For versions with alloy rims
❒Insert the wheel on the hub and, using
the wrench provided, tighten the
bolts;
❒Lower the car and remove the jack;
❒Using the wrench provided, fully tigh-
ten the bolts in the sequence shown
in fig. 10;
❒Refit the snap-fitted wheel hub cap and
make sure that the reference hole on
the wheel is coinciding with the refe-
rence pin on the cap.
IMPORTANT Incorrect fitting may cause
the wheel cap to come off while the car
is travelling.When you have finished
❒Place the spacer;
❒Fit the jack partially open in its con-
tainer C-fig. 12forcing it lightly to
prevent it from vibrating when travel-
ling;
❒Put the tools back into their places in
the container; REFITTING THE STANDARD
WHEEL
Following the procedure described pre-
viously, raise the car and remove the spa-
re wheel.
For versions with steel rim
Proceed as follows:
❒Make sure the contact surfaces
between standard wheel and hub are
clean so that the fastening bolts will
not come loose;
❒Fit the standard wheel by inserting the
first bolt for two threads into the ho-
le closest to the inflation valve;
❒Fit the wheel cap making the groove
(on the wheel cap) coincide with the
inflation valve and fit the other four
bolts;
❒Using the wrench provided, tighten
the fastening bolts;
❒Lower the car and remove the jack;
❒Using the wrench provided, fully tigh-
ten the bolts in the sequence shown
previously.
fig. 10F0L201mfig. 11F0L0218m
Page 157 of 240

157
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
WHEN NEEDING TO
CHANGE A BULB
GENERAL INSTRUCTIONS
❒When a light is not working, check
that the corresponding fuse is intact
before changing a bulb. For the loca-
tion of fuses, refer to the paragraph “If
a fuse blows” in this section;
❒Before changing a bulb check the con-
tacts for oxidation;
❒Burnt bulbs must be replaced by
others of the same type and power;
❒Always check the height of the head-
light beam after changing a bulb.
❒Stow the container C-fig. 12, com-
plete with tools in the boot;
❒Place the space-saver spare wheel B-
fig. 11in the space provided for the
purpose inside the boot and secure it
with the clamping device A-fig. 11.
fig. 12F0L0219m
Halogen bulbs must be hand-
led touching only the metal-
lic part. If the transparent bulb
is touched with the fingers, its
lighting intensity is reduced and life of
the bulb may be compromised. If tou-
ched accidentally, rub the bulb with a
cloth moistened with alcohol and allow
to dry.
Modifications or repairs to
the electrical system (elec-
tronic control units) carried out in-
correctly and without bearing the fea-
tures of the system in mind can cau-
se malfunctions with the risk of fire.
WARNING
Halogen bulbs contain pres-
surised gas which, if broken,
may cause small fragments of glass to
be projected outwards.
WARNING
Page 158 of 240

158
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
TYPES OF BULBS fig. 13
Various types of bulbs are fitted to your
car:
AGlass bulbs: clipped into position. Pull
to remove.
BBayonet type bulbs: press the bulb,
turn counterclockwise to remove
this type of bulb from its holder.
CTubular bulbs: release them from
their contacts to remove.
D-EHalogen bulbs: to remove the bulb,
release the clip holding the bulb in
place.
FGas-discharge bulbs (Xenon).
F0L0072mfig. 13
Due to high voltage, the bulb
of (Xenon) gas-discharge
headlights must only be replaced by
experts: danger of death! Contact
Fiat Dealership.
WARNING
IMPORTANT The headlight inner surface
may be lightly misted over: this is not a
fault but a natural fact due to low tempe-
rature and the level of air humidity. It will
disappear as soon the headlights are tur-
ned on. The presence of drops inside the
headlights means water infiltration, the-
refore contact Fiat Dealership.
Page 159 of 240
159
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Bulbs Ref. Figure Type Power
Main beam headlights E H1 55W
Dipped beam headlights D H7 55W
Gas-discharge dipped beam headlights (where provided) F D2R 35W
Longlife front sidelights (2 per light) A W5W 5W
Front fog lights (where provided) E H1 55W
Front direction indicators B PY21W 21W
Side direction indicators A WY5W 5W
Rear direction indicators B R10W 10W
Taillights/brake lights B P21/5W 21W/5W
Third brake light (additional brake light) A W2,3W 2,3W
Page 160 of 240
160
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Bulbs Ref. Figure Type Power
Reversing light B P21W 21W
Rear fog lights B P21W 21W
Number plate lights C C5W 5W
Puddle / door lights A W5W 5W
Front roof light C C5W 5W
Rear roof light C C10W 10W
Glovebox light C C5W 5W
Boot light A W5W 5W
Sun visor lights C C5W 5W
Page 161 of 240
161
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
To change the bulbs of sidelights and main
beams, turn cap Bcounter-clockwise and
then remove it.The bulbs are arranged inside the light unit
as follows:
Cdirection indicators
Ddipped beam headlights
Esidelights
Fmain beam headlights
After replacement, refit the covers cor-
rectly checking that they are properly se-
cured.
IF AN EXTERIOR LIGHT
BURNS OUT
For the type of bulb and power rating, see
“When needing to change a bulb”.
FRONT LIGHT UNITS fig. 14-15
The front light units contain sidelights, dip-
ped beam, main beam and direction indi-
cator bulbs.
To change the bulbs of direction indica-
tors and dipped beams, turn cap Acoun-
ter-clockwise and then remove it.
fig. 14F0L0073mfig. 15F0L0074m
Page 162 of 240

