2006 DODGE STRATUS SEDAN Owners Manual

STARTING AND OPERATING
CONTENTS

Starting Procedures....................140
▫Automatic Transaxle...................140
▫Manual Transaxle.....................140
▫Normal Starting......................140
▫Extreme Cold Weather (Below -20°FOr
-29°C) .............................141
▫If Engine Fails To Start.................142
▫After Starting........................142

Battery And Engine Block Heaters
—If Equipped
........................142

Automatic Transaxle....................143
▫Brake/Transmission Interlock.............143▫Automatic Transaxle Ignition Interlock
System.............................144
▫Four Speed Automatic Transaxle..........145
▫Reset Mode.........................145
▫Gear Ranges For Four Speed Automatic
Transaxle...........................145

Parking Brake.........................147

Brake System.........................149
▫Anti-Lock Brake System (ABS)
—If Equipped.......................149

Power Steering........................150

Traction Control—If Equipped...........150
5

Tire Safety Information..................152
▫Tire Markings........................152
▫Tire Identification Number (TIN)..........154
▫Tire Loading And Tire Pressure...........156

Ti re s—General Information...............160
▫Tire Pressure.........................160
▫Tire Inflation Pressures.................161
▫Radial-Ply Tires......................163
▫Compact Spare Tire—If Equipped.........163
▫Limited Use Spare—If Equipped.........164
▫Tire Spinning........................164
▫Tread Wear Indicators..................165
▫Life Of Tire.........................166
▫Replacement Tires.....................166
▫Alignment And Balance.................167

Tire Chains...........................168

Snow Tires...........................168

Tire Rotation Recommendations...........168

AutoStick—If Equipped................169
▫AutoStick Operation...................170
▫AutoStick General Information............170

Fuel Requirements.....................171
▫Spark Knock.........................171
▫Reformulated Gasoline.................172
▫Gasoline/Oxygenate Blends..............172
▫MMT In Gasoline.....................173
▫Materials Added To Fuel................173
▫Fuel System Cautions..................173
▫Carbon Monoxide Warnings..............174

Flexible Fuel—(Fleet Vehicles Only)........175
▫E-85 General Information................175
▫Ethanol Fuel (E-85)....................175
138 STARTING AND OPERATING

▫Fuel Requirements....................175
▫Selection Of Engine Oil For Flexible Fuel
Vehicles (E-85) And Gasoline Vehicles.......176
▫Starting............................176
▫Cruising Range.......................176
▫Replacement Parts.....................176
▫Maintenance.........................176

Adding Fuel..........................177
▫Fuel Filler Cap (Gas Cap)...............177

Vehicle Loading.......................178

Trailer Towing........................178
▫Common Towing Definitions.............178
▫Trailer Hitch Classification...............180
▫Trailer Towing Weights (Maximum Trailer
Weight Ratings)......................181
▫Trailer And Tongue Weight..............181
▫Towing Requirements..................182
▫Towing Tips.........................186
STARTING AND OPERATING 139
5

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
CAUTION!
Long periods of engine idling, especially at high
engine speeds can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
Automatic Transaxle
The gear selector must be in the NEUTRAL or PARK
position before you can start the engine. Apply the brakes
before shifting to any driving gear.
Manual Transaxle
Fully apply the parking brake, press the clutch pedal to
the floor and place the gear selector in NEUTRAL before
starting the engine.
Normal Starting
Normal Starting of either a cold or a warm engine does
not require pumping or depressing the accelerator pedal.
Simply turn the key to the“START’”position and release
when the engine starts. If the engine has not started
within 3 seconds, slightly depress the accelerator pedal
while continuing to crank. If the engine fails to start
within 15 seconds, turn the key to the“OFF”position,
wait 10 to 15 seconds, then repeat the normal starting
procedure.
140 STARTING AND OPERATING

