Safety Checks You Should Make Inside The
Vehicle
Seat Belts
Inspect the belt system periodically, checking for cuts,
frays and loose parts. Damaged parts must be replaced
immediately. Do not disassemble or modify the system.
Seat belt assemblies must be replaced after an accident if
they have been damaged (bent retractor, torn webbing,
pretensioners, etc.). If there is any question regarding belt
or retractor condition, replace the belt.
NOTE: The “Seat Belt Indicator Light” will remain on
until the driver’s seat belt is buckled.
Airbag Warning Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned on. If the bulb is not lit during starting, have the
system checked by an authorized dealer.
Defrosters
Check operation by selecting the defrost mode and place
the blower control on high speed. You should feel the air
directed against the windshield.
Safety Checks You Should Make Outside The
Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect for tread cuts or sidewall
cracks. Check wheel nuts for tightness and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of all exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73
2

▫Front Seat Adjustment — Recline ..........107
▫ Head Restraints ......................108
▫ Power Seat Adjuster — If Equipped ........109
▫ Heated Seats — If Equipped .............110
▫ 65/35 Split Folding Rear Seat .............111

To Open And Close The Hood .............114

Lights ...............................115
▫ Interior Lights .......................115
▫ Front Map/Reading Lights ..............116
▫ Multi-Function Control Lever .............116
▫ Parking Lights, Instrument Panel Lights, And
Headlights ..........................116
▫ High Beam/Low Beam Select Switch .......117 ▫
Passing Light ........................117
▫ Turn Signals .........................117
▫ Lights-On Reminder ...................118
▫ Battery Saver Feature — Exterior Lights .....118
▫ Fog Lights — If Equipped ...............118
▫ Daytime Running Lights — If Equipped .....118
▫ Light Bar — If Equipped ................119

Windshield Wipers And Washers ............121
▫ Windshield Washers ...................122
▫ Mist Feature .........................123
▫ Windshield Wiper Operation .............123
▫ Intermittent Wiper System ...............123

Tilt Steering Column ....................124
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Daytime Brightness Feature
Certain components (odometer, radio, etc.) can be illumi-
nated at full brightness during the daytime. This can be
helpful when driving with your headlights on during the
daytime such as in a parade or a funeral procession. To
activate this feature, rotate the multi-function control
lever one detent lower than the dome light.
Front Map/Reading Lights
These lights are mounted in the overhead console. Each
light can be turned on by pressing the recessed area of the
lens. To turn these lights off, press the recessed area of the
lens a second time.
Multi-Function Control Lever
The multi-function control lever controls the operation of
the park lights, headlights, headlight beam selection,
passing light, fog lights, instrument panel light dimming,
and turn signals.
Parking Lights, Instrument Panel Lights, and
Headlights
Turn the end cap of the multi-function control lever to the
first detent for parking lights and instrument panel
lights. Turn to the second detent for headlight operation.
Multi-Function Control Lever
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To change the brightness of the instrument panel lights,
rotate the center portion of the multi-function control
lever up or down.
High Beam/Low Beam Select Switch
Pull the multi-function control lever towards you to
switch the headlights to HIGH beam. Pull the multi-
function control lever a second time to switch the head-
lights to LOW beam. The “High Beam Indicator Light”
will illuminate when the high beams are on.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multi-function control lever toward
the steering wheel. This will cause the headlights to turn
on at high beam and remain on until the lever is released.
The “High Beam Indicator Light” will illuminate when
the high beams are on.
Turn Signals
Move the multi-function control lever up or down and
the arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the lever
partially up or down without moving beyond the detent.
If either light flashes at a very fast rate, check for a
defective outside light bulb. If an indicator fails to light
when the lever is moved, it would suggest that the fuse
or indicator is defective.
NOTE: A tone will chime if the turn signals are left on
for more than 2 miles (3.2 km).
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117
3

