197 Car care and technical information
Changing bulbsCheck that the new bulb is working when finished.Use only "Long Life" bulbs.Headlight aiming, see page 242.
Xenon headlight(if equipped)Xenon headlights produce roughly twice as much light as halogen
bulbs and have a significantly longer service life.
The lamp units consist of a gas discharge lamp containing xenon.
When the lights are switched on a very high voltage activates the
xenon gas. The lamps soon reach full intensity.
Cars with xenon headlights have automatic levelling. The levelling
system comprises two sensors on the front axle, one on the rear axle
and a control unit under the headlight housing. Headlight alignment
is regulated automatically to prevent dazzling oncoming traffic.
Alignment is also adjusted during braking.
WARNING
Before changing a bulb in the engine bay, switch off the engine to
avoid danger of fingers and hands being injured by moving parts.
The radiator fan can start up even when the engine is switched off.Xenon headlights are high voltage and must therefore be
changed at an authorized Saab workshop. Work involving
high-voltage components is potentially lethal.NOTICE Since the headlight lenses are made of plastic, rinse dried-on
dirt with water and allow it time to soften up before cleaning
the lenses. Avoid rubbing the lenses when dry and never use
solvents.
 Use de-icer spray instead of scraping the ice off.
NOTICE Do not fit bulbs with a higher rating than 55 W, since the head-
light reflector and the wiring of the car are not designed for a
higher wattage.
 Switch off the ignition before changing a bulb, to avoid possi-
ble short-circuiting.
 Do not touch the glass of the bulbs with your fingers. The oil
on your skin can shorten the life of the bulb.
ProCarManuals.com

213 Car care and technical information
Fuse panel in instrument panel
# Amp Function A 30 Trailer lights
B 10 Automatic transmission
C 7.5 Electric door mirrors; DICE: manual beam length
adjustment
115Brake lights
2 15 Reversing lights
3 10 Parking lights and taillights, left
4 10 Parking lights and taillights, right
5 7.5 DICE / TWICE
6 30 Electric windows, right; trailer charging
6B 7.5 Brake lights, trailer
7 10 Engine injectors
8 15 Trunk lighting; trunk lock; door lighting, circulation
pump; parking assistant; SID
9 15 Audio System; CD changer
10 15 Heating, rear seat; sunroof, remote control receiver
11 30 Electrically adjusted passenger seat
12 7.5 Automatic transmission
13 20 Audio System, amplifier
14 30 Ignition system, engine
15 20 Fuel pump
16 20 DICE (direction indicators)
16B – OnStar (if equipped)
17 20 Engine-management system; main instrument;
DICE/TWICE
18 40 Door-mirror heating; rear-window heating
19 10 OnStar; Telematics (if equipped)
20 15 ACC; interior lighting; rear fog light; high beam flasher
21 10 Audio System; rear-view mirror; load angle sensor
(cars with xenon); navigation (accessory); Cruise
Control
22 40 Interior fan
23 15 Central locking; navigation (accessory); door mirror
memory
24 – –
25 30 Electrically adjustable driver’s seat
26 7,5 Driver seat memory; mirrors memory; sunroof; par-
king assistant; seatbelt reminder
IB2439
BC123456 A
14
121110987
13
6B
1516
2324
222120191817
16B25262728293031
3635343332
393837
ProCarManuals.com

214 Car care and technical information
Relay panel under instrument panel
27 10 Engine-management system; SID; main instrument
28 7.5 Airbag
29 7.5 ABS/ESP
30 7.5 Starter motor
31 7.5 Cruise control; water valve; fog lights, front; rain
sensor
32 15 Ventilated front seats
33 7.5 Direction-indicator switch
34 30 12-volt socket (cigarette lighter) front/rear
35 15 Daytime running light
36 30 Electric windows, left
37 30 Windshield wipers
38 30 Electric heating, front seats
39 20 Limp-home solenoid; OnStar (if equipped)
# Function A –
B Electric heating of rear seat
C1 –
C2 –
D–
E Main relay (engine management system)
F–
G Fuel pump
H Ignition switch
I Rear-window / door mirrors heating
IB1796
A
BC1
C2
L2 L1 D
GE
F
H
I
K J
ProCarManuals.com

215 Car care and technical information
Fuse box under hoodFuses
J–
KStarter relay
L1 Limp-home function
L2 Trunklid
# Amp Function 1 40 Radiator fan, high speed
2 40 ABS/ESP
3 30 ABS/ESP
4 7.5 Load angle sensor (cars with xenon headlights)
515Heater
6 10 A/C; car alarm siren
715Bulb test
8––
9 20 Headlight washers
43
2
IB1797
2 1
14 1312 7 6
5 1
15 168
11
10 9
178 5
17 14 11 7 4
16 13 69
10 3
15 12
ProCarManuals.com

