2006 DODGE MAGNUM SRT low beam

Airbag Light
The light should come on and remain on for 6 to 8
seconds as a bulb check when the ignition switch is first
turned ON. If the LED is not lit during starting, have it
checked. If the light stays on or comes on while driving,
have the system checked by an authorized dealer.
Defroster
Check operation by selecting the defrost mode and place
the blower control on high speed. You should be able to
feel the air directed against the windshield.
Periodic Safety Checks You Should Make Outside
The Vehicle
Tires
Examine tires for excessive tread wear or uneven wear
patterns. Check for stones, nails, glass, or other objects
lodged in the tread. Inspect tread and sidewall for cuts or
cracks. Check wheel nuts for tightness, and tires (includ-
ing spare) for proper pressure.
Lights
Have someone observe the operation of exterior lights
while you work the controls. Check turn signal and high
beam indicator lights on the instrument panel.
Fluid Leaks
Check area under vehicle after overnight parking for fuel,
engine coolant, oil or other fluid leaks. Also, if gasoline
fumes are detected or fuel, power steering fluid or brake
fluid leaks are suspected, the cause should be located and
corrected immediately.
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

▫Lumbar Support.......................87
▫Heated Seats—If Equipped...............87
▫Head Restraints.......................88
▫Folding Rear Seat......................89

Adjustable Pedals — If Equipped...........90

To Open And Close The Hood.............91

Lights...............................92
▫Overhead Console Map/Reading Lights......92
▫Interior Lights........................92
▫Headlight Switch......................93
▫Multi-Function Lever....................94
▫Headlights, Parking Lights, Instrument Panel
Lights..............................94
▫Daytime Running Lights (Canada Only)......95
▫Lights-On Reminder....................95
▫Headlight Time Delay...................95▫Fog Lights — If Equipped................95
▫Turn Signals..........................95
▫Highbeam/Lowbeam Select Switch..........96
▫Flash To Pass.........................96

Windshield Wipers And Washers...........96
▫Windshield Wiper Operation — Front........96
▫Windshield Wiper Operation — Rear........97
▫Windshield Washers....................97
▫Adding Washer Fluid...................98

Tilt/Telescoping Steering Column...........99

Electronic Brake Control System............99
▫ABS (Anti-Lock Brake System).............99
▫TCS (Traction Control System)............100
▫BAS (Brake Assist System)...............100
▫ESP (Electronic Stability Program).........100
▫ESP/BAS Warning Lamp................103
60 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Daytime Running Lights (Canada Only)
The high beam headlights will come on as Daytime
Running Lights whenever the ignition switch is on, the
headlights are off, and the parking brake is off. The
headlight switch must be used for normal night time
driving.
Lights-on Reminder
If the headlights or parking lights are on after the ignition
is turned OFF, a chime will sound to alert the driver
when the driver’s door is opened.
Headlight Time Delay
This feature provides the safety of headlight illumination
for 90 seconds (programmable) when leaving your ve-
hicle in an unlighted area.
To activate the delay feature, turn off the ignition switch
while the headlights are still on. Then turn off the
headlights within 45 seconds. The 90 second delay inter-
val begins when headlight switch is turned off. If the
headlights or park lights are turned back on or the
ignition switch is turned on, the delay will be cancelled.If the headlights are turned off before the ignition, they
will turn off in the normal manner.
NOTE:The lights must be turned off within 45 seconds
of turning the ignition off to activate this feature
The Headlamp delay time is programmable on vehicles
equipped with the Electronic Vehicle Information Center
(EVIC). Refer to “Delay Turning Headlamps Off” in the
Electronic Vehicle Information Center section for details.
Fog Lights — If Equipped
The front fog light switch is on the headlamp
switch below the dimmer control. To activate the
front fog lights, turn on the parking lights or the
low beam headlights and press the fog lamp switch.
NOTE:The fog lights will operate with the low beam
headlights, or parking lights on. However, selecting the
high beam headlights will turn off the fog lights.
Turn Signals
Move the Multi-Function Lever up or down and the
arrows on each side of the instrument cluster flash to
show proper operation of the front and rear turn signal
lights. You can signal a lane change by moving the lever
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95
3

partially up or down without moving beyond the detent.
Releasing the lever at the detent will provide 3 flashes.
If either light has a very fast flash rate, check for a
defective outside light bulb. If an indicator fails to light
when the lever is moved, it would suggest that the fuse
or indicator bulb is defective or there may be a circuit
failure.
NOTE:The message “Turn Signal On” will appear in
the electronic vehicle information center (EVIC) — if
equipped, and a continuous chime will be heard when
the vehicle has been driven more than 1 mile (1.6 km)
with either turn signal on.
Highbeam/Lowbeam Select Switch
Push the Multi-Function Lever away from you to switch
the headlights to HIGH beam. Pull the Lever towards
you to switch the headlights back to LOW beam.
Flash to Pass
You can signal another vehicle with your headlights by
lightly pulling the Multi-Function Lever toward you.
This will cause the headlights to turn on at high beam
and remain on until the lever is released.
WINDSHIELD WIPERS AND WASHERS
Windshield Wiper Operation — Front
The front wipers and washers are operated by the
multi-function lever. The lever is located on the
left side of the steering column. Rotate the end of
the control lever to select the desired wiper speed.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle, with a variable pause be-
tween cycles, desirable. Rotate the end of the lever to the
Windshield Wiper/Washer
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

