At a glance
Controls
Driving tips
Mobility Reference
11
Instrument cluster
1Speedometer
2Indicator and warning lamps12
3Tachometer43
Indicator and warning lamps12
4Coolant temperature gauge44
5Fuel gauge43
6Button for
>Displaying the time44
>Service Interval Display447Selector lever and program display for
automatic transmission38
8Button for
>Resetting trip odometer43
>Setting the time44
9Display for
>Trip odometer/odometer43
>Time44
>Service Interval44
>Computer45

Cockpit
12
Indicator and warning lamps
Technology that monitors itself
Indicator and warning lamps that are identified
with
+ are checked for proper function each
time you turn the ignition key. They each light
up once for different periods of time.
When a malfunction occurs in a monitored sys-
tem, the corresponding lamp will either fail to go
o u t w h e n t h e e n g i n e i s s t a r t e d , o r i t w i l l c o m e o n
again during normal driving. Detailed informa-
tion is provided on the specified pages.
Battery charge current
+105
Headlamp flasher39
High beams57
Engine oil
+94
Driving stability control systems/
ABS Antilock Brake System
+48
ABS Antilock Brake System/chassis
control system for Canadian models
Brake system
+
With handbrake released50, 96
With handbrake engaged37
With other warning lamps50
Brake warning lamp for Canadian
models
Brake pads
+96
Please fasten safety belt
+29
Airbags
+53
Front fog lamps57
Automatic transmission +38
Turn signals39
DSC Dynamic Stability Control/
xDrive
+ 48, 49
Service Engine Soon
+98
Service Engine Soon warning lamp for
Canadian models.
Check Gas Cap
* +84
Engine electronics
+36
Washer fluid low41
Coolant low95
Flat Tire Monitor
* +50
Tire Pressure Monitor
* +52
Lamp defective56
Cruise control41
With ignition key in position 2, this
warning lamp indicates that a door
or the liftgate is open.

Technology for comfort, convenience and safety
54 In the event of malfunctions, deactivation, or
triggering of the airbag restraint system, have
the testing, repair, removal, and disposal of air-
bag generators executed only by a BMW Sports
Activity Vehicle Center or a workshop that
works according to BMW repair procedures
with correspondingly trained personnel and has
the required explosives licenses. Unprofes-
sional attempts to service the system could
lead to failure in an emergency or undesired air-
bag activation, either of which could result in
personal injury.<
Airbag warnings and information are also pro-
vided on the sun visors.
Automatic deactivation of front
passenger airbags
By evaluating the pressure on the seat cushion
of the front passenger seat, the system detects
whether or not the seat is occupied. The front
and side airbags for the passenger are activated
or deactivated by the system accordingly.
The indicator lamp located above the
inside rearview mirror indicates whether
the front passenger airbag system is currently
deactivated or activated, refer to Status of pas-
senger airbag in the section below.<
Before transporting a child in the front
passenger seat, follow the safety notices
and instructions under Transporting children
safely, refer to page33.
When teenagers or adults assume certain sit-
ting positions, the front and side airbags on the
passenger side can deactivate; this causes the
indicator lamp for the front passenger airbag to
light up. If this happens, have them change their
sitting position so that the passenger airbag is
activated and the indicator lamp goes out. If the
desired status cannot be achieved by changing
their sitting position, then have the person ride
in the back. Do not attach seat covers, seat
cushion padding, ball mats or other items to the
passenger seat unless they are specifically rec-
ommended by BMW. Do not place any items
under the seat which could press against the
seat from below. Otherwise, a correct analysis
of the seat cushion is not ensured.<
Status of passenger airbags
The indicator lamp for the passenger airbag
indicates the operational readiness of the front
and side airbag on the passenger side depend-
ing on whether or not the seat is occupied. The
indicator lamp indicates whether the passenger
airbags are activated or deactivated.
>The indicator lamp lights up when a child
sitting as directed in a child restraint system
designed for this is detected.
The front and side airbags on the passenger
side are not activated.
>The indicator lamp does not come on as
long as a person of sufficient size and in a
correct sitting position is detected on the
seat. The front and side airbags for the pas-
senger are activated.
>The indicator lamp does not light up when
the seat is empty.
However, the front and side airbags for the
passenger are not activated.
Operational readiness of airbag system
As of ignition key position 1, the warning lamp
lights up briefly, thus indicating the operational
readiness of the entire airbag system and the
safety belt tensioners.

