WARNING!
•Do not attempt to push or tow your vehicle to get
it started. Vehicles equipped with an automatic
transmission cannot be started this way. Un-
burned fuel could enter the catalytic converter and
once the engine has started, ignite and damage the
converter and vehicle. If the vehicle has a dis-
charged battery, booster cables may be used to
obtain a start from a booster battery or the battery
in another vehicle. This type of start can be
dangerous if done improperly. See section 6 of
this manual for the proper jump starting proce-
dures and follow them carefully.
•Never pour fuel or other flammable liquid into
the throttle body air inlet opening in an attempt to
start the vehicle. This could result in flash fire
causing serious personal injury.
If Engine Fails to Start
If the engine fails to start after you have followed the
“NORMAL STARTING”procedure, it may be flooded.Push the accelerator pedal all the way to the floor and
hold it there while cranking the engine. This should clear
any excess fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
released. If this occurs, continue cranking up to 15
seconds with the accelerator pedal pushed all the way to
the floor. Release the accelerator pedal and the key once
the engine is running smoothly. Do not overspeed en-
gine.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the“NORMAL STARTING”procedure
should be repeated.
STARTING AND OPERATING 203
5

WHAT TO DO IN EMERGENCIES
CONTENTS

Hazard Warning Flasher.................268

If Your Engine Overheats................268

Jacking And Tire Changing...............269
▫Preparations For Jacking................270
▫Jack Location/Spare Tire Stowage..........271
▫Jacking And Changing a Tire.............273
▫Compact Spare Tire-For Temporary Emergency
Use Only...........................276
▫Wheel Cover Installation (If Required)......277

Jump-Starting Procedures If Battery Is Low...277

Driving On Slippery Surfaces.............279▫Acceleration.........................279
▫Traction............................279

Freeing A Stuck Vehicle.................280

Towing A Disabled Vehicle...............281
▫With Ignition Key.....................281
▫Without The Ignition Key...............282
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................282
▫Towing This Vehicle Behind Another Vehicle
With A Tow Dolly.....................2826

Wheel Cover Installation (If Required)
1. Tighten the two lug nuts on the mounting studs on
each side of the stud which is in alignment with the valve
stem.
2. Align the valve notch in the wheel cover with the
valve stem on the wheel.3. Install the cover by hand, snapping the cover over the
two lug nuts. Do not use a hammer or excessive force to
install the cover.
4. Return to Changing a Tire Section, Item #9 above.
JUMP-STARTING PROCEDURES IF BATTERY IS
LOW
WARNING!
Take care to avoid the radiator cooling fan whenever
the hood is raised. It can start anytime the ignition
switch is on. You can be hurt by the fan.
WHAT TO DO IN EMERGENCIES 277
6

WARNING!
•Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
mission cannot be started this way. Unburned fuel
could enter the catalytic converter and once the engine
has started, ignite and damage the converter and
vehicle. If the vehicle has a discharged battery, booster
cables may be used to obtain a start from another
vehicle. This type of start can be dangerous if done
improperly, so follow this procedure carefully.
•Battery fluid is a corrosive acid solution; do not
allow battery fluid to contact eyes, skin or clothing.
Don’t lean over battery when attaching clamps or
allow the clamps to touch each other. If acid splashes
in eyes or on skin, flush contaminated area immedi-
ately with large quantities of water.
•A battery generates hydrogen gas which is flam-
mable and explosive. Keep flame or spark away from
the vent holes. Do not use a booster battery or any
other booster source with an output that exceeds 12
volts.
•The battery in this vehicle has a vent hose that
should not be disconnected and should only be
replaced with a battery of the same type (vented).
NOTE:The battery is stored under an access cover
under the rear cargo floor. Remote battery terminals are
located in the engine compartment for jump starting.
1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
inadvertent electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach and
without letting the vehicles touch. Set the parking brake,
place the automatic transmission in PARK and turn the
ignition switch to the OFF (or LOCK) position for both
vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. Connect one end of the jumper cable to the remote
jump start positive battery post (A) in the engine com-
partment. Connect the other end of the same cable to the
positive terminal of the booster battery. Refer to the
following illustration for jump starting connections.
5. Connect the other cable, first to the negative terminal
of the booster battery andthen to the engine ground (B)
278 WHAT TO DO IN EMERGENCIES

