2006 INFINITI G35 brake fluid

1. Fuse/fusible link holder
2. Battery
3. Engine oil filler cap
4. Brake fluid reservoir
5. Clutch fluid reservoir (MT models)
6. Power steering fluid reservoir
7. Engine coolant reservoir
8. Window washer fluid reservoir
9. Radiator filler cap
10. Drive belts
11. Engine oil dipstick
12. Air cleaner
SSI0160ENGINE COMPARTMENT CHECK
LOCATIONS
Maintenance and do-it-yourself
8-7
w 06.1.4/V35-D/V5.0
X

CAUTIONO Do not overfill.
O Use Genuine NISSAN PSF or equivalent. For additional brake fluid specification in-
formation, refer to ªCapacities and recom-
mended fuel/lubricantsº in the ª9. Tech-
nical and consumer informationº section.
WARNING Use only new fluid. Old, inferior, or contami-
nated fluid may damage the brake system.
Do not add synthetic brake fluid. The use of
improper fluids can damage the brake
system and affect the vehicle's stopping
ability.
CAUTION Do not spill the fluid on any painted sur-
faces. This will damage the paint. If fluid is
spilled, immediately wash the surface with
water.
BRAKE FLUID Check the fluid level in the reservoir. If
the fluid is below the MIN line
q 2
or the
brake warning light comes on, add Genu-
ine Nissan Super Heavy Duty Brake Fluid
or equivalent DOT 3 fluid up to the MAX
line
q 1
. If fluid must be added frequently,
the system should be thoroughly checked
by an INFINITI dealer. SDI1923
BRAKE AND CLUTCH FLUID
8-14 Maintenance and do-it-yourself
w 06.1.4/V35-D/V5.0
X

CLUTCH FLUID Check the fluid level in the reservoir. If
the fluid level is below the MIN line
q 2
,
add Genuine Nissan Super Heavy Duty
Brake Fluid or equivalent DOT 3 fluid up to
the MAX line
q 1
.
If fluid is added frequently, the system
should be thoroughly checked by an
INFINITI dealer. WARNING Use only new fluid from a sealed container.
Old, inferior or contaminated fluid may dam-
age the clutch system.
CAUTION Do not spill the fluid on painted surfaces.
This will damage the paint. If fluid is spilled,
wash the surface with water.
Add fluid when the low washer fluid
warning light comes on. Pull up the cap
and add a washer solvent to the water for
better cleaning. In the winter season, add
a windshield washer antifreeze. Follow
the manufacturer's instructions for the
mixture ratio.
Recommended fluid is Genuine NISSAN
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.SDI1906A SDI1388B
WINDOW WASHER FLUID
Maintenance and do-it-yourself
8-15
w 06.1.4/V35-D/V5.0
X

1. Power steering fluid pump
2. Fan
3. Alternator
4. Crankshaft pulley
5. Air conditioner compressor
D : Tension checking points WARNING Be sure the ignition key is in the OFF or LOCK
position. The engine could rotate unexpect-
edly.
1. Visually inspect each belt for signs of
unusual wear, cuts, fraying, oil adhe-
sion or looseness. If the belt is in poor
condition or loose, have it replaced or
adjusted by an INFINITI dealer.
2. Have the belts checked regularly for
condition and tension in accordance
with the maintenance schedule in the
INFINITI Service and Maintenance
Guide.
WARNING Be sure the engine and ignition switch are
off and that the parking brake is engaged se-
curely.
CAUTION Be sure to use the correct socket to remove
the spark plugs. An incorrect socket can
damage the spark plugs.SDI1389
DRIVE BELTS SPARK PLUGS
Maintenance and do-it-yourself
8-19
w 06.1.4/V35-D/V5.0
X

