2005 SUBARU LEGACY clock

6-9
Interior equipment
– CONTINUED –
Grasp the dual cupholders’ divider plate at the base.
Turn it counterclockwise to remove it.
If you hold the divider plate at the top while
turning it counterclockwise, it may break. To use again as cupholders:
Insert the protrusion on the back of the divider plate
into the hole in the center of the console box. Grasp
the divider plate at the base, and turn it clockwise to fit it.
If you hold the divider plate at the top while
turning it clockwise, it may break.
UB6209BA
UB6210BA

7-6
Starting and operating
A) Open
B) Close
3. Remove the fuel filler cap by turning it slowly coun-
terclockwise.
" Gasoline vapor is highly flammable. Before
refueling, always first stop the engine and make
sure that there are no lighted cigarettes, open
flames or electrical sparks in the adjacent area. " When opening the cap, do not remove the
cap quickly. Fuel may be under pressure and
spray out of the fuel filler neck especially in hot
weather, which may cause injury.
4. Stop filling the tank after the fuel filler pump auto-
matically clicks off. Do not add any more fuel.
5. Put the cap back on, turn it clockwise until you hear
a clicking noise. Be certain not to catch the tether un-
der the cap while tightening.
6. Close the fuel filler lid completely.
If you spill any fuel on the painted surface, rinse it off
immediately. Otherwise, the painted surface could be
damaged.
NOTE
A B
UB7501CB
UB3526AA

9-9
In case of emergency
– CONTINUED –
6. Turn the attaching bolt counterclockwise, then take
the spare tire out. Station wagon:
1. Open the lid and hang the hook provided on the
under side of the lid on the rear edge of the roof to
keep the lid open.
UB9518BA
UB6522BA

9-12
In case of emergency
6. Turn the attaching bolt counterclockwise, then take
spare tire out.
If the spare tire provided in your vehicle is a temporary
spare tire, carefully read the section “Temporary spare
tire” in this chapter and strictly follow the instructions.
NOTE
Make sure the jack is well lubricated before using
it.
7. Loosen the wheel nuts using the wheel nut wrench
but do not remove the nuts.
UB9518BAUB9203BA

9-15
In case of emergency
– CONTINUED –
surface of the wheel and hub with a cloth.
12.Put on the spare tire. Replace the wheel nuts.
Tighten them by hand.
Do not use oil or grease on the wheel studs or
nuts when the spare tire is installed. This could
cause the nuts to become loose and lead to an
accident.
13.Turn the jack handle counterclockwise to lower the vehicle. 14.Use the wheel nut wrench to securely tighten the
wheel nuts to the specified torque, following the tight-
ening order in the illustration.
The torque for tightening the nuts is 74 to 89 lbf·ft (100
to 120 N·m, 10 to 12 kgf·m). This torque is equivalent
to applying about 88 to 110 lbs (40 to 50 kg) at the top
of the wheel nut wrench. Never use your foot on the
wheel nut wrench or a pipe extension on the wrench
because you may exceed the specified torque. Have
the wheel nut torque checked at the nearest automo-
tive service facility.
15.Store the flat tire in the spare tire compartment.
Put the spacer and tighten the attaching bolt firmly.
Also store the jack and jack handle in their storage lo-
1
42
53
UG9511BB
UB9518CA

9-21
In case of emergency
– CONTINUED –
Confirm that the cooling fan is turning. If the fan is not
turning, immediately turn the engine off and contact
your authorized dealer for repair.
3. After the engine coolant temperature has dropped, turn off the engine.
If the temperature gauge stays at the overheated
zone, turn the engine off.
4. After the engine has fully cooled down, check the
coolant level in the reserve tank.
If the coolant level is below the “MIN” mark, add cool-
ant up to the “MAX” mark.
5. If there is no coolant in the reserve tank, add cool-
ant to the reserve tank. Then remove the radiator cap
and fill the radiator with coolant.
If you remove the radiator cap from a hot radiator, first
wrap a thick cloth around the radiator cap, then turn
the cap counterclockwise slowly without pressing
down until it stops. Release the pressure from the ra-
diator. After the pressure has been fully released, re-
move the cap by pressing down and turning it.Towing
Never tow AWD vehicles (both AT and MT) with
the front wheels raised off the ground while the
rear wheels are on the ground, or with the rear
wheels raised off the ground while the front
wheels are on the ground. This will cause the
vehicle to spin away due to the operation or de-
terioration of the center differential.
If towing is necessary, it is best done by your SUBARU
UG9013BA

9-31
In case of emergency
– CONTINUED –
4. Insert the wrench in the end of the motor shaft.
To lower the moonroof, turn the wrench clockwise.
To close the moonroof, turn the wrench counterclock-wise.
Have your vehicle checked and repaired by an autho-
rized SUBARU dealer.
Station wagon:
1. Take out the hex-headed wrench from the glove
box and screwdriver from the tool bag.
2. If the sun shade is completely open, slide the sun
shade toward the front of the vehicle by taking the fol-
lowing steps. 1) Push the slider at the rear of the rear moonroof
frame toward the rear of the vehicle.
UB9553BAUB9548BA

9-33
In case of emergency
– CONTINUED –
4. Insert the wrench in the end of the motor shaft.
To close the moonroof, turn the wrench clockwise.
Have your vehicle checked and repaired by an autho-
rized SUBARU dealer.
Maintenance tools !Jack
A jack and other maintenance tools are stored in the
tool bucket in the center of the spare tire located in the
trunk or in the cargo area. Sedan: To take out the jack and maintenance tools,
open the floor cover and remove the bucket from the
center of the spare tire. Then, take the jack out of the bucket.
UB9533BA
UB9209BA
