HEADLAMP AND PANEL DIMMER CONTROLRotate the control clockwise one position from off to turn on the parking lamps.
Rotate two positions from off to also turn on the headlamps. Rotate counterclockwise
from off to activate autolamp (if equipped), which provides lightsensitive automatic
on/off control of the exterior lights and keeps them on for a short period of time after
the ignition is turned off. When the control is in any position except high beams or off, pull the control
toward you to activate the foglamps (if equipped).
Use the panel dimmer control, located to the right of the headlamp control, to adjust the brightness of
the instrument panel during the headlamps and parking lamps operation. Rotate to the full up position,
past the detent, to turn on the interior lamps. Rotate to the full down position, past the detent, to
prevent the interior lights from illuminating when doors are opened.
POWER ADJUSTABLE PEDALS (if equipped)
Press and hold the top end of rocker control to adjust the accelerator and brake
pedals away from you. Hold the lower end of the control to move the pedals toward
you. Adjust the pedals only when the vehicle is stopped and the gearshift lever is in
the P (Park) position.
If equipped with memoryfunction, the adjustable pedals, along with the driver's seat, can be
automatically positioned in two programmable positions using the control located on the driver's seat.
Refer to your Owner's Guide for instructions on how to use this memory feature.
SERVICE ENGINE SOON LAMPIlluminates briefly when the ignition is turned to the ON position, to ensure the
system is functional. If the light comes on after the engine is started, refer to your
Owner's Guide. This lamp will illuminate if the fuel cap is not fully secured. In addition,
"Check fuel cap" will appear in the message center display. Make sure that the fuel cap
is secure by turning it clockwise 1/4 of a turn until it stops.
ABS WARNING LAMPIlluminates briefly when the ignition is turned to the ON position. If the light
comes on after the engine is started, refer to your Owner's Guide.
SPEED CONTROL (if equipped)
To set the speed control, press the ON button and release. Accelerate to the
desired speed and press the SET button and release. Once the system is engaged, an
icon will appear in the instrument cluster. To increase speed, tap the SET button and the
speed will increase in small increments each time, or use the accelerator pedal to reach
desired speed and then press SET. To reduce speed, press and hold CST until desired
speed is reached. Release or tap the CSTbutton and speed will decrease in small
increments. Also, you can depress the brake pedal until desired speed is reached and press SET.Press
RES/RESUME to return the vehicle to a previously set speed if the vehicle is traveling more than 30
mph (48 km/h).
STEERING WHEEL CONTROLS (if equipped)
These controls allow you to operate features of the radio and climate control systems. Press to
select AM, FM1,FM2, TAPE, CD, FES/DVD, FES/AUX or SAT1, SAT2, or SAT3, if your vehicle is equipped
with these features. In AM, FM1 or FM2 mode, press SEEK to select preset stations or the next strong
station within the selected radio band. In satellite radio mode (if equipped), press SEEK to advance
through preset channels or subscribed channels. In CD mode, press SEEK to select the next selection on
the CD. In any mode, press VOL + or – to adjust volume. Press TEMP + or – to adjust temperature and
FAN + or – to adjust fan speed.
MESSAGE CENTER (if equipped)
With the ignition on, the message center displays important
vehicle information through a constant monitor of vehicle systems. The
system will notify you of potential vehicle problems by displaying
warnings, followed by a long indicator chime. You may select the INFO
or SETUP buttons on the message center to display trip odometer, odometer, compass, distance to
empty, average fuel economy, and trip elapsed drive time. The RESET button may be used to reset
selected functions in the INFO and SETUP menus. For more information about message center
functions, please refer to your Owner's Guide.
FOURWHEEL DRIVE CONTROL (if equipped)
2H (2WD HIGH) delivers power to the rear wheels only and is the optimal
position for smoothness and fuel economy. 4H (4x4 HIGH) provides mechanically
locked fourwheel drive power to all four wheels. 4L (4x4 LOW) provides mechanically
locked fourwheel drive when extra power at reduced speeds is required. With either
an electronic shift 4WD system or manual 4WD system, to shift from 2H to 4H move the control at any
forward speed up to 55 mph (88 km/h). To shift to or from 4L, bring the vehicle to a stop and keep the
brake pedal depressed. Next, place the gearshift in N (Neutral), and then move the control to or from 4L.