Maintenance
98 This socket is located under a cover on the left
side of the driver's footwell, just under the dash-
board.
Emissions values
The warning lamp lights up. Exhaust
values are deteriorating. Have the vehi-
cle checked as soon as possible.
Under certain conditions, the indicator will flash.
This indicates a serious rate of engine misfire.
When this occurs, you should reduce speed
and consult the nearest BMW Sports Activity
Vehicle Center as soon as possible. Severe
engine misfire even for only a short period of
time can seriously damage emission control
components, especially the catalytic converter.
Display of the previously described mal-
function on Canadian models.
When the fuel filler cap is not properly
tightened, the OBD system can detect
the vapor leak and the indicator lamp will light
up. If the filler cap is subsequently tightened,
the indicator lamp should go out within a few
days.<
Event data recorders
Your vehicle may be equipped with one or more
sensing and diagnostic modules or a recording
device capable of recording or transmitting cer-
tain vehicle data or information. In addition, if
you have a Subscription Service Agreement for
the BMW Assist system, certain vehicle infor-
mation may be transmitted or recorded in order
to provide such services.
Care
You can find useful information on caring for
your BMW in the Caring for your vehicle bro-
chure.

Reference
At a glance
Controls
Driving tips
Mobility
119
Belts, refer to Safety belts29
Beverage holder, refer to Cup
holders66
Blower, refer to
– Air volume60
– Air volume, adjusting
manually63
BMW maintenance system97
Bottle holder, refer to Cup
holders66
Brake fluid96
– level96
– warning lamp96
Brake force display53
Brake lamps
– brake force display53
– indicator lamp, defective
bulb12,56
– replacing bulbs102
Brake light, refer to Brake
lamps102
Brake pads96
– breaking-in76
– warning lamp96
Brake pedal, refer to Safe
braking78
Brake rotors
– brake system76
– breaking-in76
Brakes78,96
– ABS48,78
– brake fluid96
– brake pads96
– breaking-in76
– handbrake37
– indicator/warning lamp12
Brake system96
– brake fluid96
– brake pads96
– breaking-in76
– disk brakes78
– warning lamp96
Brake wear warning
– refer to Brake pads96
– warning lamp96
Breakdown service, refer to
Receiving assistance107
Breaking-in76Bulb replacement, refer to
Lamps and bulbs99
Buttons on steering wheel13
C
California law
– Event Data Recorders98
– Proposition 65 Warning6
Calling, refer to telephone
Owner's Manual
Can holder, refer to Cup
holders66
Capacities116
Capacity, cargo area116
Car care, refer to Caring for
your vehicle brochure
Car-care products, refer to
Caring for your vehicle
brochure
Care, refer to Caring for your
vehicle brochure
Cargo, securing79
Cargo area21,70
– capacity116
– cover71
– emergency operation, refer
to Opening manually21
– enlarging70
– floor cover72
– folding rear seat backrest70
– lashing eyes73
– lid, refer to Liftgate21
– opening from outside21
– opening with remote
control19
– power socket69
Cargo loading78
– load79
– securing cargo79
– stowing cargo79
– vehicle78
Caring for artificial leather,
refer to Caring for your
vehicle brochure
Caring for carpet, refer to
Caring for your vehicle
brochureCaring for leather, refer to
Caring for your vehicle
brochure
Caring for plastic, refer to
Caring for your vehicle
brochure
Caring for vehicle finish, refer
to Caring for your vehicle
brochure
Car keys, refer to Key set18
Car phone, refer to separate
Owner's Manual
Car phone preparation69
Car radio, refer to Owner's
Manual for Radio/Onboard
Computer
Car wash77
– refer to Caring for your
vehicle brochure
Cassette operation, refer to
Owner's Manual for Radio/
Onboard Computer
CD operation, refer to Owner's
Manual for Radio/Onboard
Computer
Cellphone, refer to separate
Owner's Manual
Central locking system18
– interior20
Changes, technical, refer to
For your own safety6
Changing a wheel103
Changing gears
– automatic transmission with
Steptronic39
– manual transmission38
Changing wheels89
Charge-current indicator
lamp12,105
Charging battery106
Check Gas Cap, warning
lamp12,84
Checking oil level94
Child's seat, refer to Child
restraint systems33
Child-restraint fixing system
LATCH34