216 Car care and technical information
Relays
10 15 High beam headlight, left
11 15 Low beam headlight left
12 15 High beam headlight, right
13 15 Low beam headlight, right
14 30 Radiator fan, high speed
15 15 Fog lights (front spoiler)
16 30 Wiper, rear
17 15 Horn
18 – –
# Function 1 Bulb test; head light; high beam flasher
2 Headlight washer
3 Front fog lights
4 Wiper, rear (9-5 SportWagon)
5–
6–
7 Rain sensor
8 Radiator fan, low speed
9 Radiator fan, high speed
10 A/C-compressor
11 Radiator fan, high speed, right fan
12 Horn
13 Extra lights (accessory)
14 High beam headlight
15 Low beam headlight
16 –
17 Windshield wipers
ProCarManuals.com

237 Car care and technical information
Washing the carWash your car frequently. To facilitate clea-
ning, a suitable detergent can be added to
the water, which should be lukewarm. Saab
offers a full line of car care products, inclu-
ding car wash, for the care of your vehicle.
See your dealer for available products or
visit www.saabcatalog.com (U.S. residents
only).
Do not use a pressure washer at close
range on stone chip damage, scratches or
other damage to the paintwork. The paint
can otherwise start to flake.
Remove any bird droppings without delay,
as these can discolor the paintwork and
prove difficult to polish out.
Use a soft cloth moistened with methyl alco-
hol to remove splashes of tar or asphalt. Do
not use strong cleaners, as these can dry
out the paintwork.
The underside of the car also needs wash-
ing regularly, and this should be done extra
thoroughly at the end of winter. Clean the
underside of the car by hand if the car is usu-
ally washed in an automatic car wash wit-
hout special facilities for underbody clea-
ning.
Never wash or leave the car to dry in the
sun, but wipe it dry with a chamois leather
immediately after washing to avoid smears
and streaks.
Clean the window glass inside and out using
a high quality window cleaner. This is parti-
cularly important when the car is new, as
upholstery and trim have a tendency to
sweat a little at first.
Keep the glass well cleaned, as this helps to
prevent misting.

NOTICEAvoid using any alcohol-based cleaners
on the front and rear light clusters, as
these can cause cracking of the lenses.
NOTICE The door mirrors must be fully
retracted before the car enters an
automatic car wash.
 Remove fixed antennas, e.g. for
mobile phone, before putting car
through an automatic car wash.
 Try your brakes on leaving a car wash.
Wet brake discs may reduce the
performance of the brakes.
 Cars with Saab Parking Assistance:
Do not spray the sensors or closer
than 20 cm to the sensors with a pres-
sure washer, as this can damage
them.
ProCarManuals.com

267 Index
IIf a tire goes flat
________________ 223
Ignition switch
__________________ 132
Immobilizer
_____________________ 43
Indicator and warning lights
________ 52
Indicator lights
___________________ 52
Instrument illumination
____________ 69
Instruments and controls __________ 51
Interior equipment
_______________ 105
Interior lighting
_________________ 116
Interior rearview mirror
___________ 107
JJack
_________________________ 232
KKey
___________________________ 38
Key to chassis number
___________ 263
Key, remove
___________________ 132
LLATCH (child safety)
______________ 22
Labeling, tire sidewall ____________ 224
Labels
__________________________ 7Leather upholstery, care of
________ 236
Light horn
______________________ 67
Light switches ___________________ 67
Loading your vehicle
_____________ 226
Luggage-compartment lighting
_____ 116
MMain instrument panel
_____________ 52
Main/dipped beam
_______________ 67
Maintenance schedule ___________ 246
Maintenance, A/C-system _________ 234
Manual gearbox, technical data
____ 258
Maxi fuses
_____________________ 212
Milometer ______________________ 58
Motoring abroad
________________ 241
NNew tires, buying
_______________ 219
Night Panel
_____________________ 65
OOil capacity, engine
______________ 254
Oil change, engine ______________ 187
Oil specification
_________________ 254
Outdoor temperature
______________ 61
Owner assistance
_______________ 247
PPaintwork, touching-in
____________ 238
Parking Assistance
______________ 177
Parking lights
____________________ 67
Plates and labels
________________ 262
Poly-V-belt
_____________________ 194
Power steering
_________________ 191
Power-steering fluid
______________ 191
Pressure gauge
__________________ 60
Programming I, ACC
______________ 79
Programming II, ACC _____________ 80
Programming the ACC ____________ 79
QQuality grading, tires
_____________ 221
Questions on function of airbag
______ 35
Quick guide, Audio System
_________ 85
RRadiator fan
____________________ 194
Radio
__________________________ 88
Rain sensor
_____________________ 71
Rear fog light ____________________ 68
Rear seat, 9-5 Sedan, folding
______ 121
Rear seat, 9-5 SportWagon, folding
_ 124
Rear-seat head restraints
__________ 16
Rear-view mirror, auto-dimming
____ 111