of the vehicle with the discharged battery.Make sure
you have a good contact on the engine ground. Refer to
the following illustration for jump starting connections.
6. Start the engine in the vehicle which has the booster
battery, let the engine idle a few minutes, then start the
engine in the vehicle with the discharged battery.
7. When removing the jumper cables, reverse the above
sequence exactly. Be careful of the moving belts and fan.DRIVING ON SLIPPERY SURFACES
Acceleration
Rapid acceleration on snow covered, wet, or other slip-
pery surfaces may cause the wheels to pull erratically to
the right or left. This phenomenon occurs when there is a
difference in the surface traction under the rear (driving)
wheels.
WARNING!
Rapid acceleration on slippery surfaces is danger-
ous. Unequal traction can cause sudden pulling of
the rear wheels. You could lose control of the vehicle
and possibly have an accident. Accelerate slowly and
carefully whenever there is likely to be poor traction
(ice, snow, wet mud, loose sand, etc.).
Traction
When driving on wet or slushy roads, it is possible for a
wedge of water to build up between the tire and road
surface. This is known as hydroplaning and may cause
Jump Starting
WHAT TO DO IN EMERGENCIES 279
6

•Do not try to start engine by pushing or towing the
vehicle.
•Do not idle the engine with any spark plug wires
disconnected or removed, such as when diagnostic
testing, or for prolonged periods during very rough
idling or malfunctioning operating conditions.
Maintenance-Free Battery
The top of the MAINTENANCE-FREE battery is perma-
nently sealed. You will never have to add water, nor is
periodic maintenance required.
NOTE:The battery is stored under an access cover
under the rear cargo floor. Remote battery terminals are
located in the engine compartment for jump starting.
NOTE:The battery in this vehicle has a vent hose that
should not be disconnected and should only be replaced
with a battery of the same type (vented).
Battery Location
MAINTAINING YOUR VEHICLE 299
7

Ball Joints............................ 302
Battery............................... 299
Jump Starting........................ 277
Keyless Transmitter Replacement (RKE)..... 24
Location.........................278,299
Bearings.............................. 314
Belts, Drive........................... 296
Body Mechanism Lubrication.............. 302
B-Pillar Location....................... 227
Brake Assist System..................... 106
Brake, Parking......................... 217
Brake System.......................219,310
Anti-Lock (ABS)...................... 219
Fluid Check...................... 311,333
Hoses.............................. 310
Warning Light....................... 145
Brake/Transmission Interlock.............. 216
Break-In Recommendations, New Vehicle...... 58
Bulb Replacement...................... 326
Bulbs, Light........................... 325
Calibration, Compass.................... 152
Capacities, Fluid....................... 331Caps, Filler
Fuel............................... 250
Radiator (Coolant Pressure).............. 307
Car Washes........................... 315
Carbon Monoxide Warning.............59,249
Cargo Compartment
Luggage Carrier...................... 131
Cargo Management System............... 125
Cargo Organizer...................... 129
Rollaway Tonneau Cover............... 127
Tri-Fold Load Floor.................... 126
Waterproof Liner..................... 129
Cargo Tie-Downs....................... 130
Cassette Tape and Player Maintenance....... 185
Catalytic Converter..................... 297
CD (Compact Disc) Player.............160,166
Cellular Phone.......................... 68
Chains, Tire........................... 244
Changing A Flat Tire.................... 269
Chart, Tire Sizing....................... 224
Child Restraint...................51,53,55,56
Child Restraint Tether Anchors............. 55
Child Safety Locks....................... 19
INDEX 361
10

Electric Remote Mirrors................... 67
Electrical Power Outlets.................. 121
Electronic Speed Control (Cruise Control)..... 109
Electronic Stability Program (ESP).......... 107
Electronic Vehicle Information Center (EVIC) . . 148
Emergency, In Case of
Freeing Vehicle When Stuck............. 280
Hazard Warning Flasher................ 268
Jacking............................. 269
Jump Starting........................ 277
Overheating......................... 268
Towing............................. 281
Emission Control System Maintenance....289,336
Engine.........................285,286,287
Air Cleaner.......................... 297
Air Cleaner Filter..................... 297
Block Heater......................... 204
Break-In Recommendations............... 58
Checking Oil Level.................291,292
Compartment..................285,286,287
Coolant (Antifreeze)................305,332
Cooling............................ 305
Exhaust Gas Caution..............27,59,249Fails to Start......................... 203
Fuel Requirements.................246,331
Oil ..........................291,331,332
Oil Change Interval................... 293
Oil Selection......................293,331
Oil Synthetic......................... 295
Overheating......................... 268
Temperature Gauge................... 141
Enhanced Accident Response Feature......... 43
Event Data Recorder..................... 49
Exhaust Gas Caution.............27,59,249,304
Exhaust System........................ 304
Exterior Folding Mirrors.................. 66
Filters
Air Cleaner.......................... 297
Air Conditioning..................196,301
Engine Fuel......................... 297
Engine Oil.......................296,332
Engine Oil Disposal................... 295
Flashers
Hazard Warning...................... 268
Turn Signal.......................... 142
INDEX 363
10
