2006 CADILLAC STS key

Seats and Restraint Systems........................... 1-1
Front Seats
............................................... 1-2
Rear Seats
............................................... 1-7
Safety Belts
.............................................. 1-8
Child Restraints
.......................................1-26
Airbag System
.........................................1-49
Restraint System Check
............................1-64
Features and Controls..................................... 2-1
Keys
........................................................ 2-3
Doors and Locks
......................................2-12
Windows
.................................................2-17
Theft-Deterrent Systems
............................2-20
Starting and Operating Your Vehicle
...........2-24
Mirrors
....................................................2-41
OnStar
®System
......................................2-45
Universal Home Remote System
................2-47
Storage Areas
.........................................2-51
Sunroof
..................................................2-52
Vehicle Personalization
.............................2-53
Instrument Panel............................................. 3-1
Instrument Panel Overview
.......................... 3-4
Climate Controls
......................................3-48
Warning Lights, Gages, and Indicators
........3-57
Driver Information Center (DIC)
..................3-73
Audio System(s)
.......................................3-94Driving Your Vehicle....................................... 4-1
Your Driving, the Road, and Your Vehicle
..... 4-2
Towing
...................................................4-37
Service and Appearance Care.......................... 5-1
Service
..................................................... 5-3
Fuel
......................................................... 5-5
Checking Things Under the Hood
...............5-10
All-Wheel Drive
........................................5-50
Rear Axle
...............................................5-51
Front Axle
...............................................5-52
Bulb Replacement
....................................5-53
Windshield Replacement
...........................5-55
Windshield Wiper Blade Replacement
.........5-55
Tires
......................................................5-56
Appearance Care
.....................................5-94
Vehicle Identication
...............................5-103
Electrical System
....................................5-104
Capacities and Specications
...................5-116
Maintenance Schedule..................................... 6-1
Maintenance Schedule
................................ 6-2
Customer Assistance and Information.............. 7-1
Customer Assistance and Information
........... 7-2
Reporting Safety Defects
...........................7-13
Index.............................................................. 71
2006 Cadillac STS/STS-V Owner ManualM

Before you close the door, be sure the belt is out of
the way. If you slam the door on it, you can damage
both the belt and your vehicle.
Shoulder Belt Height Adjustment
Before you begin to drive, move the shoulder belt height
adjuster to the height that is right for you.
Adjust the height so that the shoulder portion of the belt is
centered on your shoulder. The belt should be away from
your face and neck, but not falling off your shoulder.
Incorrect positioning of the shoulder belt can reduce the
effectiveness of the safety belt.
To move it down, press
the release button (A)
and move the height
adjuster to the desired
position. You can move
the height adjuster up just
by pushing up on the
shoulder belt guide.
After you move the height adjuster to where you want
it, try to move it down without pressing the release
button to make sure it has locked into position.
Safety Belt Use During Pregnancy
Safety belts work for everyone, including pregnant
women. Like all occupants, they are more likely to be
seriously injured if they do not wear safety belts.
A pregnant woman should wear a lap-shoulder belt,
and the lap portion should be worn as low as possible,
below the rounding, throughout the pregnancy.
The best way to protect the fetus is to protect the
mother. When a safety belt is worn properly, it is more
likely that the fetus will not be hurt in a crash. For
pregnant women, as for anyone, the key to making
safety belts effective is wearing them properly.
1-20

Servicing Your Airbag-Equipped
Vehicle
Airbags affect how your vehicle should be serviced.
There are parts of the airbag system in several places
around your vehicle. You do not want the system to
inate while someone is working on your vehicle. Your
dealer and the service manual have information about
servicing your vehicle and the airbag system. To
purchase a service manual, seeService Publications
Ordering Information on page 7-14.
{CAUTION:
For up to 10 seconds after the ignition key is
turned off and the battery is disconnected, an
airbag can still inate during improper service.
You can be injured if you are close to an airbag
when it inates. Avoid yellow connectors. They
are probably part of the airbag system. Be sure
to follow proper service procedures, and make
sure the person performing work for you is
qualied to do so.
The airbag system does not need regular maintenance.
Adding Equipment to Your
Airbag-Equipped Vehicle
Q:Is there anything I might add to the front
or sides of the vehicle that could keep the
airbags from working properly?
A:Yes. If you add things that change your vehicle’s
frame, bumper system, height, front end or side
sheet metal, they may keep the airbag system from
working properly. Also, the airbag system may not
work properly if you relocate any of the airbag
sensors. If you have any questions about this, you
should contact Customer Assistance before you
modify your vehicle. The phone numbers and
addresses for Customer Assistance are in Step Two
of the Customer Satisfaction Procedure in this
manual. SeeCustomer Satisfaction Procedure
on page 7-2.
1-63

