3B1-18 POWER STEERING (P / S) SYSTEM
ªAº
1
1
1. Mark
1. Tie-rod lock washer
(A)
INSTALLATION
1) Install new tie-rod lock washer and tie-rod to rack.
2) Tighten tie-rod ball nut to specified torque.
Tightening Torque
(a): 85 N
.m (8.5 kg-m, 61.5 lb-ft)
3) Bend lock washer 2 place at the flat part of tie-rod ball nut.
4) Apply grease to ªAº indicated in figure.
5) Position boot properly in grooves of gear case and tie-rod.
Check to ensure that boot is free from twist and dent.
6) Fasten boot with new clamp and clip securely.
Special Tool
(A): 09943-55010
7) Install tie-rod end lock nut and tie-rod end to tie-rod.
Position lock nut to marking made in removal.
NOTE:
When tie-rod was replaced, measure length ªAº on re-
moved tie-rod and use it on new replacement tie-rod so as
to position lock nut properly.
8) Install steering gear case. Refer to ªPOWER STEERING GEAR
BOX ASSEMBLY INSTALLATIONº in this section.

YH4
GRAND
VITARA
3B1-26 POWER STEERING (P / S) SYSTEM
09915-77420
Oil pressure gauge
attachment and hose set09915-77410
Oil pressure gauge09943-55010
Boot clamp plier
TIGHTENING TORQUE SPECIFICATION
FasteningpartsTightening torqueFastening artsN.mkg-mlb-ft
Gear box mounting bolts555.540.0
Gear box cylinder pipe flare nuts292.921.0
Gear box low pressure pipe union bolt404.029.0
Gear box high pressure pipe union bolt353.525.5
Tie-rod end lock nut656.547.0
G16 Type engine555.540.0
Pump bracket boltJ20 Type engine252.518.5
H25 Type engine454.532.5
Pump union bolt606.043.5
Oil pump mount bolts252.518.5
Pipe clamp bolt / Reservoir bracket bolt111.18.0
Steering shaft joint bolt252.518.0
High pressure flare nuts404.029.0
Pump cover bolts232.317.0
Plug606.043.5
Pressure switch (Terminal)282.820
Suction connector bolt101.07.5
Tie-rod end nut484.835.0
Tie-rod (for canvas top LH model only)858.561.5
REQUIRED SERVICE MATERIAL
MATERIALSRECOMMENDED
SUZUKI PRODUCTUSE
Lithium greaseSUPER GREASE (A)
(99000-25010)
Oil seal lip of P / S pump pulley shaft
Power steering fluidAn equivalent of DEXRON
-III or
DEXRON
-II

To fill P / S fluid reservoir

Parts lubrication when installing
SPECIAL TOOL

YH4
GRAND
VITARA
FRONT SUSPENSION 3D-3
DIAGNOSIS
DIAGNOSIS TABLE
Refer to Section 3.
STABILIZER BAR AND BUSHING CHECK
BAR
Inspect for damage or deformation. If defective, replace.
BUSHING
Inspect for damage, wear or deterioration. If defective, replace.
STRUT DAMPER AND / OR COIL SPRING
CHECK
1) Inspect strut for oil leakage. If strut is found faulty, replace it as
an assembly unit, because it can not be disassembled.
2) Strut function check
Check and adjust tire pressures as specified.
Bounce body three or four times continuously by pushing front
end on the side with strut to be checked. Apply the same amount
of force at each push and note strut resistance both when
pushed and rebounding.
Also, note how many times vehicle body rebounds before com-
ing to stop after hands are off. Do the same for strut on the other
side.
Compare strut resistance and number of rebound on the right
with those on the left.
And they must be equal in both. With proper strut, body should
come to stop the moment hands are off or after only one or two
small rebounds. If struts are suspected, compare them with
known good vehicle or strut.
3) Inspect for damage or deformation.
4) Inspect strut boot for damage or crack.
5) Inspect for cracks or deformation in spring seat.
6) Inspect for deterioration of bump stopper.
7) Inspect strut mount for wear, cracks or deformation.
Replace any parts found defective in steps 2) ± 7).
SUSPENSION ARM / KNUCKLE CHECK
Inspect for cracks, deformation or damage.

YH4
GRAND
VITARA
4A2
1. Drive shaft oil seal
2. Double off set joint (DOJ)
3. Joint circlip
4. DOJ boot
5. Ball joint boot
6. Ball joint assembly (RH side)
7. Drive shaft assembly (LH side)
8. Left drive shaft
9. Drive shaft bearing circlip
10. Drive shaft bearing
FRONT DRIVE SHAFT / SHAFT BEARING, OIL SEAL 4A2-1
SECTION 4A2
FRONT DRIVE SHAFT/SHAFT BEARING,
OIL SEAL
CONTENTS
GENERAL DESCRIPTION4A2- 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSIS4A2- 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Diagnosis Table4A2- 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Shaft Boot And Joint Check 4A2- 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE4A2- 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drive Shaft4A2- 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shaft Bearing / Oil Seal4A2- 9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TIGHTENING TORQUE SPECIFICATIONS4A2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REQUIRED SERVICE MATERIALS4A2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS4A2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION
The drive shaft joint is a constant velocity joint (C.V. joint) which slides in the axial direction. The joint is composed
of an outer race, cage, inner race and balls. In the turning direction, the joint rotates in the same way as a ball bear-
ing. The balls lock rotation completely and transmit drive. In addition this vehicle is also characterized by a function
that the shaft can slide through the balls in the grooves of the outer race in the extension / contraction direction of
the drive shaft.