Reference
At a glance
Controls
Driving tips
Mobility
121
Driving notes76
Driving on poor roads80
Driving stability control
systems48
Driving through water80
Driving tips, refer to Driving
instructions76
Drying air, refer to Switching
cooling function on/
off60,63
DSC Dynamic Stability
Control48
– indicator lamp48
DVD changer, refer to Owner's
Manual for Radio/Onboard
Computer
Dynamic Brake Control, refer
to DBC Dynamic Brake
Control48
Dynamic Brake Control DBC
– warning lamp50
Dynamic Stability Control
DSC48
– indicator lamp48
E
Electrical malfunctions
– automatic transmission
malfunction39
– door lock20
– driver's door20
– fuel filler door84
– liftgate21
– panorama glass sunroof24
Electronic brake-force
distribution48
Electronic Stability Program,
refer to DSC Dynamic
Stability Control48
Emergency call107
Emergency operation, refer to
Manual operation
– doors20
– driver's door20
– fuel filler door84
– liftgate21
– panorama glass sunroof24Emergency Service, refer to
Receiving assistance107
Engine
– breaking-in76
– data114
– indicator lamps36
– overheated, refer to Coolant
thermometer44
– speed43
– starting36
– switching off37
Engine compartment93
Engine coolant95
Engine coolant
temperature44
Engine oil94
– additives, refer to Approved
engine oils95
– approved engine oils95
– indicator/warning lamp94
– required oil grades95
Engine oil grades95
Engine oil level94
– indicator/warning lamp94
Engine oil pressure94
– indicator/warning lamp94
Engine oil sensor94
– indicator/warning lamp94
Engine output, refer to Engine
data114
Equipment range, refer to
Service and Warranty Infor-
mation Booklet for US
models, Warranty and
Service Guide Booklet for
Canadian models
ESP Electronic Stability
Program, refer to DSC
Dynamic Stability
Control48
Exhaust system77
Exterior mirrors30
– automatically dimming77
Eye, tow starting and
towing109
F
Failure of electrical
accessories106
False alarms, refer to Avoiding
unintentional alarms25
Fastening safety belts, refer to
Safety belts29
Filter, refer to
– Microfilter61
– Microfilter/activated
charcoal filter64
First aid, refer to First-aid
kit108
First-aid kit108
Flat tire103
– compact wheel103
– Flat Tire Monitor50
– refer to Tire inflation
pressure86
– refer to Wheel changes103
– Tire Pressure Monitor52
Flat Tire Monitor50
– indicator lamp51
– initializing system51
– snow chains91
– system limits51
– warning errors51
Flooding, refer to Driving
through water77
Floor cover72
Fog lamps, indicator lamp57
Folding rear seat back70
Four wheel drive, refer to
xDrive49
Front airbags53
Front fog lamps57
– replacing bulbs102
Front passenger airbags,
automatic deactivation54
Fuel85
– average consumption46
– capacity116
– gauge43
– quality85
Fuel cap84
Fuel display, refer to Fuel
gauge43

Reference
At a glance
Controls
Driving tips
Mobility
123
Inflation pressure monitoring,
refer to
– Flat Tire Monitor50
– Tire Pressure Monitor52
Initializing, refer to Power
supply interruption22,23
INSPECTION44
Instrument cluster11
Instrument lighting58
Instrument panel, refer to
Cockpit10
Integrated universal remote
control65
Interior lamps58
– remote control19
Interior motion sensor25
– switching off19,25
Interior rearview mirror31
– automatic dimming
feature77
Interlock36
Intermittent mode of the
wipers40
Interval indicator, Service44
J
Jacking points104
Jump starting108
K
Key Memory32
Keys18
– key-specific settings, refer
to Vehicle Memory,
Key Memory32
Kick-down39
L
Labeling, tires88
Lamps and bulbs99
Lashing eyes, refer to
Securing cargo79
LATCH child-restraint fixing
system34LEDs light-emitting
diodes100
Length, refer to
Dimensions115
License plate lamp, replacing
bulbs102
Liftgate21
– closing21
– emergency operation21
– opening from outside21
– opening manually21
– remote control19
Liftgate lamp, replacing
bulbs103
Lifting handle, compact
wheel103
Light-alloy wheels, care, refer
to Caring for your vehicle
brochure
Light-emitting diodes
LEDs100
Lighter68
Lighter socket69
Lighting of instruments58
Lights, refer to Parking lamps/
low beams56
Lights on warning56
Light switch56
Load
– determining load limit78
– refer to Cargo loading78
Lock buttons, doors, refer to
Locking21
Locking
– from inside20
– from outside19
Low beams56
– automatic56
– indicator lamp, defective
bulb56
– replacing bulbs100
Lower back support, refer to
Lumbar support28
Lug bolts104
– torque105Luggage compartment21
– capacity116
– cover, refer to Cargo area
cover71
– floor cover72
– increasing volume70
– opening/closing, refer to
Liftgate21
– opening from outside21
– opening with remote
control19
Luggage compartment, refer
to Cargo area70
Luggage compartment cover,
refer to Cargo area cover71
Luggage compartment lid
– emergency operation, refer
to Opening manually21
– opening with remote control,
refer to Unlocking liftgate19
Luggage compartment lid,
refer to Liftgate21
Luggage compartment net,
refer to Partition net72
Luggage rack, refer to Roof-
mounted luggage rack80
Lug wrench103
Lumbar support28
M
Maintenance97
– refer to Service Interval
Display44
Maintenance system97
Malfunctions
– automatic transmission39
– door lock20
– fuel filler door84
– liftgate21
– panorama glass sunroof24
Manual air distribution60,63
Manual operation
– door lock20
– driver's door20
– fuel filler door84
– liftgate21
– panorama glass sunroof24
Manual transmission38

