2006 JEEP LIBERTY service schedule

Schedule “B” — Gasoline Engines
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F (0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
•Heavy loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert driving.
•If equipped for and operated with E-85 (ethanol) fuel.
NOTE: IfANY of these apply to you then change your
engine oil every 3,000 miles (5 000 km) or 3 months,
whichever comes first and follow “Schedule B” of the
“Maintenance Schedules” section of this manual.
NOTE: IfANY of these apply to you then flush and
replace your engine coolant/anti-freeze every 102,000
miles (170 000 km) or 60 months, whichever comes first,
and follow “Schedule B” of the “Maintenance Schedules”
section of this manual.
SCHEDULE “B” — GASOLINE ENGINES 369
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Drain and refill the transfer case fluid. X
Flush and replace the engine coolant/anti-freeze at
120 months, if not replaced at 102,000 miles (170
000 km). X
Inspection and service should be performed anytime a
malfunction is observed or suspected. Retain all receipts.
† Applies only if vehicle is used for frequent trailer
towing, or fleet/commercial service.
This maintenance is recommended by the manufac-
turer to the owner, but it is not required to maintain
emissions warranty. ‡Off-highway operation, trailer towing, taxi, limousine,
bus, snow plowing, or other types of commercial service
or prolonged operation with heavy loading, especially in
hot weather, require front and rear axle service indicated
witha‡in Schedule “B”. Perform these services if the
vehicle is usually operated under these conditions.
378 SCHEDULE “B” — GASOLINE ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 108,000 114,000 120,000
(Kilometers) (180 000) (190 000) (200 000)
[Months] [108] [114] [120]
Change the engine oil and engine oil filter. X X X
Rotate the tires. X X X
Inspect the engine air filter element, and replace if necessary. X
Replace the spark plugs. X
Inspect and replace the PCV valve, if necessary. X
Inspect the brake linings. X
Inspect the drive belt and replace as needed. Not required if pre-
viously replaced. XX
Flush and replace the engine coolant/anti-freeze if not done at
102,000 miles (170 000 km). X
Inspect the manual transmission fluid, add as necessary. X
Drain and refill the transfer case fluid. X
Inspection and service should be performed anytime a
malfunction is observed or suspected. Retain all receipts.
This maintenance is recommended by the manufac-
turer to the owner, but it is not required to maintain
emissions warranty.
SCHEDULE “A” — GASOLINE ENGINES 383
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

MAINTENANCE SCHEDULES — DIESEL ENGINES
There are two maintenance schedules that show the
required service for your vehicle.
First is Schedule B. It is for vehicles that are operated
under the conditions that are listed below and at the
beginning of the schedule.
•Day or night temperatures are below 32°F (0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
•Heavy loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert driving.
NOTE: Most vehicles are operated under the conditions
listed for Schedule “B.”
Second is Schedule “A”. It is for vehicles that are not
operated under any of the conditions listed under Sched-
ule “B.”
Use the schedule that best describes your driving condi-
tions. Where time and mileage are listed, follow the
interval that occurs first.
CAUTION!
Failure to perform the required maintenance items
may result in damage to the vehicle.
384 SCHEDULE “A” — GASOLINE ENGINES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Schedule “B” — Diesel Engines
Follow schedule “B” if you usually operate your vehicle
under one or more of the following conditions.
•Day or night temperatures are below 32°F (0°C).
•Stop and go driving.
•Extensive engine idling.
•Driving in dusty conditions.
•Short trips of less than 10 miles (16.2 km).
•More than 50% of your driving is at sustained high
speeds during hot weather, above 90°F (32°C).
•Trailer towing.
•Heavy loading.
•Taxi, police, or delivery service (commercial service).
•Off-road or desert driving.
386 SCHEDULE “B” — DIESEL ENGINES
8
M A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 68,750 75,000 81,250 87,500 93,750 100,000
(Kilometers) (110 000) (120 000) (130 000) (140 000) (150 000) (160 000)
Inspect the brake linings. X X
Drain and refill the front and rear axle fluid. X X
Applies only if vehicle is used for frequent trailer
towing, or fleet/commercial service.
† The replacement of such component is requested if
there is superficial wear, bearing clearance, or evident
grease leak. * This maintenance is not required if the belt was
previously replaced.
Inspection and service should be performed anytime a
malfunction is observed or suspected. Retain all receipts.
390 SCHEDULE “B” — DIESEL ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S

Miles 62,500 75,000 87,500 100,000
(Kilometers) (100 000) (120 000) (140 000) (160 000)
Change the engine oil and engine oil filter. XXXX
Inspect the engine air filter element. Replace as necessary. XX
Replace the engine air filter element. XX
Inspect the boost pressure solenoid filter. Replace as necessary. X X X
Replace the boost pressure solenoid filter, if not previously replaced. X
Replace the fuel filter/water separator unit. X X
Replace the engine timing belt, and idler pulleys. X
Inspect the engine timing belt tensioner, replace if necessary.† X
Flush and replace the engine coolant/anti-freeze. X
Replace the engine accessory drive belt. X
Inspect the brake linings. X X
Inspect the transmission fluid, add as necessary. X
Inspect the transfer case fluid. X
† The replacement of such component is requested if
there is superficial wear, bearing clearance, or evident
grease leak. Inspection and service should be performed anytime a
malfunction is observed or suspected. Retain all receipts.
392 SCHEDULE “A” — DIESEL ENGINES
8
M
A I
N T
E
N A
N C E
S
C
H E
D
U L
E
S
