NOTE:Using the“3”range while operating the vehicle
under heavy operating conditions will improve perfor-
mance and extend transmission life by reducing exces-
sive shifting and heat build up. This action will also
provide better engine braking.
The automatic transmission fluid and filter should be
changed if you REGULARLY tow a trailer for more than
45 minutes of continuous operation. See Schedule“B”in
section 8 of this manual for transmission fluid change
intervals.
NOTE:Check the automatic transmission fluid level
before towing.
Towing Tips—Electronic Speed Control (If
Equipped)

Don’t use in hilly terrain or with heavy loads.
When using the speed control, if you experience speed
drops greater than 10 mph (16 km/h), disengage until
you can get back to cruising speed.
Use speed control in flat terrain and with light loads to
maximize fuel efficiency.
Towing Tips—Autostick (If Equipped)

For vehicles equipped with Autostick. By using the
Autostick modes, and selecting a specific gear range,
frequent shifting can be avoided. The highest gear
range should be selected that allows for adequate
performance. For example, choose“4”if the desired
speed can be maintained. Choose“3”or“2”if needed
to maintain the desired speed.
Extended driving at high RPM should be avoided to
prevent excess heat generation. A reduction in vehicle
speed may be required to avoid extended driving at
high RPM. Return to a higher gear range or vehicle
speed when road conditions and RPM level allows.
Towing Tips—Cooling System
To reduce potential for engine and transmission over-
heating, take the following actions:
City Driving
When stopped for short periods of time, put transmission
in neutral and increase engine idle speed.
258 STARTING AND OPERATING

▫Body Lubrication.....................296
▫Windshield Wiper Blades................296
▫Windshield Washers...................297
▫Exhaust System......................297
▫Cooling System.......................298
▫Hoses And Vacuum/Vapor Harnesses.......303
▫Brakes.............................303
▫Brake Fluid Level Check................304
▫Fuel System Hoses....................305
▫Automatic Transmission................306
▫Front And Rear Wheel Bearings...........307
▫Appearance Care And Protection From
Corrosion...........................307
▫Cleaning The Center Console Cup Holders . . . 310

Power Distribution Centers...............311▫Front Power Distribution Center...........311
▫Rear Power Distribution Center...........313

Vehicle Storage........................317

Replacement Light Bulbs................317

Bulb Replacement......................318
▫Low Beam Headlight, High Beam Headlight,
Park/Turn Light, And Front Sidemarker
Light..............................318
▫Backup Light, Side Marker Light, Tail/Turn
Light, And Tail/Stop Light...............320
▫License Light........................322

Fluids And Capacities...................323

Fluids, Lubricants And Genuine Parts.......324
▫Engine.............................324
▫Chassis............................325
278 MAINTAINING YOUR VEHICLE

Automatic Transmission
Fluid Level Check
Regular automatic transmission fluid level checks are not
required. For this reason the dipstick is omitted.
If you notice fluid loss or gear shift malfunction, have
your authorized dealer check the transmission fluid level.
CAUTION!
Using a transmission fluid other than the manufac-
turer’s recommended fluid may cause deterioration
in transmission shift quality and/or torque converter
shudder. Using a transmission fluid other than that
recommended by the manufacturer will result in
more frequent fluid and filter changes. Refer to the
Fluids, Lubricants and Genuine Parts section for
correct fluid type.
CAUTION!
The fluid level is preset at the factory and does not
require adjustment under normal operating condi-
tions. If a transmission fluid leak occurs, visit your
authorized dealer immediately. Severe damage to the
transmission may occur. Your authorized dealer has
the proper tools to accurately adjust the fluid level.
Fluid and Filter Changes
Automatic transmission fluid and filter should be
changed as follows:
Normal Usage—No change necessary
Severe Usage (fluid and filter)—Refer to Maintenance
Schedule“B”
Severe Usage is defined as:
•Police, taxi, limousine, commercial type operation, or
trailer towing where the vehicle is drivenregularlyfor
more than 45 minutes of continuous operation.
306 MAINTAINING YOUR VEHICLE

