2006 HONDA CIVIC HYBRID service indicator

µ
If you still do not perf orm the
indicated maintenance, you will see
negative mileage. It is displayed
when you drive more than 10 miles
(f or U.S. models) or 10 km (f or
Canadian models) af ter seeing the 0
percent message. Af terward, it
shows your driving distance if you
continue to drive. Immediately have
the indicated maintenance done by
your dealer.
When the remaining engine oil lif e is
0 percent, the engine oil lif e indicator
will blink. The display comes on
everytimeyouturntheignition
switch to the ON (II) position. When
you see this message, have the
indicated maintenance perf ormed by
your dealer as soon as possible. The maximum total mileage shown
is ‘‘ 9999.’’
When the engine oil lif e is 0 percent
or negative mileage, the
maintenance minder indicator
remainsonevenif youchangethe
inf ormation display.
Immediately have the service
perf ormed, and make sure to reset
the display as described on the next
page. You can change the inf ormation
display f rom the engine oil lif e
display to the odometer, the trip
meter, or the outside temperature
every time you press and release the
SEL/RESET button.
Maintenance Minder
Maint enance
181
——y
y
(#y
y

µ
µ
If theAutoIdleStopisactiveforan
extended period, the charging
system indicator may come on. If it
happens, start the engine.
The charging system indicator may
also come on if the Integrated Motor
Assist (IMA) battery charge drops
below a desired level and the engine
starts to recharge the battery.
This indicator may blink af ter you
start the vehicle in the morning
when the temperature is below 20
°F ( 30°C). It will stop blinking
when the IMA battery warms up.
If the charging system
indicator comes on brightly
when the engine is running,
the 12 volt battery is not being
charged.
Immediately turn of f all electrical
accessories. Try not to use other
electrically operated controls such as
the power windows and rear window
def ogger. Keep the engine running;
starting the engine will discharge the
battery rapidly.
Go to a service station or garage
where you can get technical
assistance.
Charging System Indicator
228
——y
y
(#y
y

If the ABS indicator comes on with
the brake system indicator, have
your vehicle inspected by your
dealer immediately.
However,
if the brake pedal does not
feel normal, you should take
immediate action. A problem in one
part of the system’s dual circuit
design will still give you braking at
two wheels. You will feel the brake
pedal go down much farther before
the vehicle begins to slow down, and
you will have to press harder on the
pedal.
Slow down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the long
distance needed to stop, it is
hazardous to drive the vehicle. You
should have it to wed and repaired as
soon as possible (see
on page ).
If you must drive the vehicle a short
distance in this condition, drive
slowly and carefully.
The
brake system
indicator normally
comes on when
you turn the ignition switch to the
ON (II) position and as a reminder to
check the parking brake. It will stay
on if you do not fully release the
parking brake.
If the brake system indicator comes
on while driving, the brake fluid level
is probably low. Press lightly on the
brake pedal to see if it feels normal.
If it does, check the brake fluid level
thenexttimeyoustopataservice
station (see page ).
If the f luid level is low, take your
vehicle to a dealer, and have the
brake system inspected f or leaks or
worn brake pads. If the brake system indicator
(amber) comes on with the parking
brake system indicator (red) with
the parking brake released, there
may be a malfunction with the
power-assist f eature. When the
power-assist f eature malf unctions,
the brake indicator (red) comes on
and a buzzer sounds f or a second.
The power-assist f eature may stop
when the brake ef f ect is weak. Stop
your vehicle immediately at a saf e
place and contact a dealer.
196
237Emergency
Towing
Brake System Indicator
230
Canada
U.S.
——y
y
(#yy

