2006 KIA Sephia headrest

317
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Driver’s seat
➀
Seat adjustment, forward / back-
ward (see page 3- 19)
➁
Seatback recliner (see page 3- 20)
➂
Seat adjustment, height(if equipped, see page 3- 19)
➃
Seat warmer(if equipped, see page 3- 21)
➄
Headrest adjustment (see page 3- 22)
Front passenger seat
\b
Seat adjustment, forward / back-
ward (see page 3- 23)
➆
Seatback recliner (see page 3- 24)
➇
Headrest adjustment (see page 3- 24)
Rear seat
➈
Split folding rear seat (if equipped, see page 3- 25)
\f
Headrest adjustment (if equipped, see page 3- 28)
SEAT
1LDN2026A
 Type A
 Type B
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 17

Knowing your vehicle22
3
1
2
3
4
5
6
7
8
9
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
Do not adjust the driver’s head-
rest while driving.
Headrest adjustment
Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist. Removal
To remove the headrest, raise it as
far as it can go then press the
release lever (
➀) while pulling
upward (
➁).
1LDA2033
1LDA2034
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 22

Knowing your vehicle24
3
1
2
3
4
5
6
7
8
9
Adjusting the seatback recliner
To recline the seatback:
1. Lean forward slightly and lift up on
the seatback recline lever located
on the outside of the seat, at the
rear.
2. Carefully lean back on the seat and adjust the seatback to the
position you desire.
3. Release the lever and make sure the seatback is locked in place.
(The lever MUST return to its orig-
inal position for the seatback to
lock.) Headrest adjustment
Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist.
WARNING
Riding in a vehicle with a front
seatback reclined could lead to
serious or fatal injury in an acci-
dent. If a front seat is reclined,
the occupant’s hips may slide
under the lap portion of the
safety belt applying great force
to the unprotected abdomen or
neck. Serious or fatal internal
injuries could result. Keep the
seatbacks in a comfortably
upright position whenever the
vehicle is in motion.
1LDA2036
1LDA2033A
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 24

325
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Removal
To remove the headrest, raise it as
far as it can go then press the
release button (
➀) while pulling
upward (
➁).
Rear seat Split folding rear seat (if equipped)
The rear seatbacks fold forward to
provide additional cargo space and
to provide access to the cargo area.
 To fold the rear seatback(s) down, pull the lock release lever, then fold
the seatback forward and down.
 To raise the seatback, lift and push it firmly until it clicks into place.
 When you return the seatback to its upright position, reposition the
rear safety belts so that they can
be used by rear seat passengers.
4 Door (if equipped)
1. Pull the lock release lever.
2. Move the rear center three-pointseat belts (if equipped) to the out-
side (
➀) so that they don’t interfere
with the seatback when lowering.
3. Fold the seatback forward and down firmly (
➁).
1LDA2034A
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
1LDN20381LDN3025
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 25

Knowing your vehicle26
3
1
2
3
4
5
6
7
8
9
5 Door (if equipped)
1. Lift the front of seat cushion (
➀)
up.
2. Lift the rear of seat cushion up (
➁). 3. Move the seat cushion firmly until
it clicks (
➂).
4. Remove the headrest and put the headrest poles into the holes on
the rear of the seat cushion (
➃). 5. Pull the lock release lever (
➄).
6. Fold the seatback forward and down firmly (
\b).
1LDA2239/1LDA2239A
1LDA2240
1LDA22431LDA2244
1LDA22411LDA2242
Type A
Type B
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 26

Knowing your vehicle28
3
1
2
3
4
5
6
7
8
9
Headrest adjustment (if equipped)
Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist. Removal
To remove the headrest, raise it as
far as it can go then press the
release lever (
➀) while pulling
upward (
➁).
1LDA2042
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
1LDA2043
CAUTION
 Make sure the engine is off, the transaxle is in P and the
parking brake is applied
whenever loading or unload-
ing cargo. Vehicle may move if
shift lever is inadvertently
moved to another position.
 Be careful when loading cargo through the rear passenger
seats to prevent damage to
the vehicle interior.
 When cargo is loaded through the rear passenger seats,
ensure the cargo is properly
secured to prevent it from
moving while driving.
Unsecured cargo in the pas-
senger compartment can
cause damage to the vehicle
or injury to it’s occupants.
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 28

Knowing your vehicle52
3
1
2
3
4
5
6
7
8
9
WARNING
- Child
restraint
Check that the child restraint
system is secure by pushing
and pulling it in different direc-
tions. Incorrectly fitted child
restraints may swing, twist, tip
or come away causing death or
injury.
Securing a child restraint seat
with “Tether Anchor” system
Child restraint hook holders are
located on the shelf or floor behind
the rear seats.
1. Open the tether anchor cover on the shelf or floor behind the rear
seats. 2. Route the child restraint seat strap
over the seatback.
For vehicles with adjustable head-
rest, route the tether strap under
the headrest and between the
headrest posts, otherwise route
the tether strap over the top of the
seatback.
3. Connect the tether strap hook to the correct child restraint hook
holder and tighten to secure the
seat.
2GHN3300A
WARNING
If the tether strap is secured
incorrectly, the child restraint
seat may not be restrained
properly in the event of a colli-
sion.
1LDN3200/1LDN3200A
4 Door5 Door
LD CAN (ENG) new 3-1~.qxd 7/29/05 10:28 AM Page 52
