179 Starting and driving
Parking brake

The parking brake is situated between the
front seats and acts on the rear wheels.
When the parking brake is on, the indicator
light on the main instrument panel will
be on. To release the parking brake, lift the
lever slightly, press the release button and
release the lever by pushing down on it.
Parking
WARNING
Always
apply the parking brake when
you park the car.

Always
apply the parking brake
before removing the ignition key.
 Do not use the parking brake while
driving.
WARNING
 Do not leave children or pets unatten-
ded in the car. In warm, sunny
weather, the temperature inside the
car can reach 160–180°F (70–80°C).
 Park where the vehicle will not create
an obstruction or a hazard to other
road users.
 Do not park on dry grass or other com-
bustible material. The catalytic con-
verter gets very hot and could start a
fire.
 Apply the parking brake.
 Shift to Reverse for manual transmis-
sion (automatic transmission: move
selector lever to P (Park)), and remove
the ignition key. Lock the car.
NOTICEEmpty the car yourself and bear in mind:
 Never leave a mobile phone, camera,
computer or similar object visible in
your car.
 Clothing, packages and bags attract
thieves.
 Do not leave small objects such as
CDs, sunglasses and coins visible.
 If possible, park in a well-lit,
conspicuous parking space.
 Thieves strike whenever and where-
ver they are given the opportunity.
IB360
ProCarManuals.com

207 Car care and technical information
Tailgate bulbs, 9-5 SportWagon1 Turn the lock a quarter turn (90 °) with a
screwdriver or the ignition key.
2 Open and remove the cover.
3 Take out the bulb holder by twisting it
slightly counterlockwise.
4 Press in the bulb and twist it
counterclockwise.
5 Change the bulb.
6 Check that the new bulb is working.
Reassembly:1 Place the two ”hinges” in the recess in
the tailgate.
2 Then push the ”hinges” into the recess
and close the cover.
3 Turn the lock a quarter turn.
IB1227
IB1228
ProCarManuals.com

220 Car care and technical informationThe wheels and tires have been carefully
matched to the characteristics of the car and
play a key role in its outstanding roadhol-
ding and handling.
Do not take it for granted that a wheel/tire
combination will work in the best possible
way, just because it can be fitted to the car.
To ensure that the speedometer is as accu-
rate as possible it should be reprogrammed
if wheels of a different dimension are fitted.
Contact a Saab dealer.
Because of front wheel drive, the front tires
tend to wear faster than the rear ones. New
tires should always be fitted in pairs, so that
tires on the same axle have the same
amount of tread.
Store wheels lying flat or hanging –
never

standing upright.
NOTICEAlways
consult your Saab dealer before
changing the wheels and tires on your
Saab.
Wide wheels and tires with sidewalls that
are too low can:
 be damaged in potholes etc.
 cause springs, shock absorbers and
wheel bearings and body mountings
can be overloaded.
 cause the wheels to come into contact
with chassis and body components.
 can affect the function of the Elec-
tronic Stability Program (ESP).
The speed and load limits for the tires
must not be exceeded; see page 225.
Wheels larger than 17” must not be fitted.
The maximum permissible offset is
49 mm.
WARNING
Mixing tires could cause you to lose
control while driving. If you mix tires of
different sizes or types (radial and bias-
belted tires), the vehicle may not handle
properly, and you could have a crash.
Using tires of different sizes may also
cause damage to your vehicle. Be sure to
use the same size and type tires on all
wheels. It’s all right to drive with your
compact spare temporarily, it was devel-
oped for use on your vehicle. See
“Compact spare tire” on page 230.
WARNING
If you use bias-ply tires on your vehicle,
the wheel rim flanges could develop
cracks after many miles of driving. A tire
and/or wheel could fail suddenly, causing
a crash. Use only radial-ply tires with the
wheels on your vehicle.
ProCarManuals.com