The following are approximate capacities. The actual refill capacities may be slightly different. When refilling, follow the procedure in-
structed in the ª8. Maintenance and do-it-yourselfº section to determine the proper refill capacity. Capacity (Approximate)
Recommended
specificationsUS
measure Imp
measure Liter
Fuel*1 20 gal 16-5/8 gal 76
Engine oil (Drain and refill)*8
With oil filter change 5 qt 4-1/8 qt 4.7 O API Certification Mark*2, *3
O API grade SG/SH, Energy Conservin gI&IIorAPI grade SJ or SL, Energy Conserving*2, *3
O ILSAC grade GF-I, GF-II & GF-III*2, *3Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system
With reservoir 9-1/4 qt 7-5/8 qt 8.7
Genuine NISSAN Long Life Antifreeze/Coolant or equivalent
Reservoir 7/8 qt 3/5 qt 0.8
Automatic transmission fluid Ð Ð Ð Genuine NISSAN Matic J ATF*4
Manual transmission gear oil Ð Ð Ð Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85 or 75W-90
Differential gear oil Ð Ð Ð API GL-5, Viscosity SAE 80W-90*5
Transfer fluid Ð Ð Ð Genuine NISSAN Matic D ATF (Continental U.S. and Alaska) or CANADA NISSAN Automatic Trans-
mission Fluid*6
Power steering fluid (PSF) Refill to the proper fluid level according to the in-
structions in the ª8. Maintenance and do-it-yourselfº
section. Genuine NISSAN PSF or equivalent*10
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*7 or equivalent DOT 3
Multi-purpose grease Ð Ð Ð NLGI No. 2 (Lithium soap base)
Air conditioning system refrigerant Ð Ð Ð HFC-134a (R-134a)*9
Air conditioning system lubricants Ð Ð Ð NISSAN A/C System Oil Type S or exact equivalent
Windshield washer fluid Ð Ð Ð Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1: For additional information, see ªFuel recommendationº later in this section.
*2: For additional information, see ªEngine oil and oil filter recommendationº later in this section.
*3: For additional information, see ªRecommended SAE viscosity numberº later in this section.
*4: Using automatic transmission fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic transmission, which is not
covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures always above 32ÉF (0ÉC).
*6: DEXRON TM
III/MERCON TM
or equivalent may also be used. Outside the continental United States and Alaska contact an INFINITI dealer for more information regarding suitable fluids, including recommended
brand(s) of DEXRON TM
III/MERCON TM
automatic transmission fluid.
*7: Available in mainland US through an INFINITI dealer.
*8: For additional information, see ªEngine oilº in the ª8. Maintenance and do-it-yourselfº section for changing engine oil.
*9: For additional information, see ªVehicle identificationº later in this section for air conditioner specification label.
*10: For Canada, NISSAN Automatic Transmission Fluid (ATF), DEXRON TM
III/MERCON TM
or equivalent ATF may also be used.CAPACITIES AND RECOMMENDED
FUEL/LUBRICANTS
9-2 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

O Trailer towing requires more fuel than
normal circumstances.
O Avoid towing a trailer for the first 500
miles (800 km).
O Have your vehicle serviced more often
than at intervals specified in the rec-
ommended maintenance schedule in
the INFINITI Service and Maintenance
Guide.
O When making a turn, your trailer
wheels will be closer to the inside of
the turn than your vehicle wheels. To
compensate for this, make a larger
than normal turning radius during the
turn.
O Crosswinds and rough roads will ad-
versely affect vehicle/trailer handling,
possibly causing vehicle sway. When
being passed by larger vehicles, be
prepared for possible changes in
crosswinds that could affect vehicle
handling. If swaying does occur, firmly
grip the steering wheel, steer straight
ahead, and immediately (but gradu-
ally) reduce vehicle speed. This combi-
nation will help stabilize the vehicle.
Never increase speed. O Be careful when passing other vehicles.
Passing while towing a trailer requires
considerably more distance than normal
passing. Remember the length of the
trailer must also pass the other vehicle
before you can safely change lanes.
O To maintain engine braking efficiency
and electrical charging performance,
do not use sixth gear (manual trans-
mission) or fifth position (automatic
transmission).
O Avoid holding the brake pedal down
too long or too frequently. This could
cause the brakes to overheat, re-
sulting in reduced braking efficiency.
O Increase your following distance to al-
low for greater stopping distances
while towing a trailer. Anticipate stops
and brake gradually.
O Do not use cruise control while towing
a trailer.
O Check your hitch, trailer wiring har-
ness connections, and trailer wheel
lug nuts after 50 miles (80 km) of
travel and at every break.
O When stopped in traffic for long pe-
riods of time in hot weather, put the
vehicle in the P (Park) position. When towing a trailer, transmission
oil/fluid should be changed more fre-
quently.
For additional information, see the ª8.
Maintenance and do-it-yourselfº section
earlier in this manual.
FLAT TOWING Towing your vehicle with all four wheels
on the ground is sometimes called flat
towing. This method is sometimes used
when towing a vehicle behind a recre-
ational vehicle, such as a motor home.
CAUTION O Failure to follow these guidelines can re-
sult in severe transmission damage.
O Whenever flat towing your vehicle, al-
ways tow forward, never backward.
O DO NOT tow any automatic transmission
vehicle with all four wheels on the
ground (flat towing). Doing so WILL
DAMAGE internal transmission parts due
to lack of transmission lubrication.
9-22 Technical and consumer information
w 06.1.4/V35-D/V5.0
X

