3 WHAT TO DO IN AN EMERGENCY
2
!
IF THE ENGINE WILL NOT START
D010A01A-AAT D010B02A-AAT
If Engine Doesn't Turn Over or Turns Over Slowly
1. If your car has an automatic transaxle, be sure the gear selector lever is in "N" or "P" and the emer-gency brake is set.
2. Check the battery connections to be
sure they are clean and tight.
3. Turn on the interior light. If the light dims or goes out when you operatethe starter, the battery is discharged.
4. Check the starter connections to be sure they are securely tightened.
5. Do not push or pull the vehicle to start it. See instructions for "Jump Starting". D010C01A-AAT If Engine Turns Over Normally but Does Not Start
D010B02E
WARNING:
If the engine will not start, do not push or pull the car to start it. This could result in a collision or causeother damage. In addition, push or pull starting may cause the cata- lytic converter to be overloaded andcreate a fire hazard.
1. Check fuel level.2. With the key in the "OFF" position,check all connectors at ignition coilsand spark plugs(For Gasoline En-gine) or check all connectors at glow plug and glow plug relay(For Diesel Engine). Reconnect any thatmay be disconnected or loose.
3. Check fuel line in the engine room.4. If engine still refuses to start, call a
Hyundai dealer or seek other quali- fied assistance. D010C01E

6 DO-IT-YOURSELF MAINTENANCE
2
6
7
8 9 10 11 12 13
1. Power steering fluid reservoir
2. Engine oil filler cap
3. Brake booster
4. Brake fluid reservoir
5. Clutch fluid reservoir (If installed) 6. Windshield washer fluid reservoir
cap
7. Engine coolant reservoir
8. Engine oil level dipstick
9. Radiator cap 10.Automatic transaxle fluid level
dipstick (If installed)
11.Air cleaner filter
12.Battery
13.Relay box G010B01E
G010B01E-GAT (1.6 DOHC)
CAUTION:
When inspecting or servic-
ing the engine, you should handle tools and other heavy objects carefully so that the plastic cover of theengine is not damaged.
!
ENGINE COMPARTMENT
1 2345

6
DO-IT-YOURSELF MAINTENANCE
3
G010C01E-GAT
(1.8 DOHC)
G010D01E
1. Power steering fluid reservoir
2. Engine oil filler cap
3. Brake booster
4. Brake fluid reservoir
5. Clutch fluid reservoir (If installed) 6. Windshield washer fluid reservoir
cap
7. Engine coolant reservoir
8. Engine oil level dipstick
9. Radiator cap 10.Automatic transaxle fluid level
dipstick (If installed)
11.Air cleaner filter
12.Battery
13.Relay box CAUTION:
When inspecting or servic-ing the engine, you shouldhandle tools and other heavy objects carefully so that the plastic cover of theengine is not damaged.
!
12 3
45
6 7 8 9 10 11 12 13

6 DO-IT-YOURSELF MAINTENANCE
4
1
2 34
5
1. Power steering fluid reservoir
2. Engine oil filler cap
3. Brake booster
4. Brake fluid reservoir
5. Clutch fluid reservoir (If installed) 6. Windshield washer fluid reservoir
cap
7. Engine coolant reservoir
8. Engine oil level dipstick
9. Radiator cap 10.Automatic transaxle fluid level dip-
stick (If installed)
11.Air cleaner filter
12.Battery
13.Relay box G010C02E
G010A01E-GAT (2.0 DOHC)
CAUTION:
When inspecting or servic-
ing the engine, you should handle tools and otherheavy objects carefully so that the plastic cover of the engine is not damaged.
!
6 7 8 9 10 11 12 13

6
DO-IT-YOURSELF MAINTENANCE
5
6 7 8 9 10 11 12 13 1
2 3
4 5
G010A02E
G010F01E-GAT
(2.0 DOHC CVVT)
CAUTION:
When inspecting or servic- ing the engine, you shouldhandle tools and other heavy objects carefully so that the plastic cover of theengine is not damaged.
!
1. Power steering fluid reservoir
2. Engine oil filler cap
3. Brake booster
4. Brake fluid reservoir
5. Clutch fluid reservoir (If installed) 6. Windshield washer fluid reservoir
cap
7. Engine coolant reservoir
8. Engine oil level dipstick
9. Radiator cap 10.Automatic transaxle fluid level dip-
stick (If installed)
11.Air cleaner filter
12.Battery
13.Relay box

6 DO-IT-YOURSELF MAINTENANCE
6
7 9 10 11
81
2
1. Radiator cap
2. Engine oil filler cap
3. Brake booster
4. Brake fluid reservoir 5. Fuel filter
6. Clutch fluid reservoir
7. Windshield washer fluid reservoir
8. Power steering fluid reservoir
9. Engine oil level dipstick
10.Air cleaner filter
11.Battery 12.Relay boxG010E01E
G010E01E-GAT
(DIESEL)
1 23
456
CAUTION:
When inspecting or servic-
ing the engine, you should handle tools and otherheavy objects carefully so that the plastic cover of the engine is not damaged.
!

6 DO-IT-YOURSELF MAINTENANCE
46FUSE PANEL DESCRIPTION
G200B01E-GAT Engine Compartment (Gasoline Engine)
G280B01E
NOTE: Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing. When you inspect the fuse box on your vehicle, refer to the fuse box label.
FUSE
RATING 120A
50A 20A20A 20A 40A30A 30A 30A15A10A 15A 20A15A 10A 15A15A 15A PROTECTED COMPONENTS
Generator
Fusible link (P/WDW), Tail lamp relay, Power connector
Condenser fan relay.1
Radiator fan relay
Generator, Engine control relay, Fuel pump relay, PCM
Ignition switch, Start relay ABS control (Motor) ABS control (Solenoid)
Blower relay Injectors
PCM, Heated oxygen sensor, SMATRA, Heater relay, Glow plug relayDRL control Head lamp washer
Front fog lamp relaySiren, PCM
A/C relay, Horn relay Head lamp (Hight)
Head lamp (Low)
BATT
BATT
COND RADECU
IGN
ABS.1
ABS.2
BLOWER INJ.
SNSR
DRL
H/LP WASHER F/FOG
ECU
HORN & A/C
H/LP (HI)
H/LP (LO)
FUSIBLE
LINK
FUSE
DESCRIPTION

6
DO-IT-YOURSELF MAINTENANCE
47
G280C01E
G200C01E-GAT
(Diesel Engine)
FUSE
RATING 120A50A 30A 30A30A 40A 30A30A 30A 80A60A 30A 30A15A 10A 15A20A 15A 10A15A 15A 15A PROTECTED COMPONENTS
Generator
Fusible link (P/WDW), Tail lamp relay, Power connector
Condenser fan relay.1
Radiator fan relay
Generator, Engine control relay, Fuel pump relay, PCM
Ignition switch, Start relay ABS control (Motor) ABS control (Solenoid)
Blower relay
Grow plug relay
Heater relay #1
Heater relay #2
Fuel filter relay Injectors
PCM, Heated oxygen sensor, SMATRA, Heater relay, Glow plug relay DRL control Head lamp washer
Front fog lamp relay Siren, PCM
A/C relay, Horn relayHead lamp (Hight)
Head lamp (Low)
BATT
BATT
COND RADECU
IGN
ABS.1
ABS.2
BLOWER
GLOW PLUG HEATER #1
HEATER #2
FUEL FILTER
INJ.
SNSR DRL
H/LP WASHER
F/FOGECU
HORN & A/C
H/LP (HI)
H/LP (LO)
FUSIBLE
LINK
FUSE
DESCRIPTION
