2006 INFINITI G35 mirror controls

HEADLIGHTS
Replacing the xenon headlight
bulb Xenon headlight bulb:
WARNING HIGH VOLTAGE
When xenon headlights are on, they produce
a high voltage. To prevent an electric shock,
never attempt to modify or disassemble. Al-
ways have your xenon headlights replaced
at an INFINITI dealer. For additional informa-
tion, see ªHeadlight and turn signal switchº
in the ª2. Instruments and controlsº section.
If replacement is required, see an INFINITI
dealer. EXTERIOR AND INTERIOR LIGHTS Item Wattage (W) Bulb No.
Front turn signal light* 21 T20
Front park light* 5 T10
Front side marker light 3.8 T10
Front fog light Sedan: 60/55
Coupe: 55 Sedan: H4
Coupe: H1
Rear combination light
Turn signal 21 T20
Stop/Tail* (LED) Ð
Side marker light* Sedan: (LED)/Coupe: 3.8 Sedan: Ð/Coupe: T10
Back-up light 18 T16
License plate light 5 T10
High-mounted stop light* (LED) Ð
Map light 8 Ð
Rear personal light (Sedan) 8 Ð
Step light 5 Ð
Trunk light 3.4 158
Vanity mirror light 1.32 Ð
*: See an INFINITI dealer for replacement.
Maintenance and do-it-yourself
8-33
w 06.1.4/V35-D/V5.0
X

TIRE PRESSURE
Tire pressure monitoring system
(TPMS) This vehicle is equipped with the tire
pressure monitoring system (TPMS). It
monitors tire pressure of all tires except
the spare. When the low tire pressure
warning light is lit, one or more of your
tires is significantly under-inflated.
The TPMS will activate only when the ve-
hicle is driven at speeds above 16 MPH
(25 km/h). Also, this system may not de-
tect a sudden drop in tire pressure (for
example a flat tire while driving).
For more details, refer to ªLow tire pres-
sure warning lightº in the ª2. Instruments
and controlsº section, ªTire pressure
monitoring system (TPMS)º in the ª5.
Starting and drivingº section, and ªFlat
tireº in the ª6. In case of emergencyº sec-
tion. Tire inflation pressure Check the tire pressure of the tires (in-
cluding the spare) often and always
prior to long distance trips. The recom-
mended tire pressure specifications are
shown on the F.M.V.S.S./C.M.V.S.S.
label or the Tire and Loading Informa-
tion label under the ªCOLD TIRE PRES-
SUREº heading. The Tire and Loading
Information label is affixed to the driver
side center pillar. Tire pressures should
be checked regularly because:
O Most tires naturally lose air over
time.
O Tires can lose air suddenly when
driven over potholes or other objects
or if the vehicle strikes a curb while
parking.
The tire pressures should be check
when the tires are cold. The tires are
considered COLD after the vehicle has
been parked for 3 or more hours, or
driven less than 1 mile (1.6 km) at mod-
erate speeds.SDI1779A
Vanity mirror light
SDI1401B
License plate light WHEELS AND TIRES
Maintenance and do-it-yourself
8-37
w 06.1.5/V35-D/V5.0
X

Installation on rear seat outboard or
center positions ........................................ 1-20
Precautions on child restraints .................. 1-18
Top tether strap anchor point locations ..... 1-27
Child safety ...................................................... 1-12
Child safety rear door lock................................. 3-5
Chimes
Audible reminders ..................................... 2-16
Seat belt warning light and chime ............. 2-13
Cigarette lighter and ashtray ........................... 2-30
Circuit breaker, Fusible link ............................. 8-26
Cleaning exterior and interior ..................... 7-2, 7-4
Clock ............................................................... 2-29
Clutch fluid ...................................................... 8-14
Coat hook ........................................................ 2-38
Cold weather driving........................................ 5-30
Command (See Bluetooth
Hands-Free Phone
System) ........................................................... 4-36
Compact Disc (CD) changer operation .............. 4-25
Compass display ............................................... 2-6
Console box .................................................... 2-36
Control panel buttons (models with navigation
system) ............................................................. 4-2
Controls
Control panel buttons (display with
navigation system)...................................... 4-2
Heater and air conditioner controls
(automatic) ................................................ 4-10
Steering wheel audio controls .................. 4-28
Coolant
Capacities and recommended fuel/
lubricants ................................................... 9-2
Changing engine coolant ............................ 8-9
Checking engine coolant level .................... 8-8 Corrosion protection .......................................... 7-5
Cruise control .................................................. 5-20
Cup holder....................................................... 2-32
Curtain side-impact air bag system (See
supplemental side air bag and curtain
side-impact air bag systems) ........................... 1-48
D
Daytime running light system .......................... 2-24
Defroster switch, Rear window and outside
mirror defroster switch .................................... 2-20
Dimensions and weights ................................... 9-9
Display controls (See control panel buttons),
With navigation system ..................................... 4-2
Door open warning light ................................... 2-11
Door Pockets .................................................... 2-31
Drive belts ....................................................... 8-19
Drive positioner, Automatic.............................. 3-34
Driving
All-wheel drive (AWD) safety precautions .... 5-6
Cold weather driving ................................. 5-30
Driving with automatic transmission ... 5-6, 5-12
Driving with manual transmission ....... 5-7, 5-16
Precautions when starting and driving ........ 5-2
E
Economy, Fuel.................................................. 5-22
Emission control information label ................... 9-12
Emission control system warranty ................... 9-24
Engine
Before starting the engine ......................... 5-10
Break-in schedule ..................................... 5-22 Capacities and recommended fuel/
lubricants ................................................... 9-2
Changing engine coolant ............................ 8-9
Changing engine oil and filter.................... 8-11
Checking engine coolant level .................... 8-8
Checking engine oil level .......................... 8-10
Coolant temperature gauge......................... 2-4
Engine block heater .................................. 5-32
Engine compartment check locations .......... 8-7
Engine cooling system ................................ 8-8
Engine oil .................................................. 8-10
Engine oil and oil filter recommendation..... 9-5
Engine oil viscosity ..................................... 9-5
Engine serial number ................................. 9-11
Engine specifications .................................. 9-8
If your vehicle overheats ............................ 6-11
Starting the engine .................................... 5-11
Entry/exit function, Automatic drive
positioner ........................................................ 3-34
Event data recorders........................................ 9-26
Exhaust gas (Carbon monoxide) ......................... 5-2
F
F.M.V.S.S./C.M.V.S.S. certification label ........... 9-11
Filter
Air cleaner housing filter .......................... 8-20
Changing engine oil and filter.................... 8-11
Flashers (See hazard warning flasher
switch) ............................................................. 2-25
Flat tire.............................................................. 6-2
Flat tire, Tire pressure monitoring system
(TPMS) ............................................................... 5-3
Flat towing....................................................... 9-22
10-2
w 06.1.5/V35-D/V5.0
X