265 Index
IndexAA/C system, fault diagnosis
_______ 235
A/C system, maintenance
_________ 234
ABS brakes
____________________ 152
ACC
__________________________ 73
ACC functions
___________________ 76
ACC, automatic climate control
_____ 73
ACC, calibration
_________________ 81
ACC, condensation _______________ 82
ACC, programming _______________ 79
ACC, useful tips
_________________ 81
Adjusting the steering wheel
_______ 106
Adjustment, seats
________________ 12
Air conditioning (A/C), fault diagnosis
and maintenance ______________ 234
Air distribution, ACC ______________ 78
Airbag
_________________________ 28
Alarm _________________________ 44
Alarm functions
__________________ 47
Alarm signals
________________ 44
, 47
Alternator
_____________________ 194
Alternator drive belt
__________ 194
, 257
Alternator rating
________________ 257
Anticorrosion treatment
___________ 240
Antidazzle rear-view mirror
________ 111
Ashtrays
______________________ 117
Audio System
___________________ 83Audio System, quick guide
_________ 85
Autochecking of lights on starting
____ 58
Auto-dimming rear-view mirror with
garage door opener
____________ 108
Automatic climate control (ACC)
_____ 73
Automatic transmission, technical
data
_________________________ 258
Aviod theft, tip
__________________ 179
BBattery
________________________ 192
Battery charging/replacing
________ 193
Battery, boost starting
____________ 174
Before a long journey ____________ 241
Before towing a camper or trailer
___ 164
Belt guide
______________________ 16
Boost starting using jump leads
____ 174
Brake and clutch fluid
____________ 189
Brake-fluid reservoir
_____________ 189
Brakes, technical data ____________ 259
Bulbs, changing
________________ 197
Bulbs, table of
__________________ 210
Buying new tires ________________ 219
CCD changer
_____________________ 95
CD player
______________________ 93CHECK messages
_______________ 64
CHECKING
_____________________ 64
Calibration, ACC
_________________ 81
Cancelling the programmed settings
__ 79
Car alarm
_______________________ 44
Car care _______________________ 181
Cargo net, 9-5 SportWagon
_______ 128
Carpeting, care of
_______________ 236
Cassette player
__________________ 90
Catalytic converter, important
considerations _________________ 137
Central locking ___________________ 38
Change language in SID
___________ 66
Change of address notification
_____ 248
Changing a wheel
_______________ 231
Changing bulbs
_________________ 197
Changing wiper blades
___________ 195
Charger/Jump starting ____________ 176
Charging the battery/Jump starting
__ 176
Chassis number
________________ 262
Chassis number, key to
___________ 263
Checks before towing a camper or
trailer
________________________ 164
Child safety
_____________________ 21
Child safety locks, rear doors
_______ 41
Cleaning, engine bay
_____________ 238
Clock
_______________________ 65
, 66
Color code, body
________________ 262
Color code, trim _________________ 262
Compact spare wheel
____________ 230
Compass
______________________ 112
Condensation, ACC
_______________ 82
ProCarManuals.com

267 Index
IIf a tire goes flat
________________ 223
Ignition switch
__________________ 132
Immobilizer
_____________________ 43
Indicator and warning lights
________ 52
Indicator lights
___________________ 52
Instrument illumination
____________ 69
Instruments and controls __________ 51
Interior equipment
_______________ 105
Interior lighting
_________________ 116
Interior rearview mirror
___________ 107
JJack
_________________________ 232
KKey
___________________________ 38
Key to chassis number
___________ 263
Key, remove
___________________ 132
LLATCH (child safety)
______________ 22
Labeling, tire sidewall ____________ 224
Labels
__________________________ 7Leather upholstery, care of
________ 236
Light horn
______________________ 67
Light switches ___________________ 67
Loading your vehicle
_____________ 226
Luggage-compartment lighting
_____ 116
MMain instrument panel
_____________ 52
Main/dipped beam
_______________ 67
Maintenance schedule ___________ 246
Maintenance, A/C-system _________ 234
Manual gearbox, technical data
____ 258
Maxi fuses
_____________________ 212
Milometer ______________________ 58
Motoring abroad
________________ 241
NNew tires, buying
_______________ 219
Night Panel
_____________________ 65
OOil capacity, engine
______________ 254
Oil change, engine ______________ 187
Oil specification
_________________ 254
Outdoor temperature
______________ 61
Owner assistance
_______________ 247
PPaintwork, touching-in
____________ 238
Parking Assistance
______________ 177
Parking lights
____________________ 67
Plates and labels
________________ 262
Poly-V-belt
_____________________ 194
Power steering
_________________ 191
Power-steering fluid
______________ 191
Pressure gauge
__________________ 60
Programming I, ACC
______________ 79
Programming II, ACC _____________ 80
Programming the ACC ____________ 79
QQuality grading, tires
_____________ 221
Questions on function of airbag
______ 35
Quick guide, Audio System
_________ 85
RRadiator fan
____________________ 194
Radio
__________________________ 88
Rain sensor
_____________________ 71
Rear fog light ____________________ 68
Rear seat, 9-5 Sedan, folding
______ 121
Rear seat, 9-5 SportWagon, folding
_ 124
Rear-seat head restraints
__________ 16
Rear-view mirror, auto-dimming
____ 111
ProCarManuals.com

