
operating hints” on page 333.
For safety reasons, you can enjoy DVD video discs and video
CDs only when the vehicle is completely stopped with the
engine switch in “ACC” or “IG−ON” mode and the parking
brake applied. While you are driving, you can hear audio alone
even in the DVD video or video CD mode.
The DVD player can play the discs labeled as shown below. (a) Inserting or ejecting discs
The engine switch must be in “ACC” or “IG
−ON” mode.
Your automatic changer can store up to 6 discs.
G22048
 Setting a single disc:
1. Push the “LOAD” button briefly.
The green indicators at both ends of the slot start blinking and
“WAIT” appears on the display. After the blinking indicators
stay on and the “WAIT” changes to the “LOAD”, the DVD door
opens.

AUDIO
314(e) Operating a DVD video disc
NOTE: The playback condition of some DVD video discs
may be determined by a DVD video software producer.
This DVD player plays a disc as the software producer
intended. So some functions may not work properly. Be
sure to
read the instruction manual for the DVD video disc
separately provided. For the detailed information about
DVD video discs, see “(h) DVD player and DVD video disc
information”
Precautions on DVD video disc
When recording with a DVD video or video CD, audio tracks
may not record in some cases while the menu is displayed. As
audio will not play in this case, verify that the video tracks are
playing and then activate playback.
When playback of a disc is completed:
If an audio CD is playing, the next CD will be selected and
playback will begin automatically.
If a DVD video or video CD is playing, playback will stop or
the menu screen will be displayed. The next disc will not
play back automatically. (Audio tracks cannot be heard
while the disc is stopped)
The title/chapter number and playback time display may not
appear while playing back certain DVD video discs.
CAUTION
Conversational speech on some DVDs is recorded at a
low volume to emphasize the impact of sound effects.
If you adjust the volume assuming that the
conversations represent the maximum volume level
that the DVD will play, you may be startled by louder
sound effects or when you change to a different audio
source. The louder sounds may have a significant
impact on the human body or pose a driving hazard.
Keep this in mind when you adjust the volume.

AUDIO
317
Description of each switch—
Switches on top page
“Menu” and “Top Menu” switches: If you touch any of the
above switches, the menu screen for DVD video appears. (For
the operation, see the manual that come with the DVD video
disc provided separately.)
“
” switch: The menu control key appears on the screen.
(See page 318.)
“
” switch: Use this switch to pause the video screen.
When you touch this switch again, the video screen advances
frame by frame.
“ ” switch: Touch this switch to fast reverse during
playback and reverse slowly during pause.
“  ” switch: Use this switch to resume normal play after stop
or pause.
“  ” switch: Touch this switch to fast forward during
playback and forward slowly during pause.
Switches on second page
“Set Up” switch: The initial setup screen appears. (See page
320.)
“Search” switch: The title search screen appears. (See
page 318.)
“Return” switch: Use this switch to display the
predetermined scene and start playing from there.
“Audio” switch: The audio changing screen appears. (See
page 319.)
“Sub Title” switch: The subtitle changing screen appears.
(See page 319.)
“Angle” switch: The angle selection screen appears. (See
page 320.)

STARTING AND DRIVING
343
Engine switch
G31031
By pushing the engine switch with an electronic key in
possession, you can select “ACC”, “IGON” or “OFF”
mode and start or stop the engine. (For details, see
“Selecting the mode” on page 344 and “Starting the engine” on
page 350 and “Stopping the engine” on page 351.)
When an electronic key is in the vehicle, it is automatically
detected and checked if it corresponds to the registered ID
code for the vehicle, thereby allowing engine operation and
mode selection.
Press the engine switch slowly and firmly. Quick operation
may not activate the desired mode. In the following conditions, the system malfunctions. Contact
your Lexus dealer.

If the engine switch is not illuminated when the clearance
lights are turned on.
 If the engine switch indicator light flashes amber.
 If the switch movement seems unusual.
If, in an emergency, you must turn the engine off while the
vehicle is moving, press the engine switch for more than 3
seconds. At this time, “ACC” mode is selected.
CAUTION
 Do not press the engine switch during driving, except
in an emergency situation.
 If you leave your vehicle in hot weather, the switch
surface may get hot. Take care not to get burned.