Shifting
Automatic transmission ...................... 5-6, 5-12
Manual transmission .......................... 5-7, 5-16
Shoulder belt guide .......................................... 1-17
Shoulder belt height adjustment ...................... 1-16
Side air bag system (See supplemental side
air bag and curtain side-impact air bag
systems) .......................................................... 1-48
SNOW mode switch ......................................... 2-27
Spark plugs ..................................................... 8-19
Speedometer ..................................................... 2-3
Starting
Before starting the engine ......................... 5-10
Jump starting .............................................. 6-8
Precautions when starting and driving ........ 5-2
Push starting............................................. 6-10
Starting the engine .................................... 5-11
Status light, Front passenger air bag ............... 1-44
Steering
Power steering fluid .................................. 8-13
Power steering system .............................. 5-25
Rear active steer (RAS) system .................. 5-29
Steering wheel switch for audio
controls .................................................... 4-28
Tilting steering wheel................................ 3-30
Storage ............................................................ 2-31
Stowing golf bags............................................ 2-39
Sun shade ....................................................... 2-42
Sun visors ....................................................... 3-32
Sunglasses holder ........................................... 2-32
Sunroof ........................................................... 2-42
Automatic sunroof..................................... 2-42
Supplemental air bag warning labels ................ 1-51
Supplemental air bag warning light.......... 1-51, 2-14 Supplemental restraint system ......................... 1-36
Precautions on supplemental restraint
system ...................................................... 1-36
Supplemental side and curtain side-impact
air bag systems ............................................... 1-48
Switch
Autolight switch ........................................ 2-22
Fog light switch......................................... 2-25
Hazard warning flasher switch .................. 2-25
Headlight switch........................................ 2-21
Ignition switch (except Intelligent Key
system) ....................................................... 5-6
Ignition switch automatic transmission
models ............................................... 5-6, 5-12
Ignition switch manual transmission
models ............................................... 5-7, 5-16
Power door lock switch ............................... 3-4
Rear window and outside mirror defroster
switch ....................................................... 2-20
Steering wheel switch for audio control .... 4-28
Turn signal switch..................................... 2-24
Vehicle Dynamic Control (VDC) off
switch ....................................................... 2-28
T
Tachometer........................................................ 2-4
Temperature gauge, Engine coolant
temperature gauge ............................................ 2-4
Theft (INFINITI Vehicle Immobilizer System),
Engine start ..................................................... 2-18
Three way catalyst ............................................. 5-3
Tilting steering wheel ...................................... 3-30 Tire
Flat tire ....................................................... 6-2
Pressure, Low tire pressure warning
light .......................................................... 2-12
Tire pressure monitoring system (TPMS) ..... 5-3
Uniform tire quality grading ...................... 9-23
Tires
Spare tire ................................................. 8-48
Tire and Loading Information label ............ 9-12
Tire chains ................................................ 8-44
Tire dressing ............................................... 7-3
Tire pressure............................................. 8-37
Tire pressure monitoring system
(TPMS) ................................................. 5-3, 6-2
Tire rotation .............................................. 8-45
Types of tires ............................................ 8-43
Wheel/tire size ........................................... 9-9
Wheels and tires ....................................... 8-37
Top tether strap child restraints ....................... 1-26
Towing
Flat towing ................................................ 9-22
Tow truck towing ....................................... 6-12
Towing a trailer ......................................... 9-18
Towing load/specification chart................. 9-18
Towing safety ............................................ 9-19
TPMS, Tire pressure monitoring system ............. 5-3
Trailer towing ................................................... 9-18
Transceiver, HomeLink Universal
Transceiver ...................................................... 2-46
Transmission
Automatic transmission fluid (ATF)............. 8-13
Driving with automatic transmission ... 5-6, 5-12
Driving with manual transmission ....... 5-7, 5-16
Transmission selector lever lock release .... 5-15
10-6
w 06.1.4/V35-D/V5.0
X