WARNING!
Never pour fuel or other flammable liquid into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in flash fire causing
serious personal injury.
CAUTION!
Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
axle cannot be started this way. Unburned fuel could
enter the catalytic converter and once the engine has
started, ignite and damage the converter and vehicle.
If the vehicle has a discharged battery, booster cables
may be used to obtain a start from another vehicle.
This type of start can be dangerous if done improp-
erly, so follow the procedure carefully. See section 6
of this manual for jump starting instructions.
Extreme Cold Weather (below -20°For-29°C)
To insure reliable starting at these temperatures, use of an
externally powered electric engine block heater and
battery blanket heater package (available from your
dealer) is recommended.
Ignition Key Positions
STARTING AND OPERATING 141
5

If Engine Fails to Start
If the engine fails to start after you have followed the
“NORMAL STARTING”or“EXTREME COLD
WEATHER”procedures, it may be flooded. Push the
accelerator pedal all the way to the floor and hold it there
while cranking the engine. This should clear any excess
fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
released. If this occurs, continue cranking with the accel-
erator pedal pushed all the way to the floor. Release the
accelerator pedal and the key once the engine is running
smoothly.If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the“NORMAL STARTING”or“EX-
TREME COLD WEATHER”procedure should be re-
peated.
After Starting
The idle speed will automatically decrease as the engine
warms up. At cooler ambient temperatures, the idle
speed for the 2.7L engine may increase during extended
idles for improved heater performance.
BATTERY AND ENGINE BLOCK HEATERS—If
EQUIPPED
The engine block heater warms engine coolant and
permits quicker starts in cold weather. Connect the cord
to a standard 110-115 volt AC electrical outlet with a
grounded, three wire extension cord. The engine block
heater cord is found under the hood near the air cleaner
housing.
142 STARTING AND OPERATING

WARNING!
Remember to disconnect the cord before driving.
Damage to the 110-115 volt AC electrical cord could
cause electrocution.
Use the heater when temperatures below 0°F (-18°C) are
expected to last for several days.
AUTOMATIC TRANSAXLE
Brake/Transmission Interlock
This interlock system prevents you from moving the gear
selector out of the Park position unless the brake pedal is
pressed. The system is active when the ignition switch is
in the RUN position.
WARNING!
Unintended movement of a vehicle could injure
those in and near the vehicle. As with all vehicles,
you should never exit a vehicle while the engine is
running. Before exiting a vehicle you should shift
the transmission into Park, remove the key from the
ignition, and apply the park brake. Once the key is
removed from the ignition the transmission shift
lever is locked in the Park position, securing the
vehicle against unwanted movement. Furthermore,
you should never leave children unattended inside a
vehicle. The following indicators should be used to
ensure that you have engaged the transmission shift
lever into the“Park”position:
•When shifting into Park, depress the button on
the shift lever and firmly move the lever all the
way forward until it stops.
•Look at the shift indicator window on the console
to ensure it is in the“P”position.
•When engaged in Park you will not be able to
move the shifter rearward without depressing the
shift lever button.
STARTING AND OPERATING 143
5

CAUTION!
Damage to the transaxle may occur if the following
precautions are not observed:
•Shift into PARK only after the vehicle has come to
a complete stop.
•Shift into or out of REVERSE only after the
vehicle has come to a complete stop and the
engine is at idle speed.
•Do not shift from REVERSE, PARK, or NEUTRAL
into any forward gear when the engine is above
idle speed.
•Before shifting into any gear, make sure your foot
is firmly on the brake pedal.
WARNING!
It is dangerous to shift the selector lever out of“P”or
“N”if the engine speed is higher than idle speed. If
your foot is not firmly on the brake pedal, the
vehicle could accelerate quickly forward or in re-
verse. You could lose control of the vehicle and hit
someone or something. Only shift into gear when
the engine is idling normally and when your right
foot is firmly on the brake pedal.
Automatic Transaxle Ignition Interlock System
This system prevents the key from being removed unless
the shift lever is in PARK and the shift knob push-button
is out. It also prevents shifting out of PARK unless the
key is in the OFF or RUN positions.
NOTE:If a malfunction occurs, the system may trap the
key in the ignition cylinder to warn you that this safety
feature is inoperable. The engine can be started and
stopped but the key cannot be removed until you obtain
service.
144 STARTING AND OPERATING