Lights-On Reminder
A chime will sound if the driver’s door is left open, and
the headlights or parking lights are left on.
Battery Saver Feature — Exterior Lights
If the park lights, headlights, fog lights, or high beams are
left on when the ignition switch is in the OFF position,
the battery saver feature will automatically turn off the
exterior lights after eight minutes. Normal operation will
resume when the ignition is turned ON or when the
switch is turned to another position.
Fog Lights — If Equipped
The front fog light switch is in the multi-function
control lever. To activate the front fog lights, turn
on the park or low beam headlights and pull out
the end of the lever. The “Fog Light Indicator Light” will
illuminate when the fog lights are on.
NOTE: The fog lights will only operate with the park
lights or the headlights on low beam. Selecting high
beam headlights will turn off the fog lights.
Daytime Running Lights — If Equipped
The headlights come on at a low intensity level after the
engine has started. They will turn off when the vehicle is
turned off, when the headlights are switched on, or when
the parking brake is set.
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

INSTRUMENT CLUSTER DESCRIPTION
1. Tachometer
Indicates the permissible engine revolutions-per-minute
for each gear range. Before reaching the red area, ease up
on the accelerator to prevent engine damage.
2. Turn Signal Indicator Light The arrows will flash in unison with the exterior
turn signals, when using the multi-function control
lever. A chime will sound if the turn signals are left on
continuously for 2 miles (3 km) until they are deacti-
vated.
3. High Beam Indicator Light This light shows that the headlights are on high
beam. Pull the multi-function control lever to-
wards the steering wheel to switch the headlights from
high to low beam. 4. Speedometer
Indicates vehicle speed.
5. Tire Pressure Monitoring Telltale Light
Each tire, including the spare (if provided),
should be checked monthly when cold and
inflated to the inflation pressure recommended
by the vehicle manufacturer on the vehicle
placard or tire inflation pressure label. (If your vehicle
has tires of a different size than the size indicated on the
vehicle placard or tire inflation pressure label, you should
determine the proper tire inflation pressure for those
tires.)
As an added safety feature, your vehicle has been
equipped with a tire pressure monitoring system (TPMS)
that illuminates a low tire pressure telltale when one or
more of your tires is significantly under-inflated. Accord-
ingly, when the low tire pressure telltale illuminates, you
should stop and check your tires as soon as possible, and
UNDERSTANDING YOUR INSTRUMENT PANEL 173
4

FUSE PANEL
Interior Fuses
The fuse panel is on the left side of the instrument panel.
A label is attached to the fuse panel cover to identify each
fuse for ease of replacement.
Cavity Fuse Description
1 15 Amp Blue Horn Relay, Power Sunroof Relay, Power Window Relay
2 10 Amp Red Rear Fog Lights (Export Only)
3 20 Amp Yellow Cigar Lighter
4 10 Amp Red Headlight Low Beam Right
5 10 Amp Red Headlight Low Beam Left
6 20 Amp Yellow Body Control Module/Power Door Locks
7 10 Amp Red Left Park Light/Left Tail Lamp/License Plate Lamp
8 Spare
9 10 Amp Red Right Park Light/RightTail Lamp/License Plate Lamp/
Cluster
10 Spare
11 15 Amp Blue Flasher
12 15 Amp Blue Stop Lights
Fuse Panel
MAINTAINING YOUR VEHICLE 349
7

Cavity Fuse Description
13 10 Amp Red Body Control Module/ CMTC/Cluster/Pass. Airbag
On,Off Indicator, Auto Day-
light Mirror/Light Bar
Switch (Renegade Only)
14 10 Amp Red PDC Fuel Pump/AC Clutch, Starter Relay/Engine
Controller/Transmission
Controller (Diesel Only)
15 Spare
16 20 Amp Yellow Power Outlet (Rear)
17 15 Amp Blue Rear Wiper
18 20 Amp Yellow Radio Choke & Relay
19 20 Amp Yellow Frt Fog Lights/Trailer Tow Stop and Turn Lights
20 Spare
21 10 Amp Red RadioCavity Fuse Description
22 20 Amp Yellow Power Sunroof Relay/ Antenna Module (Export
Only)
23 Spare
24 10 Amp Red PDC Blower Motor
25 10 Amp Red Heated Seat Switches/HVAC Control Head/Trailer Tow
Battery Charge
26 10 Amp Red Headlight High Beam Right
27 10 Amp Red Headlight High Beam Left
28 Spare
29 10 Amp Red Heated Mirrors/Rear Win- dow Defroster Indicator
30 15 Amp Blue Heated Seat Module
31 Spare
32 10 Amp Red Wiper Switch/Front and Rear Wipers
33 10 Amp Red SKIM Module/Data Link Connector
