Make sure there are no objects
near the anchors that could
prevent a secure connection
between the child seat and the
anchors. Move the seat belt buckle or
tongue away f rom the lower
anchors.
To install a LATCH-compatible child
seat:
Place the child seat on the vehicle
seat, then attach the seat to the
lower anchors according to the
child seat maker’s instructions.
Your vehicle is equipped with
LATCH (lower anchors and tethers
f or children) at the outer second row
seats. The lower anchors are located
between the seat-back and seat
bottom, and are to be used only with
a child seat designed f or use with
LATCH.
The location of each lower anchor is
indicated by a small button above the
anchor point.
Some LATCH-compatible seats
have a rigid-type connector as
shown above.
1.
2. 3.
CONT INUED
Installing a Child Seat
Installing a Child Seat with
LATCH
Driver and Passenger Saf ety
47
LOWER
ANCHORS
BUTTON
Rigid-type

Make sure you have properly
completed the ‘‘Training
HomeLink’’ procedure.
Find the ‘‘training’’ button on your
garage door opener unit. The
location will vary, depending on
the manufacturer.Press and hold the button on
HomeLink f or 3 to 4 seconds.
PressandholdtheHomeLink
button again f or 3 to 4 seconds.
This should turn of f the training
indicator on the garage door
opener unit. (Some systems may
require you to press the button up
to three times.)
Press the HomeLink button again.
It should operate the garage door.
The ‘‘Training HomeLink’’
procedure trains HomeLink to the
proper garage door opener code.
The f ollowing procedure
synchronizes HomeLink to the
garage door opener so it sends and
receives the correct codes. For security purposes, newer garage
door opening systems use a ‘‘rolling’’
or variable code. Information from
theremotecontrolandthegarage
door opener are needed bef ore
HomeLink can operate the garage
door opener.
Press the training button on the
garage door opener unit until the
indicator next to the button comes
on. The indicator may blink, or
comeonandstayon.Youthen
have approximately 30 seconds to
complete the f ollowing steps.6.
2. 4.
5.
1. 3.
HomeL ink Universal Transceiver
T raining With a Rolling Code
System
182
TRAINING BUTTON

µ
µ
Î
ÎÎ Î
No.No. Amps.
Amps. Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16 20 A
20 A
20 A
20 A
10 A
20 A
20 A
15 A
15 A
10 A
20 A
7.5 A
7.5 A 20 A
20 A
15 A
10 A
7.5 A
7.5 A 10 A
15 A
7.5 A
7.5 A 10 A
7.5 A
7.5 A 30 A Fuel Pump
SRS
Heater Control, A/C Clutch
Relay, Cooling Fan Relay
Power Mirror, ABS
Daytime Running Light
ECU(PCM),CruiseControl
OPDS, Rear Wiper
ACC Relay
Back-up Lights, Instrument
Lights
Turn Signals
VTM-4
Front Wiper
Not used Driver’s Power Window
Driver’s Power Seat Reclining
Heated Seat
Driver’s Power Seat Sliding
Not used
Daytime Running Light
Driver’s side Rear Power
Window
Front Passenger’s Power
Window
Front Accessory Socket
Small Light
Interior Light
Power Door Lock
Back Up
Moonroof
Moonroof
Passenger’s Side Rear Power
Window
Canadian models
:
Canadian models
Fuse Locations
284
Driver’s Side INTERIOR FUSE BOX
Passenger’s Side
Front Front
:

...................
Radiator Overheating . 274
.............
Radio/CD Sound System . 115
...........................
Readiness Codes .296
...............................
Rear A/C Unit .113
............
Rear Audio Control Panel . 147
........
Rear Entertainment System . 142
..
Rear Lights, Bulb Replacement . 252
.
Rear View Camera and Monitor . 184
............................
Rear View Mirror .92
.................
Rear Window Def ogger . 77
.
Rear Window Wiper and Washer . 74
..........
Reclining the Seat Backs . 87-90
.............................
Reminder Lights .61
...............
Remoto Audio Controls . 138
.................
Remote Control (RES) . 169
.......................
Remote Transmitter .83
Replacement Inf ormation ................
Engine Oil and Filter . 240
.................................
Floor Mats .254
..........................................
Fuses .279
................................
Light Bulbs .248
........................................
Minder .235
................................
Timing Belt .245
...........................................
Tires .259 .............................
Wiper Blades .255
Replacing Seat Belts Af ter a ............................................
Crash .23
...
Reserve Tank, Engine Coolant . 189
...............................
Restraint, Child .38
..................
Reverse Gear Position . 201
................................
Rotation, Tire .259
......................................
Saf ety Belts .10
............
Safety Defects, Reporting . 302
.................................
Saf ety Features .9
.........................................
Airbags .11
.....................................
Seat Belts .10
.............
Saf ety Labels, Location of . 58
...............................
Saf ety Messages .ii
.........................................
Seat Belts .10
...............
Additional Information . 21
Automatic Seat Belt ...............................
Tensioners .23
.....................................
Cleaning .254
......................
Lap/Shoulder Belt .22
................................
Maintenance .23
Reminder Light and ................................
Beeper .21, 62 ...................
System Components . 25
...............
Use During Pregnancy . 19
...
Wearing a Lap/Shoulder Belt . 15
....................................
Seat Heaters .86
.................................................
Seats .87
............
Folding the Second Seat . 89
...............
Folding the Third Seat . 90
..........................
Head Restraints .91
.........
Reclining the Second Seat . 89
............
Reclining the Third Seat . 90
.......................
Third Seat Access .89
...................
Seats, Adjusting the . 87-90
............................
Security System .174
...............................
Serial Number .286
...........................
Service Intervals .229
.............................
Service Manual .303
.........
Service Station Procedures . 187
..........................
Setting the Clock .140
Shif ting the Automatic .............................
Transmission .200
.....
Shif t Lever Position Indicator . 200
........................
Shif t Lock Release .203
Side Marker Lights, Bulb .........................
Replacement in .249
..............................
Side Airbags .11, 31
..........................
Of f Indicator .34, 63