14. Oil Pressure Warning Light
This light shows low engine oil pressure. The
light should turn on momentarily when the
engine is started. If the light turns on while driving,
stop the vehicle and shut off the engine as soon as
possible. A continuous chime will sound when this
light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked using the procedure
shown in section 7. (See page 267 for more information.)
15. High Beam Light
This light shows that the headlights are on high
beam. Push the Multi-Function lever away from
the steering wheel to switch the headlights to high
beam.
16. Seat Belt Reminder Light
When the ignition switch is first turned ON, this
light will turn on for 5 to 8 seconds as a bulb
check. During the bulb check, if the driver’s or
front passenger’s seat belt is unbuckled, a chime will
sound. After the bulb check or when driving, if thedriver’s or front passenger’s seat belt remains unbuck-
led, the Seat Belt Warning Light will flash or remain on
continuously. (See page 33 for more information.)
17. Transmission Range Indicator
This display indicator shows the automatic transmission
gear selection.
18. Front Fog Light Indicator — If Equipped
This light shows the front fog lights are ON.
(See page 95 for more information.)
19. Electronic Vehicle Information Center Display
When the appropriate conditions exist, this display
shows the Electronic Vehicle Information Center (EVIC)
messages. (See page 140 for more information.)
20. Brake System Warning Light
This light monitors various brake functions,
including brake fluid level and parking
brake application. If the brake light turns on,
it may indicate that the parking brake is
applied, there is a low brake fluid level or there is a
problem with the anti-lock brake system.
UNDERSTANDING YOUR INSTRUMENT PANEL 137
4

▫Windshield Washers/Headlight Washers.....277
▫Exhaust System......................277
▫Cooling System.......................278
▫Hoses And Vacuum/Vapor Harnesses.......283
▫Brakes.............................283
▫Brake Fluid Level Check................284
▫Fuel System Hoses....................285
▫Automatic Transmission................286
▫Front And Rear Wheel Bearings...........287
▫Appearance Care And Protection From
Corrosion...........................287
▫Cleaning The Center Console Cup Holders . . . 290

Power Distribution Centers...............290
▫Front Power Distribution Center...........290▫Rear Power Distribution Center...........293

Vehicle Storage........................296

Replacement Light Bulbs................296

Bulb Replacement......................297
▫Low Beam Headlamp, High Beam Headlamp,
And Park/Turn Lamp..................297
▫Tail/Stop, Turn Signal Lamp, And Backup
Lamp..............................299
▫License Lamp........................301

Fluids And Capacities...................302

Fluids, Lubricants And Genuine Parts.......303
▫Engine.............................303
▫Chassis............................303
262 MAINTAINING YOUR VEHICLE

CAUTION!
•When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.
•When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
Front Power Distribution Center Fuses
Cavity Fuse Circuits
1 20 Amp
YellowLeft High Beam Headlight
2 20 Amp
YellowRight High Beam Headlight
3 15 Amp
Dk. BlueAdjustable Pedal
4 20 Amp
YellowHorn
5 25 Amp
ClearHeadlamp Washer — If
Equipped
6 15 Amp
Dk. BlueFront Control Module (FCM)
7 20 Amp
YellowFog Lamp
8 15 Amp
Dk. BluePark Lamp
9 15 Amp
Dk. BlueNon ABS Brakes
10 5 Amp
OrangeStarter
MAINTAINING YOUR VEHICLE 291
7

Cavity Fuse Circuits
11 20 Amp
YellowAuto Shutdown/Powertrain
Control Module (PCM)
12——
13——
14 25 Amp
ClearPowertrain Control Module
15 20 Amp
YellowInjectors, Ignition Coils
16 15 Amp
Dk. BluePowertrain Control Module
17 30 Amp
PinkAntilock Brake System (ABS)
Valves
18 30 Amp
PinkWindshield Wiper/Washer
19 50 Amp
RedRadiator Fan
20 20 Amp
Lt. BlueStarter
21 50 Amp
RedABS Pump MotorCavity Fuse Circuits
22 40 Amp
GreenRadiator Fan High/Low
23 50 Amp
RedHigh Intensity Lighting
24 60 Amp
YellowRadiator Fan
25 30 Amp
PinkLighting Left High Beam/
Right Low Beam
26 20 Amp
Lt. BlueTransmission
27 30 Amp
PinkLighting Left Low Beam/
Right High Beam
