MAINTAINING YOUR VEHICLE
CONTENTS

2.4L Engine..........................213

2.7L Engine..........................214

Onboard Diagnostic System — OBD II......215

Emissions Inspection And Maintenance
Programs
............................216

Replacement Parts.....................217

Dealer Service........................217

Maintenance Procedures.................218
▫Engine Oil..........................218
▫Crankcase Emission Control System........224
▫Maintenance-Free Battery................224
▫Air Conditioner......................226▫Power Steering — Fluid Check............227
▫Suspension Ball Joints..................228
▫Body Mechanism Lubrication.............228
▫Windshield Wiper Blades................229
▫Windshield Washers...................230
▫Exhaust System......................231
▫Cooling System.......................231
▫Hoses And Vacuum/Vapor Harnesses.......235
▫Brakes.............................236
▫Fuel System Hoses....................238
▫Automatic Transmission................238
7

Refrigerant Recovery and Recycling
R-134a Air Conditioning Refrigerant is a hydrofluorocar-
bon (HFC) that is endorsed by the Environmental Pro-
tection Agency and is an ozone-saving product. How-
ever, the manufacturer recommends that air conditioning
service be performed by dealers or other service facilities
using recovery and recycling equipment.
NOTE:Use only manufacturer approved A/C System
Sealers, Stop Leak Products, Seal Conditioners, Compres-
sor Oil, or Refrigerants.
Power Steering — Fluid Check
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
“DaimlerChrysler Dealership”.
Before removing the reservoir cap, wipe the outside of
the cap and reservoir so that no dirt can fall into the
reservoir.
WARNING!
Fluid level should be checked on a level surface with
the engine off to prevent injury from moving parts,
and to insure accurate fluid level reading. Do not
overfill. Use only the manufacturer’s recommended
fluid.
Power Steering Fluid Reservoir
MAINTAINING YOUR VEHICLE 227
7

Insure nylon tubing in these areas has not melted or
collapsed.
NOTE:Often, fluids such as oil, power steering fluid,
and brake fluid are used during assembly plant opera-
tions to ease the assembly of hoses to couplings. There-
fore, oil wetness at the hose-coupling area is not neces-
sarily an indication of leakage. Actual dripping of hot
fluid when systems are under pressure (during vehicle
operation) should be noted before hose is replaced based
on leakage.
NOTE:Inspection of brake hoses should be done
whenever the brake system is serviced and every engine
oil change.
WARNING!
Worn brake hoses can burst and cause brake failure.
You could have an accident. If you see any signs of
cracking, scuffing, or worn spots, have the brake
hoses replaced immediately.
Master Cylinder
The fluid level in the master cylinder should be checked
when performing under hood services, or immediately if
the brake system warning lamp shows system failure.
Be sure to clean the top of the master cylinder area before
removing the cap. If necessary, fill brake fluid reservoir to
the top of the fill mark chevron. With disc brakes, fluid
level can be expected to fall as the brake pads wear.
However, low fluid level may be caused by a leak and a
checkup may be needed.
Brake Fluid Reservoir
MAINTAINING YOUR VEHICLE 237
7

Chassis
Component Fluid, Lubricant, or Genuine Part
Automatic Transaxle MoparATF+4 Automatic Transmission Fluid.
Brake Master Cylinder MoparDOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid
is not available, then DOT 4 is acceptable. Use only recommended brake flu-
ids.
Power Steering Reservoir MoparPower Steering Fluid + 4, MoparATF+4 Automatic Transmission
Fluid.
Steering Gear & Linkage, Ball
Joints, Prop Shafts & Yokes, Wheel
BearingsMoparMulti-Purpose Lubricant NLGI Grade 2 or equivalent.
MAINTAINING YOUR VEHICLE 257
7