CONT INUED
BatteryCharging System ...........................
Indicator .57, 228
............................
Jump Starting .223
..............................
Maintenance .212
............................
Specif ications .243
..............................
Bef ore Driving .149
....................................
Belts,Seat .8,18
.............................
Beverage Holder .96
Brakes ...........
Anti-lock System (ABS) . 174
.............
Break-in, New Linings . 150
....................
Bulb Replacement .200
...........................................
Fluid .196
...................
Pad Wear Indicator . 174
.........................................
Parking .94
...........
System Indicator . 58, 63, 230
.............................
Braking System .173
.................
Break-in, New Vehicle . 150
..
Brightness Control, Instruments . 74
........................
Brights, Headlights .73
....................................
Accessories .156
ACCESSORY (Ignition Key .......................................
Position) .79
...............
Accessory Power Socket . 96
....................
Additives, Engine Oil . 190
...............................
Airbag (SRS) .9, 21
...
Airbags, Additional Information . 21
...
Additional Safety Precautions . 32
..........
AdvancedAirbagSystem . 28
.............................
Airbag Service .32
How the Passenger Airbag Of f ......................
Indicator Works .31
How the Side Airbag Of f ......................
Indicator Works .30
..
How the SRS Indicator Works . 30
How Your Front Airbags .........................................
Work .24
...
How Your Side Airbags Work . 28
How Your Side Curtain Airbags .........................................
Work .31
........................
SRS Components .21
..............
Air Conditioning System . 100
.......................
Air Pressure, Tires .208
......................................
Antif reeze .192 Anti-lock Brakes (ABS)
...............................
Indicator .59, 174
...................................
Operation .174
..............
Anti-thef t, Audio System . 142
Anti-thef t Steering Column ..............................................
Lock .79
........................................
Armrest .91
................................
Audio System .106
.....
Auto Door Locking/Unlocking . 81
.........................
Auto Door Locking .81
.....................
Auto Door Unlocking .83
........................
Auto Idle Stop .170, 171
...
Automatic Seat Belt Tensioners . 19
.............
Automatic Speed Control . 145
.
Automatic Transmission (CVT) . 166
..........................
Capacity,Fluid .242
...............
Checking Fluid Level . 195
.......................................
Shif ting .167
Shif t Lever Position ...............................
Indicators .166
................
Shif t Lever Positions . 167
....................
Shif t Lock Release . 169
Index
A B
INDEX
I
——y
y
(#yy

Î
Bulb Replacement..........................
Back-up Lights .201
.....................
Brake Lights .200, 201
........
Front Side Marker Lights .199
...........
Front Turn Signal Light .199
.................................
Headlights .197
..........................
Parking Lights .199
.........
Rear Side Marker Lights .200
..........
Rear Turn Signal Lights .200
............................
Specif ications .243
..............................
Bulbs, Halogen .197 ................
DANGER, Explanation of .ii
...................................
Dashboard .3, 56
................
Daytime Running Lights .73
.........
Def ects, Reporting Saf ety .254
........................
Def og and Def rost .103
................
Def ogger, Rear Window .75
..............
Def rosting the Windows .103
....................................
Dimensions .242
...............
Dimming the Headlights .73
Dipstick
..........
Automatic Transmission .195
..................................
Engine Oil .154
..........................
Directional Signals .73
Disc Brake Pad Wear
...................................
Indicators .173
.....................................
Disc Player .112
..................
Display Change Button .64
.....................
Disposal of Used Oil .192
Doors
.
Auto Door Locking/Unlocking .81
.....................
Auto Door Locking .81
.................
Auto Door Unlocking .83
..............
Locking and Unlocking .80
......................
Power Door Locks .80
.........................................
Card, PC .129
............................
Capacities Chart .242
.............
Carbon Monoxide Hazard . 52
.............................
Carrying Cargo .158
..............
CAUTION, Explanation of . ii
.......................................
CD Player .112
....................................
Ceiling Light .97
........................
Certif ication Label .240
............................................
Chains .211
....................
Changing a Flat Tire .217
Changing Oil ........................................
How to .190 ......................................
When to .179
...
Charging System Indicator . 62,228
..............
Check Fuel Cap Indicator . 68
............
Checklist, Bef ore Driving . 164
.....................................
Child Saf ety .34
Child Seats .............
LATCH Anchor System . 43
.............................
Lower Anchor .43
............................
Tether Anchor .46
..................
Childproof Door Locks . 81
.........................
Clock, Setting the .119
........................
CO in the Exhaust .247
............
Cold Weather, Starting in . 165
..............................
Compact Spare .216
.................
Consumer Inf ormation . 252
.............
Controls, Instruments and . 55
Coolant ........................................
Adding .192
....................................
Checking .154
.........................
Proper Solution .192
...................
Temperature Gauge . 67
Crankcase Emissions Control ........................................
System .247
............
Cruise Control Operation . 145
....
Customer Service Inf ormation . 252
Index
C D
II
——y
y
(#y
y