Miles 57,000 60,000 63,000 66,000 69,000 72,000
(Kilometers) (95 000) (100 000) (105 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if re-
quired.*X XXX X
Replace theair cleaner filter.X
Replace thespark plugs.5.7L Engine. X
Inspect the front and rear brake linings and
rotors.XX
Check and Inspect the accessory drive belt
and tensioner. Replace if required.X
Check and replace, if necessary, thePCV
valve.*‡X
Change the automatic transmission fluid and
filter.X
Replace the air conditioning filter. X X
Flush and replace engine coolant at 60 months
if not done at 102,000 miles.X
Rotate the tires. X X X
SCHEDULE“B”335
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (180 000) (185 000) (190 000) (195 000) (200 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if re-
quired.*XXXX
Replace theair cleaner filter.X
Inspect the front and rear brake linings and rotors. X X
Replace thespark plugs.5.7L Engines. X
Check and replace, if necessary, thePCV valve.*X
Change the automatic transmission fluid and filter. X
Replace the air conditioning filter. X X
Flush and replace the engine coolant at 120 months,
if not replaced at 102,000 miles.X
Rotate the tires. X X X
* This maintenance is recommended by the manufacturer
to the owner but is not required to maintain the emis-
sions warranty.
‡This maintenance is not required if previously replaced.Inspection and service should also be performed anytime
a malfunction is observed or suspected. Retain all re-
ceipts.
338 SCHEDULE“B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

ABS (Anti-Lock Brake System)............. 214
Adding Engine Coolant (Antifreeze)......... 300
Adding Fuel.......................... 244
Adding Washer Fluid.................105,297
Additives, Fuel........................ 243
Adjustable Pedals....................... 95
Air Conditioner Maintenance.............. 294
Air Conditioning....................... 181
Air Conditioning Filter................190,295
Air Conditioning, Operating Tips........... 191
Air Conditioning Refrigerant.............. 295
Air Conditioning System................. 181
Air Pressure, Tires...................... 227
Airbag................................ 38
Airbag Deployment....................42,48
Airbag Light....................43,50,60,136
Airbag Maintenance...................... 49
Airbag, Side........................... 46
Airbag, Window (Side Curtain)...........38,46
Alarm System (Security Alarm)............. 25
Alignment and Balance.................. 233
Alterations/Modifications, Vehicle............ 7
Antenna, Satellite Radio.................. 175Antifreeze (Engine Coolant)............299,323
Disposal............................ 301
Anti-Lock Brake System (ABS)............. 214
Anti-Lock Warning Light................. 141
Anti-Theft Security Alarm (Theft Alarm)...... 25
Appearance Care....................... 307
Auto Down Power Windows............... 29
Auto Up Power Windows................. 29
Automatic Dimming Mirror................ 67
Automatic Door Locks..................17,18
Automatic Headlights................... 101
Automatic Temperature Control (ATC)....... 184
Automatic Transmission............198,203,306
Adding Fluid.....................306,325
Fluid and Filter Changes................ 306
Fluid Change........................ 306
Fluid Level Check..................... 306
Fluid Type.......................... 325
Gear Ranges......................... 199
Torque Converter..................... 201
Automatic Transmission Limp Home Mode . . . 202
Autostick..........................205,210
352 INDEX

Ball Joints............................ 296
Battery............................... 292
Jump Starting........................ 270
Keyless Transmitter Replacement (RKE)..... 24
Location.........................271,292
Bearings.............................. 307
Belts, Drive........................... 290
Body Mechanism Lubrication.............. 296
B-Pillar Location....................... 222
Brake Assist System..................... 108
Brake, Parking......................... 212
Brake System.......................214,303
Anti-Lock (ABS)...................... 214
Fluid Check......................304,325
Hoses.............................. 303
Warning Light....................... 139
Brake/Transmission Interlock.............. 210
Break-In Recommendations, New Vehicle...... 59
Bulb Replacement...................... 318
Bulbs, Light........................... 317
Calibration, Compass.................... 146
Capacities, Fluid....................... 323Caps, Filler
Fuel............................... 244
Radiator (Coolant Pressure).............. 301
Car Washes........................... 307
Carbon Monoxide Warning.............59,244
Cargo Tie-Downs....................... 127
Cassette Tape and Player Maintenance....... 180
Catalytic Converter..................... 291
CD (Compact Disc) Player.............154,161
Cellular Phone.......................... 70
Chains, Tire........................... 238
Changing A Flat Tire.................... 263
Chart, Tire Sizing....................... 219
Child Restraint...................51,53,55,57
Child Restraint Tether Anchors............. 55
Child Safety Locks....................... 20
Clean Air Gasoline...................... 241
Climate Control........................ 181
Clock..........................156,162,178
Compact Disc (CD) Maintenance........... 181
Compact Spare Tire..................... 229
Compass............................. 146
Compass Calibration.................... 146
INDEX 353
