5/100 POWERTRAIN WARRANTY
The following powertrain components are covered for 5 years or
100,000 kilometres, whichever occurs first, measured from the
vehicle’s original warranty start date.
Vehicles placed in police, taxi, limousine, postal or ambulance
service and all SRT vehicles, are excluded from the 5-year or
100,000-kilometrePowertrain
Warranty and are covered only under
the 3-year or 60,000-kilometreBasic Warranty.
• Engine– Cylinder block and all internal parts; cylinder head
assemblies; timing case, timing chain, timing belt, gears and
sprockets; vibration damper; oil pump; water pump and housing;
intake and exhaust manifolds; flywheel with starter ring gear; core
plugs; valve covers; oil pan; turbocharger housing and internal
parts; turbocharger wastegate actuator; supercharger; serpentine
belt tensioner; seals and gaskets for listed components only. • Transmission– Transmission case and all internal parts; torque
converter; drive/flex plate; transmission range switch;
transmission control module; bell housing; oil pan; seals and
gaskets for listed components only.
Note: Manual transmission clutch parts are not covered at any time.
• Rear-Wheel Drive (RWD)– Rear axle housing and all internal
parts; axle shafts; axle shaft bearings; driveshaft assemblies; drive-
shaft centre bearings; universal joints and yokes; seals and gaskets
for listed components only.
5/100 POWERTRAIN WARRANTY
2006 Chrysler 300C/300 • Dodge Magnum/Charger

2006 Chrysler 300C/300 • Dodge Magnum/Charger
Maintenance Service
Schedule “B”
Odometer Reading
Date
175,000 km
Retailer copy.
Remove and attach to Repair Order
26-92-35-01 3N.
Maintenance Service Schedule “B”
175,000 km

Change engine oil and engine oil filter (or every 3 months).

Inspect and lubricate, as required, all steering and suspension components.

Replace the air cleaner filter.

Replace the engine timing belt (3.5L only).
INSPECT THE FOLLOWING:

Inspect the brake hoses.

Check the automatic transmission fluid level.

Inspect the CV joints.

Check the coolant level, hoses, and clamps.

Inspect the exhaust system.

2006 Chrysler 300C/300 • Dodge Magnum/Charger
Odometer Reading
Date
Repair Order No.
DAIMLERCHRYSLER
RETAILERSTA M P
Signature of authorized DaimlerChrysler Canada Retailer

Change engine oil and engine oil filter
(or every 3 months).

Inspect and lubricate, as required, all steering
and suspension components.

Replace the air cleaner filter.

Replace the engine timing belt (3.5L only).
INSPECT THE FOLLOWING:

Inspect the brake hoses.

Check the automatic transmission fluid level.

Inspect the CV joints.

Check the coolant level, hoses and clamps.

Inspect the exhaust system.
Maintenance Service Schedule “B”
175,000 km