Reference
At a glance
Controls
Driving tips
Mobility
125
Power socket in cargo area69
Power windows22
– initializing22
– safety switch22
Precious wood, refer to Caring
for your vehicle brochure
Pressure, tires86
Pressure monitoring,
tires50,52
Programming settings, refer
to Vehicle Memory,
Key Memory32
Puncture, Flat Tire Monitor50
R
Radiator, refer to Coolant95
Radio, refer to Owner's
Manual for Radio/Onboard
Computer
Radio-control key, refer to
Master key with remote
control18
Radio navigation, refer to
separate Owner's Manual
Rain sensor40
Range, setting units45
Reading lamps
– front58
– rear58
Rear armrest, refer to Armrest,
rear68
Rear backrests, folding70
Rear lamps, refer to Tail
lamps102
Rear reflector, refer to Tail
lamps102
Rear seat back, folding70
Rearview mirrors, exterior30
Rear window defroster
– air conditioner60
– automatic climate control64
Rear window safety switch22
Rear window wiper41
– wiper blade replacement99
Rechargeable flashlight67Recirculated-air mode
– air conditioner60
– automatic climate control63
Refueling84
Remaining distance, refer to
Cruising range46
Remaining distance for
Service44
Remote control19
– garage-door opener65
– liftgate19
– malfunction19
Removing condensation,
windows
– air conditioner60
– automatic climate control63
Replacement fuses106
Replacement keys18
Replacing bulbs, refer to
Lamps and bulbs99
Replacing tires
– new wheels and tires89
– wheel changes103
Replacing windshield
wiper99
Report an accident, refer to
Initiating an emergency
call107
Reporting safety defects7
Required oil grades, refer to
Approved engine oils95
Reserve indicator lamp, refer
to Fuel gauge
43
Restraint systems
– for children33
– refer to Safety belts29
Reverse gear
– automatic transmission with
Steptronic39
– manual transmission38
Roadside Assistance, refer to
Receiving assistance107
Roadside parking lamps57
Roller cover for cargo area,
refer to Cargo area cover71
Roll-up cover, refer to Cargo
area cover71Roof load capacity, refer to
Weights116
Roof-mounted luggage
rack80
Rope, refer to Tow starting
and towing109
Rotating coin holder, refer to
Storage compartments67
Run-flat indicator, refer to
– Flat Tire Monitor50
S
Safety belts29
– safe seating position26
– warning lamp30
Safety belt tensioners, refer to
Safety belts29
Safety defects, reporting7
Safety feature
– panorama glass sunroof23
– window22
Safety systems, refer to
– ABS Antilock Brake
System48
– Airbags53
– DSC Dynamic Stability
Control48
– xDrive49
Screw thread for tow
fitting109
Seat heating29
Seat memory, refer to Seat
and mirror memory29
Seats
– adjusting electrically27
– adjusting sports seat28
– heating29
– memory, refer to Seat and
mirror memory29
– sitting safely26
– storing the setting29
Securing cargo, refer to Cargo
loading78
Selector lever
– automatic transmission38
– automatic transmission with
Steptronic38
