2006 BMW MOTORRAD K 1200 S technical data

Threaded fastenersFront wheelValue ValidFront brake caliper to wheel
carrier
M8 x 32 -10.9 30 Nm
Clamping screw for quick-
release axle in wheel
carrier
M8 x 30 19 Nm
Quick-release axle in threaded
bush
M24 x 1.5 50 NmRear wheelValue ValidSilencer to rear footrest, right
M8 x 3016 Nm
Silencer to manifold
M8 x 60 - 10.9 35 Nm
Rear wheel to wheel flange
9133zTechnical data

Rear wheelValue ValidWheel carrier with threaded
bushes, M10 x 43 x 1.25Tighten in diagonally opposite
sequence
60 Nm
Wheel carrier with cut thread,
M10 x 40 x 1.25 Tighten in diagonally opposite
sequence
60 NmEngineType
Type, engine
Transversely mounted, four-cylinder four-
stroke in-line engine tilted 55° forward, with
four valves per cylinder, two overhead cam-
shafts with cam followers; liquid cooled, with
electronic fuel injection, integrated six-speed
cassette gearbox, dry-sump lubrication.
Technical data
Effective displacement 1157 cm
3
Cylinder bore79 mm
Piston stroke 59 mm
Compression ratio 13:1
9134zTechnical data

Nominal output123 kW, - At engine speed: 10250 min
-1
with OE Reduced power output, 74 kW: 74 kW, - At engine speed: 7000 min
-1
with OE Reduced power output, 79 kW: 79 kW, - At engine speed: 8750 min
-1
Max. torque130 Nm, - At engine speed: 8250 min
-1
with OE Reduced power output, 74 kW: 110 Nm, At: 5250 min
-1
with OE Reduced power output, 79 kW: 103 Nm, At: 4500 min
-1
Maximum permissible engine speed11000 min
-1
Idle speed1150
±50
min
-1
Fuel
Recommended fuel grade 98 ROZ/RON, Premium plus unleaded
95 ROZ/RON, Premium unleaded (fuel grade,
usable with power- and consumption-related
restrictions)
Fuel tank capacity 19 l, Usable 4 l, Including reserve of
9135zTechnical data

Engine oil
Engine oil capacity, total3.5 l, With filter change
0.5 l, Difference between MIN / MAX marks
Lubricant Castrol GPS 10W-40 (SAE 10W40; API SG;
JASO MA)
Oil grades Mineral oils of API classification SF through
SH. BMW Motorrad recommends not using
oil additives, because they can have a detri-
mental effect on clutch operation. Please do
not hesitate to contact your authorised BMW
Motorrad dealer if you have any questions re-
lating the choice of a suitable engine oil for
your motorcycle.
Permissible viscosity classes
SAE 10 W-40 -20 °C, Operation at low temperatures
SAE 15 W-40 -10 °C
9136zTechnical data

Riding specificationsTop speed>200 km/hClutchClutch typeMultiplate clutch running in oil bathTransmissionGearbox typeClaw-shift 6-speed cassette gearbox, integ-
rated into engine block
9137zTechnical data

Gear ratios
Gearbox transmission ratios1.559 (92:59 teeth), Primary transmission ra-
tio
2.294 (39:17 teeth), 1st gear
1.789 (34:19 teeth), 2nd gear
1.458 (35:24 teeth), 3rd gear
1.240 (31:25 teeth), 4th gear
1.094 (35:32 teeth), 5th gear
0.971 (33:34 teeth), 6th gear
1.045 (23:22 teeth), Angular drive
9138zTechnical data

Final driveFinal drive, typeShaft drive with bevel gears
Final drive gear ratio 2.82Running gearFront suspensionDouble leading link
Front suspension - total suspension travel 115 mm, Static 125 mm, Dynamic
Rear suspension type Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring preload steplessly
hydraulically adjustable, rebound stage
damping steplessly adjustable.
with OE Electronic Suspension Adjust-
ment (ESA): Central spring strut pivoted to lever system
with coil spring and single-tube gas-filled
shock absorber; spring basic setting three-
way adjustable, compression and rebound
stages each three-way adjustable
Rear suspension, total suspension travel 135 mm, at wheel
9139zTechnical data

BrakesFront brake, typehydraulically operated twin disc brake with 4-
piston fixed calipers and floating brake discs
Front brake pads, material Sintered metal
Rear brake, type Hydraulically operated disc brake with 2-
piston floating caliper and fixed disc
Rear brake pads, material Organic materialWheels and tyresFront wheel, typeCast aluminium, MT H2
Front wheel, rim size 3.50" x 17"
Front wheel, tyre designation 120/70 ZR 17
Rear wheel, type Cast aluminium, MT H2
Rear wheel, rim size 6.00" x 17"
Rear wheel, tyre designation 190/50 ZR17
9140zTechnical data