10 Index A
ABS (Anti-lock brake system) ........................... 5-26
Advanced air bag system ................................. 1-42
Air bag system
Front (See INFINITI advanced air bag
system) ..................................................... 1-42
Side and curtain (See supplemental side
air bag and curtain side-impact air bag
systems) ................................................... 1-48
Front passenger air bag and status light ... 1-44
Air bag warning labels ...................................... 1-51
Air bag warning light ................................ 1-51, 2-14
Air cleaner housing filter ................................. 8-20
Air conditioner
Air conditioner operation........................... 4-10
Air conditioner service ...................... 4-10, 4-14
Air conditioner specification label ............. 9-13
Air conditioning system refrigerant
and lubricant recommendations ......... 4-14, 9-7
Ambient temperature ................................. 4-13
Heater and air conditioner (automatic) ...... 4-10
In-cabin microfilter .................................... 4-13
Alcohol, drugs and driving ................................. 5-5
All-wheel drive (AWD)....................................... 5-23
All-wheel drive (AWD) warning light ................... 2-9
Anchor point locations
Top tether strap......................................... 1-27
Antenna ........................................................... 4-29 Anti-lock Brake System (ABS) .......................... 5-26
Anti-lock brake warning light ........................... 2-10
Appearance care
Exterior appearance care............................. 7-2
Interior appearance care ............................. 7-4
Armrest
Rear armrest pocket .................................. 2-37
Ashtray (See cigarette lighter and ashtray) ...... 2-30
Audible reminders ............................................ 2-16
Audio operation precautions ............................ 4-16
Audio system ................................................... 4-14
Steering wheel switch for audio control .... 4-28
Autochanger
Compact Disc (CD) .................................... 4-25
Autolight system.............................................. 2-22
Automatic
Anti-glare inside mirror ............................. 3-32
Automatic adjusting function ..................... 2-41
Automatic sunroof..................................... 2-42
Automatic transmission fluid (ATF)............. 8-13
Drive positioner ........................................ 3-34
Driving with automatic transmission ... 5-6, 5-12
Avoiding collision and rollover ........................... 5-5
B
Battery ............................................................. 8-16
Battery saver system................................. 2-23
Before starting the engine................................ 5-10 Belts (See drive belts) ...................................... 8-19
Bluetooth Hands-Free Phone System ............. 4-30
Booster seats ................................................... 1-31
Brake
Anti-lock brake system (ABS) .................... 5-26
Brake and clutch fluid ............................... 8-14
Brake booster ........................................... 8-24
Brake fluid ................................................ 8-14
Brake pedal .............................................. 8-23
Brake pedal check .................................... 8-23
Brake system ............................................ 5-26
Parking brake check ......................... 5-19, 8-23
Parking brake operation ............................ 5-19
Warning light ............................................ 2-10
Break-in schedule ............................................ 5-22
Brightness control, Instrument panel ............... 2-24
Bulb check/instrument panel............................. 2-9
Bulb replacement ............................................. 8-31
C
Capacities and recommended fuel/lubricants .... 9-2
Car phone or CB radio ..................................... 4-29
Card holder ..................................................... 2-38
CD care and cleaning ....................................... 4-27
Child restraints ................................................. 1-18
Booster seats ............................................. 1-31
Installation on front passenger seat .......... 1-28
w 06.1.5/V35-D/V5.0
X

