Seat Belt Maintenance
Do not bleach, dye or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage will also weaken the fabric.
If the belts need cleaning, use MoparTotal Clean, a mild
soap solution, or lukewarm water. Do not remove the
belts from the vehicle to wash them.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
FUSE PANEL
Interior Fuses
The fuse panel is on the lower instrument panel just to
the left of the steering column.
Fuse Panel Location
MAINTAINING YOUR VEHICLE 381
7
Page 382 of 440
Cavity Fuse/Color Description
1 30 Amp Pink Audio Amp (B+)
2 15 Amp Blue Sunroof (B+)
3 10 Amp Red Htd Mirror (EBL)
4 20 Amp Yellow Rr Pwr Out (B+)
5 10 Amp Red Rr HVAC (R/O)
6 10 Amp Red OCM (B+)
7 20 Amp Yellow Door Locks (B+)
8 15 Amp Blue Steer Col Lock (B+)
9 20 Amp Yellow Pwr Outlet (B+)
10 10 Amp Red Ign Run Only Out (R/O)
11 Spare
12 10 Amp Red Mem. Sw, Courtesy Lamp
(B+)
13 Spare
14 20 Amp Yellow Cigar Ltr (R/A)
15 10 Amp Red Tire Press Mon (R/O)Cavity Fuse/Color Description
16 10 Amp Red SCM, Cluster OBD (B+)
17 15 Amp Blue Flipper Glass (B+)
19 10 Amp Red OCM (R/S)
20 10 Amp Red WCM, Cluster (R/S)
21 15 Amp Blue Autowipe (Accy Delay)
22 15 Amp Blue Rear Wiper (B+)
24 10 Amp Red PDC, FCM, A580 (R/S)
25 10 Amp Red ABS, Trans. Case Switch
(R/S)
CB1 20 Amp Cycle -Wipers (B+)
CB2 20 Amp Non - Cycle Seats (B+)
CB3 20 Amp Non - Cycle Windows (De-
lay)
382 MAINTAINING YOUR VEHICLE
Page 383 of 440
Underhood Fuses (Power Distribution Center)
Cavity Fuse/Color Description
1 40 Amp Green HVAC Blower
2 30 Amp Pink Power Outlets
3 30 Amp Pink Rr Wiper/Ign R/O
Cavity Fuse/Color Description
4 30 Amp Pink ABS Pump
5 50 Amp Red Cabin Htr 1 (Diesel Only)
6 50 Amp Red ASD
7 30 Amp Pink Rr HVAC (XK)
8 40 Amp Green Acc Delay/Seats
9 Spare
10 40 Amp Green Starter/JB Power
11 30 Amp Pink Cig Ltr/T-Tow
12 40 Amp Green EBL/Htd Mirror
13 40 Amp Green JB Power
14 50 Amp Red Cabin Htr 2 (Diesel Only)
15 50 Amp Red Cabin Htr 3 (Diesel Only)
16 25 Amp Natural IPM/Coils
17 Spare
18 20 Amp Yellow TCM/AC Clutch
19 20 Amp Yellow Ign Sw
Power Distribution Center
MAINTAINING YOUR VEHICLE 383
7
Page 384 of 440
Cavity Fuse/Color Description
20 20 Amp Yellow PCM Batt (Gasoline Only)
21 30 Amp Pink ABS Valves
22 Spare
23 20 Amp Yellow FDCM
24 20 Amp Yellow Fuel Pump
25 20 Amp Yellow FDCM/E-Diff.
26 15 Amp Blue Hyd/PCM (Diesel Only)
27 15 Amp Blue Brake/Stop Lamps
28 25 Amp Natural NGC/Injectors
29 Spare
30 Spare
31 Mini Relay Cabin Htr 1 Rly (Diesel
Only)
32 Micro Relay TCM Rly (Gasoline Only)
33 Micro Relay Starter Rly
34 Micro Relay AC Clutch RlyCavity Fuse/Color Description
35 Micro Relay Fuel Pump Rly
36 Mini Relay Cabin Htr 3 Rly (Diesel
Only)
38 Mini Relay Cabin Htr 2 Rly (Diesel
Only)
39 Mini Relay HVAC Blower Rly
40 Mini Relay ASD Rly
384 MAINTAINING YOUR VEHICLE
Page 385 of 440
Underhood Fuses (Integrated Power Module)
Cavity Fuse/Color Description
1 Micro Relay Wiper On/Off Rly
2 Micro Relay Wiper Hi/Lo Rly
3 Micro Relay Horn Rly
Cavity Fuse/Color Description
4 Micro Relay Rear Fog Rly (BUX Only)
5 Micro Relay Lt T-Tow Stop/Turn Rly
6 Micro Relay Rt T-Tow Stop/Turn Rly
7 Micro Relay Park Lamps Rly
8 10 Amp Red Lt Park Lamps
9 10 Amp Red T-Tow Park Lamps
10 10 Amp Red Rt Park Lamps
11 Mini Relay Rad Fan Hi Rly
12 20 Amp Yellow FCM Batt #4
13 20 Amp Yellow FCM Batt #2
14 20 Amp Yellow Adjustable Pedal
15 20 Amp Yellow Ft Fog Lamps
16 20 Amp Yellow Horn
17 20 Amp Yellow Rear Fogs
18 20 Amp Yellow FCM Batt #1
19 20 Amp Yellow Lt T-Tow Stop/Turn
Integrated Power Module
MAINTAINING YOUR VEHICLE 385
7
Page 386 of 440
Cavity Fuse/Color Description
20 20 Amp Yellow FCM Batt #3
21 20 Amp Yellow Rt T-Tow Stop/Turn
22 30 Amp Pink FDCM Mod
23 50 Amp Red Rad Fan
24 Mini Relay Rad Fan Lo Rly
25 Micro Relay Ft Fog Lamps Rly
26 Micro Relay Adjustable Pedal Rly
27 15 Amp Blue IOD #1
28 20 Amp Yellow IOD #2 (Audio)
29 10 Amp Red ORC (Ign R/.S)
30 10 Amp Red ORC (Ign R/O)VEHICLE STORAGE
