2005 SUBARU BAJA keyless

2-1
2
Keys and doors
Keys ............................................................... 2-2 Key number ....................................................... 2-2
Door locks ..................................................... 2-3 Locking and unlocking from the outside ........ 2-3
Locking and unlocking from the inside .......... 2-4
Power door locking switches ...................... 2-5
Remote keyless entry system (if equipped) .............................................. 2-7Locking the doors ............................................. 2-8
Unlocking the doors ......................................... 2-8
Illuminated entry ............................................... 2-9
Vehicle finder function ..................................... 2-9
Sounding a panic alarm ................................... 2-9
Selecting audible signal operation .................. 2-9
Replacing the battery ....................................... 2-10
Replacing lost transmitters .............................. 2-11
Security system (if equipped) ..................... 2-15 System operation .............................................. 2-15
Arming the system ............................................ 2-15
Disarming the system ....................................... 2-17
Sounding a panic alarm ................................... 2-18
Valet mode ......................................................... 2-18
Passive arming .................................................. 2-18
Child safety locks ......................................... 2-21
Windows ........................................................ 2-22 Power windows ................................................. 2-22
Tailgate .......................................................... 2-25 License plate bracket ....................................... 2-26
Switchback door ........................................... 2-27 Switchback door indicator light ...................... 2-31 Moonroof (if equipped) ................................. 2-31
Tilting/sliding moonroof ................................... 2-32
Sun shade .......................................................... 2-33

2-7
Keys and doors
– CONTINUED –
Remote keyless entry system (if
equipped)
yDo not expose the transmitter to severe
shocks, such as those experienced as a result
of dropping or throwing. y Do not take the transmitter apart except when
replacing the battery. y Do not get the transmitter wet. If it gets wet,
wipe it dry with a cloth immediately.
This device complies with Part 15 of the FCC
Rules and with RSS-210 of Industry Canada. Oper-
ation is subject to the following two conditions: (1)
This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved
by the party responsible for compliance could
void the user’s authority to operate the equipment.
Two transmitters are provided for your vehicle.
The keyless entry system has the following functions. y
Locking and unlocking the doors without a key
y Sounding a panic alarm
y Arming and disarming the security system (if your
vehicle is equipped with an optional security system).
See the next section “Security system (if equipped)”
for detailed information.
The operable distance of the keyless entry system is
approximately 30 feet (10 meters). However, this dis-
tance will vary depending on environmental condi-
tions. The system’s operable distance will be shorter
in areas near a facility or electronic equipment emitting
strong radio waves such as a power plant, broadcast
station, TV tower, or remote controller of home elec-
tronic appliances.
The keyless entry system does not operate when the
key is inserted in the ignition switch.

2-10
Keys and doors
„
Replacing the battery
Do not let dust, oil or water get on or in the
transmitter when replacing the battery.
When the transmitter battery begins to get weak,
transmitter range will begin to decrease and the LED
will not illuminate. Replace the battery as soon as pos-
sible.
To replace the battery:
1. Remove the two screws on the back of the trans- mitter case by using a Phillips screwdriver.
2. Separate the case.
3. Remove the old battery from the holder.
1) Positive (+) side facing up
4. Replace with a new battery (Type CR2032 or
equivalent) making sure to install the new battery with
the positive (+) side facing up.
5. Install the back half of the transmitter case.
6. Reinstall the two screws on the back of the trans-
mitter case.
After the battery is replaced, the transmitter must
be synchronized with the keyless entry system’s
control unit. Press either the “LOCK/ARM” or “UN-
HS2017BA
1
HS2018BB

2-11
Keys and doors
– CONTINUED –
LOCK/DISARM” button six times to synchronize
the unit. „ Replacing lost transmitters
If you lose a transmitter or want to purchase additional
transmitters (up to four can be programmed), you
should re-program all of your transmitters for security
reasons. It is recommended that you have your dealer
program all of your transmitters into your system. T Programming the transmitters
The keyless entry system is equipped with a special
code learning feature that allows you to program new
transmitter codes into the system or to delete old
ones. The system can learn up to four unique transmit-
ter codes. The four transmitter codes may be the
same or different. To enter the programming mode:0
1. Press “UNLOCK/DISARM” button to disarm the se-
curity system. (if your vehicle is equipped with the op-
tional security system.)
HS2016CA