Floor mat cleaning ............................................. 7-4
Fluid
Automatic transmission fluid (ATF)............. 8-13
Brake and clutch fluid ............................... 8-14
Brake fluid ................................................ 8-14
Capacities and recommended fuel/
lubricants ................................................... 9-2
Engine coolant............................................ 8-8
Engine oil .................................................. 8-10
Power steering fluid .................................. 8-13
Window washer fluid ................................. 8-15
FM-AM-SATELLITE radio with compact disc (CD)
changer ........................................................... 4-22
Fog light switch ............................................... 2-25
Front passenger air bag and status light.......... 1-44
Front power seat adjustment .............................. 1-2
Fuel
Capacities and recommended fuel/
lubricants ................................................... 9-2
Fuel economy ............................................ 5-22
Fuel economy information (display) ............ 4-4
Fuel-filler cap ............................................ 3-28
Fuel-filler door .......................................... 3-28
Fuel octane rating ....................................... 9-3
Fuel recommendation.................................. 9-3
Gauge ......................................................... 2-5
Fuses ............................................................... 8-25
Fusible links .................................................... 8-26
G
Garage door opener, HomeLink Universal
Transceiver ...................................................... 2-46
Gas cap ........................................................... 3-28 Gauge................................................................ 2-3
Engine coolant temperature gauge.............. 2-4
Fuel gauge .................................................. 2-5
Odometer.................................................... 2-3
Speedometer .............................................. 2-3
Tachometer ................................................. 2-4
General maintenance ......................................... 8-2
Glove box ........................................................ 2-35
Glove box (upper) ............................................ 2-35
Glove box lock ................................................. 2-35
Golf bag stowing ............................................. 2-39
H
Hands-Free Phone System, Bluetooth ............ 4-30
Hazard warning flasher switch ......................... 2-25
Head restraints .................................................. 1-8
Headlights
Bulb replacement...................................... 8-33
Headlight switch........................................ 2-21
Xenon headlights ...................................... 2-21
Heated seats ................................................... 2-26
Heater
Engine block heater .................................. 5-32
Heater and air conditioner (automatic) ...... 4-10
HomeLink Universal Transceiver .................... 2-46
Hood release ................................................... 3-24
Hook, Coat hook.............................................. 2-38
Horn ................................................................ 2-26
How to stop alarm, Vehicle security ................. 2-18 I
Ignition switch
(except Intelligent Key system) ................... 5-6
Automatic transmission models .......... 5-6, 5-12
Key positions .............................................. 5-8
Manual transmission models .............. 5-7, 5-16
Immobilizer system .......................................... 2-18
In-cabin microfilter ........................................... 4-13
Indicator lights ................................................. 2-14
INFINITI Vehicle Immobilizer System
Engine start ........................................ 5-8, 5-10
Inside
Automatic anti-glare mirror ....................... 3-32
Inspection/maintenance (I/M) test ................... 9-25
Instrument brightness control .......................... 2-24
Instrument panel ............................................... 2-2
Instrument pocket ............................................ 2-31
Intelligent Key system
Engine starting .......................................... 3-14
Key operating range .................................. 3-16
Key operation............................................. 3-11
Mechanical key and valet key ................... 3-23
Operating the engine................................. 3-14
Remote keyless operation ......................... 3-20
Trouble-shooting guide .............................. 3-19
Warning light............................................. 2-12
Warning signals ......................................... 3-17
Intelligent Key warning light............................. 2-12
Interior light replacement ................................ 8-33
Interior lights .................................................. 2-44
Interior trunk lid release .................................. 3-27
ISOFIX child restraint........................................ 1-25
10-3
w 06.1.5/V35-D/V5.0
X
