2006 AUDI A4 Audio

CD/SD 74CD/SDIntroductionGeneral
C D a n d M P 3 o p e r a t i o n i s s e l e c t e d b y u s i n g t h e
function button.Depending on the equipment in your vehicle, you can use the
function to play an audio CD in the DVD navigation drive,
use a CD changer*
page 79 or the MP3 player integrated into the
Navigation System page 83.
You switch between the CD and MP3 function by using the control
button with the Source function
page 77.
Selecting CD functionFig. 74 Display: Main CD menu (example of a list of tracks)– Insert an audio CD into a drive
page 34
– Press the function button
page 16. A main
audio menu
fig.74 or the previously active function
menu appears in the display.
– If necessary, press the control button with the Source
function and select CD
page 77.
– Press one of the control buttons
page 17 to move to
the appropriate submenus to
fig.74.
CD/SD
CD/SD
CD/SD
A1
A4

CD/SD75
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP The following submenus are available in the CD
function:The following submenus are available in the CD Setup
function:
Selecting MP3 functionFig. 75 Display: Main MP3 menu (example of a list of tracks)– Insert an MP3 card or an MP3 CD into the appropriate
drive
page 37.
Control button
functions
page 74,
fig. 74
CD submenus

CD list*
Audio CD
Empty
CD ROM
CD unreadable

Source
CD
MP3

Sound
Balance
Fader
Tr e b l e
Bass
DSP
a)b)

Volume settings (Navigation info)
a)Digital Signal Processingb)Vehicles with a BOSE® sound system in conjunction with an AudioPilot do
n o t h a v e a D S P f u n c t i o n . I n t h i s c a s e y o u r v e h i c l e i s e q u i p p e d w i t h D y n a m i c
Noise Compensation
page 94.

CD control
Forward
Reverse
Next
Previous
Random
Scan
A1A2A3A4
CD Setup submenu
Press the
function button in
the CD function
page 82
Repeat CD
SETUP

CD/SD 76
– Press the function button
page 16. A main
audio menu
page 74, fig.74 or the previously active
function menu appears in the display.
– If necessary, press the control button with the Source
function and select MP3
page 77.
– Press one of the control buttons
page 17 to move to
the appropriate submenus to
page 75, fig.75.
The following submenus are available in the MP3
function:
CD/SD
A1
A
Control button
functions
page 74,
fig. 74
MP3 submenus

MP3 list
CD
Card 1
Card 2
Navigation DVD
Empty
Audio
CD ROM
Unreadable

Source
CD
MP3

Sound
Balance
Fader
Tr e b l e
Bass
DSP
a)b)

Volume settings (Navigation info)
a)Digital Signal Processing

MP3 ctrl
Forward
Reverse
Next
Pre viou s
Random
Scan
Name (Details)
A1AA A

CD/SD77
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP The following submenus are available in the MP3
Setup function:
Source control buttonSelecting audio sourceFig. 76 CD/SD: List of available audio sources–Press the Source control button in the CD or MP3 menu.
– Select the desired equipment by rotating and pressing
the control knob.Depending on vehicle equipment, the following choices are avail-
able:

CD


MP3
Various submenus are available, depending on the equipment
selected.
b)Vehicles with a BOSE® sound system in conjunction with an AudioPilot do
n o t h a v e a D S P f u n c t i o n . I n t h i s c a s e y o u r v e h i c l e i s e q u i p p e d w i t h D y n a m i c
Noise Compensation
page 94.
MP3 Setup submenus
Press the
function button in
the MP3 function
page 88
Repeat
With subdirectories
Tr a c k d i s p l a y
Categ. display
SETUP

CD/SD 78
Tips

Sound controls can be adjusted individually for each piece of
equipment
page 92.


The audio source selected is shown in the title line of the
display.
Main CD menuSelecting a CD trackFig. 77 CD: Track selection (main menu)–Press the Source control button from a CD/SD menu.
– Select CD
page 77.– In the main CD menu
fig.77, select the desired track
on the active CD with the control knob.
The playing time of the track will be displayed after the track name.
If the vehicle has a CD changer*, you can select a CD using the CD
list control button
page 79
An audio CD inserted into the DVD Navigation drive
page 35 is
shown as CD 1 in the title line. If your vehicle is equipped with a CD
changer*, an audio CD inserted into the DVD Navigation drive can
be selected with the CD list control button via location CD 7.

CD/SD79
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP
CD list control buttonApplies to vehicles: with CD changerCD selectionFig. 78 CD: Selecting CDs from the changer–Press the CD list control button in the CD menu.
– Select the desired CD
fig.78. The CD title list is
displayed.
– Select your track as necessary.The selected CD location appears in the title line.
If there is no CD in one of the slots in the changer, “Empty” is
displayed in the CD list.Audio CDs (CD-A) can also be played in the DVD Navigation drive. If
there is a CD changer* in the vehicle, an audio CD inserted in the
DVD Navigation drive can be played over CD 7.
Sound control buttonSound settingsStarting at
page 92, you can read how to select the sound
settings for the CD function.

Adjusting sound settings 92Adjusting sound settingsSetting basic sound characteristicsFig. 96 Sound: Setting the balance (example radio menu)Fig. 97 Sound: Balance adjustment (example radio menu)
– Press the control button for the Sound function from an
audio or Setup menu.
– Select the desired sound setting (e.g. Balance)
fig.96
with the control knob.
– R o t a t e t h e s p e c i f i c c o n t r o l k n o b i n t h e s o u n d a d j u s t m e n t
menu (e.g. Balance)
fig.97 to set the sound character-
istic to your liking.
– B y p r e s s i n g t h e c o n t r o l k n o b o r t h e b u t t o n , t h e
setting is imported and you leave the settings menu.The Display
fig.97 shows the degree of adjustment.
RETURN

Adjusting sound settings93
General operation
RADIO, CD
NAME, TEL
NAV, INFO
CAR, SETUP The following sound adjustments are possible:


Balance (left/right volume relationship)


Fader (front/rear sound relationship)


Tr e b l e


Bass


DSP (Digital Signal Processing)
page 93


Volume settings (Navigation info)
page 94
The sound setting for the Tre b l e and Bass (lows) can be adjusted
separately for radio, CD and MP3 operation.
The settings that you enter apply to the operating mode that is
currently active in the Navigation System. If you change the bass
setting, for example, when playing a CD, it will not affect radio or
MP3 operation.
DSP (Digital Signal Processing)Fig. 98 DSP: GALA settings– Press the control button for the Sound function from an
audio or Setup menu.
– Select DSP.
– Select GALA.
– Select one of the five levels, or
– Select off to switch the function off.Th e GALA function matches the volume to the speed to compensate
for road and wind noise.
If you set level 1, the volume is increased less as speed increases. If
you set level 5, the volume is increased more as speed increases.