162
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Gas-discharge lamps (Xenon)
(where provided)
IMPORTANT When gas-discharge bulbs
are provided, front fog lights are not fit-
ted.
MAIN BEAM HEADLIGHTS fig. 17
To change the bulb, proceed as follows:
❒remove the protecting cover by tur-
ning it counter-clockwise;
❒disconnect the electric connector A;
❒release the bulb holder catch B;
❒remove the bulb Cand replace it;
❒fit the new bulb, making the outline
of the metallic part coincide with the
grooves on the reflector, refit bulb
holder catch Aand reconnect the
electrical connector B;
❒refit the protective cover by turning it
clockwise and locking it properly. DIPPED BEAM HEADLIGHTS
fig. 16
Gas-filled filament lamps
To change the bulb, proceed as follows:
❒remove the protecting cover by tur-
ning it counter-clockwise;
❒disconnect the electric connector A;
❒release the bulb holder catch B;
❒remove the bulb Cand replace it;
❒fit the new bulb, making the outline
of the metallic part coincide with the
grooves on the reflector, refit bulb
holder catch Band reconnect the
electrical connector A;
❒refit the protective cover by turning it
clockwise and locking it properly.
fig. 16F0L0075m
Due to high voltage, the bulb
of (Xenon) gas-discharge
headlights must only be replaced by
experts: danger of death! Contact
Fiat Dealership.
WARNINGfig. 17F0L0076m
Page 163 of 240

163
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
Side fig. 19
To change the bulb, proceed as follows:
❒lever in the point shown by the arrow
to compress the catch and remove the
unit A;
❒turn the bulb holder Bcounter-
clockwise, remove the snap-fitted bulb
and replace it;
❒refit the bulb holder Bin the transpa-
rent cover, then position the unit
making sure the catch clicks into pla-
ce.FRONT FOG LIGHTS
(where provided)
IMPORTANT Contact Fiat Dealership to
have front fog lights replaced.
FRONT SIDELIGHTS fig. 20
To change the bulb, proceed as follows:
❒remove the protecting cover by tur-
ning it counter-clockwise;
❒remove the snap-fitted bulb holder A,
extract the bulb Band change it;
❒refit the snap-fitted bulb holder A;
❒refit the protective cover by turning it
clockwise and locking it properly. DIRECTION INDICATORS
Front fig. 18
To change the bulb, proceed as follows:
❒remove the protecting cover by tur-
ning it counter-clockwise;
❒turn the bulb holder Acounter-
clockwise and remove it;
❒remove the bulb Bpushing it gently
and turning counterclockwise (“bayo-
net”);
❒replace the bulb;
❒refit the bulb holder Aby turning it
clockwise and locking it properly;
❒refit the protective cover by turning it
clockwise and locking it properly.
fig. 18F0L0077mfig. 19F0L0082mfig. 20F0L0078m
