212006 Passenger Car • Minivan • Pacifica
ROADSIDE ASSISTANCE
• FLAT TIRE?If you have a flat tire, the service facility will remove
it and install your spare tire. The spare tire must be inflated and in
sound operating condition. Tire repairs are not covered.
• OUT OF FUEL?If your vehicle runs out of fuel, a small amount
of gasoline will be delivered to your location, where regulations
permit. In all other cases, including alternate fuels, your vehicle will
be towed to the nearest re-fuelling centre. In these instances, the
cost of fuel purchased will be your responsibility.
Please read “About Roadside Assistance” (page 22) because there
are some limitations that may affect the service available to you.
TO REQUEST ASSISTANCE(SEE ALSO INSIDE FRONT COVER)
If your vehicle requires any of the services provided by the program,
call this toll-free number anytime, from any location in Canada or
the United States: 1 800 363-4869(this number does not ring
at DaimlerChrysler Canada). Please identify yourself as a
DaimlerChrysler vehicle owner and be ready to provide:
❏Your Vehicle Identification Number
❏Your licence plate number
❏Your odometer reading (kilometres)
❏The location of your vehicle and the phone number where
you can be reached
❏Type of service needed (tow, flat tire, battery boost, etc.)
Note:• In severe weather, some delays may be expected.
• You will have to personally authorize the service provided
by the tow company
•If your vehicle is towed to a retailer, you are responsible for
contacting the retailer to authorize the service
TOWING AFTER THE PROGRAM EXPIRES
Coverage under the Roadside Assistance Program expires at 5 years
or 100,000 kilometres(or at 3 years or 60,000 kilometres, if
applicable), whichever occurs first. If you call the toll-free number
for assistance after the Program expires, you will have to pay for the
service provided.
Some emissions coverage lasts longer than the Roadside
Assistance Program.* For warranted emission system repairs after
the program expires, towing (only) will be provided on a
reimbursement basis. Call the toll-free number and service will be
dispatched, but you will have to pay for the tow. For reimbursement
consideration, see your authorized retailer for further details.
*See page 10.
Page 49 of 130
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.
Maintenance Service
Schedule “B”
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
50,000 km Maintenance Service Schedule “B”
50,000 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension components.
Replace the engine air cleaner filter if required (all models).
Replace the spark plugs (PT Cruiser and Sebring 2.4L engine only).
Check and replace, if necessary, the PCV valve (not required if previously replaced).
Replace the make-up air filter (PT Cruiser only).
Adjust the generator drive belt tension. (PT Cruiser only).
Inspect and check tension for power steering belt. Adjust or replace if required
(2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid (Pacifica only).*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition (if equipped)
(PT Cruiser only).
Inspect the tie rod ends and boot seals (PT Cruiser, Pacifica and Minivan only).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid
must be changed at more frequent intervals than shown in schedule B if the vehicle
is used for trailer tow, taxi, police or other type of commercial service.
Page 50 of 130
DAIMLERCHRYSLER
RETAILERSTA M P
Signature of authorized DaimlerChrysler Canada Retailer
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension
components.
Replace the engine air cleaner filter if required (all models).
Replace the spark plugs (PT Cruiser and Sebring 2.4L engine
only).
Check and replace, if necessary, the PCV valve (not required if
previously replaced).
Replace the make-up air filter (PT Cruiser only).
Adjust the generator drive belt tension (PT Cruiser only).
Inspect and check tension for power steering belt. Adjust or
replace if required (2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid
(Pacifica only).
*Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan
only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition
(if equipped) (PT Cruiser only).
Inspect the tie rod ends and boot seals (PT Cruiser, Pacifica and
Minivan only).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear
carrier fluid must be changed at more frequent intervals than shown in
schedule B if the vehicle is used for trailer tow, taxi, police or other type of
commercial service.
Maintenance Service Schedule “B”
50,000 km
Page 57 of 130
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.
Maintenance Service
Schedule “B”
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
70,000 km Maintenance Service Schedule “B”
70,000 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension components.
Inspect the engine air cleaner filter and replace if necessary (Sebring, Pacifica
and Minivan only).
Change the all-wheel-drive overrunning clutch and rear carrier fluid (Pacifica only).*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition (if equipped)
(PT Cruiser only).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid
must be changed at more frequent intervals than shown in schedule B if the vehicle
is used for trailer tow, taxi, police or other type of commercial service.
Page 58 of 130
DAIMLERCHRYSLER
RETAILERSTA M P
Signature of authorized DaimlerChrysler Canada Retailer
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and
suspension components.
Inspect the engine air cleaner filter and replace if
necessary (Sebring, Pacifica and Minivan only).
Change the all-wheel-drive overrunning clutch and
rear carrier fluid.*
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake linings, hoses and calipers
(Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica
and Minivan only).