YH4
GRAND
VITARA
4A2-2 FRONT DRIVE SHAFT / SHAFT BEARING, OIL SEAL
DIAGNOSIS
DIAGNOSIS TABLE
ConditionPossible CauseCorrection
When starting:
Abnormal Noise
Loose wheel nuts.

Loose drive shaft flange bolts.

Broken or otherwise damaged wheel
bearing.Tighten wheel nuts.
Tighten drive shaft flange bolts.
Replace or change.
When making turns:
Abnormal Noise
Grease leakage from drive shaft joint
boot.

Worn or broken drive shaft joint.Replace joint boot and apply grease.
Replace drive shaft joint.
When running:
Abnormal Noise
Broken drive shaft joint.

Poorly lubricated or worn drive
shaft joint.

Loose drive shaft flange bolts.

Deformed drive shaft oil seal.Replace drive shaft joint.
Lubricate or replace joint.
Tighten drive shaft flange bolts.
Replace.
Vibration
Worn drive shaft joint.

Deformed drive shaft oil seal.

Deformed drive shaft.Replace drive shaft joint.
Replace.
Replace.
DRIVE SHAFT BOOT AND JOINT CHECK
Check drive shaft boot for tear. If even a small tear is noted, replace
with new one.
Check drive shaft joint for wear, breakage and other damage and
replace if any defect exists.

YH4
GRAND
VITARA
1. Oil filler / level plug
2. Front drain plug
1. Circlip
2. Washer
1. Drive shaft flange
bolts and nuts
1. Oil seal
FRONT DRIVE SHAFT / SHAFT BEARING, OIL SEAL 4A2-3
ON-VEHICLE SERVICE
DRIVE SHAFT
REMOVAL (LEFT SIDE)
1) Hoist vehicle and remove wheel.
2) Remove axle shaft drive flange.
3) Remove drive shaft circlip and front spindle thrust washer.
4) Remove drive shaft flange bolts and nuts.
5) Remove drive shaft assembly to differential side as shown in left
figure.
CAUTION:
To prevent breakage of boots (wheel side and differential
side), be careful not to bring them into contact with other
parts when removing drive shaft assembly.
6) Remove drive shaft thrust washer (vehicle with G16 or J20 en-
gine) from drive shaft and remove drive shaft oil seal as shown
in figure.
CAUTION:
Be careful not to cause damage to drive shaft joint.

YH4
GRAND
VITARA
1. Oil filler / level plug
2. Front drain plug
1. Circlip
2. Washer
1. Differential side joint
2. Tire lever
3. Front differential assembly
1. Oil seal 2
1
4A2-4 FRONT DRIVE SHAFT / SHAFT BEARING, OIL SEAL
REMOVAL (RIGHT SIDE)
1) Hoist vehicle and remove wheel.
2) Drain differential gear oil.
3) Remove axle shaft drive flange.
4) Remove circlip and front spindle thrust washer.
5) Remove knuckle and wheel hub comp, refer to steps 5) to 7) and
9) to 14) of item COIL SPRING REMOVAL in Section 3D.
6) Remove drive shaft assembly.
To detach snap ring fitted on the spline of differential side joint
(inboard joint) from differential side gear, pull inboard joint by us-
ing a tire lever.
CAUTION:
To prevent breakage of boots (wheel side and differential
side), be careful not to bring them into contact with other
parts when removing drive shaft assembly.
7) Remove drive shaft thrust washer (to vehicle with G16 or J20 en-
gine) from drive shaft and remove drive shaft oil seal as shown
in figure.
CAUTION:
Be careful not to cause damage to drive shaft joint.

YH4
GRAND
VITARA
1. Boot
2. Snap ring
1. Circlip
2 Snap ring plier
3. Cage
FRONT DRIVE SHAFT / SHAFT BEARING, OIL SEAL 4A2-5
DISASSEMBLY
1) Remove boot band of differential side joint.
2) Slide boot toward the center of shaft and remove snap ring from
outer race, then take shaft out of outer race.
3) Remove circlip and then cage.
4) Remove inside and outside boots from shaft.
CAUTION:

Do not disassemble wheel side joint (outboard joint). If
any malcondition is found in joint, replace it as assem-
bly.

Do not disassemble ball joint of differential side joint.
If any malcondition is found in ball joint, replace differ-
ential side joint assembly.
INSPECTION

Check boots for breakage or deterioration. Replace them as nec-
essary.

Check circlip, snap ring and boot bands for breakage or deforma-
tion. Replace as necessary.
CLEANING

Wash disassembled parts (except boots) in degreaser. After
washing, dry parts completely by blowing air.

Clean boots with cloth. DO NOT wash boots in degreaser, such
as gasoline or kerosene, etc.
Washing in degreaser causes deterioration of boot.