268 IndexRearview mirrors
________________ 107
Reclamation
___________________ 242
Recommendations for cars with
automatic transmission, towing a
camper or trailer
_______________ 162
Refuelling
_____________________ 138
Relay panel ____________________ 214
Remote control __________________ 38
Remote-control battery, changing
____ 41
Remove the key
________________ 132
Replacement, wheel _____________ 222
Reporting safety defects
__________ 248
Reprogramming of systems _______ 264
Reservoir, power-steering fluid _____ 191
Rev counter
____________________ 58
Reversing lights _________________ 70
Roof load
_____________________ 166
Running-in ____________________ 157
SSDM
_________________________ 249
SID
___________________________ 61
Saab 9-5 Audio System
___________ 83
Saab Information Display (SID)
_____ 61
Saab Parking Assistance
_________ 177
Safety belts
_____________________ 16
Safety belts, care of
_____________ 235
Safety-belt pretensioners
__________ 16
Safety-belt reminder
______________ 16
Seats
__________________________ 12Securing a load
__________________ 42
Selector lever indication, automatic
transmission
___________________ 61
Sentronic, manual mode
__________ 148
Service costs
___________________ 247
Service information
______________ 248
Service intervals
________________ 246
Service record retention
__________ 247
Settings, seats
__________________ 12
Side airbags
____________________ 32
Signalling, horn _________________ 106
Sliding floor, 9-5 SportWagon
______ 129
Snow chains
___________________ 159
Spare wheel ___________________ 230
Spare wheel and tools
___________ 170
Spark plugs
____________________ 257
Speedometer ________________ 58
, 59
Starting in cold weather, ACC
_______ 79
Starting in hot weather, ACC _______ 79
Steering wheel adjustment
________ 106
Steering, technical data
__________ 259
Steps for determining correct load
limit
_________________________ 228
Stone-chip damage, repairing
______ 238
Storage compartments
___________ 118
Sun visors
_____________________ 117
Sunroof
_______________________ 114
Suspension ____________________ 259
Suspension, technical data
________ 259
Switches
_______________________ 67
Symboler ________________________ 9
Systems, adjustment
_____________ 264
TTCS OFF
_______________________ 57
Table of fuses
__________________ 213
Tachometer
_____________________ 58
Tailgate, opening
_________________ 42
Tank gauge
_____________________ 59
Technical data __________________ 251
Temperature control, ACC
_________ 75
Temperature gauge, engine ________ 59
Temperature zones, ACC
__________ 75
Textile carpeting
________________ 236
Through-load hatch ______________ 123
Tie Downs
_____________________ 123
Tightening torque, wheel studs
_____ 231
Tip, driving at night
______________ 168
Tip, to avoid theft
________________ 179
Tire chains
_____________________ 223
Tire date code __________________ 229
Tire inspection and rotation
________ 218
Tire markings
___________________ 225
Tire pressure ___________________ 169
Tire sidewall labeling
_____________ 224
Tire terminology and definitions
____ 226
Tire, compact spare
______________ 230
Tires
_____________________ 217
, 260
Tires, winter
____________________ 260
Tools
_________________________ 170
Touching-in the paintwork
_________ 238
Towbar attachment
______________ 161
Towbar load
____________________ 165
Towing the car __________________ 171
ProCarManuals.com
