5-31
Audio
– CONTINUED –
surface is touched directly, contamination could cause
poor tone quality. Do not touch the disc surface.yUse a clean disc whenever possible. If there are de-
posits, wipe the disc surface from the center outward
with a dry, soft cloth. Be sure not to use a hard cloth,
thinner, benzene, alcohol, etc. y Do not use any disc that is scratched, deformed, or
cracked. Also, do not use any disc that has a non-stan-
dard shape (for example, a heart shape). Malfunctions
or problems might result. y A disc is vulnerable to heat. Never keep it either in
places exposed to direct sunlight, near heaters or in
vehicles parked in the sun or hot days.
HS5018BA

12-7
Specifications
– CONTINUED –
Fuses and circuits „Fuse panel located behind the coin tray
1
23456
78 9101112
13 14 15
16 17 18 19
20 21 22 23
HSC001BB
Fuse panelFuse ratingCircuit
115AyHeater fan
215AyHeater fan
315AyPower door lock
y Remote keyless entry
420AyCigarette lighter
y Remote controlled rear
view mirrors
510AyTail light
y Parking light
615AySRS airbag
715AyFog light
820AyABS solenoid
915AyRadio
10Empty
1115AyEngine ignition system
y SRS airbag
y AT control system

12-8
Specifications
1210Ay
Illumination brightness control
1310AyCombination meter
y SRS lamp
1410AyRear window wiper and washer
1530AyWindshield wiper and washer
1620AyBrake light
1715AyAir conditioner
1815AyBackup light
y Cruise control
1920AyMirror heater
20Empty
21Empty
2210AyABS ignition
Fuse panelFuse ratingCircuit
2320AyAccessory power outlet
(cargo)
y Seat heater
Fuse panelFuse ratingCircuit

14-5
Index
Seatbelt pretensioners .................................. 1-28
Seats .............................................................. 1-2
Turn signal light .......................................... 11-73
Fuel ..................................................................... 7-2
Economy hints ................................................ 8-2
Filler lid and cap ............................................. 7-4
Gauge .................................................. 3-10, 3-17
Requirements ................................................. 7-2
Fuses ............................................................... 11-65
Fuses and circuits ............................................. 12-7 G
GAWR (Gross Axle Weight Rating) ................... 8-19
Glove box ............................................................ 6-5
GVWR (Gross Vehicle Weight Rating) .............. 8-19 H
Hazard warning flasher ....................................... 3-7
Head restraint adjustment (Front) ........................ 1-5
Headlight beam leveler ...................................... 3-34
Headlight flasher ............................................... 3-31
Headlight indicator light ..................................... 3-28
Headlights .............................................. 3-30, 11-70
Headrest adjustment (Wagon) ........................... 1-11
Heater operation .................................................. 4-6
High beam indicator light ................................... 3-27
High mount stop light ....................................... 11-83 Horn ................................................................... 3-51
Hose and connections ..................................... 11-19 I
Ignition switch ...................................................... 3-3
Illuminated entry ................................................ 2-11
Illumination brightness control ........................... 3-33
Immobilizer .......................................................... 2-3
Indicator light
High beam .................................................... 3-27
Selector lever position .................................. 3-27
Turn signal .................................................... 3-27
Inside mirror ...................................................... 3-45
Intercooler water spray .................................... 11-55 Switch ........................................................... 3-44
Warning light ................................................. 3-26
Interior light .......................................................... 6-2
Internal trunk lid release handle ........................ 2-28 J
Jack and jack handle ......................................... 9-24
Jump starting ..................................................... 9-13 K Key Interlock release ............................................. 3-6

14-8
Index
Trunk light ................................................... 11-82
REV indicator light and buzzer .......................... 3-13
Rocking the vehicle ........................................... 8-16
Roof rail and crossbar ....................................... 8-20 S Seat Fabric ........................................................... 10-6
Heater ............................................................. 1-7
Seatbelt .................................................................. 6
Maintenance ................................................. 1-27
Pretensioners ............................................... 1-28
Safety tips ..................................................... 1-13
Warning light and chime ...................... 1-15, 3-20
Seatbelts ........................................................... 1-13
Security system ................................................. 2-17
Selector lever .................................................... 7-23 Position indicator .......................................... 3-27
Shift lock release ............................................... 7-27
Side ventilators .................................................... 4-3
Snow tires ......................................................... 8-14
Sounding a panic alarm ..................................... 2-11
Spark plugs ..................................................... 11-28
Specifications .................................................... 12-2
Speedometer .............................................. 3-8, 3-15
SRS airbag (Supplemental Restraint System airbag) ....................................................... 6, 1-53 SRS airbag system monitors ............................. 1-73
SRS airbag system servicing ............................ 1-74
SRS airbag system warning light ...................... 3-20
SRS frontal airbag ............................................. 1-57
SRS side airbag ................................................ 1-65
Starting the engine .............................................. 7-9
State emission testing (U.S. only) ....................... 7-7
Stopping the engine .......................................... 7-11
Storage compartments ........................................ 6-5
Sun shades ....................................................... 2-35
Sun visors ........................................................... 6-4
Supplemental Restraint System airbag
(SRS) ............................................................. 1-53
Synthetic leather upholstery .............................. 10-6 T
Tachometer ................................................ 3-9, 3-16
Temperature gauge .................................. 3-11, 3-18
Temporary spare tire ........................................... 9-3
Tilt steering wheel ............................................. 3-50 Tire
Chains .......................................................... 8-16
Inspection ................................................... 11-47
Pressures and wear ................................... 11-48
Replacement .............................................. 11-53
Rotation ...................................................... 11-52
Tires .................................................................. 12-5
