2005 SUBARU BAJA Owners Manual

2-16
Keys and doors
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood and switchback
door are locked.
5. Close all doors.
1) Press to Arm the system.
2) Press to Disarm the system. 1) Security system indicator light
6. Briefly press the “LOCK/ARM” button (for less than
two seconds). All doors will lock, an electronic chirp
will sound once, the turn signal lights will flash once
and the indicator light starts flashing slowly (approxi-
mately once every two seconds).
If any of the doors (except the switchback door) is not
fully closed, an electronic chirp sounds five times, the
turn signal lights flash five times to alert you that the
doors are not properly closed. When you close the
door, the system will automatically arm and doors will
automatically lock.
1 2
HS2016EB
1
UB2033BB

2-17
Keys and doors
– CONTINUED –
TTo arm the system using power door locking
switches
1. Close all windows and moonroof.
2. Remove the key from the ignition switch.
3. Open the doors and get out of the vehicle.
4. Make sure that the engine hood and switchback
door are locked.
5. Close the doors but leave only the driver’s door or
the front passenger’s door open.
6. Push the power door locking switch forward
(“LOCK” side) to set the door locks.
7. Close the door. An electronic chirp will sound once,
the turn signal lights will flash once and the indicator
light will start flashing slowly (approximately once ev- ery two seconds) to inform you that the system hasarmed.
NOTE
The system can be armed even if the engine hood,
the windows, the switchback door and/or moon-
roof are open. Always make sure that they are fully
closed before arming the system. „
Disarming the system
Briefly press the “UNLOCK/DISARM” button (for less
than two seconds) on the remote transmitter. The driv-
er’s door will unlock, an electronic chirp will sound
twice, the turn signal lights will flash twice and the in-
dicator light will go off.
To unlock all other doors, briefly press the “UNLOCK/
DISARM” button a second time. T Emergency disarming
If you cannot disarm the system using the transmitter
(i.e. the transmitter is lost, broken or the transmitter
battery is too weak), you can disarm the system with-
out using the transmitter. To disarm the system:
1. Unlock the door with the key and then open the
door.
6
7
UB2024CC

2-18
Keys and doors
2. The alarm will sound.
3. Insert the key into the ignition switch and cycle it
from “LOCK” to “ON” three (3) times
within 5 sec-
onds .
„ Sounding a panic alarm
To activate the alarm, keep the “LOCK/ARM” button
pressed for more than two seconds .
The horn will sound and the turn signal lights will flash.
To deactivate it, press the “LOCK/ARM” button or “UNLOCK/DISARM” button.
Unless a button on the remote is pressed, the alarm
will be deactivated after approximately 30 seconds. „ Valet mode
When you choose the valet mode, the security system
does not operate. In valet mode, the remote transmit-
ter is used only for locking and unlocking the doors
and panic activation.
To enter the valet mode, open the driver’s door and
keep the “UNLOCK/DISARM” button depressed for
more than two seconds . The security system indica-
tor light will continue to flash 2 times per second indi-
cating that the system is in the valet mode.
To exit valet mode, open the driver’s door and keep the “UNLOCK/DISARM” button pressed
for more
than two seconds . The indicator will stop flashing.
„ Passive arming
When passive arming mode has been programmed by
the dealer, arming of the system is automatically ac-
complished without using the remote transmitter. Note
that in this mode, DOORS MUST BE MANUALLYLOCKED. T To enter the passive mode
Since programming the passive arming mode is a
complicated procedure, have it done by your nearestSUBARU dealer. T Arming the system
In passive mode, the system will automatically activate the alarm but WILL NOT automatically
lock the doors. In order to lock the doors you
must either lock them as indicated in step 4 be-
low or with the key once they have been closed.
Failure to lock the doors manually will result in
a higher security risk.

2-19
Keys and doors
– CONTINUED –
1. Turn the ignition switch to “ON”.
1) ON
2) LOCK
2. Turn the ignition switch from “ON” to “LOCK” and
remove the key from the ignition switch. 3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with the in-
side door lock levers.
5. Close the doors. The system will automatically arm
after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming will
take place immediately regardless of whether or not
the passive mode has been selected. T
Disarming the system
To disarm the system, briefly press the “UNLOCK/
1
2
HS2024BC
4
3
5
UB2024DC

2-20
Keys and doors
DISARM” button on the transmitter. T
Tripped sensor identification
If an electronic chirp sounds four times and the turn
signal lights flash four times when you disarm the sys-
tem, this indicates that the alarm was triggered. The
number of times the indicator light flashes indicates
what sensor caused the alarm condition.
To enter identification mode:
1. Open the driver’s door and leave it open.
2. Turn the ignition switch to “ON” twice. (“LOCK”
“ON” “LOCK” “ON” “LOCK”)
3. The indicator light will start flashing.
The indicator light provides the following indications.
Flashing once: Any door has been opened.
Flashing three times: The impact sensor in the sys-
tem’s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person.
Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
NOTE
The battery must be reconnected before the indi-
cator light will flash.
To exit this mode, close the door and turn the ignition switch to “ON”.

2-21
Keys and doors
– CONTINUED –
Child safety locks
Always use the child safety lock whenever a
child rides in the rear seat. Serious injury could
result if a child accidentally opened the door
and fell out.
1) Lock
2) Unlock
Each rear door has a child safety lock that prevents the doors from being opened even if the inside door
handle is pulled.
When the child safety lock lever is in the lock position,
the door cannot be opened from inside regardless of
the position of the inner door handle lock lever. The
door can only be opened from the outside.
1
2
UB2002BB

2-22
Keys and doors
Windows „
Power windows
To avoid serious personal injury caused by en-
trapment, you must do the following.yWhen operating the power windows, be ex-
tremely careful to prevent anyone’s fingers,
arms, neck or head from being caught in the
window. y Always lock the passengers’ windows using
the lock switch when children are riding in the
vehicle. y Before leaving the vehicle, always remove
the key from the ignition switch for safety and
never allow an unattended child to remain in
the vehicle. Failure to follow this procedure
could result in injury to a child operating the
power window.
The power windows operate only when the ignition
switch is in the “ON” position. T
Driver’s side switches
1) Lock switch
2) For driver’s window
3) For rear left passenger’s window
4) For front passenger’s window
5) For rear right passenger’s window
All door windows can be controlled by the power win-
dow switch cluster at the driver side door.
1
2
3 4
5
UB2008BB

2-23
Keys and doors
– CONTINUED –
VOperating the driver’s window
1) Lock
2) Unlock
3) Close
4) Open
5) Automatically open
To open:
Push the switch down lightly and hold it. The window
will open as long as the switch is held.
This switch also has a one-touch auto down feature
that allows the window to be opened fully without hold-
ing the switch.
Push the switch down until it clicks and release it, and
the window will fully open. To stop the window half- way, pull the switch up lightly.
To close:
Pull the switch up lightly and hold it. The window will
close as long as the switch is held. V
Operating the passengers’ windows
To open the passengers’ windows, push the appropri-
ate switch down and hold it until the window reaches
the desired position. To close the window, pull the
switch up and hold it until it reaches the desired posi-
tion. V Locking the passengers’ windows
To lock the passengers’ windows, push the lock
switch. When the lock switch is in the “LOCK” position,
the passengers’ windows cannot be opened or closed.
1 2 3
4
5 3
4
UB2008DB