Some mechanical noise may be heard when the system engages. This is normal and no service is
required. Note: The manual 4WD system has an N (Neutral) position in the transfer case. This setting
overrides the transmission and puts the vehicle in Neutral regardless of gearshift position. This setting
should only be used when towing the vehicle.
INDASH CD6/MP3 DISC AUDIO SYSTEM (if equipped)
Please see reverse side for more details.
PASSENGER AIRBAG DEACTIVATED LAMP (if equipped)
Please refer to the Seating and Safety Restraints section of your Owner's Guide
for information on the Passenger Airbag Deactivated Lamp.
TRACTION ASSIST (if equipped)
The TCS switch has an indicator light that illuminates when the system is off. The
system will automatically turn on every time the ignition is turned off and on. For more
information, please see your Owner’s Guide.
AUXILIARY POWER POINT (12V)An auxiliary power point is located on the instrument panel. For SuperCab and
SuperCrew vehicles, there is an additional auxiliary power point located on the lower
rear side of the center console that is accessible from the rear seats. Do NOTplug
optional electrical accessories into the cigarette lighter.
REMOTE ENTRY SYSTEM(if equipped)Press this control once to lock all doors. Pressing the control a second time will chirp
the horn to confirm that all doors are closed and locked, and the parklamps will flash once.
Press this control once to unlock the driver's door and twice to unlock all doors.
Press this control to sound the panic alarm. To silence, press the control again, or
turn the ignition on.
The remote entrysystem can also control the memory feature (if equipped). Please refer
to your Owner's Guide for instructions on how to activate this feature.
KEYLESS ENTRY SYSTEM(if equipped)
With this control you can lock or unlock all doors without using a key.
Unlock all doors = Enter the fivedigit program code and then press 3 • 4
Lock all doors = Press 7 • 8 and 9 • 0 at the same time
DRIVER / PASSENGER BELTMINDER The BeltMinder feature is a supplemental warning to the safety belt warning function.
This feature provides additional reminders by intermittently sounding a chime and
illuminating the safety belt warninglamp in the instrument cluster when the driver's and
front passenger's safety belts are unbuckled. Both the driver's and front passenger's
safety belt usages are monitored and either may activate the BeltMinder feature.
REVERSE SENSING SYSTEM (RSS) (if equipped)
This sonar system sounds a tone to warn the driver of obstacles near the rear bumper
when the reverse gear is selected. Obstacles can be detected within approximately
6feet (2 m) behind the rear bumper while the vehicle moves in reverse at speeds less
than 3 mph (5 km/h). The reverse sensing system defaults to on, but can be disabled
by turning the ignition on, placing the gearshift in (R) Reverse and pressing the RSS
control.
An indicator light on the control, located next to the cigarette lighter, will illuminate when the system
is turned off.
TOWING INFORMATIONFor more details on towing with your vehicle, please refer to your Owner's Guide or request a copy
of the Ford Motor Company 2005 MY RV and Trailer Towing Guidefrom your dealer.
DOOR CONTROLS
The Ford F150: there’s nothing like it on earth. It’s the boldest, strongest, and most capable Ford F150
to roam the crowded street or climb a remote trail. Outside, its stance is firm. Inside, it initiates a new era
of truck design and comfort. Underneath, it is built on the strongest, most advanced F150 chassis and
suspension ever. And above all, it is Built Ford Tough. The F150 comes equipped with many new
features, some of which will require no explanation, while others may be new to you. This Quick
Reference Guide was designed to acquaint you with many of the features you will use most. This Quick
Reference Guide is not intended to replace the vehicle Owner’s Guide. Please refer to it for more detailed
information on your F 150.1
2
3
4
5
6
7
8
9
10
11
12
101112345876921
ADDITIONAL FEATURES
C OCKPIT FEATURES
