2006 KIA AMANTI wheel

743
Maintenance
1
2
3
4
5
6
7
8
910
Checking a tire lifeIf any tires that are over 6 years
based on the manufacturing date,
tire strength and performance
decline with age naturally (even if the
tires are not used like a spare tire).
Therefore, the tires should be
replaced by new ones including the
spare tire. You can find the manufac-
turing date on the tire sidewall (pos-
sibly only on the inside of the wheel),
which has DOT marking. DOT is seri-
al numbers on tires, which consist of
a combination of numbers and
English letters. You can check the
manufacturing date to the last four
position of the DOT.
DOT : XXXX XXXX OOOO
The front part of the DOT means a
plant code number, tire size and
tread pattern and the last four num-
bers indicate week and year manu-
factured.
For example:
DOT XXXX XXXX 1602 represents
that the tire was produced in the 16th
week of 2002.
WARNING
A tire more than 6 years old may
cause separation of the cord
layers inside the tire leading to
loss of vehicle or a serious
injury. Therefore, make sure to
check the manufacturing date
and replace the old tire in 6
years after the tire manufactur-
ing date.
WARNING
- Tire temperature
The temperature grade for this
tire is established for a tire that
is properly inflated and not
overloaded. Excessive speed,
underinflation, or excessive
loading, either separately or in
combination, can cause heat
build-up and possible sudden
tires failure. This can cause loss
of vehicle control and serious
injury or death.

755
Maintenance
1
2
3
4
5
6
7
8
910
Bright-metal maintenanceTo remove road tar and insects,
use a tar remover, not a scraper or
other sharp object.
 To protect the surfaces of bright-
metal parts from corrosion, apply a
coating of wax or chrome preser-
vative and rub to a high luster.
 During winter weather or in coastal
areas, cover the bright metal parts
with a heavier coating of wax or
preservative. If necessary, coat the
parts with non-corrosive petroleum
jelly or other protective compound.
Underbody maintenanceCorrosive materials used for ice and
snow removal and dust control may
collect on the underbody. If these
materials are not removed, acceler-
ated rusting can occur on underbody
parts such as the fuel lines, frame,
floor pan and exhaust system, even
though they have been treated with
rust protection.
Thoroughly flush the vehicle under-
body and wheel openings with luke-
warm or cold water once a month,
after off-road driving and at the end
of each winter. Pay special attention
to these areas because it is difficult
to see all the mud and dirt. It will do
more harm than good to wet down
the road grime without removing it.
The lower edges of doors, rocker
panels, and frame members have
drain holes that should not be
allowed to clog with dirt; trapped
water in these areas can cause rust-
ing.
WARNING
After washing the vehicle, test
the brakes while driving slowly
to see if they have been affected
by water. If braking performance
is impaired, dry the brakes by
applying them lightly while
maintaining a slow forward
speed.

Maintenance56
7
1
2
3
4
5
6
7
8
910
Aluminum wheel maintenance The aluminum wheels are coated
with a clear protective finish.
 Do not use any abrasive cleaner,
polishing compound, solvent, or
wire brushes on aluminum wheels.
They may scratch or damage the
finish.
 Use only a mild soap or neutral
detergent, and rinse thoroughly
with water. Also, be sure to clean
the wheels after driving on salted
roads. This helps prevent corro-
sion.
 Avoid washing the wheels with
high-speed car wash brushes.
 Do not use any acid detergent. It
may damage and corrode the alu-
minum wheels coated with a clear
protective finish.

10
Specifications28
1
2
3
4
5
6
7
8
9
DimensionsWeights
Itemin (mm)
Overall length 196.0 (4,979)
Overall width 72.8 (1,850)
Overall height 58.5 (1,486)
Front tread 61.8 (1,570)
Rear tread 61.4 (1,560)
Wheelbase 110.2 (2,800)
SPECIFICATIONSThe specifications given here are for general information only. Please check with an authorized Kia dealer for more
precise and more up-to-date information.
Refer to the label describing GVWR & GAWR weights
attached to your vehicle.
(see page 5-21, Label information)

Specifications48
1
2
3
4
5
6
7
8
910
Gear ratio
Tires
ItemFrontRear
Tire size 225/60R16 98H 225/60R16 98H
30 (210) 30 (210)
Wheel size 6.5J x 16 6.5J x 16
Wheel lug nut torque 65~79 65~79
lb·ft (kg·m, N·m) (9~11, 88~107) (9~11, 88~107)
Inflation pressure
psi (kPa)
Engine Gasoline Engine
Gear Automatic transaxle
1st 3.789
2nd 2.057
3rd 1.421
4th 1.039
5th 0.731
Reverse 3.865
F.G.R 3.333