ÎÎ
...........
Protecting Larger Children .48
..................................
Saf ety Belts .8, 18
.........
Safety Defects, Reporting . 254
.................................
Saf ety Features .7
...........................................
Airbags .9
.......................................
Seat Belts .8
.............
Saf ety Labels, Location of . 53
...............................
Saf ety Messages .ii
.....................................
Seat Belts .8, 18
...............
Additional Information . 18
Automatic Seat Belt ...............................
Tensioners .19
................
Lap/Shoulder Belt . 14, 18
........................
Maintenance .20, 203
Reminder Light and ................................
Beeper .18, 59
...................
System Components . 18
...............
Use During Pregnancy . 16Wearing a Lap/Shoulder
.....................................
Belt .14, 18
........................
Seats, Adjusting the .89
............................
Security System .144
...............................
Serial Number .240
...........................
Service Intervals .185
...........................
Service Manual .255
.........
Service Station Procedures . 151
..........................
Setting the Clock .119
...
Shif t Lever Position Indicators . 166
........................
Shif t Lock Release .169
................................
Side Airbags .9 ,28
..........................
Of f Indicator .30, 59
......................
Side Curtain Airbags .29
Side Marker Lights, Bulb ..............................
Replacement .199
...............................
Signaling Turns .73
.....................................
Snow Tires .211
................................
Sound System .106
Spare Tire ......................................
Inf lating .216
............................
Specif ications .243
....................
Specif ications Charts . 242
................................
Speed Control .145
Speed-Sensitive Volume .......
Compensation (SVC) . 111, 124
...................
Radiator Overheating . 225
............
Radio/CD/Sound System . 106
Radio/CD/PC Card Sound ........................................
System .121
...................
Readiness Codes . 229, 250
Rear Lights, Bulb ......................
Replacement .200, 201
............................
Rear View Mirror .93
.................
Rear Window Def ogger . 75
................
Reclining the Seat-backs . 89
.............................
Reminder Lights .61
.......................
Remote Transmitter .87
Replacement Inf ormation ..............
Dust and Pollen Filter . 204
................
Engine Oil and Filter . 190
..........................................
Fuses .232
................................
Light Bulbs .197
................
Maintenance Minder . 179
...........................................
Tires .207
.............................
Wiper Blades .205
Replacing Seat Belts Af ter a ............................................
Crash .20 Reserve Tank, Engine
...............................
Coolant .153, 192
...............................
Restraint, Child .34
..................
Reverse Gear Position . 168
.................................
Potation, Tire .210
Index
R
S
VI
——y

y
(#yy

ÎÎ
CONT INUED
.........................................
Spotlights .63
..........
SRS, Additional Inf ormation .21
...
Additional Safety Precautions .32
.............................
Airbag Service .32
How the Passenger Airbag Of f
......................
Indicator Works .31
How the Side Airbag Of f ......................
Indicator Works .30
..
How the SRS Indicator Works .30
How Your Front Airbags
.........................................
Work .24
...
How Your Side Airbags Work .28
How Your Side Curtain
..........................
Airbags Work .29
........................
SRS Components .21
.............................
SRS Indicator .30,59
....
START (Ignition Key Position) .79
..............
State Emissions Testing .250
.......................
Starting the Engine .165
In Cold Weather at High ..................................
Altitude .165
................
With a Dead Battery . 223
........
Steam Coming f rom Engine . 225
Steering Wheel ..................................
Adjustment .75
.............
Anti-theft Column Lock . 79...................
Stereo Sound System . 106
....................
Storing Your Vehicle .213
Supplemental Restraint ..................................
System .9,21
......................................
Servicing .32
.........................
SRS Indicator .30 ,59
...................
System Components . 21
.........................................
SVC .111, 124
..................................
Synthetic Oil .190
Taillights, Changing ..................................
Bulbs .200, 201
.
Taking Care of the Unexpected . 215
Technical Descriptions ....
DOT Tire Quality Grading . 244
.....
Emissions Control Systems . 247
.....................
Oxygenated Fuels .150
..........
State Emissions Testing . 250
Three Way Catalytic ...............................
Converter .249
.................................
Tire Labeling .246
.......................
Temperature Gauge .67
..............
Tether Anchorage Points . 46
............................
Thef t Protection .142 ..
Three Way Catalytic Converter . 209
..........................
Time, Setting the .119
....................................
Tire Chains .211
.........
Tire, How to Change a Flat . 217
.........................
Tire Inf ormation .244
...............................................
Tires .207
..............................
Air Pressure .208
.........................
Checking Wear .209
..........................
Compact Spare .216
......
DOT Tire Quality Grading . 244
......................................
Inf lation .207
..................................
Inspection .209
..............................
Maintenance .209
...................................
Replacing .210
......................................
Rotating .210
...........................................
Snow .211
............................
Specif ications .243
................................
Tire Chains .211
...................
Tools, Tire Changing . 217
Towing .....................................
A Trailer .175
..................
Emergency Towing . 237
...........................
Traction Devices .211
Index
INDEX
T
VII
——y


y
(#yy