Check the brake master cylinder fluid level
(Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug
condition (if equipped) (PT Cruiser only).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning
clutch/rear carrier fluid must be changed at more frequent intervals
than shown in schedule B if the vehicle is used for trailer tow, taxi,
police or other type of commercial service.
Maintenance Service Schedule “B”
70,000 km
Page 69 of 130
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.
Maintenance Service
Schedule “B”
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
100,000 km
Maintenance Service Schedule “B”
100,000 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension components.
Replace the engine air cleaner filter if required (all models).
Replace the ignition cables (PT Cruiser and Sebring only).Replace the spark plugs (PT Cruiser and 2.4L engine Sebring only).
Check and replace, if necessary, the PCV valve (not required if previously replaced).
Replace the make-up air filter (PT Cruiser only).
Flush and replace engine coolant at 60 months or 170,000 km, whichever comes first.
Inspect the serpentine drive belt, replace if necessary (not required if previously replaced)
(Pacifica and Minivan only).
Replace the accessory drive belts (2.7L Sebring only).
Change the automatic transmission fluid and filter.
Adjust the generator drive belt tension. (PT Cruiser only).
Inspect and check tension for power steering belt. Adjust or replace if required (2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid (Pacifica only).*
Replace the air conditioning filter (Pacifica and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:Inspect the brake linings (PT Cruiser only).
Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the front and rear brakes and components (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition (if equipped) (PT Cruiser only).
Inspect the tie rod ends and boot seals (PT Cruiser, Pacifica and Minivan only).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be changed at more frequent
intervals than shown in schedule B if the vehicle is used for trailer tow, taxi, police or other type of commercial service.
Page 70 of 130
DAIMLERCHRYSLER
RETAILERSTA M P
Signature of authorized DaimlerChrysler Canada Retailer
2006 Passenger Car • Minivan • Pacifica
Odometer Reading
Date
Repair Order No.
Maintenance Service Schedule “B”
100,000 kmChange engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension
components.
Replace the engine air cleaner filter if required (all models).
Replace the ignition cables (PT Cruiser and Sebring only).Replace the spark plugs (PT Cruiser and 2.4L engine Sebring only).
Check and replace, if necessary, the PCV valve (not required if previously
replaced).
Replace the make-up air filter (PT Cruiser only).
Flush and replace engine coolant at 60 months or 170,000 km, whichever
comes first.
Inspect the serpentine drive belt, replace if necessary (not required if
previously replaced) (Pacifica and Minivan only).
Replace the accessory drive belts (2.7L Sebring only).
Change the automatic transmission fluid and filter.
Adjust the generator drive belt tension (PT Cruiser only).
Inspect and check tension for power steering belt. Adjust or replace if
required (2.4L Sebring only).
Change the all-wheel-drive power transfer unit fluid (Pacifica only).*
Replace the air conditioning filter (Pacifica and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:Inspect the brake linings (PT Cruiser only).
Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the front and rear brakes and components (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition (if
equipped) (PT Cruiser only).
Inspect the tie rod ends and boot seals (PT Cruiser, Pacifica
and Minivan only).
Check the coolant level, hoses, and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier fluid must be
changed at more frequent intervals than shown in schedule B if the vehicle is used for trailer
tow, taxi, police or other type of commercial service.
Page 85 of 130
Retailer Copy
Remove and attach to Repair Order
26-92-02-01 3N.
Maintenance Service
Schedule “B”
Odometer Reading
Date
140,000 km Maintenance Service Schedule “B”
140,000 km
Change engine oil and engine oil filter (or every 3 months).
Inspect and lubricate, as required, all steering and suspension components.
Inspect the engine air cleaner filter and replace if necessary (Sebring, Pacifica
and Minivan only).
Change the all-wheel-drive overrunning clutch and rear carrier fluid (Pacifica only).*
Replace the air conditioning filter (Pacifica and Minivan only).
Rotate tires and check tire pressure.
INSPECT THE FOLLOWING:
Inspect the brake linings (PT Cruiser only).
Inspect the brake linings, hoses and calipers (Sebring only).
Inspect the front and rear brakes and components (Sebring only).
Inspect the brake hoses (PT Cruiser, Pacifica and Minivan only).
Check the brake master cylinder fluid level (Sebring only).
Check the automatic transmission fluid level.
Check the manual transaxle fluid level and fill-plug condition (if equipped)
(PT Cruiser only).
Check the coolant level, hoses and clamps.
Inspect the exhaust system.
*The all-wheel-drive power transfer unit fluid and overrunning clutch/rear carrier
fluid must be changed at more frequent intervals than shown in schedule B if the
vehicle is used for trailer tow, taxi, police or other type of commercial service.
