ENGINE
ccclv
The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed under driving conditions such as high
speeds and frequent acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston rings
and cylinder walls have not become conditioned.
Oil consumption:
Max. 1.0 L per 1000 km (1.1 qt./600 miles,
0.9 Imp. qt./600 miles)
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has not
changed.
The diluting ingredients evaporate out when the vehicle is then
driven at high speeds, as on an expressway, making it appear
that oil is excessively consumed after driving at high speeds.
Importance of engine oil level check
One of the most important points in proper vehicle
maintenance is to keep the engine oil at the optimum level so
that oil function will not be impaired. Therefore, it is essential
that the oil level be checked regularly. Lexus recommends that
the oil level be checked every time you refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to
serious engine trouble due to insufficient oil.
For detailed information on oil level check, see “Checking the
engine oil level” on page ccclvi.

ENGINE
ccclvi
USED ENGINE OIL
CAUTION
Used engine oil contains potentially harmful
contaminants which may cause skin disorders such
as inflammation or skin cancer, so care should be
taken to avoid prolonged and repeated contact with
it. To remove used engine oil from your skin, wash
thoroughly with soap and water.
 Do not leave used oil within the reach of children.
 Dispose of used oil and used oil filters only in a safe
and acceptable manner. Do not dispose of used oil
and used oil filters in household trash, in sewers or
onto the ground. Call your Lexus dealer or a service
station for information concerning recycling or
disposal.
CHECKING THE ENGINE OIL LEVEL
With the engine at operating temperature and turned off,
check the oil level on the dipstick.
1. To get a correct reading, the vehicle should be on level
ground. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull the dipstick out, hold a rag under the end and wipe it
clean.
3. Reinsert the dipstick and push it in as far as it will go, or the
reading will not be correct.

ENGINE
ccclvii
1Add oil2O.K.3Too full
4. Pull the dipstick out and look at the oil level while holding a
rag under the end. If it is between the low level mark (
4) and
the full level mark (5), it is O.K.
NOTICE
Be careful not to drop engine oil on the vehicle
components.
If the oil level is below or only slightly above the low mark,
add engine oil of the same type as already in the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. We recommend that you use a funnel
when adding oil. The approximate quantity of oil needed to
raise the level between low mark and full mark on the dipstick
is indicated as follows:
1.5 L (1.6 qt., 1.3 Imp. qt.)
For the engine oil capacity, see “Specifications” on page cccxlix.
When the level reaches within the correct range, return the filler
cap and turn the cap clockwise until you hear a click.

ENGINE
ccclviii
NOTICE
Be careful not to spill engine oil on the vehicle
components.
 Avoid overfilling, or the engine could be damaged.
Check the oil level on the dipstick once again after
adding the oil.
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use
Lexus approved “Toyota Genuine Motor Oil” or equivalent to
satisfy the following grade and viscosity.
Oil grade: ILSAC multigrade engine oil
Recommended viscosity: SAE 5W −30
62Z002
Outside temperature
SAE 5W30 is the best choice for good fuel economy and
good starting in cold weather.
If SAE 5W30 is not available, SAE 10W30 may be used.
However, it should be replaced with SAE 5W30 at the next
oil change.

ENGINE
ccclix
Oil identification mark
The ILSAC (International Lubricant Standardization and
Approval Committee) Certification Mark is added to some oil
containers to help you select the oil you should use.
To ensure excellent lubrication performance for your engine,
“Toyota Genuine Motor Oil” is available, which has been
specifically tested and approved for all Lexus engines.
Please contact your Lexus dealer for further details about
“Toyota Genuine Motor Oil”.
CHECKING THE ENGINE COOLANTLEVEL
1Reservoir cap2Upper line3Lower line
Look at the seethrough coolant reservoir when the
engine is cold. The coolant level is satisfactory if it is
between the “F” and “L” lines on the reservoir. If the level
is low, add the coolant. (For the coolant type, see “Coolant
type selection” described below.)
The coolant level in the reservoir will vary with engine
temperature. However, if the level is on or below the “L” line,
add coolant. Bring the level up to the “F” line.

ELECTRICAL COMPONENTS
cd
If electrolyte gets on your skin, thoroughly wash the
contacted area. If you feel a pain or burn, get medical
attention immediately.
 If electrolyte gets on your clothes, there is a
possibility of its soaking through to your skin, so
immediately take off the exposed clothing and follow
the procedure above, if necessary.
 If you accidentally swallow electrolyte, drink a large
quantity of water or milk. Follow with milk of
magnesia, beaten raw egg or vegetable oil. Then go
immediately for emergency help.Checking battery exterior
1Terminals 2Holddown clamp
Check the battery for corroded or loose connections,
cracks, or loose holddown clamps.
1. If the battery is corroded, wash it off with a solution of warm
water and baking soda. Coat the terminals with grease to
prevent further corrosion.
2. If the connections are loose, tighten the clamp bolts — but
do not overtighten.
3. Tighten the hold −down clamp only enough to keep the
battery firmly in place. Overtightening may damage the battery
case.

GAS STATION INFORMATION
Fuel selection:
Premium unleaded gasoline with an Octane Rating of 91
(Research Octane Number 96) or higher required for
optimum engine performance. However, if such premium
type cannot be obtained, you may use unleaded gasoline
with an Octane Rating as low as 87 (Research Octane
Number 91). Fuel tank capacity:
70 L (18.5 gal., 15.4 Imp. gal.) Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC multigrade engine oil
Recommended oil viscosity: SAE 5W −30
Oil capacity: L (qt., Imp. qt.)
Drain and refill With filter 4.7 (5.0, 4.1)
Without filter 4.5 (4.8, 4.0)
See page ccclvi for detailed information. Engine coolant:
Capacity: 9.2 L (9.7 qt., 8.2 Imp. qt.)
Coolant type — “T oyota Super Long Life Coolant” or similar
high quality ethylene glycol based non −silicate, non− amine,
non−nitrite, and non −borate coolant with long −life hybrid
organic acid technology (Coolant with long −life hybrid
organic acid technology is a combination of low phosphates and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page ccclix
.