STARTING AND DRIVING
346If you push the engine switch while the brake pedal is
depressed with the transmission not in “P” or “N”, “IG
−ON”
mode is selected with the engine not running.
It is not a malfunction if the needles on all meters and gauges
move slightly when selected in “IG− ON” mode.
NOTICE
Do not leave the engine switch in “IGON” mode while
the engine is not running. The battery will be
discharged.
“OFF” mode
G31032
This mode turns the engine and all accessories off.
To select the “OFF” mode from “IG− ON” mode:
 If the engine is not running, push the engine switch once
while the brake pedal is not depressed.
 If the engine is running, push the engine switch once
regardless of brake pedal position while the vehicle is
completely stopped.
To select the “OFF” mode from “ACC” mode, push the engine
switch twice while the brake pedal is not depressed.
The engine immobilizer is automatically set, the security
indicator light blinks and the engine switch indicator light is
turned off. (For details, see “Engine immobilizer” on page 11.)
The steering wheel can be locked only in this mode.

STARTING AND DRIVING
349
How to start the engine
Before starting the engine, be sure to follow the instructions.
CRANKING HOLD FUNCTION
Once you push the engine switch while the brake pedal is
depressed, the cranking hold function continues to crank the
engine in “IG−ON” mode until it starts.
The function stops cranking the engine after about 25 seconds
at maximum if the engine has not started yet. When you crank
the engine again, wait a few seconds and restart it.
BEFORE STARTING THE ENGINE
1. Check the area around the vehicle before entering it.
2. Adjust seat position, seatback angle, seat cushion angle,
seat cushion height, head restraint height and steering wheel
angle.
3. Adjust the inside and outside rear view mirrors.
4. Lock all doors.
5. Fasten seat belts.
Remember to check that the service reminder indicators
function when the engine switch is selected in “IG− ON” mode,
and check the fuel gauge to see that you have sufficient fuel. BEFORE CRANKING
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and accessories.
3. Put the selector lever in ”P”. If you need to restart the engine
while the vehicle is moving, put the selector lever in ”N”. A
starter safety device will prevent the starter from operating if
the selector lever is in any drive position.
4. Depress
the brake pedal and hold it to the floor until driving
off.
The multiport fuel injection system/sequential multiport fuel
injection system in your engine automatically controls the
proper air −fuel mixture for starting. You can start a cold or hot
engine as follows:

STARTING AND DRIVING
351
Stopping the engine
G31036
If you press the engine switch while the selector lever is
in “P” and the engine is running, regardless of brake pedal
position, the engine will be turned off.
With the transmission not in “P”, the engine switch is selected
in “ACC” mode.
If, in an emergency, you must turn the engine off while the
vehicle is moving, press the engine switch for more than 3
seconds. At this time, “ACC” mode is selected.
Several hours after the engine is turned off, you may hear a
sound coming from underneath the luggage compartment for
several minutes. This is normal operation and does not
indicate a malfunction. (See page v.)
CAUTION
To avoid serious personal injury or an accident, observe
the following precautions.
Turn off the engine, only when the vehicle is
completely stopped.
 When you leave the vehicle, the selector lever must
be in “P” and the parking brake must be applied, or
the vehicle may suddenly move.

STARTING AND DRIVING
362
(d) Backing up
G31028
 1Brake pedal 2“R” (Reverse) position
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with your foot, shift the
selector lever to the “R” position.
NOTICE
Never shift into reverse while the vehicle is moving.
When the selector lever is shifted into the “R” position, the
outside rear view mirrors automatically down to help backing
up. For details, see “Power rear view mirror control” on page
206.
Vehicles with rear view monitor system: When the selector
lever is shifted into the “R” position with the engine switch in
“IG−ON” mode, rear view monitor system will activate. For
instructions, see “Rear view monitor system” on page 388.