2-14
Keys and doors
system has exited the programming mode.
2. Make sure that the keyless entry system properly
operates by operating each transmitter. T
Deleting old transmitter codes
The control unit of the keyless entry system has four
memory locations to store transmitter codes, giving it
the ability to operate with up to four transmitters. When
you lose a transmitter, the lost transmitter’s code re-
mains in the memory. For security reasons, lost trans-
mitter codes should be deleted from the memory.
To delete old transmitter codes, program four trans-
mitter codes into the system. If you have only one cur-
rent transmitter, program it four times. If you have two
current transmitters, program each one twice. If you
have three current transmitters, program two of them
once and the third one twice. This process will leave
only current transmitter codes in the system’s memo- ry.
NOTE
Make sure no one else is operating their keyless
entry system within range of your vehicle when
programming transmitters. If someone else were
to operate their remote transmitter while you are
programming your transmitters, it is possible that
their transmitter code will be programmed into
your system, allowing them unauthorized access to your vehicle.

6-2
Interior and exterior equipments
Interior and exterior equipmentsInterior light „
Dome light
The dome light switch has three positions: ON: The light stays on continuously.
DOOR (middle position): The light comes on when
any of the doors is open. The light remains on for sev-
eral seconds and gradually goes out after all doors areclosed.
The light also can be turned on by use of the keyless
entry transmitter. See the “Remote keyless entry sys-
tem (if equipped)” in chapter 2 for detailed information.
OFF: The light stays off. When leaving your vehicle, make sure the light goes
out to avoid battery discharge.
ON
DOOR
OFF
HS6025BB

12-5
Specifications
– CONTINUED –
Fuses and circuits „Fuse panel located behind the coin tray
19
18
17
16
20
15
14
12
11
10 9
8
7
6
5
4
3
2
1
13
UBC001BB
Fuse panelFuse ratingCircuit
115Ay
Heater fan
215AyHeater fan
315AyPower door lock
y Keyless entry
420AyMirror heater
y Cigarette lighter
y Remote controlled rear
view mirrors
510AyTail light
y Parking light
615AySRS airbag
715AyFront fog light
830AyABS solenoid
915AyRadio
y Clock
1015AyTrailer
1115AyEngine ignition system
y SRS airbag

14-2
Index
A
ABS (Anti-lock Brake System) ........................... 7-33
Warning light ................................................. 3-12
Accessories .............................................. 5-4, 11-60
Air cleaner element ......................................... 11-23
Air conditioner operation ................................... 4-10
Air filtration system ............................................ 4-13
All-Wheel Drive warning light ............................ 3-14
Aluminum wheels ............................................ 11-52
Antenna system .................................................. 5-2
Anti-lock Brake System (ABS) ........................... 7-33
Ashtray .............................................................. 6-12
AT OIL TEMPerature warning light ................... 3-12
Audio set ............................................................. 5-4
Auto-dimming mirror/compass .......................... 3-29
Automatic transmission ............................ 7-15, 7-21 Capacities ..................................................... 12-3
Fluid ............................................................ 11-29
Selector lever ....................................... 7-16, 7-22
Shift lock release ................................. 7-20, 7-30
SPORTSHIFT mode – Turbo models ........... 7-21
Temperature warning light ............................ 3-12
Automatic/Emergency Locking Retractor
(A/ELR) .......................................................... 1-16
AWD warning light ............................................. 3-14 B
Battery ............................................................. 11-56
Jump starting ................................................ 9-18
Replacement (Remote keyless entry system) ...................................................... 2-10
Bed extender ..................................................... 6-17Brake Booster ....................................................... 11-41
Fluid ............................................................ 11-38
Pad and lining ............................................. 11-43
Pedal .......................................................... 11-41
Brake pedal
Free play .................................................... 11-41
Reserve distance ........................................ 11-42
Brake system .................................................... 7-32
Warning light ................................................ 3-13
Braking .............................................................. 7-32
Breaking-in of new brake pads and linings ....................................................... 11-44
Tips ............................................................... 7-32
Bulb Chart ............................................................. 12-8
Replacing ................................................... 11-61
C
Capacities ......................................................... 12-3