Keys...............................................................2-3
Keyless Access System...................................2-4
Keyless Access System Operation....................2-5
Doors and Locks............................................2-12
Door Locks..................................................2-12
Power Door Locks........................................2-12
Programmable Automatic Door Locks..............2-13
Rear Door Security Locks..............................2-13
Lockout Protection........................................2-14
Trunk..........................................................2-14
Windows........................................................2-17
Power Windows............................................2-18
Sun Visors...................................................2-20
Theft-Deterrent Systems..................................2-20
Theft-Deterrent System..................................2-21
Valet Lockout Switch.....................................2-23Starting and Operating Your Vehicle................2-24
New Vehicle Break-In....................................2-24
Ignition Positions..........................................2-24
Retained Accessory Power (RAP)...................2-25
Starting the Engine.......................................2-25
Engine Coolant Heater..................................2-27
Automatic Transmission Operation
(5-Speed Automatic)..................................2-28
Automatic Transmission Operation
(6-Speed Automatic)..................................2-32
Parking Brake..............................................2-35
Shifting Into Park (P).....................................2-36
Shifting Out of Park (P).................................2-38
Parking Over Things That Burn.......................2-38
Engine Exhaust............................................2-39
Running the Engine While Parked...................2-40
Section 2 Features and Controls
2-1

Keys
{CAUTION:
Leaving children unattended in a vehicle is
dangerous, but it is even more dangerous if
the keyless access transmitter is also left in
the vehicle. A child or others could be badly
injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
Do not leave the keyless access transmitter in
a vehicle with children.
2-3

There is one key for the
driver’s door, glove box
and rear seat pass-through
door. See “Rear Seat
Pass-Through Door” under
Trunk on page 2-14for
more information.
Your vehicle has a Keyless Access System with
pushbutton start. SeeIgnition Positions on page 2-24
for information on starting the vehicle.
Notice:If you ever lose your transmitter(s) and/or
key, it could be difficult to get into your vehicle. You
may even have to damage your vehicle to get in.
Be sure you have a spare transmitter and/or key.
In an emergency, contact Cadillac Roadside Assistance.
SeeRoadside Service on page 7-5.
If your vehicle is equipped with the OnStar
®system,
OnStar®may be able to send a command to unlock
your vehicle if needed. If the vehicle battery is dead,
OnStar
®will be unable to unlock the vehicle. See
OnStar®System on page 2-45for more information.
Keyless Access System
Your vehicle has a Keyless Access System that
operates on a radio frequency subject to Federal
Communications Commission (FCC) Rules and with
Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
2-4

If you ever notice a decrease in the keyless access
transmitter range, try doing one of the following:
Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.
Check the location. Other vehicles or objects may
be blocking the signal. Take a few steps to the left
or right, hold the transmitter higher, and try again.
Check to determine if battery replacement is
necessary. See “Battery Replacement” under
Keyless Access System Operation on page 2-5.
Check to make sure that an electronic device such
as a cellular phone or lap top computer is not causing
interference.
If you are still having trouble, see your dealer or a
qualied technician for service.
Keyless Access System Operation
Your vehicle has a Keyless Access System that lets
you lock and unlock your vehicle’s doors, open the trunk
lid, remotely start the engine, and locate your vehicle,
or sound your vehicle’s alarm from a distance as
much as much as 30 feet (10 m) away.The Keyless Access System also lets you lock and
unlock the vehicle’s doors and access the trunk without
removing the remote transmitter from your pocket,
purse, briefcase, etc. The system operates when the
transmitter is located within 3 feet (1 m) of the door
or trunk of your vehicle. See “Keyless Doors Unlock”
and “Keyless Ft (Front) Door Unlock” underVehicle
Personalization on page 2-53.
Your vehicle comes with
two transmitters.
Q(Lock):Press this button to lock the doors. The lock
status light on the front doors will turn on for ve seconds
and the turn signal indicators will ash. If this button is
pressed twice, the doors will lock, the status light on
the door will turn on for ve seconds, the turn signal
indicators will ash twice, and the horn will sound once.
2-5

You may be able to close the windows from outside
the vehicle using the lock button on the keyless access
transmitter. The engine must be off. Press and hold the
lock button for more than two seconds to close any open
window(s) on your vehicle. If any window is unable to
close completely, it will reverse and the horn will chirp.
See “Anti-Pinch Feature” underPower Windows on
page 2-18for more information.
You can program your vehicle so the turn signal
indicators will not ash and the horn will not sound
when pressing the lock button on the keyless access
transmitter. For more information see “Lights Flash at
Lock” and “Horn Chirps at Lock” underVehicle
Personalization on page 2-53.
/(Remote Start):Pressing this button operates the
remote start feature. See “Remote Vehicle Start” at
the end of this section for more detailed information.
"(Unlock):Press this button once to unlock the
driver’s door. The turn signal indicators will ash twice.
Press the unlock button twice within ve seconds to
unlock all the doors. If it is dark enough outside, your
interior lamps will come on.You can program your vehicle so the turn signal
indicators will not ash and the fog lamps and reverse
lamps remain on steady for approximately 20 seconds
when the keyless access transmitter is used to unlock the
vehicle. See “Lights Flash at Lock” and “Ext. (Exterior)
Lights at Unlock” underVehicle Personalization
on page 2-53.
If your vehicle has the memory feature you can program
and recall memory settings when you press the unlock
button on the keyless access transmitter. SeeMemory
Seat, Mirrors and Steering Wheel on page 2-70for more
information.
G(Trunk):Press and hold this button for
approximately one second to open the trunk while the
engine is turned off or the shift lever is in PARK (P).
L(Vehicle Locator/Panic Alarm):Press and
release this button to locate your vehicle. The horn
will chirp three times and the turn signal lamps will ash
three times. Press and hold the button for three seconds
to sound the panic alarm. The horn will chirp and the turn
signal lamps will ash for 30 seconds. Press and release
the button again to cancel the panic alarm.
2-6