Miles 57,000 60,000 63,000 66,000 69,000 72,000
(Kilometers) (95 000) (100 000) (105 000) (110 000) (115 000) (120 000)
Change engine oil and engine oil filter, if not
replaced at 3 months.XXXXX X
Inspect theair cleaner filterand replace if neces-
sary.*XXXXX
Replace theair cleaner filter.X
Inspect and check tension for power steering belt
(2.4 Liter Engine). Adjust or replace if required.X
Inspect the front and rear brake pads, linings,
rotors, rear drums and shoes.XX
Replace theignition cableson 2.4 liter engine. X
Replace the accessory drive belts on the 2.7 liter
engine.X
Replace thespark plugson the 2.4 liter engine. X
Check and replace, if necessary, thePCV valve.*‡ X
Change the automatic transmission fluid and
filter.X
Rotate the tires. X X X
Flush and replace engine coolant at 60 months, if
not done at 100,000 miles.X
SCHEDULE “B” 267
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 108,000 111,000 114,000 117,000 120,000
(Kilometers) (185 000) (190 000) (195 000) (200 000) (205 000)
Change engine oil and engine oil filter, if not re-
placed at 3 months.XXXXX
Inspect theair cleaner filterand replace if neces-
sary.*XXXX
Replace theair cleaner filter.X
Replace thespark plugson the 2.4 liter engine. X
Replace theignition cableson the 2.4 liter engine. X
Inspect the front and rear brake pads, linings, ro-
tors, rear drums and shoes.XX
Inspect and check tension for power steering belt
(2.4 Liter Engine). Adjust or replace if required.X
Replace the accessory drive belts on the 2.7 liter en-
gine.X
Check and replace, if necessary, thePCV valve.*X
Change the automatic transmission fluid and fil-
ter.X
Flush and replace engine coolant at 120 months, if
not done at 100,000 miles.X
Rotate the tires. X X
270 SCHEDULE “B”
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Oil ..........................218,255,256
Oil Change Interval................... 219
Oil Selection......................220,255
Oil Synthetic......................... 221
Overheating......................... 198
Timing Belt.......................... 224
Engine Oil Viscosity..................... 255
Entry System, Illuminated................. 13
Exhaust Gas Caution...............46,180,231
Exhaust System........................ 231
Exterior Light Service.................... 249
Filters
Air Cleaner.......................... 222
Automatic Transaxle................... 240
Engine Fuel......................... 223
Engine Oil.......................221,256
Engine Oil Disposal................... 221
Flashers
Hazard Warning...................... 198
Turn Signal.......................... 89
Flash-To-Pass........................... 66
Flat Tire Changing...................... 200Flexible Fuel Vehicles
Cruising Range....................... 182
Engine Oil.......................... 182
Fuel Requirements.................181,182
Maintenance......................... 183
Replacement Parts.................... 183
Starting............................ 182
Floor Console.......................... 52
Fluid, Brake........................... 257
Fluid Capacities........................ 255
Fluid Leaks............................ 47
Fluid Level Checks...................... 239
Automatic Transaxle................... 239
Capacities........................... 255
Cooling System....................... 232
Engine Oil.......................... 218
Power Steering....................... 227
Fluids............................... 256
Fluids, Lubricants and Genuine Parts........ 256
Fog Light Service....................... 252
Fog Lights........................66,90,252
Folding Rear Seat....................... 60
Freeing A Stuck Vehicle.................. 209
290 INDEX

Filter Disposal....................... 221
Identification Logo.................... 220
Materials Added to.................... 221
Pressure Gauge....................... 92
Quality............................. 220
Recommendation..................220,255
Synthetic........................... 221
Viscosity.........................221,255
Onboard Diagnostic System............215,216
Opener, Garage Door (HomeLink) .......... 73
Operator Manual (Owner’s Manual).......... 4
Overdrive............................ 152
Overheating, Engine..................... 198
Owner’s Manual (Operator Manual).......4,281
Paint Care............................ 241
Paint Damage......................... 241
Panic Alarm........................... 19
Parking Brake......................... 153
Parking On Hill........................ 154
Passing Light........................... 66
Pets.................................. 45
Placard, Tire and Loading Information....... 163Power
Brakes............................. 155
Door Locks.......................... 14
Outlet (Auxiliary Electrical Outlet)......... 80
Seats............................... 58
Steering............................ 157
Steering, Checking.................... 227
Sunroof............................. 78
Windows............................ 24
Power Steering Fluid.................... 257
Pregnant Women and Seat Belts............. 31
Preparation for Jacking................... 200
Pretensioners
Seat Belts............................ 30
Programmable Electronic Features.........73,77
Programming Transmitters
(Remote Keyless Entry)...............19,73,77
Radial Ply Tires........................ 170
Radiator Cap (Coolant Pressure Cap)........ 233
Radio Broadcast Signals................... 98
Radio Operation...............108,113,126,128
Radio Remote Controls.................. 125
INDEX 295