Index2
10Air Bag - Advanced Supplemental Restraint System . 3-60
Air Bag Warning Light . . . . . . . . . . . . . . . . . . . . . . . 3-81
Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-29
Air Conditioner (Specifications) . . . . . . . . . . . . . . . . 4-66
Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-30
Air Conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-63 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-62
System Operation Tips . . . . . . . . . . . . . . . . . . . . . . 4-64
Air Intake Control Button . . . . . . . . . . . . . . . . . . . . . 4-58
Alignment, Tire Balance and Wheel . . . . . . . . . . . . . 7-39
Aluminum Wheel Maintenance . . . . . . . . . . . . . . . . . 7-56
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-111
Anti-Lock Brake System . . . . . . . . . . . . . . . . . . . . . . 4-15 Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-36
Anti-Theft Steering Column Lock, Ignition Switch and . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Ashtray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-102
Automatic Climate Control System . . . . . . . . . . . . . . . . . . . . . 4-54
Headlight Aiming . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Power Window . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5, 7-25
Transaxle (Specifications) . . . . . . . . . . . . . . . . . . . . 8-5
Transaxle Fluid Level, Checking the . . . . . . . . . . . 7-25
Window Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Balance, Wheel Alignment and Tire . . . . . . . . . . . . . 7-39 Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-34
Recharging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-35
Service, for Best . . . . . . . . . . . . . . . . . . . . . . . . . . 7-35
Before Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Belts, Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Pre-tensioner, seat . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Blade Replacement, Windshield Wiper . . . . . . . . . . . 7-32
Blades, Wiper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-32
Body Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Brake Fluid Level, Checking . . . . . . . . . . . . . . . . . . . . . . 7-21
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13, 7-22
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
System, Anti-Lock . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Wear Indicators, Disc . . . . . . . . . . . . . . . . . . . . . . . 4-12
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
7-21 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Break-In Process, Vehicle . . . . . . . . . . . . . . . . . . . . . . 1-2
Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-44
Bulbs, Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
Capacities (Specifications) . . . . . . . . . . . . . . . . . . . . . 8-5
Capacity, Oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-17
Care of the Safety Belt System, Proper Use and . . . . . . . 3-47
Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-53
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 7-57
1
2
3
4
5
6
7
8
910
AB
C

Index6
10Label
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
Tire Specification/Pressure . . . . . . . . . . . . . . . . . . . 5-22
Vehicle Certification Number . . . . . . . . . . . . . . . . . 5-21
Lamp, door courtesy . . . . . . . . . . . . . . . . . . . . . . . . . 3-98
Lap/Shoulder Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-43 Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
Webbing, Cleaning the . . . . . . . . . . . . . . . . . . . . . . 7-57
Light Bulbs (Specifications) . . . . . . . . . . . . . . . . . . . . . . . 8-5
Bulb Replacement, Interior . . . . . . . . . . . . . . . . . . 7-47
Bulb Replacement, License Plate . . . . . . . . . . . . . . 7-58
Bulb Replacement, Rear Combination . . . . . . . . . . 7-48
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 3-97
Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-97
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . . . . . . . . 3-102
Lighting, Control . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Lights, interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-97
Locks From inside the vehicle, operating door . . . . . . . . . 3-11
From outside the vehicle, operating door . . . . . . . . . 3-9
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-9
Low Fuel Level Warning . . . . . . . . . . . . . . . . . . . . . . 4-39
Low Brake Fluid Level Warning . . . . . . . . . . . . . . . . 4-39
Lubricant Specifications . . . . . . . . . . . . . . . . . . . . . . 7-51
Lubricants and Fluids . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Lubrication, Body . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-28
Lumbar Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-23 Main Fuse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Aluminum Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . 7-56
Bright Metal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
Finish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-53
Normal - Schedule 1 . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-11
Severe - Schedule 1 . . . . . . . . . . . . . . . . . . . . . . . . . 7-8
Service, Scheduled . . . . . . . . . . . . . . . . . . . . . . . . . . 7-4
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Underbody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-55
When Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . 5-20
Malfunction Indicator . . . . . . . . . . . . . . . . . . . . . . . . 4-40
Mirror Day/Night Rearview . . . . . . . . . . . . . . . . . . . . . . . 3-94
Outside Rearview . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-92
Mode selection Button . . . . . . . . . . . . . . . . . . . . . . . 4-60
Modifications, Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Night, Driving at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
1
2
3
4
5
6
7
8
910
L
MNO

Index8
10Roadside Assistance, Emergency . . . . . . . . . . . . . . . . 9-2
Road Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Rocking the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
Rotation, Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38
Safety Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Into the auto lock mode . . . . . . . . . . . . . . . . . . . . . 3-53
Restraint System . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
System, Proper Use and Care of . . . . . . . . . . . . . . . 3-47
Warning Light and Chime . . . . . . . . . . . . . . . . . . . 3-42
Into the Auto Lock mode, placing a passenger . . . . 3-53
Safety Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Schedule 1- Normal Maintenance . . . . . . . . . . . . . . . . 7-5
Schedule 2- Service Maintenance . . . . . . . . . . . . . . . . 7-8
Scheduled Maintenance Service . . . . . . . . . . . . . . . . . 7-4
Seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . 3-18 Adjustment, Driver’s . . . . . . . . . . . . . . . . . . . . . . . 3-20
Adjusting the front passenger seat . . . . . . . . . . . . . 3-25
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
3-30
Severe maintenance schedule . . . . . . . . . . . . . . . . . . . 7-8
Snow Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Spare Tire Removing the . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-20
Special Driving Conditions . . . . . . . . . . . . . . . . . . . . . 5-7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2 Lubricant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-51
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34 Starting
Emergency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Jump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
6-4
The Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Steering Column Lock, Ignition Switch and Anti-Theft . . . . . 4-2
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18, 7-24
Wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18, 7-25
Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. 4-19
Storage Compartment . . . . . . . . . . . . . . . . . . . . . . . . 3-99
Suggestions for Economical Operation . . . . . . . . . . . . 5-6
Sunglass Holder . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-101
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-108
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-104
Switch, Ignition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-34
Temperature Control Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-56
Gauge, Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-35
Tie-down Hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-16
Tilt Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Tips On Driving Your Vehicle . . . . . . . . . . . . . . . . . . . . . 5-4
For Towing a Stuck Vehicle . . . . . . . . . . . . . . . . . . 6-19
Tire Balance, Wheel Alignment and . . . . . . . . . . . . . . . 7-39
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
7-37
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
1
2
3
4
5
6
7
8
910
S
T
